Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Crank Arm Nut | 25 N.m | 18 lb ft |
| Washer Solvent Container Screws | 5 N.m | 45 lb in |
| Wiper Arm Nut | 25 N.m | 18 lb ft |
| Wiper Module Bolts | 10 N.m | 89 lb in |
| Wiper Motor Screws | 8 N.m | 71 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Wiper/Washer System Schematics
Scheme 2
Scheme 2: Wiper/Washer System Component Views
| Callout | Component Name |
|---|
| 1 | Windshield Washer Fluid Pump |
| 2 | Horn |
| 3 | Fog Lamp - LF |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Windshield Wiper Motor Assembly |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Turn Signal/Multifunction Switch |
| 2 | Windshield Wiper/Washer Switch |
| 3 | Hazard Switch |
| 4 | Instrument Panel Cluster (IPC) |
| 5 | Traction Control Switch (NW7) |
| 6 | Radio |
| 7 | A/T Shifter (MN5) |
| 8 | HVAC Control Assembly |
| 9 | Steering Wheel Controls - Right (K34) |
| 10 | Steering Wheel Controls - Left (K34) |
| 11 | Rear Compartment Lid Release Switch |
