Maintenance Information Saturn SL I

Procedures 3 illustrations ~3520 words

MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article in this section. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 1

Scheme 1: VIN Code ID Explanation
Scheme 1: VIN Code ID Explanation

SHORT TRIP/CITY & LONG TRIP/HIGHWAY SERVICE DEFINITIONS

Note. Starting in the 1996 model year, General Motors has renamed their maintenance schedules; One is referred to as the Short-Trip/City and the other is the Long Trip/Highway schedule. These schedule requirements are similar to the familiar Severe Service and Normal schedules and can be used in place of one another.

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. When Most Trips Are Less Than 10 Miles And Outside Temperatures Remain Below Freezing.
  3. Towing Or Heavily Loaded
  4. Severe Dust Conditions
  5. Hot Weather, Stop-And-Go Driving
  6. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

ENGINE COOLANT SUPPLEMENT PELLETS

CAUTIONUse (2) two engine coolant supplement pellets (P/N 21007224) when changing engine coolant for any reason.

Note. For more information on engine coolant service refer to the 93-T-26-SATURN INFO. ON ENGINE COOLANT SUPPLEMENT PELLET USAGE article in the TSB section.

SERVICE LABOR TIMES

Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Tire inflation specifications and recommended tire size are listed on the information decal on driver's door. Informations can also be found on tire-loading sticker on underside of trunk lid.

WHEEL TIGHTENING

Tighten wheel lug nuts to 103 ft. lbs. (140 N.m). If wheels are equipped with locking type lug nuts, ALWAYS position the Keyed nut opposite the valve stem.

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

Vehicles are factory equipped with maintenance-free battery. Replacement battery must be of the same group number as original battery.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG) - 1992.5-95 MODELS

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.

Modification to the air bag system component or wiring can adversely affect system performance and possibly cause injury.

CAUTIONThe Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the inflator module for up to 10 minutes after the ignition switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the inflator module to avoid an accidental deployment.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

AIR CONDITIONING SERVICING (1994-95)

CAUTIONAvoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service.
WARNINGR-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See the appropriate A/C SYSTEM GENERAL SERVICING article in the AIR CONDITIONING & HEAT section.

ANTI-LOCK BRAKE SYSTEM (If Equipped)

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

To prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes.

COOLANT (PHOSPHATE-FREE FORMULATIONS)

CAUTIONOnly a phosphate-free product should be used to replace the factory coolant, damage to water jacket sealing surfaces and cause cooling system corrosion.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.
CAUTIONTo avoid possible damage to vehicle use only phosphate-free ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Etylene-Gylcol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component.

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

METHANOL GASOLINE

CAUTIONFuel that is more than 5% methanol should not be used in this vehicle. It can corrode metal parts in the fuel system, and damage plastic and rubber parts. Even at 5% methanol or less, solvents and corrosion preventers must be used with this fuel to avoid these problems.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

SPARK PLUGS

Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY

Everything is covered for 3 years or 36,000 miles, whichever occurs first. Warranty covers repairs to any components (damage due to owner's negligence and tires excluded) that are defective in material or workmanship under normal vehicle use. Warranty repairs (parts and labor) will be made by the dealer at no charge using new or rebuilt parts. Maintenance items are only covered up to their first scheduled replacement interval.

TOWING

If vehicle cannot be driven because of a warranted defect, towing expense, to the nearest Saturn dealer, will be covered.

BATTERY

Battery replacement is covered at no charge for 12 months or 12,000 miles, whichever occurs first. Thereafter, replacement is covered on a prorated charge for 36 months or 36,000 miles, whichever occurs first. Labor is covered at no charge during warranty period.

CORROSION COVERAGE

Warranty covers rust-through in any sheet metal panel due to corrosion for 6 years or 100,000 miles, whichever occurs first. Emissions "Defect" & "Performance" Warranties (Federal) -Defect Warranty ensures vehicle meets applicable EPA regulations. It further warrants that vehicle's emission control system is free from defects in materials and workmanship for 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts necessary for vehicle to pass a Federally required state or local emissions test. Other emission control parts related to these components are also covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.

EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)

If vehicle fails a smog inspection, all necessary repairs and adjustments will be made by manufacturer to ensure vehicle passes inspection. Warranty begins at warranty start date and lasts for 3 years or 50,000 miles, whichever occurs first.

