Automatic Transmission - 5l40-e/5l50-e - Component Locator — Transmission — Automatic Trans

Scheme 52

Scheme 52: Disassembled Views

Callout	Component Name
1	Torque Converter Assembly
2	Torque Converter Housing to Main Case Bolt
3	Torque Converter Housing Assembly - Model Dependent
4	Torque Converter Housing Fluid Seal Assembly
5	Reverse Clutch Housing Thrust Washer - Selective
6	Direct and Reverse Clutch Assembly
7	Forward and Coast Clutch Assembly
8	Input Sun Gear - W/Forward Clutch Roller Inner Race Shaft
9	Direct Clutch Hub Thrust Washer
10	Direct Clutch Assembly- W/Input and Reaction Carrier in Hub
11	Input and Reaction Carrier Inner Shaft Thrust Washer
12	Intermediate Clutch Sprag Assembly
14	Intermediate and Overdrive Clutch Housing Retainer Ring - Selective
15	Overdrive Clutch Housing Assembly
16	Low Clutch Sprag Assembly
17	Low Clutch Roller Thrust Bearing
18	Center Support
19	Input and Reaction Carrier Assembly
20	Input and Reaction Carrier Thrust Bearing
21	Output Shaft Assembly W/Rear Internal Gear - Model Dependent
22	Input and Reaction Carrier Washer Selective Steel - Model Dependent
23	Input and Reaction Carrier Thrust Bearing
24	Automatic Transmission Case Assembly

Scheme 53

Callout	Component Name
24	Automatic Transmission Case Assembly
25	Automatic Transmission Case Extension Gasket - Model Dependent
25	Automatic Transmission Case Extension Gasket - Model Dependent
26	Output Shaft Bearing - Model Dependent
27	Automatic Transmission Case Extension - Model Dependent
27	Automatic Transmission Case Extension - Model Dependent
28	Output Shaft Bearing - Model Dependent
28	Output Shaft Bearing - Model Dependent
29	Automatic Transmission Prop Shaft - Model Dependent
30	Output Shaft Assembly Retainer - Model Dependent
31	Automatic Transmission Prop Shaft Flange - Model Dependent
32	Automatic Transmission Prop Shaft Flange - O-Ring Seal - Model Dependent
33	Automatic Transmission Prop Shaft Thrust Washer - Model Dependent
34	Prop Shaft Flange Nut - Model Dependent
35	Automatic Transmission Case Extension Bolt - Model Dependent
35	Automatic Transmission Case Extension Bolt - Model Dependent
36	Automatic Transmission Fluid Level Hole Plug
37	Automatic Transmission Fluid Level Hole Plug O-Ring Seal
38	Center Support Fluid Passage Sleeve
39	Overdrive Clutch Fluid Passage Sleeve
40	Automatic Transmission Pressure Test Plug
42	Output Speed Sensor
43	Output Speed Sensor Bolt
44	Input Speed Sensor
45	Input Speed Sensor Bolt
46	Automatic Transmission Fluid Pump Cover Gasket
47	Control Valve Body and Accumulator Assembly
49	Control Valve Body Bolt M6 x 1.0 x 50
50	Control Valve Body Bolt M6 x 1.0 x 38
51	Control Valve Body Bolt M6 x 1.0 x 50
52	Manual Shaft Detent Assembly
53	Control Valve Body Bolt M6 x 1.0 x 68
54	Wiring Harness Clip
55	Automatic Transmission Wiring Harness
56	Automatic Transmission Wiring Harness - O-Ring Seal - 2
57	Automatic Transmission Filter Seal - 2
59	Automatic Transmission Fluid Filter
60	Automatic Transmission Fluid Pan Gasket
61	Automatic Transmission Fluid Pan Magnet
62	Automatic Transmission Fluid Pan Assembly
65	Automatic Transmission Fluid Pan Bolt
66	Automatic Transmission Pressure Test Plug O-Ring Seal

