Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Door Rearview Mirror Motor Screws | 2 N.m | 18 lb in |
| Door Rearview Mirror Nuts | 10 N.m | 89 lb in |
| Mirror Set Screw | 2N.m | 18 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Outside Rearview Mirror Schematics
Scheme 2
Scheme 2: Mirror Component Views
| Callout | Component Name |
|---|
| 1 | Door Lock Actuator - Driver |
| 2 | Window Switch - Driver (A31) |
| 3 | Outside Rearview Mirror - Driver (D48) |
| 4 | Outside Rearview Mirror Switch (D48) |
| 5 | Speaker - LF Door |
| 6 | C166 |
| 7 | C165 |
| 8 | Window Motor - Driver (A31) |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Speaker - RF Door |
| 2 | Outside Rearview Mirror - Passenger (D48) |
| 3 | Door Lock Actuator - Passenger |
| 4 | Window Switch - Passenger (A31) |
| 5 | Window Motor - Passenger (A31) |
| 6 | C167 |
Scheme 4
Scheme 4: Inside Rearview Mirror (UE1)
| Connector Part Information OEM: 15324871 Service: See Catalog Description: 16-Way F Micro-Pack 100 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 175266-5/15 Core/Insulation Crimp: J/J Release Tool/Test Probe: 15317247/J-35616-16 (L-GY) |
Connector Part Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | GY | 157 | Courtesy Lamp Control |
| 2-5 | | | Not Used |
| 6 | D-BU/WH | 149 | Courtesy Lamp Supply Voltage |
| 7 | | | Not Used |
| 8 | BK | 550 | Ground |
| 9-10 | | | Not Used |
| 11 | D-GN/WH | 2514 | Keypad Signal |
| 12 | L-GN/BK | 2515 | Keypad Supply Voltage |
| 13 | | | Not Used |
| 14 | YE/BK | 2516 | Keypad Green LED Signal |
| 15 | BN/WH | 2517 | Keypad Red LED Signal |
| 16 | | | Not Used |
Connector Terminal Identification
Scheme 5
Scheme 5: Inside Rearview Mirror (w/o UE1)
| Connector Part Information OEM: 12124782 Service: 15306078 Description: 7-Way F VH Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SVH-21T-P1.1/20 Core/Insulation Crimp: E/2 Release Tool/Test Probe: 12094429/J-35616-18 (BK) |
Connector Part Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | | | Not Used |
| 2 | BK | 550 | Ground |
| 3-5 | | | Not Used |
| 6 | GY | 157 | Courtesy Lamp Control |
| 7 | D-BU/WH | 149 | Courtesy Lamp Supply Voltage |
Connector Terminal Identification
Scheme 6
Scheme 6: Outside Rearview Mirror - Driver
| Connector Part Information OEM: E-5965-003 Service: See Catalog Description: 3-Way F (BK) |
|---|
| Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD |
Connector Part Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | L-BU | 82 | Driver Mirror Motor Left Control (A31) |
| 2 | TN | 329 | Driver Mirror Motor Supply Voltage (A31) |
| 3 | YE | 88 | Driver Mirror Motor Up Control (A31) |
Connector Terminal Identification