EMISSION "DEFECT" WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, manufacturer will repair or replace part. Warranty begins at warranty start date and lasts for 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles, whichever occurs first. If part is defective in material or workmanship, manufacturer will repair or replace part. See customer's copy of warranty information for specific items covered.

FUSES & CIRCUIT BREAKERS

Instrument panel fuse block is located under the dash panel, left of steering column. To identify and check fuses, refer to the fuse usage chart on reverse side of fuse panel door.

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION (1991-92)
Scheme 2: FUSE PANEL IDENTIFICATION (1991-92)

Fuse Identification

  1. 1 - Spare (1991-92) 10 Amp (Red) (1992.5 Mid-Year Models) - Air Bag
  2. 2 - 7.5 Amp (Brown) - Turn Signals, Brake Transaxle Shift Interlock
  3. 3 - 7.5 Amp (Brown) - Anti-Lock Brakes, Power Windows, A/C, Traction Switch
  4. 4 - 15 Amp (Blue) - A/C-Heater Blower Motor, Recirculation Door, Rear Defogger
  5. 5 - 10 Amp (Red) - Chime, Performance/Normal Switch, Seat Belt Indicator Light, Passive Restraints
  6. 6 - 25 Amp (Clear) - Windshield Wiper/Washer
  7. 7 - 5 Amp (Tan) - Cruise Control
  8. 8 - Spare
  9. 9 - Spare
  10. 10 - 5 Amp (Tan) - Radio 7.5 Amp (Brown) (1992.5 Mid-Year Models) - Radio
  11. 11 - Spare
  12. 12 - 10 Amp (Red) - Electric Fuel Pump
  13. 13 - 5 Amp (Tan) - Cigarette Lighter Ring Light, Radio, Ashtray Light, Performance/Normal Switch Light, PRND32 Light, A/C-Heater Control Head Display Lights
  14. 14 - 10 Amp (Red) - Taillights, Front Parking Light, Front & Rear Marker Lights, Radio Display Light, IP Cluster Lights 10 Amp (Red) (1992.5 Mid-Year Models) - DRL
  15. 15 - 5 Amp (Tan) - IP Cluster High Beam Telltale Indicator 10 Amp (Red) (1992.5 Mid-Year Models) - Taillights, Front Parking Light, Front & Rear Marker Lights, Radio Display Light, IP Cluster Lights, Fog Lights
  16. 16 - 20 Amp (Yellow) - Passive Restraints
  17. 25 Amp (Clear) (1992.5 Mid-Year Models) - Passive Restraints
  18. 17 - 20 Amp (Yellow) - Power Sun Roof
  19. 18 - 10 Amp (Red) - Dome Light, Luggage Compartment Light, Outside Remote Mirrors, MAP Lights
  20. 19 - 5 Amp (Tan) - Radio/Clock Memory, Chime Module
  21. 20 - 20 Amp (Yellow) - Power Door Locks, Cigarette Lighter

RELAY IDENTIFICATION

  1. 1 - 35 Amp - Power Windows
  2. 2 - 35 Amp - Electric Fuel Pump
  3. 3 - 35 Amp - Rear Defogger
  4. 4 - 35 Amp - A/C-Heater Blower Motor
  5. 5 - 6 Bulbs - Turn Signal/Hazard Flashers

POWER DISTRIBUTION BOX IDENTIFICATION (1991-92)

Note. Illustration of Power Distribution Box not available from manufacturer.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 30 Amp (Green) - Heater-Air Conditioning Blower Motor, Air Recirculation Door, Rear Defogger, Anti-Lock Brakes, Power Windows, Air Conditioning, Cruise Control, Starter Solenoid
  2. 2 - 30 Amp (Green) - Tail Lights, Front Parking Lights, Front Marker Lights, Rear Marker Lights, Radio Display Lights, IP Cluster Lights, Cigar Lighter Ring Light, Radio, Ashtray Light, PRNDL Light, Performance/Normal Switch Light, HVAC Control Lights, Dome Lights, Luggage Compartment Light, Power Mirrors, Map Lights, Radio/Clock Memory, Chime, Passive Restraints, IP Cluster Indicator Telltales
  3. 3 - 30 Amp (Green) - Anti-Lock Brakes (Enable Relay)
  4. 4 - 30 Amp (Green) - Chime, Performance/Normal Switch, Passive Restraints Turn Signals, Transaxle Shift Interlock, Back-up Lights, EGR Solenoid, Distributorless Ignition System, PCM Fuel Injectors, Low Coolant Level Switch, Radio, Windshield Wipers/Washers
  5. 5 - Not Used
  6. 6 - 30 Amp (Green) - Engine Cooling Fan
  7. 7 - 30 Amp (Green) - Power Windows, Power Sunroof
  8. 8 - Not Used