Scheme 54

Callout	Component Name
200	Reverse Clutch Housing Fluid Seal Ring - 3
201	Input Shaft Bearing Assembly
202	Automatic Transmission Fluid Pump Cover Assembly
203	Check Valve Retainer and Ball Assembly
203	Check Valve Retainer and Ball Assembly
204	Valve Bushing/Spring Retainer
204	Valve Bushing/Spring Retainer
205	Line Boost Valve Bushing Seal
206	Line Boost Valve Bushing
207	Line Boost Valve
208	Line Boost Valve Spring
209	Pressure Regulator Valve Spring
210	Pressure Regulator Valve
211	Automatic Transmission Fluid Pump Retainer Pin
211	Automatic Transmission Fluid Pump Retainer Pin
212	Automatic Transmission Pump Cover Seal
213	Automatic Transmission Fluid Pump Screen Assembly
214	Brass Orifice Insert
215	Turbine Shaft Bushing
216	Automatic Transmission Fluid Pump Slide - Selective
217	Automatic Transmission Fluid Pump Slide Seal Support
218	Automatic Transmission Fluid Pump Slide Seal
219	Automatic Transmission Fluid Pump Slide Ring
220	Automatic Transmission Fluid Pump Slide Ring
221	Automatic Transmission Fluid Pump Vane Ring
222	Automatic Transmission Fluid Pump Vane
223	Automatic Transmission Fluid Pump Rotor - Selective
224	Automatic Transmission Fluid Pump Rotor Guide
225	Automatic Transmission Fluid Pump Vane Ring
226	Torque Converter Bushing
227	Torque Converter Housing
228	Torque Converter Housing Seal Bolt M4 x 0.7 x 10.0 - 4
229	Torque Converter Housing Seal
231	Automatic Transmission Fluid Pump Slide Pin Assembly
232	Orifice Sleeve
233	Orifice Cup Plug - 2
233	Orifice Cup Plug - 2
234	TCC Control Valve Spring
234	TCC Control Valve Spring
235	TCC Control Valve
236	Automatic Transmission Fluid Pump Retainer Pin
237	TCC Enable Valve
238	Pressure Relief Ball Valve Spring
239	Pressure Relief Ball Valve
240	Automatic Transmission Fluid Pump Bolt M6 x 1.0 x 40
241	Automatic Transmission Fluid Pump Bolt M8 x 1.25 x 40
242	Automatic Transmission Fluid Pump Slide O-ring Seal

Scheme 55

Callout	Component Name
300	Control Valve Body Bolt M6 x 1.0 x 38 - 7
301	Control Valve Top Channel Plate
302	Control Valve Channel Plate Ball Check Spring
303	Control Valve Channel Plate Gasket
304	Control Valve Bottom Channel Plate
305	Control Valve Body Gasket
306	Control Valve Body Ball Check Valve
307	Control Valve Body Spacer Plate
308	TCC PWM Solenoid Valve Filter Assembly
309	Control Valve Body Spacer Plate Gasket
310	Control Valve Rear Body Assembly
311	Control Valve Front Body Assembly
312	Pressure Control Solenoid Valve Filter Assembly
313	Direct Clutch Accumulator Piston Spring - Model Dependent
314	Direct Clutch Accumulator Piston Fluid Seal Ring - Model Dependent
315	Direct Clutch Accumulator Piston - Model Dependent
316	Direct Clutch Accumulator Piston Fluid Seal Ring - Model Dependent
317	Direct Clutch Accumulator Housing - Model Dependent
318	Accumulator Housing Bolt M6 x 1.0 x 30 - 12 - Model Dependent
318	Accumulator Housing Bolt M6 x 1.0 x 30 - 12
318	Accumulator Housing Bolt M6 x 1.0 x 30 - 12
318	Accumulator Housing Bolt M6 x 1.0 x 30 - 12
319	Overdrive Clutch Accumulator Piston Spring
320	Overdrive Clutch Accumulator Piston Fluid Seal Ring
321	Overdrive Clutch Accumulator Piston
322	Overdrive Clutch Accumulator Piston Fluid Seal Ring
323	Overdrive Clutch Accumulator Housing
324	Intermediate Clutch Accumulator Piston Spring
325	Intermediate Clutch Accumulator Piston Fluid Seal Ring
326	Intermediate Clutch Accumulator Piston
327	Intermediate Clutch Accumulator Piston Fluid Seal Ring
328	Intermediate Clutch Accumulator Housing
329	2nd Clutch Accumulator Piston Spring - Model Dependent
330	2nd Clutch Accumulator Piston Seal Ring - Model Dependent
331	2nd Clutch Accumulator Piston - Model Dependent
332	2nd Clutch Accumulator Piston Seal Ring - Model Dependent
333	2nd Clutch Accumulator Housing - Model Dependent
334	2nd Clutch Accumulator Piston Inner Spring - Model Dependent

