Engine Mechanical - 2.4l - Component Locator Saturn Sky I final

Mechanical 6 illustrations ~108 words

Scheme 85

Scheme 85: Disassembled Views (LE5, LE8, LE9)
Scheme 85: Disassembled Views (LE5, LE8, LE9)
CalloutComponent Name
201Exhaust Valve
202Intake Valve
203Timing Chain Guide Bolt Access Hole
204Cylinder Head
205Cylinder Head Gallery Plug
206Hydraulic Lash Adjuster
207Roller Finger Follower
208Cylinder Head Bolt
209Small Cylinder Head Bolt
210Valve Stem Seal
211Valve Spring
212Valve Spring Retainer
213Valve Keys
214Hydraulic Lash Adjuster
215Roller Finger Follower
216Lntake Camshaft
219Camshaft Cap
220Exhaust Camshaft
221Camshaft Cap
222Camshaft Cap Bolt
300Coolant Air Bleed Fitting
413Engine Oil Fill Cap
507Fuel Injector Rotator Cup
508Fuel Injector O-ring
509Fuel Injector
510Fuel Injector O-ring
511Fuel Injector Clip
512Fuel Rail
513Camshaft Cover Gasket
514Camshaft Cover
515Camshaft Cover Bolt
707Front Lift Bracket Bolt
708Front Lift Bracket
709Rear Lift Bracket
710Rear Lift Bracket Bolt
713Fuel Injector Wiring Harness
717Spark Plug
718Camshaft Position Actuator Solenoid Valve - Exhaust
719Camshaft Position Actuator Solenoid Valve - Intake
720Camshaft Position Actuator Solenoid Valve Bolt
721Ignition Coil
724Ignition Coil Bolt
725Camshaft Position Sensor
726Camshaft Position Sensor Bolt
727Camshaft Position Sensor
728Camshaft Position Sensor Bolt

Scheme 86

Scheme 86
Scheme 86
CalloutComponent Name
408Oil Indicator Tube O-ring
409Oil Indicator Tube
410Oil Indicator Tube Bolt
411Oil Indicator O-ring
412Oil Indicator
500Intake Manifold Gasket
501Intake Manifold Bolt
502Intake Manifold
503Throttle Body Seal
504Throttle Body
506Throttle Body Bolt
711Map Sensor

Scheme 87

Scheme 87
Scheme 87
CalloutComponent Name
600Exhaust Manifold Stud
601Exhaust Manifold Gasket
602Exhaust Manifold
603Exhaust Manifold Nut
604Exhaust Manifold Heat Shield
605Exhaust Manifold Heat Shield Stud
712Oxygen Sensor

Scheme 88

Scheme 88
Scheme 88
CalloutComponent Name
100Engine Block
101Crankshaft Bearing - Upper
102Crankshaft Thrust Bearing - Upper
103Crankshaft
104Crankshaft Bearing - Lower
105Crankshaft Thrust Bearing - Lower
106Lower Crankcase
107Lower Crankcase Perimeter Bolt
108Lower Crankcase Main Bearing Bolt
109Crankshaft Rear Seal
110Flywheel - Automatic Transmission
111Automatic Transaxle Flywheel to Crankshaft Bolt
112Manual Transaxle Flywheel
113Manual Transaxle Flywheel Bolt
114Engine Block to Transaxle Alignment Pin
115Engine Block Gallery Plug
116Cylinder Head Alignment Pin
117Cylinder Bore Sleeve
118Connecting Rod Cap Bolt
119Connecting Rod
120Connecting Rod Bearing
121Piston Assembly
122Piston Ring Assembly
200Cylinder Head Gasket
301Thermostat Housing
302Thermostat Housing to Block Gasket
303Water Pipe Support Bracket Bolt
304Water Pipe Support Bracket Bolt Stud
305Water Pipe Support Bracket
306Thermostat Gasket
307Thermostat
308Thermostat Housing Cap
309Thermostat Housing Cap Bolt
310Water Transfer Pipe
311Water Transfer Pipe O-ring Seals
312Water Pump
313Water Pump to Engine Block Seal
400Engine Oil Pan
401Engine Oil Pan Alignment Pins
402Engine Oil Pan Drain Plug
403Engine Oil Pan Bolt
404Engine Oil Pan Long Bolt
405Oil Filter
406Oil Filter Cap O-ring
407Oil Filter Cap
433Piston Oil Squirter
700Oil Pressure Switch
701Crankshaft Position Sensor Bolt
702Crankshaft Position Sensor
703Knock Sensor
706Coolant Temperature Sensor