MINI-FUSE & RELAY IDENTIFICATION

  1. 1 - 7.5 Amp (Brown) - Automatic Transaxle G2 Actuator
  2. 2 - 7.5 Amp (Brown) - Powertrain Control Module (Automatic Transaxle Only)
  3. 3 - 7.5 Amp (Brown) - Automatic Transaxle Torque Converter Clutch Actuator
  4. 4 - Not Used
  5. 5 - 10 Amp (Red) - Left Hand Headlamp Door Motor (Coupe Only)
  6. 6 - 10 Amp (Red) - Horn
  7. 7 - 20 Amp (Yellow) - Brake Lights
  8. 8 - 7.5 Amp (Brown) - Automatic Transaxle G3 Actuator
  9. 9 - 7.5 Amp (Brown) - Automatic Transaxle HLP Actuator
  10. 10 - 7.5 Amp (Brown) - Automatic Transaxle I4 Actuator
  11. 11 - 7.5 Amp (Brown) - Air Conditioning System
  12. 12 - 25 Amp (Clear) - Rear Window Defogger
  13. 13 - 10 Amp (Red) - Hazard Flasher, HI-Beam Indicator Light
  14. 14 - 5 Amp (Tan) - Anti-Lock Brake System Memory
  15. 15 - 7.5 Amp (Brown) - Distributorless Ignition System Module
  16. 16 - 5 Amp (Tan) - EGR Solenoid Canister Purge Solenoid
  17. 17 - Not Used
  18. 18 - Not Used
  19. 19 - Not Used
  20. 20 - 10 Amp (Red) - Right Hand Headlamp Door Motor (Coupe Only)
  21. 21 - 10 Amp (Red) - Right HI-Beam Headlamp, Right LO-Beam Headlamp (Sedan), Right Hand HI/LO Beam Headlight (Coupe Only)
  22. 22 - 10 Amp (Red) - Back-up Lights
  23. 23 - 7.5 Amp (Brown) - Low Coolant Level Switch, Fuel Injectors, Powertrain Control Module (Automatic Transaxle Only)
  24. 24 - 5 Amp (Tan) - Powertrain Control Module
  25. 25 - 5 Amp (Tan) - Powertrain Control Module Memory
  26. 26 - 7.5 Amp (Brown) - Left HI-Beam Headlight, Left LO-Beam Headlight (Sedan), Left Hand HI/LO Beam Headlight (Coupe Only)
  27. 27 - Not Used
  28. 28 - Not Used

RELAY IDENTIFICATION (1991-92)

  1. 1 - 30 Amp - Horn
  2. 2 - 30 Amp - Air Conditioning System
  3. 3 - 30 Amp - Engine Cooling Fan
  4. 4 - 30 Amp - Automatic Transaxle

