Automatic Transmission - AF17-4: Specifications Saturn Astra I

Automatic Trans 33 illustrations ~509 words

Transmission Fluid Temperature Sensor Specifications

TemperatureTemperatureMinimum ResistanceNominal ResistanceMaximum Resistance
10°C50°F580064457090
110°C230°F231247263

Transmission Fluid Temperature (TFT) Sensor Specifications

Fastener Tightening Specifications

Description of UsageRef No.*QtySizeSpecification
MetricEnglish
2-3 Shift Solenoid Valve Assembly Bolt3141M5x10 mm6.7 N.m59 lb in
Apply Tube Retainer Bolt501M6x12 mm5.4 N.m48 lb in
Control Valve Body Bolt2815M6x20 mm10 N.m89 lb in
Control Valve Body Bolt2821M6x76 mm10 N.m89 lb in
Control Valve Body Bolt2831M6x55 mm10 N.m89 lb in
Control Valve Body Bolt2841M6x12 mm10 N.m89 lb in
Control Valve Body Bolt3001M5x75 mm6.7 N.m59 lb in
Control Valve Body Cover Bolt2914M8x38-S mm24 N.m18 lb ft
Control Valve Body Cover Bolt2922M8x72 mm24 N.m18 lb ft
Control Valve Body Cover Bolt2932M8x90 mm24 N.m18 lb ft
Control Valve Body Cover Bolt2941M8x25 mm24 N.m18 lb ft
Control Valve Body Cover Bolt2953M8x60 mm24 N.m18 lb ft
Control Valve Body Cover Bolt2961M8x106.5 mm24 N.m18 lb ft
Control Valve Body Fluid Passage Bolt331M6x50 mm10 N.m89 lb in
Control Valve Body Fluid Passage Bolt341M6x20 mm10 N.m89 lb in
Front Control Valve Body Cover Bolt3514M5x40 mm6.7 N.m59 lb in
Front Control Valve Body Cover Bolt3522M5x75 mm6.7 N.m59 lb in
Front Control Valve Body Cover Bolt3532M5x12 mm6.7 N.m59 lb in
Front Differential Transfer Drive Gear Assembly Bearing Retainer Bolt8071M8x20 mm13 N.m115 lb in
Front Valve Body Bolt3552M5x54 mm6.7 N.m59 lb in
Front Valve Body Bolt3561M5x16 mm6.7 N.m59 lb in
Line Pressure Control Solenoid Valve Retainer Bolt3431M5x10 mm6.7 N.m59 lb in
Lockup Solenoid Clamp Bolt3041M5x16 mm6.7 N.m59 lb in
Lube Fluid Pipe Retainer Bolt8041M6x12 mm5.4 N.m48 lb in
Manual Shaft Detent Spring Bolt7122M6x14 mm10 N.m89 lb in
Manual Shift Shaft Detent Lever Bolt7151M6x14 mm10 N.m89 lb in
Manual Shift Shaft Detent Lever Bolt7181M6x23 mm10 N.m89 lb in
Manual Shift Shaft Retaining Nut6916.9 N.m61 lb in
Middle Control Valve Body Bolt3651M5x16 mm6.7 N.m59 lb in
Middle Control Valve Body Bolt3662M5x38 mm6.7 N.m59 lb in
No. 2 Rear Control Valve Body Bolt3623M5x16 mm6.7 N.m59 lb in
No. 2 Rear Control Valve Body Bolt3632M5x50 mm6.7 N.m59 lb in
Park/Neutral Position Switch Bolt712M8x26 mm25 N.m18 lb ft
Rear Valve Body Cover No. 1 Bolt4376M6x12 mm10 N.m89 lb in
Rear Valve Body Cover No. 1 Bolt4435M6x12 mm10 N.m89 lb in
Rear Valve Body to No. 2 Rear Valve Body Bolt3574M5x16 mm6.7 N.m59 lb in
Rear Valve Body to No. 2 Rear Valve Body Bolt3581M5x38 mm6.7 N.m59 lb in
Shift Solenoid Valve Assembly Bolt3151M5x10 mm6.7 N.m59 lb in
Torque Converter Housing Bolt8012M8x39 mm30 N.m22 lb ft
Torque Converter Housing Bolt80211M8x30 mm30 N.m22 lb ft
Torque Converter Housing Bolt8132M8x25-S mm30 N.m22 lb ft
Transmission Case Cover Bolt2010M8x25 mm25 N.m18 lb ft
Transmission Fluid Baffle Bolt452M6x12 mm5.4 N.m48 lb in
Transmission Fluid Baffle Bolt8103M6x12 mm5.4 N.m48 lb in
Transmission Fluid Drain Plug819139 N.m29 lb ft
Transmission Fluid Pump Cover Bolt1928M6x18 mm10 N.m89 lb in
Transmission Fluid Pump to Case Bolt56M8x20 mm25 N.m18 lb ft
Transmission Speed Sensor Bolt752M6x17 mm5.4 N.m48 lb in
Transmission Wiring Harness Bolt771M6x17 mm5.4 N.m48 lb in

