Scheme 16
Scheme 17
| Callout | Component Name |
|---|---|
| 1 | A/T Shift Lock Solenoid (2 BK) |
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
- 3: Checks for Diagnostic Trouble Codes (DTCs) in the BCM and the PCM.
- 4: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Install a scan tool. Does the scan tool power up? | Go to Step 2 | Go to Scan Tool Does Not Power Up in Data Link Communications |
| 2 | Turn ON the ignition, with the engine OFF. Attempt to establish communication with the body control module (BCM) and the powertrain control module (PCM). Does the scan tool communicate with the BCM and PCM? | Go to Step 3 | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications |
| 3 | Select the BCM and PCM display DTCs function on the scan tool. Does the scan tool display any DTCs? | Go to Step 4 | Go to Symptoms - Automatic Transmission Shift Lock Control |
| 4 | Does the scan tool display any DTCs which begin with a "U"? | Go to Diagnostic Trouble Code (DTC) List in Data Link Communications | Go to Step 5 |
| 5 | Does the scan tool display DTC B1000? | Go to Diagnostic Trouble Code (DTC) List in Body Control System | Go to Step 6 |
| 6 | Does the scan tool display DTC P0713, P0719 or P0724? | Go to Diagnostic Trouble Code (DTC) List/Type in Automatic Transmissions | Go to Step 7 |
| 7 | Does the scan tool display DTC B2707 or B2708? | Go to Diagnostic Trouble Code (DTC) List | Go to Symptoms - Automatic Transmission Shift Lock Control |
Diagnostic System Check - Automatic Transmission Shift Lock Control
The numbers below refer to the step numbers on the diagnostic table.
- 2: Listen for an audible click when the automatic transmission shift lock control solenoid operates. Command both the ON and OFF states. Repeat the commands as necessary.
- 4: Tests for ground at the control circuit of the automatic transmission shift lock control solenoid.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Automatic Transmission Shift Lock Control Schematics Connector End View Reference: Body Control System Connector End Views | |||
| 1 | Did you perform A Diagnostic System Check - Automatic Transmission Shift Lock Control? | Go to Step 2 | Go to Diagnostic System Check - Automatic Transmission Shift Lock Control |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the shifter unlock solenoid output control parameter ON and OFF. Does the automatic transmission shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Turn OFF the ignition. Connect a test lamp between the automatic transmission shift lock control solenoid voltage supply circuit at the connector of the automatic transmission shift lock control solenoid connector and a good ground. Turn ON the ignition, with the engine OFF. Does the test lamp illuminate? | Go to Step 4 | Go to Step 8 |
| 4 | Turn OFF the ignition. Disconnect the automatic transmission shift lock control solenoid. Connect a test lamp between the shift lock solenoid control circuit at the connector of the automatic transmission shift lock solenoid and battery positive voltage. Turn ON the ignition, with the engine OFF. With a scan tool, command the shifter unlock solenoid output control ON and OFF several times. Does the test lamp illuminate ON and OFF with each command? | Go to Step 6 | Go to Step 5 |
| 5 | Test the control circuit of the automatic transmission shift lock control solenoid for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 7 |
| 6 | Inspect for poor connections at the harness connector of the automatic transmission shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 9 |
| 7 | Inspect for poor connections at the harness connector of the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 10 |
| 8 | Repair the open or short to ground in the automatic transmission shift lock control solenoid voltage supply circuit. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 11 | |
| 9 | Replace the automatic transmission shift lock control solenoid. Refer to Automatic Transmission Shift Lock Actuator Replacement . Did you complete the replacement? | Go to Step 11 | |
| 10 | Replace the body control module (BCM). Refer to Body Control Module Replacement in Body Control System. Did you complete the replacement? | Go to Step 11 | |
| 11 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B2707
The numbers below refer to the step numbers on the diagnostic table.
- 2: Listen for an audible click when the automatic transmission shift lock control solenoid operates. Command both the ON and OFF states. Repeat the commands as necessary.
- 3: Tests the control circuit of the automatic transmission shift lock control solenoid.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Automatic Transmission Shift Lock Control Schematics Connector End View Reference: Body Control System Connector End Views | |||
| 1 | Did you perform A Diagnostic System Check - Automatic Transmission Shift Lock Control? | Go to Step 2 | Go to Diagnostic System Check - Automatic Transmission Shift Lock Control |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the shifter unlock parameter output control ON and OFF. Does the automatic transmission shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the automatic transmission shift lock control solenoid. Connect a test lamp between the shift lock solenoid control circuit at the connector of the automatic transmission shift lock solenoid and battery voltage. Turn ON the ignition, with the engine OFF. With a scan tool, command the shifter unlock parameter output control ON and OFF several times. Does the test lamp illuminate ON and OFF with each command? | Go to Step 5 | Go to Step 4 |
| 4 | Test the control circuit of the automatic transmission shift lock control solenoid for a short to battery voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 5 | Inspect for poor connections at the harness connector of the automatic transmission shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 7 |
| 6 | Inspect for poor connections at the harness connector of the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Replace the automatic transmission shift lock control solenoid. Refer to Automatic Transmission Shift Lock Actuator Replacement . Did you complete the replacement? | Go to Step 9 | |
| 8 | Replace the body control module (BCM). Refer to Body Control Module Replacement in Body Control System. Did you complete the replacement? | Go to Step 9 | |
| 9 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B2708
Symptoms - Automatic Transmission Shift Lock Control
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Automatic Transmission Shift Lock Control Description and Operation . |
