Outside Rearview Mirror - Passenger
| Connector Part Information OEM: E-5965-003 Service: See Catalog Description: 3-Way F (BK) |
|---|
| Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD |
Connector Part Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | GY | 90 | Passenger Mirror Motor Left Control (A31) |
| 2 | TN/WH | 330 | Passenger Mirror Motor Supply Voltage (A31) |
| 3 | BN/WH | 1498 | Passenger Mirror Motor Up Control (A31) |
Connector Terminal Identification
Scheme 8
Scheme 8: Outside Rearview Mirror Switch
| Connector Part Information OEM: 12064769 Service: 12101762 Description: 10-Way F Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD |
Connector Part Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | | | Not Used |
| B | BK | 550 | Ground (A31) |
| C | TN | 329 | Driver Mirror Motor Supply Voltage (A31) |
| D | GY | 90 | Driver Mirror Motor Left Control (A31) |
| E | GY | 8 | Instrument Panel Lamp Supply Voltage (A31) |
| F | BN/WH | 1498 | Passenger Mirror Motor Up Control (A31) |
| G | RD/WH | 440 | Battery Positive Voltage (A31) |
| H | TN/WH | 330 | Passenger Mirror Motor Supply Voltage (A31) |
| J | L-BU | 82 | Driver Mirror Motor Left Control (A31) |
| K | YE | 88 | Driver Mirror Motor Up Control (A31) |
Connector Terminal Identification
Intermittent
Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to Testing for Intermittent Conditions and Poor Connections .
Repair Procedures
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Power Mirror Switch Replacement»(ref-269799-S36432997552007110200000)
- «Mirror Replacement»(ref-269799-S14344255542007110200000)
Scheme 9
Scheme 9: Power Mirror Switch Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the door panel. Refer to Door Trim Panel Replacement . |
| 1 | Front Side Window Switch Assembly Tip: Use a flat-bladed tool to release the switch from the trim panel. |
Power Mirror Switch Replacement
Scheme 10
Scheme 10: Mirror Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the door trim panel. Refer to Door Trim Panel Replacement . Fully lower the door window before removing the trim panel. |
| 1 | Mirror Outside Rearview Nut (Qty: 3) NOTE: Refer to Fastener Notice . Tip: Disconnect the mirror electrical connector. Tighten: 10 N.m (89 lb in) |
| 2 | Outside Rearview Mirror Assembly |
| NOTE |
|---|
| Refer to Fastener Notice . |
Scheme 11
Scheme 11: Outside Rearview Mirror Motor Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the door trim panel. Refer to Door Trim Panel Replacement . Remove the door mirror face. Refer to Mirror Face Replacement . |
| 1 | Front Door Mirror Motor Screw NOTE: Refer to Fastener Notice . Tighten: 2 N.m (18 lb in) |
| 2 | Front Door Mirror Motor Tip: Disconnect the electrical connector from the mirror motor. |
| NOTE |
|---|
| Refer to Fastener Notice . |
Outside Rearview Mirror Motor Replacement
Scheme 12
Scheme 12: Mirror Face Replacement
| Callout | Component Name |
|---|
| CAUTION: Refer to Glass and Sheet Metal Handling Caution . |
| 1 | Outside Rearview Mirror Face Tip: Release the mirror face backing from the mirror housing by pulling outward. |
| CAUTION |
|---|
| Refer to Glass and Sheet Metal Handling Caution . |
Scheme 13
Scheme 13: Rearview Mirror Replacement
| Callout | Component Name |
|---|
| 1 | Rearview Mirror Screw NOTE: Refer to Fastener Notice . Tighten: 2 N.m (18 lb in) Tip: Do Not remove the set screw completely from the mirror base. |
| 2 | Rearview Mirror Procedures Remove the wiring harness cover if equipped. Remove the mirror from the mounting pad. Disconnect the wiring harness from the rearview mirror. |
| NOTE |
|---|
| Refer to Fastener Notice . |
Rearview Mirror Replacement
Outside Rearview Mirror Controls
The outside rearview mirrors are controlled by the outside rearview mirror switch located on the driver door. The outside rearview mirror switch contains a mirror select switch and a 4 position mirror direction switch. The mirror select switch is a 2 position switch (L, R), used to select the mirror to be adjusted. The mirror direction switch is used to control the mirror in the up, down, left, and right directions.