Fastener Tightening Specifications

Transmission General Specifications

NameAF17-4
RPO CodesMNF
Vehicle Platform Engine/Transmission UsageA3360 Z18XER
Transmission DriveFWD
1st Gear Ratio2.807
2nd Gear Ratio1.479
3rd Gear Ratio1.000
4th Gear Ratio0.735
Differential4.048
Reverse Ratio2.769
Pressure TapsLine Pressure
Transmission Fluid TypeT - IV
Transmission Fluid Capacity - ApproximateComplete Overhaul: Dry 7.2L (7.6 qt)
Transmission Type: 4Four forward gears, neutral control and lock-up slip control
Case MaterialDie Cast Aluminum
Transmission Weight67.5 kg (149 lb)

Fluid Capacity Specifications

ApplicationSpecification
MetricEnglish
Complete Overhaul, GM P/N 88900925 (Canadian P/N 22689186)7.2 liters7.6 quarts
Remove drain plug and fill, GM P/N 88900925 (Canadian P/N 22689186)4.0 liters4.2 quarts

Fluid Capacity Specifications

Shim Size Specifications

IdentificationSpecifications
MetricEnglish
Available Shims0.95 mm0.037 in
1.00 mm0.039 in
1.05 mm0.041 in
1.10 mm0.043 in
1.15 mm0.045 in
1.20 mm0.047 in

Front Differential Side Gear Shim (630)

IdentificationSpecifications
MetricEnglish
Available Shims2.00 mm0.078 in
2.05 mm0.081 in
2.10 mm0.083 in
2.15 mm0.085 in
2.20 mm0.087 in
2.25 mm0.089 in
2.30 mm0.090 in
2.35 mm0.093 in
2.40 mm0.095 in
2.45 mm0.097 in
2.50 mm0.099 in
2.55 mm0.100 in
2.60 mm0.102 in
2.65 mm0.104 in
2.70 mm0.106 in
2.75 mm0.108 in
2.80 mm0.110 in
2.85 mm0.112 in
2.90 mm0.114 in

Front Differential Carrier Bearing Shim (645)

Transmission Clearance Specifications

ApplicationSpecification
MetricEnglish
Front Differential Assembly (13)
Unloaded Rotating Torque - New Bearings0.78-1.37 N.m7-12 lb in
Unloaded Rotating Torque - Reused Bearings0.39-0.69 N.m3-6 lb in
Fluid Pump Assembly (2)
Driven Gear (189) to Body Clearance - Maximum0.15 mm0.006 in
Drive Gear (190) Tip to Body Clearance - Maximum0.25 mm0.010 in
Driven Gear (189) Tip to Body Clearance - Maximum0.25 mm0.010 in
Fluid Pump Body Bushing, ID - Maximum38.138 mm1.500 in
Side Clearance of Drive and Driven Gear to Body0.02-0.05 mm0.0008-0.0020 in
Stator Shaft Bushing, ID - Maximum18.026 mm0.710 in
2nd and 4th Gear Band Servo (56)
Piston Stroke2.659-3.141 mm0.105-0.123 in

Transmission Clearance Specifications

ApplicationSpecification
MetricEnglish
Overdrive Clutch - C0 (15)
Piston Stroke1.043-1.357 mm0.041-0.053 in
Relaxed Clutch Pack Stack Up Clearance0.341-0.979 mm0.013-0.039 in
Available Overdirive Clutch Backing Plate (210) Thickness3.6 mm0.142 in
3.8 mm0.150 in
4.0 mm0.157 in
Forward Clutch - C1 (18)
Piston Stroke0.442-0.758 mm0.017-0.030 in
Relaxed Clutch Pack Stack Up Clearance0.442-0.758 mm0.017-0.030 in
Available Forward Clutch Backing Plate (576) Thickness3.4 mm0.134 in
3.6 mm0.142 in
3.8 mm0.150 in
1st and Reverse Clutch (B2)
Piston Stroke1.730-2.570 mm0.068-0.10 in
Relaxed Clutch Pack Stack Up Clearance0.599-1.901 mm0.024-0.075 in
Reverse Clutch - C2 (23)
Piston Stroke0.932-1.608 mm0.367-0.0633 in
Relaxed Clutch Pack Stack Up Clearance0.432-1.228 mm0.017-0.048 in
Coast Clutch - C3 (15)
Piston Stroke2.682-3.018 mm0.106-0.12 in
Relaxed Clutch Pack Stack Up Clearance2.211-2.769 mm0.087-0.109 in

Clutch Assembly Specifications

Scheme 1

Scheme 1: 2-4 Band Servo Piston Pin Selection
Pin Length - MarkPin Identification
MetricEnglish
122.35 mm4.817 in1 Groove
122.60 mm4.827 in2 Grooves
122.85 mm4.837 in3 Grooves
123.10 mm4.846 in4 Grooves
123.35 mm4.856 in5 Grooves