Scheme 3

Scheme 3: FUSE PANEL IDENTIFICATION (1993-94)
Scheme 3: FUSE PANEL IDENTIFICATION (1993-94)
  1. 1 - 10 Amp (Red) - Air Bag
  2. 2 - 7.5 Amp (Brown) - Turn Signals, Brake Transaxle Shift Interlock
  3. 3 - 7.5 Amp (Brown) - Anti-Lock Brakes, Power Windows, A/C, Traction Switch
  4. 4 - 15 Amp (Blue) - A/C-Heater Blower Motor, Recirculation Door, Rear Defogger
  5. 5 - 10 Amp - Chime, Performance/Normal Switch, Seat Belt Indicator Light, Passive Restraints
  6. 6 - 25 Amp (Clear) - Windshield Wiper/Washer
  7. 7 - 5 Amp (Tan) - Cruise Control
  8. 8 - Spare
  9. 9 - Spare
  10. 10 - 7.5 Amp (Brown) - Radio
  11. 11 - Spare
  12. 12 - 10 Amp (Red) - Electric Fuel Pump
  13. 13 - 5 Amp (Tan) - Cigarette Lighter Ring Light, Radio, Ashtray Light, Performance/Normal Switch Light, PRND32 Light, A/C-Heater Control Head Display Lights
  14. 14 - 10 Amp (Red) - DRL (Canada)
  15. 15 - 10 Amp (Red) - Taillights, Front Parking Light, Front & Rear Marker Lights, Radio Display Light, IP Cluster Lights, Fog Lights
  16. 16 - 25 Amp (Clear) - Passive Restraints
  17. 17 - 15 Amp (Blue) - Power Sunroof, Rear Wiper/Washer (Wagon)
  18. 18 - 10 Amp (Red) - Dome Light, Luggage Compartment Light, Outside Remote Mirrors, MAP Lights
  19. 19 - 5 Amp (Tan) - Radio/Clock Memory, Chime Module, Cargo Light (Wagon), Hatch Ajar Light (Wagon)
  20. 20 - 20 Amp (Yellow) - Power Door Locks, Cigarette Lighter

RELAY IDENTIFICATION (1993-94)

  1. 1 - 35 Amp - Power Windows
  2. 2 - 35 Amp - Electric Fuel Pump
  3. 3 - 35 Amp - Rear Defogger
  4. 4 - 35 Amp - A/C-Heater Blower Motor
  5. 5 - 6 Bulbs - Turn Signal/Hazard Flashers

POWER DISTRIBUTION BOX IDENTIFICATION (1993-94)

Note. Illustration of Power Distribution Box not available from manufacturer.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 30 Amp (Green) - Heater-Air Conditioning Blower Motor, Air Recirculation Door, Rear Defogger, Anti-Lock Brakes, Power Windows, Air Conditioning, Cruise Control, Starter Solenoid
  2. 2 - 30 Amp (Green) - Tail Lights, Front Parking Lights, Front Marker Lights, Rear Marker Lights, Radio Display Lights, IP Cluster Lights, Cigar Lighter Ring Light, Radio, Ashtray Light, PRNDL Light, Performance/Normal Switch Light, HVAC Control Lights, Dome Lights, Luggage Compartment Light, Power Mirrors, Map Lights, Radio/Clock Memory, Chime, Passive Restraints, IP Cluster Indicator Telltales
  3. 3 - 30 Amp (Green) - Anti-Lock Brakes
  4. 4 - 30 Amp (Green) - Chime, Performance/Normal Switch, Passive Restraints Turn Signals, Transaxle Shift Interlock, Back-up Lights, EGR Solenoid, Distributorless Ignition System, PCM Fuel Injectors, Low Coolant Level Switch, Radio, Windshield Wipers/Washers
  5. 5 - Not Used
  6. 6 - 30 Amp (Green) - Engine Cooling Fan
  7. 7 - 30 Amp (Green) - Power Windows, Power Sunroof, Rear Wiper (Wagon)
  8. 8 - Not Used

MINI-FUSE & RELAY IDENTIFICATION (1993-94)

