Sealers, Adhesives, and Lubricants
| Application | Type of Material | GM Part Number | |
|---|---|---|---|
| United States | Canada | ||
| Transfer Case Lubricant | Hypoid Gear Oil | 12378261 | 10953455 |
Sealers, Adhesives, and Lubricants
Scheme 20
| Callout | Component Name |
|---|---|
| 100 | Case |
| 101 | Cover |
| 102 | Bolt |
| 103 | Bolt |
| 104 | Ventilation Baffle |
| 105 | Locating Pin - Transfer Case-to-Transaxle |
| 201 | Output Shaft |
| 202 | Shim - 40 mm |
| 203 | Bearing |
| 204 | Spacer |
| 205 | Race |
| 206 | Race |
| 207 | Bearing |
| 208 | Output Yoke |
| 209 | Washer |
| 210 | Nut |
| 211 | Shim - 80 mm |
| 212 | Race |
| 213 | Bearing |
| 214 | Input Gear |
| 215 | Washer |
| 216 | Shim - 25 mm |
| 217 | Bearing |
| 218 | Race |
| 301 | Seal - Output Shaft |
| 302 | O-Ring |
| 303 | Sealing Washer |
| 304 | O-Ring |
| 305 | Seal - Input Shaft |
| 401 | Fill Plug |
| 402 | Washer |
| 403 | Drain Plug |
| 404 | Washer |
| 406 | Clamp |
| 407 | Ventilation Hose |
| 408 | Ventilation Valve |
Intermittent
Test the vehicle under the same conditions that the customer reported in order to verify the system is operating properly.
Noisy in Drive
| Cause | Correction |
|---|---|
| Inspect for the proper transaxle and gear oil levels prior to performing system diagnosis. Refer to Transfer Case Fluid Drain and Fill . | |
| Loose propeller shaft mounting bolts | Tighten the bolts as required. Refer to Propeller Shaft Replacement in Propeller Shaft. |
| Worn propeller shaft constant velocity and/or universal joints | Replace components as required. Refer to Propeller Shaft Replacement in Propeller Shaft. |
| Worn or loose propeller shaft center support bearing | Replace components as required. Refer to Propeller Shaft Replacement in Propeller Shaft. |
| Worn axle shaft constant velocity joints | Replace the constant velocity joints as required. |
| Loose rear differential mounts or worn bushings | Tighten the mount bolts or replace as required. |
| Incorrect oil in the transfer case | Replace with GM P/N 12378261 (Canadian P/N 10953455). |
| Bearing noise within the transfer case A "grinding" or "roar" type noise will increase or decrease relative to the vehicle speed. | Check for the proper fluid level. Fill as required. If the noise continues, repair or replace the transfer case as required. |
| Gear set "whine" noise within the transfer case "Whine" type noises will increase or decrease relative to the vehicle speed. | Check for the proper fluid level. Fill as required. If the noise continues, replace the transfer case as required. Contributing factors may include: Incorrect backlash between the gear set Worn or damaged gear teeth Transaxle assembly noise Differential noise |
Noisy in Drive
Noisy When Coasting
| Cause | Correction |
|---|---|
| Inspect for the proper transaxle and gear oil levels prior to performing system diagnosis. Refer to Transfer Case Fluid Drain and Fill . | |
| Loose propeller shaft mounting bolts | Tighten the bolts as required. Refer to Propeller Shaft Replacement in Propeller Shaft. |
| Worn propeller shaft universal joints | Replace components as required. Refer to Propeller Shaft Replacement in Propeller Shaft. |
| Worn or loose propeller shaft center support bearing | Replace components as required. Refer to Propeller Shaft Replacement in Propeller Shaft. |
| Worn axle shaft constant velocity joints | Replace the constant velocity joints as required. |
| Loose rear differential mounts or worn bushings | Tighten the mount bolts or replace as required. |
| Incorrect oil in the transfer case | Replace with GM P/N 12378261 (Canadian P/N 10953455). |
| Bearing noise within the transfer case A "grinding" or "roar" type noise will increase or decrease relative to the vehicle speed. | Check for the proper fluid level. Fill as required. If the noise continues, replace the transfer case as required. |
| Gear set "whine" noise within the transfer case "Whine" type noises will increase or decrease relative to the vehicle speed. | Check for the proper fluid level. Fill as required. If the noise continues, replace the transfer case as required. Contributing factors may include: Incorrect backlash between the gear set Worn or damaged gear teeth Transaxle assembly noise Differential noise |
Noisy When Coasting