Servo Pin Selection

Scheme 2

Scheme 2: Race and Bearing Specifications
AlphaRef No.ComponentMetricEnglish
A585Forward Clutch Housing Thrust Bearing Assembly
Bearing - Outer Diameter31.50 mm1.24 in
Bearing - Inner Diameter16.05 mm0.63 in
B612Rear Ring Gear Rear Thrust Bearing Race
Bearing - Outer Diameter32.50 mm1.28 in
Bearing - Inner Diameter18.80 mm0.74 in
B613Rear Ring Gear Rear Thrust Bearing
Rear Race - Outer Diameter30.50 mm1.20 in
Rear Race - Inner Diameter19.00 mm0.75 in
C545Sun Gear Thrust Bearing Assembly
Bearing - Outer Diameter32.50 mm1.28 in
Bearing - Inner Diameter18.80 mm0.74 in
C603Sun Gear Thrust Bearing Race
Rear Race - Outer Diameter29.60 mm1.16 in
Rear Race - Inner Diameter19.21 mm0.76 in
D532Front Planetary Ring Gear Flange Thrust Washer
Bearing - Outer Diameter83.50 mm3.29 in
Bearing - Inner Diameter68.10 mm2.68 in
D541Carrier Thrust Washer
Rear Race - Outer Diameter85.00 mm3.35 in
Rear Race - Inner Diameter69.00 mm2.72 in
E523Overrun Clutch Inner Race Thrust Bearing with Race
Bearing - Outer Diameter83.50 mm3.29 in
Bearing - Inner Diameter64.51 mm2.54 in
E522Overrun Clutch Inner Race Thrust Bearing Race
Front Race - Outer Diameter80.40 mm3.16 in
Front Race - Inner Diameter68.01 mm2.68 in
F551Input Shaft Thrust Bearing
Bearing - Outer Diameter31.23 mm1.23 in
Bearing - Inner Diameter18.58 mm0.73 in
F552Input Shaft Thrust Bearing Race
Rear Race - Outer Diameter33.40 mm1.31 in
Rear Race - Inner Diameter21.50 mm0.85 in
G549Input Shaft Front Thrust Washer
Bearing - Outer Diameter33.10 mm1.30 in
Bearing - Inner Diameter18.58 mm0.73 in
H602Rear Planetary Ring Gear Thrust Bearing
Bearing - Outer Diameter71.00 mm2.80 in
Bearing - Inner Diameter57.00 mm2.24 in
H543Carrier Thrust Bearing
Front Race - Outer Diameter71.00 mm2.80 in
Front Race - Inner Diameter60.40 mm2.38 in
I270Front Differential Transfer Drive Gear Rear Thrust Bearing Assembly
Bearing - Outer Diameter65.92 mm2.60 in
Bearing - Inner Diameter50.80 mm2.00 in
I269Front Differential Transfer Drive Gear Rear Thrust Bearing Race
Front Race - Outer Diameter63.00 mm2.48 in
Front Race - Inner Diameter43.40 mm1.71 in
J262Front Differential Transfer Drive Gear Front Thrust Bearing Assembly
Bearing - Outer Diameter46.00 mm1.81 in
Bearing - Inner Diameter30.00 mm1.18 in
J263Front Differential Transfer Drive Gear Front Thrust Bearing Race
Rear Race - Outer Diameter42.00 mm1.65 in
Rear Race - Inner Diameter17.10 mm0.67 in

Race and Bearing Specifications

Scheme 3

Scheme 3: Automatic Transmission Controls Schematics

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6: Automatic Transmission Electronic Component Views
CalloutComponent Name
32Transmission Fluid Temperature Sensor
72Park/Neutral Position Switch
74Transmission Output Speed Sensor Assembly
76Transmission Input Speed Sensor Assembly
301Neutral Switching Solenoid Valve
310Lock Up Control Solenoid (SLU)
312Line Pressure Control Solenoid Valve Assembly (SLT)
3132-3, 3-4 Shift Solenoid Valve Assembly (S1)
3161-2/3-4 Shift Solenoid Valve Assembly (S2)

Scheme 7

Scheme 7: Disassembled Views
CalloutComponent Name
1Torque Converter Assembly
2Transmission Fluid Pump Assembly
10Torque Converter Housing
12Output Gear Assembly
13Front Differential Assembly
14Front Differential Transfer Drive Gear Assembly
15Overdrive and Coast Clutch Assembly
162nd and 4th Gear Band Assembly
17Transmission Case Assembly
18Forward Clutch Assembly
19Transmission Case Cover
20Transmission Case Cover Bolts M8x1.0x25 (Qty: 10)
21Transmission Case Cover Fluid Seal Rings (Qty: 5)
23Reverse Clutch Assembly with Input Shaft Assembly
25Rear Ring Gear Assembly
27Front Planetary Ring Gear Assembly
29Control Valve Body Cover
39Transmission Control Valve Body Assembly
542Carrier Assembly
544Sun Gear