  1. 1 - 7.5 Amp (Brown) - Automatic Transaxle G2 Actuator
  2. 2 - Not Used
  3. 3 - 7.5 Amp (Brown) - Automatic Transaxle Torque Converter Clutch Actuator
  4. 4 - Not Used
  5. 5 - 10 Amp (Red) - Left Hand Headlamp Door Motor (Coupe Only)
  6. 6 - 10 Amp (Red) - Horn
  7. 7 - 15 Amp (Blue) - Brake Lights
  8. 8 - 7.5 Amp (Brown) - Automatic Transaxle G3 Actuator
  9. 9 - 7.5 Amp (Brown) - Automatic Transaxle HLP Actuator
  10. 10 - 7.5 Amp (Brown) - Automatic Transaxle I4 Actuator
  11. 11 - 7.5 Amp (Brown) - Air Conditioning System
  12. 12 - 25 Amp (Clear) - Rear Window Defogger
  13. 13 - 10 Amp (Red) - Hazard Flasher, Headlamp HI-Beam Indicator Light
  14. 14 - 5 Amp (Tan) - Anti-Lock Brake System Memory
  15. 15 - 7.5 Amp (Brown) - Distributorless Ignition System Module
  16. 16 - 5 Amp (Tan) - EGR Solenoid Canister Purge Solenoid
  17. 17 - Not Used
  18. 18 - Not Used
  19. 19 - Not Used
  20. 20 - 10 Amp (Red) - Right Hand Headlamp Door Motor (Coupe Only)
  21. 21 - 10 Amp (Red) - Right HI-Beam Headlamp, Right LO-Beam Headlamp (Sedan/Wagon), Right Hand HI/LO Beam Headlight (Coupe Only)
  22. 22 - 10 Amp (Red) - Back-up Lights
  23. 23 - 10 Amp (Red) - Low Coolant Level Switch, Fuel Injectors, Powertrain Control Module (Automatic Transaxle Only)
  24. 24 - 5 Amp (Tan) - Powertrain Control Module
  25. 25 - 5 Amp (Tan) - Powertrain Control Module Memory
  26. 26 - 7.5 Amp (Brown) - Left HI-Beam Headlight, Left LO-Beam Headlight (Sedan/Wagon), Left Hand HI/LO Beam Headlight (Coupe Only)
  27. 27 - 15 Amp (Blue) - Fog Lamps
  28. 28 - Not Used
  1. 1 - 30 Amp - Horn
  2. 2 - 30 Amp - Air Conditioning System
  3. 3 - 30 Amp - Engine Cooling Fan
  4. 4 - 30 Amp - Automatic Transaxle
  5. 5 - 30 Amp - Fog Lamps

FUSE PANEL IDENTIFICATION (1995)

Note. Illustration of Fuse Box not available from manufacturer.

  1. 1 - 10 Amp (Red) - Air Bag
  2. 2 - 7.5 Amp (Brown) - Turn Signals, Brake Transaxle Shift Interlock
  3. 3 - 7.5 Amp (Brown) - Anti-Lock Brakes, Power Windows, A/C, Traction Switch
  4. 4 - 15 Amp (Blue) - A/C-Heater Blower Motor, Recirculation Door, Rear Defogger
  5. 5 - 10 Amp - Chime, Performance/Normal Switch, Seat Belt Indicator Light, Passive Restraints
  6. 6 - 25 Amp (Clear) - Windshield Wiper/Washer
  7. 7 - 5 Amp (Tan) - Cruise Control
  8. 8 - Spare
  9. 9 - Spare
  10. 10 - 7.5 Amp (Brown) - Radio
  11. 11 - Spare
  12. 12 - 10 Amp (Red) - Electric Fuel Pump
  13. 13 - 5 Amp (Tan) - Cigarette Lighter Ring Light, Radio, Ashtray Light, Performance/Normal Switch Light, PRND32 Light, A/C-Heater Control Head Display Lights
  14. 14 - 10 Amp (Red) - DRL (Canada)
  15. 15 - 10 Amp (Red) - Taillights, Front Parking Light, Front & Rear Marker Lights, Radio Display Light, IP Cluster Lights, Fog Lights
  16. 16 - 25 Amp (Clear) - Passive Restraints
  17. 17 - 15 Amp (Blue) - Power Sunroof, Rear Wiper/Washer (Wagon)
  18. 18 - 10 Amp (Red) - Dome Light, Luggage Compartment Light, Outside Remote Mirrors, MAP Lights
  19. 19 - 5 Amp (Tan) - Radio/Clock Memory, Chime Module, Cargo Light (Wagon), Hatch Ajar Light (Wagon)
  20. 20 - 20 Amp (Yellow) - Power Door Locks, Cigarette Lighter

RELAY IDENTIFICATION (1995)

  1. 1 - 35 Amp - Power Windows
  2. 2 - 35 Amp - Electric Fuel Pump
  3. 3 - 35 Amp - Rear Defogger
  4. 4 - 35 Amp - A/C-Heater Blower Motor
  5. 5 - 6 Bulbs - Turn Signal/Hazard Flashers

POWER DISTRIBUTION BOX IDENTIFICATION (1995)

Note. Illustration of Power Distribution Box not available from manufacturer.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

MAXI-FUSE IDENTIFICATION (1995)