Scheme 56

Callout	Component Name
340	Front Control Valve Body
341	Safety Mode Valve
342	Safety Mode Valve Spring
343	Valve Spring Retainer - 3
343	Valve Spring Retainer - 3
343	Valve Spring Retainer - 3
344	3-4 Shift Valve Spring
345	3-4 Shift Valve
346	3-4 Shift Control Valve
347	TCC Regulator Apply Valve Spring
348	TCC Regulator Apply Valve
349	Solenoid Valve - O-Ring Seal
350	Solenoid Valve - O-Ring Seal
351	Solenoid Valve Retainer - 2
351	Solenoid Valve Retainer - 2
352	TCC PWM Solenoid Valve
353	Feed Limit Valve
354	Feed Limit Valve Spring
355	Pressure Control Solenoid - O-Ring Seal
356	Pressure Control Solenoid - O-Ring Seal
357	Pressure Control (PC) Solenoid Assembly

Scheme 57

Callout	Component Name
343	Valve Spring Retainer
343	Valve Spring Retainer
343	Valve Spring Retainer
349	Solenoid Valve - O-Ring Seal
349	Solenoid Valve - O-Ring Seal
349	Solenoid Valve - O-Ring Seal
350	Solenoid Valve - O-Ring Seal
350	Solenoid Valve - O-Ring Seal
350	Solenoid Valve - O-Ring Seal
351	Solenoid Valve Retainer
351	Solenoid Valve Retainer
351	Solenoid Valve Retainer
365	Rear Control Valve Body
366	1-2 Shift Control Valve
367	1-2 Shift Control Valve Spring
368	1-2 Shift Solenoid (SS) Valve Assembly
369	2-3 Shift Solenoid (SS) Valve Assembly
370	2-3 Shift Control Valve
371	2-3 Shift Valve
372	2-3 Shift Valve Spring
373	4-5 Shift Valve Spring
374	4-5 Shift Valve
375	4-5 Shift Control Valve
376	4-5 Shift Solenoid (SS) Valve Assembly
377	Manual Valve
378	Manual Valve Link Washer - Waved
379	Manual Valve Link
380	Manual Valve Link Retainer
381	Low Pressure Control Valve Bore Plug
382	Low Pressure Control Valve Spring
383	Low Pressure Control Valve
384	Low Pressure Control Valve Bore Retainer
385	Reverse Lockout Valve
386	Reverse Lockout Valve Spring
387	1-2 Shift Valve
388	1-2 Shift Valve Spring