Scheme 8

Scheme 8
CalloutComponent Name
17Transmission Case Assembly
29Control Valve Body Cover
34Control Valve Body Fluid Passage Bolt M6 x 1.0 x 20 (Qty: 1)
37Control Valve Body Fluid Passage Cover
38Control Valve Body Fluid Passage Cover Gasket
39Transmission Control Valve Body Assembly
42Transmission Fluid Filter Assembly
44Transmission Fluid Baffle
45Transmission Fluid Baffle Bolt M6 x 1.0 x 12 (Qty: 2)
50Apply Tube Retainer Bolt M6 x 1.0 x 12 (Qty: 1)
51Apply Tube Retainer
52Apply Tube
552nd and 4th Gear Band Servo Piston Spring
562nd and 4th Gear Band Servo Piston Pin - Selective
572nd and 4th Gear Band Servo Piston and Cover O-Ring Seal (Qty: 3)
582nd and 4th Gear Band Servo Piston
592nd and 4th Gear Band Servo Piston Pin Retainer
602nd and 4th Gear Band Servo Piston Inner Seal
612nd and 4th Gear Band Servo Piston Cover
622nd and 4th Gear Band Servo Cover Retaining Ring
632nd and 4th Gear Band Servo Cover
642-4 Gear Band Anchor Pin
68Transmission Case Locating Pin (Qty: 2)
84Transmission Case Fluid Passage Seal to Valve Body (Qty: 2)
85Transmission Fluid Passage Seal
86Transmission Case Fluid Passage Seal (Qty: 4)
87Transmission Case Fluid Passage Seal
89Transmission Fluid Passage Seal (Qty: 2)
90Front Differential Transfer Drive Gear Assembly Bearing
281Control Valve Body Bolt M6 x 1.0 x 20 (Qty: 5)
282Control Valve Body Bolt M6 x 1.0 x 76 (Qty: 1)
283Control Valve Body Bolt M6 x 1.0 x 55 (Qty: 1)
284Control Valve Body Bolt M6 x 1.0 x 12 ((Qty: 1)
291Control Valve Body Cover Bolt M8 x 1.0 x 38 (Qty: 4)
292Control Valve Body Cover Bolt M8 x 1.0 x 72 (Qty: 2)
293Control Valve Body Cover Bolt M8 x 1.0 x 90 (Qty: 2)
294Control Valve Body Cover Bolt M8 x 1.0 x 25 (Qty: 1)
295Control Valve Body Cover Bolt M8 x 1.0 x 60 (Qty: 3)
296Control Valve Body Cover Bolt M8 x 1.0 x 106.5 (Qty: 1)
713Manual Shift Shaft Seal Assembly

Scheme 9

Scheme 9
CalloutComponent Name
69Manual Shift Shaft Retaining Nut
70Manual Shift Shaft Retaining Nut Lock Washer
71Park/Neutral Position Switch Bolt M8 x 1.0 x 26 (Qty: 2)
72Park/Neutral Position Switch
74Transmission Output Speed Sensor Assembly
75Transmission Speed Sensor Bolt M6 x 1.0 x 17 (Qty: 2)
76Transmission Input Speed Sensor Assembly
77Transmission Wiring Harness Bolt M6 x 1.0 x 17 (Qty: 1)
78Automatic Transmission Wiring Harness Assembly

Scheme 10

Scheme 10
CalloutComponent Name
5Transmission Fluid Pump to Case Bolt M8 x 1.0 x 20 (Qty: 6)
185Transmission Fluid Pump Body O-Ring Seal
186Transmission Fluid Pump Body Seal Assembly
187Fluid Pump Body
188Fluid Pump Body to Fluid Pump Stator Shaft Assembly Alignment Pin (Qty: 2)
189Fluid Pump Body Driven Gear
190Fluid Pump Body Drive Gear
191Fluid Pump Cover and Stator Shaft Assembly
192Transmission Fluid Pump Cover Bolt M6 x 1.0 x 18 (Qty: 8)
193Fluid Pump Cover O-Ring Seals (Qty: 2)

Scheme 11

Scheme 11
CalloutComponent Name
209Overdrive Clutch Backing Plate Retaining Ring
210Overdrive Clutch Backing Plate
211Overdrive Clutch Plate Assembly - Fiber
212Overdrive Clutch Plate Assembly - Steel
213Coast Clutch Backing Plate
214Coast Clutch Backing Plate Retaining Ring
215Coast Clutch Plate Assembly - Fiber
216Coast Clutch Plate Assembly - Steel
217Overdrive and Coast Clutch Spring Retaining Ring
218Overdrive and Coast Clutch Spring
219Coast Clutch Piston Inner Seal
220Coast Clutch Piston Outer Seal
221Coast Clutch Piston
222Overdrive Clutch Piston Inner Seal
223Overdrive Clutch Piston Outer Seal
224Overdrive Clutch Piston
225Overdrive and Coast Clutch Housing
226Overdrive and Coast Clutch Housing Thrust Washer

Scheme 12

Scheme 12
CalloutComponent Name
236Output Gear
237Output Gear Bearing Assembly
238Output Gear Bearing Assembly Lock Nut
239Output Gear Retaining Ring

