Computer/integrating Systems: Specifications Saturn ION I

Fastener Tightening Specifications

Fastener Tightening Specifications

Computer/Integrating Systems Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs. IMPORTANT: Twisted-pair wires provide an effective shield that helps protect sensitive electronic components from electrical interference. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.25 in)

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Body Control Module (BCM) C1 Connector Part Information 1326143-2 37-Way F Amp (BK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 OG 840 Battery Positive Voltage 3 YE 243 Accessory Voltage 4 YE 443 Accessory Voltage 5 D-BU 1307 Power Window Master Switch Lockout Control (Sedan) 6 D-BU 1307 Power Window Master Switch Lockout Control (Sedan w/A31) 7 D-BU 1307 Power Window Master Switch Lockout Control (Sedan w/A31) 8-16 - - Not Used 17 OG 1140 Battery Positive Voltage 18 GY 120 Fuel Pump Supply Voltage 19 D-GN/WH 465 Fuel Pump Relay Control 20 OG 1140 Battery Positive Voltage 21 RD 142 Battery Positive Voltage 22 RD 442 Battery Positive Voltage 23 BN 441 Ignition 3 Voltage (A31) 24 - - Not Used 25 PK 1200 Headlamp High Beam Signal 26 L-BU 20 Stop Lamp Switch Signal 27 L-BU 20 Stop Lamp Switch Signal 28 L-BU 20 Stop Lamp Switch Signal 29 L-BU 20 Stop Lamp Switch Signal 30 L-BU 20 Stop Lamp Switch Signal 31 - - Not Used 32 PK 3 Ignition 1 Voltage 33 - - Not Used 34 RD 342 Battery Positive Voltage 35-36 - - Not Used 37 RD 242 Battery Positive Voltage

Body Control Module (BCM) C2 Connector Part Information 1326143-1 38-Way F Amp (GY) Pin Wire Color Circuit No. Function 1 - - Not Used 2 OG 40 Battery Positive Voltage 3 OG 240 Battery Positive Voltage 4 - - Not Used 5 BN 9 Park Lamp Supply Voltage (T82) 6 OG 840 Battery Positive Voltage 7 PK 1200 Headlamp High Beam Signal 8 L-BU 20 Stop Lamp Switch Signal 9 PK 339 Ignition 1 Voltage (2.0L) 10 PK 339 Ignition 1 Voltage (2.2L w/M/T) 11 PK 339 Ignition 1 Voltage 12 - - Not Used 13 OG 52 Blower Motor Supply Voltage 14 BN 41 Ignition 3 Voltage 15 BN 141 Ignition 3 Voltage 16 - - Not Used 17 OG 1040 Battery Positive Voltage 18 OG 1440 Battery Positive Voltage 19-20 - - Not Used 21 OG 40 Battery Positive Voltage 22 YE 143 Accessory Voltage 23 YE 143 Accessory Voltage (A/T) 24-27 - - Not Used 28 PK 339 Ignition 1 Voltage (2.2L w/M/T) 29 YE 343 Accessory Voltage 30 - - Not Used 31 OG 52 Blower Motor Supply Voltage 32 OG 52 Blower Motor Supply Voltage 33 YE 1139 Ignition 1 Voltage 34 - - Not Used 35 PK 1539 Ignition 1 Voltage 36 - - Not Used 37 OG 1140 Battery Positive Voltage 38 OG 140 Battery Positive Voltage

Body Control Module (BCM) C3 Connector Part Information 1326144-1 56-Way F Amp (BK) Pin Wire Color Circuit No. Function 1 BK/WH 56 Trunk Release Motor Supply Voltage 2 TN 694 Driver Door Lock Actuator Unlock Control (AU3) 3 OG 1732 Inadvertent Power Supply Voltage 4 D-BU 338 Run/Crank Voltage 5 BN 4 Accessory Voltage 6 BN 9 Park Lamp Supply Voltage 7 BN 9 Park Lamp Supply Voltage 8 BN 9 Park Lamp Supply Voltage 9 BN 9 Park Lamp Supply Voltage 10 RD 228 Windshield Washer Pump Control 11 WH 156 Courtesy Lamp Low Control 12 OG 1732 Inadvertent Power Supply Voltage (2.2L) 13 OG 1732 Inadvertent Power Supply Voltage (DG7) 14 - - Not Used 15 D-GN 113 Windshield Wiper Switch Signal 2 16 - - Not Used 17 YE/BK 68 Low Coolant Level Indicator Signal 18 BK/WH 151 Ground (Sedan) 19 - - Not Used 20 BK/WH 151 Ground (Sedan) 21 L-BU 395 Passenger Door Jamb Switch Signal (Sedan) 22 L-BU 395 Passenger Door Jamb Switch Signal (Sedan) 23 YE 196 Windshield Wiper Motor Park Switch Signal 24 - - Not Used 25 PK 849 Brake Fluid Level Sensor Signal 26 PU 1807 BCM Class 2 Serial Data (JM4/JL9) 27 PU 1807 BCM Class 2 Serial Data 28-32 - - Not Used 33 WH 682 Driver Door Lock Actuator Unlock Control (AU3) 34 WH 682 Driver Door Lock Actuator Unlock Control (AU3) 35 D-GN 146 Trunk Ajar Indicator Control (AU3) 36-38 - - Not Used 39 WH 193 Rear Defog Relay Control 40 BK 28 Horn Relay Control 41 YE 317 Fog Lamp Relay Coil Supply Voltage (T37/T96) 42 - - Not Used 43 YE 18 Left Turn Signal Lamps Supply Voltage 44 L-BU 14 Left Turn Signal Lamp Supply Voltage 45 D-GN 19 Right Turn Signal Lamps Supply Voltage 46 D-BU 15 Right Turn Signal Lamp Supply Voltage 47 BK 650 Ground 48 GY 295 Door Lock Actuator Lock Control (Sedan w/AU3) 49 GY 295 Door Lock Actuator Lock Control (Sedan w/AU3) 50 GY 295 Door Lock Actuator Lock Control (AU3) 51 GY 295 Door Lock Actuator Lock Control (AU3) 52 TN 294 Door Lock Actuator Unlock Control (AU3) 53 TN 294 Door Lock Actuator Unlock Control (Sedan w/AU3) 54 - - Not Used 55 TN 294 Door Lock Actuator Unlock Control (Sedan w/AU3) 56 D-BU 1201 Headlamp Low Beam Signal