Scheme 58

Callout	Component Name
400	Reverse Clutch Housing Bushing
401	Reverse Clutch - W/Input Housing Assembly
402	Reverse Clutch Piston Inner Seal
403	Reverse Clutch Housing Ball Check Valve
404	Reverse Clutch Piston
405	Direct Clutch Housing Ball Check Valve
406	Direct Clutch Piston Assembly
407	Direct and Reverse Clutch Spring
408	Direct and Reverse Clutch Spring Retainer
409	Direct and Reverse Clutch Spring Retainer Ring
410	Direct Clutch Apply Plate
411	Direct Clutch Plate Assembly - Outer Spline - 4
412	Direct Clutch Plate Assembly - Inner Spline - 4
413	Direct Clutch Backing Plate
414	Direct Clutch Backing Plate Retainer Ring - Selective
415	Reverse Clutch Spacer
416	Reverse Clutch Apply Plate
417	Reverse Clutch Plate Assembly - Outer Spline - 2
418	Reverse Clutch Plate Assembly - Inner Spline - 2
419	Reverse Clutch Backing Plate
420	Reverse Clutch Backing Plate Retainer Ring - Selective

Scheme 59

Callout	Component Name
430	Input Shaft - O-Ring Seal
431	Input Shaft Fluid Seal Ring
432	Input Shaft Fluid Seal Ring - 3
433	Forward Clutch - W/Input Housing Assembly
434	Forward Clutch Housing Ball Check Valve Assembly
435	Forward Clutch Bushing
436	Forward Clutch Piston Assembly
437	Coast Clutch Piston Ball Check Valve Assembly
438	Coast Clutch Piston Assembly
439	Forward and Coast Clutch Spring
440	Forward and Coast Clutch Spring Retainer Ring
441	Coast Clutch Spacer Plate - Selective
442	Coast Clutch Apply Plate
443	Coast Clutch Plate Assembly - Outer Spline - 3
444	Coast Clutch Plate Assembly - Inner Spline - 3
445	Coast Clutch Backing Plate
446	Coast Clutch Housing
447	Forward Clutch Apply Plate
448	Forward Clutch Plate Assembly - Outer Spline - 4
449	Forward Clutch Plate Assembly - Inner Spline - 4
450	Forward Clutch Backing Plate
451	Forward Clutch Backing Plate Retainer Ring - Selective

Scheme 60

Callout	Component Name
455	Forward Clutch Roller Inner Race Thrust Ring
456	Forward Clutch Roller Inner Bearing
457	Input Sun Gear Shaft Assembly
458	Forward Clutch Roller Outer Race Washer
459	Forward Clutch Sprag Outer Race
460	Forward Clutch Sprag Assembly Retainer Rings - 2
460	Forward Clutch Sprag Assembly Retainer Rings - 2
461	Forward Clutch Sprag Assembly
462	Orificed Cup Plug - Lube

Scheme 61

Callout	Component Name
465	Input and Reaction Carrier Bushing - 2
465	Input and Reaction Carrier Bushing - 2
466	Direct Clutch Drum

Scheme 62

Callout	Component Name
470	Overdrive and Reverse Clutch - W/Hub Assembly
471	Intermediate Clutch Roller Thrust Washer
472	Intermediate Clutch Sprag Assembly Retainer Rings - 2
472	Intermediate Clutch Sprag Assembly Retainer Rings - 2
473	Intermediate Clutch Sprag Assembly
474	Intermediate Clutch Sprag Outer Race
475	Intermediate Clutch Roller Thrust Washer
476	Intermediate Clutch Roller Thrust Bearing Assembly
477	Intermediate Clutch Roller Thrust Bearing Assembly Retainer

Scheme 63

Callout	Component Name
480	Overdrive Clutch Backing Plate Retainer Ring - Selective
481	Overdrive Clutch Backing Plate
482	Overdrive Clutch Plate Assembly - Inner Spline
483	Overdrive Clutch Plate Assembly - Outer Spline
484	Overdrive Clutch Spacer
485	Overdrive Clutch Spring Retainer Ring
486	Overdrive Clutch Piston Spring
487	Overdrive Clutch Piston Assembly
488	Intermediate Clutch Backing Plate Retainer Ring - Selective
489	Intermediate Clutch Backing Plate
490	Intermediate Clutch Plate Assembly - Inner Spline - 3
491	Intermediate Clutch Plate Assembly - Outer Spline - 3
492	Intermediate Clutch Apply Plate
493	Overdrive Clutch Housing
494	Intermediate Clutch Spring
495	Intermediate Clutch Piston Assembly
496	Intermediate Clutch Housing
497	Intermediate Clutch Housing Retainer Ring