Scheme 13

Scheme 13
CalloutComponent Name
263Front Differential Transfer Drive Gear Front Thrust Bearing Race
264Front Differential Transfer Drive Gear Drive Pinion Bearing Inner Race
265Front Differential Transfer Drive Gear Drive Pinion
266Front Differential Transfer Drive Gear Counter Driven Gear
267Front Differential Transfer Drive Gear Bearing Inner Race
268Front Differential Transfer Drive Gear Lock Nut
269Front Differential Transfer Drive Gear Rear Thrust Bearing Race
270Front Differential Transfer Drive Gear Rear Thrust Bearing Assembly

Scheme 14

Scheme 14
CalloutComponent Name
300Control Valve Body Bolt
301Neutral Switching Solenoid Valve
302Front Control Valve Body Cover
303Front Control Valve Body Cover Gasket
304Lock Up Solenoid Clamp Bolt
305Lock Up Solenoid Clamp
306Front Control Valve Body
307Front Control Valve Body to Front Control Valve Body Spacer Plate Gasket
308Front Control Valve Body Spacer Plate
309Front Control Valve Body Spacer Plate to Middle Control Valve Body Gasket
310Lock Up Control Solenoid (SLU)
311Middle Control Valve Body Assembly
312Line Pressure Control Solenoid Valve Assembly (SLT)
3132-3 Shift Solenoid Valve Assembly (S1)
3142-3 Shift Solenoid Valve Assembly Bolt
315Shift Solenoid Valve Assembly Bolt
3161-2/3-4 Shift Solenoid Valve Assembly (S2)
317Check Valve B
318Check Valve Spring B
319Check Valve A
320Check Valve A Spring
321Fluid Strainer
322Check Ball
323Rear Control Valve Body Assembly
325No. 2 Rear Control Valve Body Assembly
326No. 2 Rear Control Valve Body Assembly Spacer Plate Gasket
327No. 2 Rear Control Valve Body Assembly Spacer Plate
328No. 2 Rear Control Valve Body Gasket
329Rear No. 1 Control Valve Body Spacer Plate Gasket
330Rear No. 1 Control Valve Body Spacer Plate
331Rear No. 1 Control Valve Body Gasket
336Manual Valve Link
337Manual Valve
340Pressure Relief Valve Spring
341Pressure Relief Valve
342Line Pressure Control Solenoid Valve Retainer
343Line Pressure Control Solenoid Valve Retainer Bolt
351Front Control Valve Body Cover Bolt (Qty: 4)
352Front Control Valve Body Cover Bolt (Qty: 2)
353Front Control Valve Body Cover Bolt (Qty: 2)
354Automatic Transmission Wiring Harness Assembly Retainer (Qty: 2)
355Front Valve Body Bolt (Qty: 2)
356Front Valve Body Bolt (Qty: 1)
357Rear Valve Body to No. 2 Rear Valve Body Bolts (Qty: 4)
358Rear Valve Body to No. 2 Rear Valve Body Bolt (Qty: 1)
359No. 2 Rear Valve Body Fluid Baffle (Qty: 1)
360No. 2 Rear Valve Body Wiring Harness Assembly Retainer (Qty: 1)
362No. 2 Rear Control Valve Body Bolts (Qty: 3)
363No. 2 Rear Control Valve Body Bolts (Qty: 2)
365Middle Control Valve Body Bolt (Qty: 1)
366Middle Control Valve Body Bolts (Qty: 2)
368Middle Control Valve Body Fluid Cooler By-pass Valve
369Middle Control Valve Body Fluid Cooler By-pass Valve Spring

Scheme 15

Scheme 15
CalloutComponent Name
306Front Control Valve Body
370Solenoid B-1 Modulator No. 2
371Solenoid B-1 Modulator Valve No. 2 Spring
372Sleeve/Bore Plug Retainer
373Solenoid Modulator Valve Bore Plug
374Neutral Relay Valve
375Neutral Relay Valve Spring

Scheme 16

Scheme 16
CalloutComponent Name
311Middle Control Valve Body Assembly
376Primary Regulator Valve Sleeve
377Primary Regulator Valve Plunger
378Primary Regulator Valve Spring
379Primary Regulator Valve
380Lock Up Control Solenoid (SLU) Valve
381Lock Up Control Solenoid (SLU) Spring
382Sleeve/Bore Plug Retainer
383Solenoid Modulator Valve Bore Plug
384Solenoid Modulator Valve Bore Plug
3853-4 Shift Valve Sleeve
3863-4 Shift Valve Spring
3873-4 Shift Valve
3882-3 Shift Valve Spring
3892-3 Shift Valve
3901-2 Shift Valve
3911-2 Shift Valve Spring
392Solenoid B-1 Modulator Valve No. 1 Plunger
393Solenoid B-1 Modulator Valve No. 1 Spring
394Solenoid B-1 Modulator Valve No. 1
395Solenoid B-1 Modulator Valve No. 1 Sleeve
396Accumulator Regulator Valve Sleeve
397Accumulator Regulator Valve Plunger
398Accumulator Regulator Valve Spring
399Accumulator Regulator Valve