Body Control Module (BCM) C4 Connector Part Information 1326144-2 56-Way F Amp (GY) Pin Wire Color Circuit No. Function 1 RD 228 Windshield Washer Pump Control 2 BN 9 Park Lamp Supply Voltage 3 - - Not Used 4 BN 9 Park Lamp Supply Voltage 5 BN 9 Park Lamp Supply Voltage (T82) 6 BN 4 Accessory Voltage 7 D-BU 338 Run/Crank Voltage 8 - - Not Used 9 BN/WH 230 Instrument Panel Lamps Dimming Control 10 - - Not Used 11 YE 18 Left Turn Signal Lamps Supply Voltage 12 D-GN 19 Right Turn Signal Lamps Supply Voltage 13 GY 8 Instrument Panel Lamps Supply Voltage 14 GY 8 Instrument Panel Lamps Supply Voltage 15 GY 8 Instrument Panel Lamps Supply Voltage 16 GY 8 Instrument Panel Lamps Supply Voltage 17 GY 8 Instrument Panel Lamps Supply Voltage 18 PU 1807 BCM Class 2 Serial Data 19 PU 1807 BCM Class 2 Serial Data 20 PU 1807 BCM Class 2 Serial Data 21 - - Not Used 22 L-GN 66 A/C Request Signal 23 PK/WH 1970 Headlamp Low Beam Relay Control (T82) 24-26 - - Not Used 27 BK/WH 151 Ground 28 PU 719 Low Reference 29 - - Not Used 30 GY 8 Instrument Panel Lamps Supply Voltage (A/T) 31 GY 8 Instrument Panel Lamps Supply Voltage (T37/T96) 32 YE 317 Fog Lamp Relay Coil Supply Voltage (T37/T96) 33 BK 28 Horn Relay Control 34 BN 323 Shift Lock Solenoid Supply Voltage (A/T) 35 - - Not Used 36 WH 193 Rear Defog Relay Control 37 PU/WH 549 Headlamp Switch Headlamps Off Signal (T82) 38 - - Not Used 39 PU/WH 1572 Traction Control Indicator Control (NW7) 40 L-BU 1508 Turn/Hazard Switch Supply Voltage 41 GY 112 Windshield Wiper Switch Signal 1 42 BN/WH 1571 Traction Control Switch Signal (NW7) 43 L-BU 1134 Park Brake Switch Signal 44 L-BU 395 Passenger Door Jamb Switch Signal 45 L-GN/BK 394 Driver Door Jamb Switch Signal 46 L-BU 292 Rear Defog Switch Signal 47 D-BU 1201 Headlamp Low Beam Signal 48 WH/BK 1073 5-Volt Reference 49 GY 728 Security Indicator Control 50 L-GN/BK 1137 DRL Ambient Light Sensor Signal 5-Volt (T82) 51 - - Not Used 52 OG 192 Front Fog Lamp Switch Signal (T37/T96) 53 WH 1390 Off/Run/Crank Voltage 54 - - Not Used 55 YE/BK 1138 DRL Ambient Light Sensor Low Reference (T82) 56 - - Not Used

Body Control Module (BCM) C5 (UE1 or U2K) Connector Part Information 12193928 6-Way F Metri-Pack 280 Series Flexlock (GY) Pin Wire Color Circuit No. Function A OG 1340 Battery Positive Voltage B-C - - Not Used D PU 1807 Class 2 Serial Data (UE1) E-F - - Not Used

Data Link Connector (DLC) Connector Part Information 179631-1 16-Way F (WH) Pin Wire Color Circuit No. Function 1 D-GN 5060 Low Speed GMLAN Serial Data 2 PU 1807 Class 2 Serial Data 3 - - Not Used 4 BK 550 Ground 5 BK/WH 151 Ground 6 TN/WH 2500 High Speed GM LAN Serial Data Bus+ (2.2L) 7-13 - - Not Used 14 TN 2501 High Speed GM LAN Serial Data Bus- (2.2L) 15 - - Not Used 16 OG 40 Battery Positive Voltage

Begin the system diagnosis with Diagnostic System Check - Vehicle in Vehicle DTC Information. The Diagnostic System Check - Vehicle will provide the following information

1. The identification of the control modules which are not communicating.
2. The identification of any stored diagnostic trouble codes (DTCs) and their status.

The use of the Diagnostic System Check - Vehicle will identify the correct procedures to begin vehicle diagnosis. These must be performed before system DTC or symptom diagnosis.