Scheme 64

Callout	Component Name
500	Low Clutch Roller Retainer
501	Low Clutch Roller Thrust Washer
501	Low Clutch Roller Thrust Washer
502	Low Clutch Sprag Assembly Retainer Rings - 2
502	Low Clutch Sprag Assembly Retainer Rings - 2
503	Low Clutch Sprag Assembly
504	Low Clutch Sprag Outer Race
505	Low Clutch Sprag Inner Race

Scheme 65

Callout	Component Name
510	Low and Reverse Clutch Plate Retainer Ring - Selective
511	Low and Reverse Clutch Backing Plate
512	Low and Reverse Clutch Plate Assembly - Inner Spline - 5
513	Low and Reverse Clutch Plate Assembly - Outer Spline - 5
514	Low and Reverse Clutch Apply Plate
515	Low and Reverse Clutch Spring Retainer Ring
516	Low and Reverse Clutch Spring
517	Low and Reverse Clutch Piston
518	Center Support
519	Input and Reaction Bearing Assembly
520	2nd Clutch Piston
521	2nd Clutch Spring
522	2nd Clutch Spring Retainer Ring
523	2nd Clutch Apply Plate
524	2nd Clutch Plate Assembly - Outer Spline - 5
525	2nd Clutch Plate Assembly - Inner Spline - 5
526	2nd Clutch Backing Plate
527	2nd Clutch Backing Plate Retainer Ring - Selective
528	2nd Coast Clutch Piston Assembly
529	2nd Coast Clutch Spring
530	2nd Coast Clutch Spring Retainer Ring
531	2nd Coast Clutch Spacer
532	2nd Coast Clutch Plate Assembly - Outer Spline - 3
533	2nd Coast Clutch Plate Assembly - Inner Spline - 3
534	2nd Coast Clutch Backing Plate
535	2nd Coast Clutch Plate Backing Plate Retainer Ring - Selective

Scheme 66

Callout	Component Name
540	Input and Reaction Carrier Outer Retainer Ring
541	Input and Reaction Bearing Assembly
542	2nd Clutch Roller Inner Race Bearing Assembly
543	2nd Clutch Sprag Retainer
544	2nd Clutch Roller Outer Race Washer
544	2nd Clutch Roller Outer Race Washer
545	2nd Clutch Sprag Outer Race
546	2nd Clutch Sprag Assembly Retainer - 2
546	2nd Clutch Sprag Assembly Retainer - 2
547	2nd Clutch Sprag Assembly
548	Input and Reaction Carrier Bushing
549	2nd Clutch Sprag Inner Race
550	Reaction Internal Gear
551	Reaction Internal Gear Flange Washer
552	Reaction Carrier Bushing - 2
552	Reaction Carrier Bushing - 2
553	Input and Reaction Carrier
554	Input and Reaction Bearing Assembly

Scheme 67

Callout	Component Name
560	Rear Internal Gear
561	Input and Reaction Carrier Bushing
562a	Output Shaft Assembly - Model Dependent
562b	Output Shaft Assembly - Model Dependent
562c	Output Shaft Assembly - Model Dependent
563	Rear Internal Retainer Ring
564	Cup Plug