Scheme 17

Scheme 17
CalloutComponent Name
323Rear Control Valve Body Assembly
325No. 2 Rear Control Valve Body Assembly
362No. 2 Rear Control Valve Body Bolts (Qty: 3)
363No. 2 Rear Control Valve Body Bolts (Qty: 2)
401Sleeve/Bore Plug Retainer
402Lock Up Relay Control Valve Sleeve
403Lock Up Relay Control Valve Plunger
404Lock Up Relay Control Valve Spring
405Lock Up Relay Control Valve
408Lock Up Control Valve Spring
409Lock Up Control Valve
410Lock Up Control Valve Plunger
411Solenoid Modulator Valve Bore Plug
414Solenoid Modulator Valve Bore Plug
415Secondary Regulator Valve
416Secondary Regulator Valve Spring
417B-1 Modulator Control Valve
418B-1 Modulator Control Valve Spring
419Low Modulator Valve
420Low Modulator Valve Spring
421Solenoid Modulator Valve
422Solenoid Modulator Valve Spring
425C-2 Accumulator Inner Spring
426C-2 Accumulator Outer Spring
427C-2 Accumulator Piston
428C-2 Accumulator O-Ring Seal
429B-1 Accumulator Snap Ring
430B-1 Accumulator Piston
431B-1 Accumulator Split Seal Ring
432Rear Valve Body Cover No. 1 Gasket
433Rear Valve Body Cover No. 1 Plate
434Rear Valve Body Cover No. 1 Gasket
435Rear Valve Body Cover No. 1 Check Ball
436Rear Valve Body Cover No. 1
437Rear Valve Body Cover No. 1 Bolt
438B-1 Accumulator Counter Spring
440Rear Valve Body Cover No. 2 Gasket
441Rear Valve Body Cover No. 2 Plate
442Rear Valve Body Cover No. 2 Gasket
443Rear Valve Body Cover No. 2 Bolt
444Rear Valve Body Cover No. 2
445C-1 Control Valve
446C-1 Control Valve Sleeve
447C-0 Accumulator Spring
448C-0 Accumulator Piston
449C-0 Accumulator O-Ring Seal
4522-3 Timing Valve
4532-3 Timing Valve Spring
454C-1 Damper Piston
455C-1 Damper Piston Split Seal Ring
456C-1 Damper Spring
457C-3 Modulator Valve
458C-3 Modulator Valve Spring Seat
459C-3 Modulator Valve Spring

Scheme 18

Scheme 18
CalloutComponent Name
17Transmission Case Assembly
5101st and Reverse Clutch Piston Inner Seal
5111st and Reverse Clutch Piston
5121st and Reverse Clutch Piston Outer Seal
5131st and Reverse Clutch Spring Assembly
5141st and Reverse Clutch Spring Retaining Ring
5161st and Reverse Clutch Plate Assembly - Fiber
5171st and Reverse Clutch Plate - Steel
5181st and Reverse Clutch Backing Plate Retaining Ring
5191st and Reverse Clutch Backing Plate

Scheme 19

Scheme 19
CalloutComponent Name
520Overrun Clutch Inner Race
521Overrun Clutch Inner Race Thrust Washer
522Overrun Clutch Inner Race Thrust Bearing Race
523Overrun Clutch Inner Race Thrust Bearing with Race
524Overrun Clutch Retaining Ring
525Overrun Clutch End Bearing
526Overrun One-Way Clutch
527Overrun Clutch Thrust Washer
528Front Planetary Ring Gear
529Front Planetary Ring Gear O-Ring Seal
530Front Planetary Ring Gear Flange
531Front Planetary Ring Gear Flange Retaining Ring
532Front Planetary Ring Gear Flange Thrust Washer

Scheme 20

Scheme 20
CalloutComponent Name
548Sun Gear Input Flange Thrust Washer
549Input Shaft Front Thrust Washer
550Input Shaft
551Input Shaft Thrust Bearing
552Input Shaft Thrust Bearing Race
553Sun Gear Input Flange Retaining Ring
554Sun Gear Input Flange
555Input Shaft Seal Ring - Slotted
556Reverse Gear Clutch Plate Assembly - Fiber
557Reverse Gear Clutch Plate Assembly - Steel
558Reverse Gear Clutch Plate Retaining Ring
559Reverse Gear Clutch Spring Retaining Ring
560Reverse Gear Clutch Spring
564Reverse Gear Clutch Piston Inner Seal
565Reverse Gear Clutch Piston
566Reverse Gear Clutch Piston Outer Seal
567Reverse Gear Clutch Drum

Scheme 21

Scheme 21
CalloutComponent Name
574Forward Clutch Housing Seal - Slotted
575Forward Clutch Backing Plate Retaining Ring
576Forward Clutch Backing Plate
577Forward Clutch Plate Assembly - Fiber
578Forward Clutch Plate Assembly - Steel
579Forward Clutch Piston Return Spring Retaining Ring
580Forward Clutch Piston Return Spring Assembly
581Forward Clutch Piston Outer Seal
582Forward Clutch Piston Inner Seal
583Forward Clutch Piston
584Forward Clutch Housing
585Forward Clutch Housing Thrust Bearing Assembly

