Removal Procedure
- Remove rear bumper fascia. Refer to «Rear Bumper Fascia Replacement»(ref-301138-S30116703832008101700000) .
- Disconnect electrical from the rear object sensor.
- Lift the locking tabs on the housing and remove the rear object sensor.
Installation Procedure
- Paint the rear object sensor. Refer to «Basecoat/Clearcoat Paint Systems»(ref-301155-S21816629462008101700000) .
- Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «Paint Gages»(ref-301155-S19470782662008101700000) .
- Insert the sensor into the housing.
- Connect the electrical connector to the rear object sensor.
- Install the rear bumper fascia. Refer to «Rear Bumper Fascia Replacement»(ref-301138-S30116703832008101700000) .
Rear Object Sensor Housing Replacement
- Remove the rear fascia. Refer to «Rear Bumper Fascia Replacement»(ref-301138-S30116703832008101700000) .
- Disconnect the sensor harness.
- Remove the sensor from the sensor housing. The sensor housing must be painted if replaced. If reinstalled, painting will not be necessary.
- Sand/grind sonic weld plastic residue from the fascia.
- Apply structural adhesive epoxy, Lord Fusor™ 127EZ or equivalent, to fascia at mating surface.
- Using the alignment tabs, install the sensor housing to the fascia.
- Allow adhesive to cure according to manufacturer's directions.
- Install the sensor to the sensor housing.
- Connect the electrical harness.
- Install the rear fascia. Refer to «Rear Bumper Fascia Replacement»(ref-301138-S30116703832008101700000) .
Scheme 3
Scheme 3: Rearview Camera Image Display Module Replacement
| Callout | Component Name |
| 1 | Body Side Trim Panel Stow Compartment Door Assembly |
| 2 | Rearview Camera Image Display Module Assembly Procedure: Disconnect the electrical Connector. |