Scheme 89

Scheme 89
Scheme 89
CalloutComponent Name
123Balance Shaft Rear Bearing
124Exhaust Balance Shaft
125Intake Balance Shaft
126Exhaust Balance Shaft Bearing Carrier
127Intake Balance Shaft Bearing Carrier
128Exhaust Balance Shaft Drive Sprocket
129Intake Balance Shaft Drive Sprocket
130Balance Shaft Drive Sprocket Bolts
223Upper Timing Chain Guide Bolt
224Upper Timing Chain Guide
225Exhaust Camshaft Position Actuator
226Intake Camshaft Position Actuator
227Camshaft Position Actuator Bolt
228Timing Chain Oil Nozzle
229Timing Chain Oil Nozzle Bolt
230Timing Chain Drive Sprocket
231Fixed Timing Chain Guide
232Fixed Timing Chain Guide Bolt
233Timing Chain
234Timing Chain Tensioner Washer
235Timing Chain Tensioner Body
236Timing Chain Tensioner O-ring Seal
237Timing Chain Tensioner Plunger
238Adjustable Timing Chain Guide
239Adjustable Timing Chain Guide Bolt
240Balance Shaft Drive Sprocket
241Balance Shaft Drive Chain Guide
242Balance Shaft Drive Chain Guide Bolt
243Balance Shaft Drive Chain Guide
244Balance Shaft Drive Chain Guide Bolt
245Balance Shaft Drive Chain
246Balance Shaft Drive Chain Tensioner Assembly
247Balance Shaft Drive Chain Tensioner Assembly Bolt
248Adjustable Balance Shaft Drive Chain Guide
249Adjustable Balance Shaft Drive Chain Guide Bolt
314Water Pump Drive Sprocket
315Water Pump Drive Sprocket Bolt
316Water Pump Bolt
317Engine Front Cover Access Plate Gasket
318Engine Front Cover Access Plate
319Engine Front Cover Access Plate Bolt
414Engine Front Cover Alignment Pins
415Engine Front Cover Gasket
416Oil Pump Cover Bolt
417Oil Pump Cover
418Oil Pump Outer Gerotor
419Oil Pump Inner Gerotor
420Engine Front Cover
421Engine Front Cover Bolt
422Oil Pressure Relief Valve Spring
423Oil Pressure Relief Valve Plunger
424Oil Pressure Relief Valve O-ring Seal
425Oil Pressure Relief Valve Plug
426Crankshaft Front Seal
427Crankshaft Damper
428Crankshaft Damper Bolt
429Friction Washer, some models
704Belt Tensioner
705Belt Tensioner Bolt

Scheme 90

Scheme 90: Engine Identification (LAP, LAT, LE5, LE8, LE9)
Scheme 90: Engine Identification (LAP, LAT, LE5, LE8, LE9)

Identification can be made through the use of the Broadcast Code label on the engine front cover (1) and the use of the partial VIN etched in one of two places - the primary location is on the starter motor flange (3). The secondary location is the oil filter bowl (2).

  1. Barcode (1)
  2. Sequence Number (2)
  3. Day (3)
  4. Month (4)
  5. Year (5)
  6. Engine Assembly Plant (6)
  7. Broadcast Code (7)
  8. Part Designation (8)
  9. Engine Assembly Number (9)
  10. Broadcast Code (10)

The partial VIN identifies the specific vehicle by sequence number.