Scheme 22

Scheme 22
CalloutComponent Name
541Carrier Thrust Washer
542Carrier Assembly
543Carrier Thrust Bearing
544Sun Gear
545Sun Gear Thrust Bearing Assembly
600Overdrive Clutch Hub
601Overdrive Clutch Hub Retaining Ring
602Rear Planetary Ring Gear Thrust Bearing
603Sun Gear Thrust Bearing Race
604Rear Planetary Ring Gear Flange Retaining Ring
605Rear Planetary Ring Gear Flange
606Rear Planetary Ring Gear
607Coast Clutch Outer Race
608Coast Clutch End Bearing
609Coast One Way Clutch
610Coast Clutch Retainer Plate
611Coast Clutch Retainer Plate Retaining Ring
612Rear Ring Gear Rear Thrust Bearing Race
613Rear Ring Gear Rear Thrust Bearing
614Rear Planetary Ring Gear Flange Thrust Washer

Scheme 23

Scheme 23
CalloutComponent Name
10Torque Converter Housing
17Transmission Case Assembly
80Front Wheel Drive Shift Oil Seal
630Front Differential Side Gear Thrust Washer
631Front Differential Side Gear
632Front Differential Pinion Shaft Thrust Washer
633Front Differential Pinion Gear
634Front Differential Ring Gear Mounting Bolt Lock
635Front Differential Ring Gear
636Front Differential Ring Gear Mounting Bolt
637Front Differential Tapered Outer Roller Bearing
638Front Differential Speed Sensor Reluctor Wheel
639Front Differential Pinion Shaft Retaining Pin
640Front Differential Carrier Assembly
641Front Differential Tapered Outer Roller Bearing
642Front Differential Pinion Shaft
645Front Differential Carrier Bearing Shim - Selective
646Front Differential Carrier Bearing Race
647Front Differential Carrier Bearing Race
800Front Differential Carrier Seal Assembly

Scheme 24

Scheme 24
CalloutComponent Name
17Transmission Case Assembly
700Park Pawl Shaft
701Park Pawl Spring - Return
702Park Pawl
703Park Pawl Locking Pin
704Park Pawl Pin Spring
705Park Pawl Pin Spring Guide Sleeve
708Park Pawl Lock Guide
709Park Pawl Actuator Rod
710Manual Shift Shaft Detent Assembly
711Manual Shift Shaft Detent Lever Spring
712Manual Shaft Detent Spring Bolt M6 x 1.0 x 14 (Qty: 2)
713Manual Shift Shaft Seal Assembly
714Manual Shift Shaft Spacer
715Manual Shift Shaft Detent Lever Bolt M6 x 1.0 x 14 (Qty: 1)
716Manual Shift Shaft
717Park Pawl Stop Pin
718Manual Shift Shaft Detent Lever Bolt M6 x 1.0 x 28 (Qty: 1)
719Manual Shift Shaft Locking Pin

Scheme 25

Scheme 25
CalloutComponent Name
10Torque Converter Housing
40Fluid Passage Plug
41Fluid Passage Plug Seal
262Front Differential Transfer Drive Gear Front Thrust Bearing Assembly
800Front Differential Carrier Seal Assembly
801Torque Converter Housing Bolt M8 1.0 x 39 (Qty: 2)
802Torque Converter Housing Bolt M8 x 1.0 x 30 (Qty: 10)
803Lube Fluid Pipe Retainer
804Lube Fluid Pipe Retainer Bolt M6 x 1.0 x 12 (Qty: 1)
805Lube Fluid Pipe
806Front Differential Transfer Drive Gear Assembly Bearing Retainer
807Front Differential Transfer Drive Gear Assembly Bearing Retainer Bolt M8 x 1.0 x 20 (Qty: 1)
808Front Differential Transfer Drive Gear Assembly Bearing
810Transmission Fluid Baffle Bolt M6 x 1.0 x 12 (Qty: 3)
811Transmission Fluid Baffle
812Chip Collector Magnet
813Torque Converter Housing Bolt M8 x 1.0 x 25 (Qty: 2)
815Automatic Transmission Fluid Pressure Test Hole Plug O-Ring Seal
816Automatic Transmission Fluid Pressure Test Hole Plug
819Transmission Fluid Drain Plug
820Transmission Fluid Drain Plug Washer

Scheme 26

Scheme 26: Component Location
CalloutComponent Name
21Transmission Case Cover Fluid Seal Ring (Qty: 5)
80Front Wheel Drive Shaft Oil Seal
84Transmission Case Fluid Passage Seal
185Transmission Fluid Pump Body O-Ring Seal
186Transmission Fluid Pump Body Seal Assembly
193Fluid Pump Cover O-Ring Seals (Qty: 2)
219Coast Clutch Piston Inner Seal
220Coast Clutch Piston Outer Seal
222Overdrive Clutch Piston Inner Seal
223Overdrive Clutch Piston Outer Seal
5101st and Reverse Clutch Piston Inner Seal
5121st and Reverse Clutch Piston Outer Seal
529Front Planetary Ring Gear O-Ring Seal
564Reverse Gear Clutch Piston Inner Seal
566Reverse Gear Clutch Piston Outer Seal
574Forward Clutch Housing Seal - Slotted
581Forward Clutch Piston Outer Seal
582Forward Clutch Piston Inner Seal
713Manual Shift Shaft Seal Assembly
800Front Differential Carrier Seal Assembly