  1. 1 - 30 Amp (Green) - Power Windows, Power Sunroof, Rear Wiper (Wagon)
  2. 2 - 30 Amp (Green) - Heater-Air Conditioning Blower Motor, Air Recirculation Door, Rear Defogger, Anti-Lock Brakes, Power Windows, Air Conditioning, Cruise Control, Starter Solenoid, DRL Relay, Chime
  3. 3 - Not Used
  4. 4 - Not Used
  5. 5 - 30 Amp (Green) - - Performance/Normal Switch, Turn Signals, Back-up Lights, Transaxle Shift Interlock, EGR Solenoid, SIR (Air Bag) Canister Purge Solenoid, Electronic Ignition System, IP Cluster Indicator Telltales, Windshield Wipers/Washers Fuel Injectors, Low Coolant Level Switch, Radio, Powertrain Control Module (PCM) IP Cluster Gauges, DRL Module
  6. 6 - 30 Amp (Green) - Dome Lights, IP Cluster Lights, IP Dimmer, Cigar Lighter, Cigar Lighter Ring Light, Radio, Ashtray Light, PRNDL Light, Performance/Normal Switch Light, HVAC Control Lights, Luggage Compartment Light, Power Mirrors, Map Lights, Radio/Clock Memory, Wagon Hatch Release, Door Locks, Transaxle Actuators, Fuel Pump
  7. 7 - 30 Amp (Green) - Engine Cooling Fan
  8. 8 - 30 Amp (Green) - Anti-Lock Brakes

MINI-FUSE & RELAY IDENTIFICATION (1995)

  1. 1 - 10 Amp (Red) - Horn
  2. 2 - 10 Amp (Red) - Right HI-Beam Headlamp, Right LO-Beam Headlamp (Sedan/Wagon), Right Hand HI/LO Beam Headlight (Coupe Only)
  3. 3 - 10 Amp (Red) - Left Hand Headlamp Door Motor (Coupe Only)
  4. 4 - 10 Amp (Red) - Left HI-Beam Headlight, Left LO-Beam Headlight (Sedan/Wagon), Left Hand HI/LO Beam Headlight (Coupe Only)
  5. 5 - 10 Amp (Red) - Right Hand Headlamp Door Motor (Coupe Only)
  6. 6 - 15 Amp (Blue) - Fog Lamps
  7. 7 - 10 Amp (Red) - Linear EGR, Canister Purge Solenoid
  8. 8 - 7.5 Amp (Brown) - Automatic Transaxle Pressure Actuator
  9. 9 - 7.5 Amp (Brown) - Air Conditioning System
  10. 10 - 5 Amp (Tan) - Powertrain Control Module
  11. 11 - 7.5 Amp (Brown) - Distributorless Ignition System Module
  12. 12 - 10 Amp (Red) - Automatic Transaxle 3rd and 4th Gear Actuators
  13. 13 - 5 Amp (Tan) - Powertrain Control Module Memory
  14. 14 - 10 Amp (Red) - Fuel Injectors
  15. 15 - 10 Amp (Red) - Back-up Lights
  16. 16 - 10 Amp (Red) - Automatic Transaxle Torque Converter Clutch and 2nd Gear Actuators
  17. 17 - 15 Amp (Blue) - Brake Lights
  18. 18 - 5 Amp (Tan) - Anti-Lock Brake System Memory
  19. 19 - 10 Amp (Red) - Front Parking Lights, Front Marker Lights, License Lights Rear Marker Lights, Radio Display Lights, IP Cluster Lights, Cigar Lighter Ring Light, Ashtray Light, PRNDL Light, IP Dimmer, HVAC Control Lights
  20. 20 - 10 Amp (Red) - Hazard Flasher, Headlamp HI Beam Indicator, DRL Relay (SC) DRL Module
  21. 21 - 25 Amp (Clear) - Rear Window Defogger
  22. 22 - Diode - A/C (For Electrical System Protection)
  1. 1 - 30 Amp - Horn
  2. 2 - 30 Amp - Air Conditioning System
  3. 3 - 30 Amp - Engine Cooling Fan
  4. 4 - 30 Amp - Fog Lamps
  5. 5 - 20 Amp - Daytime Running Lights (Sedan, Wagon, SC1)
  6. 6 - 30 Amp - Anti-Lock Brakes (Non-Interchangeble with Other Relays)

More articles — Maintenance
