Entertainment Schematic Icons
Entertainment Schematic Icons Icon Icon Definition IMPORTANT: Twisted-pair wires provide an effective "shield" that helps protect sensitive electronic components from electrical interference. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.2 in)
Scheme 16
Scheme 16: Entertainment Schematic Icons
Scheme 17
Scheme 17: Radio/Audio System Schematics
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 21: Entertainment Component Views
| Callout | Component Name |
|---|
| 1 | Driver Outside Rearview Mirror |
| 2 | LF Door Tweeter Speaker (UZ6) |
| 3 | Driver Door Jamb Switch |
| 4 | Instrument Panel (I/P) Dimmer Switch |
| 5 | Fog Lamp Switch (T37) |
| 6 | Rear Compartment Lid Release Switch |
| 7 | LF Door Speaker |
| 8 | Outside Rearview Mirror Switch (DG7) |
| 9 | Window Switch - Driver (A31) |
| 10 | Door Lock Switch - Driver (AU3) |
Scheme 22
| Callout | Component Name |
|---|
| 1 | Radio |
| 2 | Passenger Door Jamb Switch |
| 3 | RF Door Tweeter Speaker (UZ6) |
| 4 | Radio Antenna |
| 5 | Passenger Outside Rearview Mirror |
| 6 | Front Passenger Door Lock Switch (AU3) |
| 7 | Front Passenger Window Switch (A31) |
| 8 | RF Door Speaker |
Scheme 23
| Callout | Component Name |
|---|
| 1 | LR Speaker |
| 2 | Audio Amplifier (UZ6) |
| 3 | Rear Compartment Courtesy Lamp |
| 4 | RR Speaker |
Scheme 24
| Callout | Component Name |
|---|
| 1 | Digital Radio Receiver (U2K) |
Scheme 25
| Callout | Component Name |
|---|
| 1 | Digital Radio Antenna (U2K) |
| 2 | Cellular/Navigation Antenna (UE1) |