Scheme 68

Callout	Component Name
600	Manual Shaft Detent Lever
601	Manual Shaft Detent Lever Pin
602	Transmission Manual Shift Shaft Switch Assembly
603	Manual Shaft Detent Lever Pin
604	Transmission Case
605	Manual Shift Shaft Seal - Model Dependent
605	Manual Shift Shaft Seal - Model Dependent
606a	Manual Shift Shaft - 2WD - Model Dependent
606b	Manual Shift Shaft - AWD - Model Dependent
607	Park Pawl Actuator Bracket
608	Park Pawl Actuator Bracket
609	Park Pawl Actuator Bracket Bolt M8 x 1.25 x 25 - 2
610	Park Pawl Shaft
611	Park Pawl Spring
612	Park Pawl
613	Park Pawl Actuator Assembly
614	Cup Plug - Model Dependent
615	Transmission Manual Shift Shaft Spacer - Model Dependent

Scheme 69

Scheme 69: Component Location

Callout	Component Name
17	Low Clutch Roller Thrust Bearing
20	Input and Reaction Carrier Thrust Bearing
23	Input and Reaction Carrier Thrust Bearing - Model Dependent
26	Output Shaft Bearing
28	Output Shaft Bearing
69	Input and Reaction Carrier Thrust Bearing - Model Dependent
201	Input Shaft Bearing Assembly
215	Turbine Shaft Bushing
226	Torque Converter Bushing
400	Reverse Clutch Housing Bushing
435	Forward Clutch Bushing
456	Forward Clutch Roller Inner Bearing
461	Forward Clutch Sprag Assembly
465	Input and Reaction Carrier Bushing Assembly - 2
465	Input and Reaction Carrier Bushing Assembly - 2
473	Intermediate Clutch Sprag Assembly
476	Intermediate Clutch Roller Thrust Bearing Assembly
503	Low Clutch Sprag Assembly
519	Input and Reaction Bearing Assembly
541	Input and Reaction Bearing Assembly
542	2nd Clutch Roller Inner Race Bearing Assembly
547	2nd Clutch Sprag Assembly
548	Input and Reaction Carrier Bushing
552	Reaction Carrier Bushing - 2
552	Reaction Carrier Bushing - 2
554	Input and Reaction Bearing Assembly
561	Input and Reaction Carrier Bushing

Scheme 70

Callout	Component Name
4	Torque Converter Housing Fluid Seal Assembly
29	Transmission Prop Shaft Flange Seal
32	Transmission Prop Shaft Flange - O-ring Seal
38	Center Support Fluid Passage Sleeve
39	Overdrive Clutch Fluid Passage Sleeve
56	A/Transmission Wiring Harness - O-ring Seal - 2
57	Automatic Transmission Filter Seal - 2
64	Automatic Transmission Fluid Pan Drain Plug Seal
200	Reverse Clutch Housing Fluid Seal Ring - 3
218	Automatic Transmission Fluid Pump Slide Seal
220	Automatic Transmission Fluid Pump Slide Ring
229	Torque Converter Housing Seal
242	Automatic Transmission Fluid Pump Slide O-ring Seal
314	Clutch Accumulator Piston Fluid Seal Ring
316	Clutch Accumulator Piston Fluid Seal Ring
402	Reverse Clutch Piston Inner Seal
404	Reverse Clutch Piston
406	Direct Clutch Piston Assembly
430	Input Shaft - O-Ring Seal
431	Input Shaft Fluid Seal Ring
432	Input Shaft Fluid Seal Ring - 3
436	Forward Clutch Piston Assembly
438	Coast Clutch Piston Assembly
487	Overdrive Clutch Piston Assembly
495	Intermediate Clutch Piston Assembly
517	Low and Reverse Clutch Piston
520	2nd Clutch Piston
528	2nd Coast Clutch Piston Assembly
605	Manual Shift Shaft Seal

Scheme 71

Scheme 71: Ball Check Valve Locations

Automatic Transmission - 5l40-e/5l50-e - Component Locator Saturn Sky I final

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

More articles — Transmission

Login / Signup

Enter the code

You have successfully logged in!