Scheme 27

Scheme 27
CalloutComponent Name
90Front Differential Transfer Drive Gear Assembly Bearing
226Overdrive and Coast Clutch Housing Thrust Washer
237Output Gear Bearing Assembly
262Front Differential Transfer Drive Gear Front Thrust Bearing Assembly
264Front Differential Transfer Drive Gear Drive Pinion Bearing Inner Race
267Front Differential Transfer Drive Gear Bearing Inner Race
521Overrun Clutch Inner Race Thrust Washer
522Overrun Clutch Inner Race Thrust Bearing Race
523Overrun Clutch Inner Race Thrust Bearing with Race
525Overrun Clutch End Bearing
527Overrun Clutch Thrust Washer
532Front Planetary Ring Gear Flange Thrust Washer
548Sun Gear Input Flange Thrust Washer
608Coast Clutch End Bearing
614Rear Planetary Ring Gear Flange Thrust Washer
630Front Differential Side Gear Thrust Washer
632Front Differential Pinion Shaft Thrust Washer
637Front Differential Tapered Outer Roller Bearing
641Front Differential Tapered Outer Roller Bearing
645Front Differential Carrier Bearing Shim - Selective
646Front Differential Carrier Bearing Race
647Front Differential Carrier Bearing Race
808Front Differential Transfer Drive Gear Assembly Bearing

Scheme 28

Scheme 28
CalloutComponent Name
321Fluid Strainer

Scheme 29

Scheme 29
CalloutComponent Name
322Check Ball
340Pressure Relief Valve Spring
341Pressure Relief Valve

Scheme 30

Scheme 30
CalloutComponent Name
338Pressure Relief Valve
339Pressure Relief Valve Spring

Scheme 31

Scheme 31
CalloutComponent Name
317Check Valve B
318Check Valve Spring B
319Check Valve A
320Check Valve A Spring
321Fluid Strainer

Scheme 32

Scheme 32
CalloutComponent Name
435Rear Valve Body Cover No. 1 Check Ball

Torque Converter Diagnosis

The torque converter clutch (TCC) is applied by fluid pressure, which is controlled by the pressure control solenoid valve. The pressure control solenoid valve is located inside of the automatic transmission assembly. The pressure control solenoid valve is controlled through a combination of computer controlled switches and sensors.

Torque Converter Stator

The torque converter stator roller clutch can have 2 different malfunctions.

  1. The stator assembly freewheels in both directions.
  2. The stator assembly remains locked up at all times.

Torque Converter Clutch Shudder

The key to diagnosing torque converter clutch (TCC) shudder is to note when it happens and under what conditions.

TCC shudder which is caused by the transmission should only occur during the apply or the release of the converter clutch. Shudder should never occur after the TCC plate is fully applied.

Engagement Time From Park or Neutral to Drive is Not Within Specifications

ConditionAction
DEFINITION: Engagement time from park or neutral to drive is not within specifications
Fluid level low and/or contaminated with water or engine coolantPerform Transmission Fluid Check . If contaminated with engine coolant replace transmission.
Fluid is burntInspect transmission oil cooler system for restricted or kinked lines. Flush system. Refer to Transmission Fluid Cooler Flushing and Flow Test .
Unit filled with wrong type of fluidDrain and fill with proper type of fluid.
Input Speed Sensor (76)Perform electrical function check on the input speed sensor (76). Replace input speed sensor (76) if failed.
Valve body (39)Replace valve body (39).
Internal transmission part failureDisassemble the transmission and inspect the following: Clutch assemblies, O-rings cut or damaged, clutch disc failure Fluid pump wore or scored components Replace transmission if any parts are faulty.

Engagement Time From Park or Neutral to Reverse is Not Within Specifications

ConditionAction
DEFINITION: Engagement time from park or neutral to reverse is not within specifications
Fluid level low and/or contaminated with water or engine coolantPerform Transmission Fluid Check . If contaminated with engine coolant replace transmission.
Fluid is burntInspect transmission oil cooler system for restricted or kinked lines. Flush system. Refer to Transmission Fluid Cooler Flushing and Flow Test .
Unit filled with wrong type of fluidDrain and fill with proper type of fluid.
Input Speed Sensor (76)Perform electrical function check on the input speed sensor (76). Replace input speed sensor (76) if failed.
Valve body (39)Replace valve body (39).
Internal transmission part failureDisassemble the transmission and inspect the following: Clutch assemblies, O-rings cut or damaged, clutch disc failure Fluid pump wore or scored components Replace transmission if any parts are faulty.

Torque Converter Clutch Stuck On or Off

ConditionAction
DEFINITION: Torque converter clutch stuck on or no lock-up
Park/neutral position switch (72)Replace park/neutral position switch (72).
Vehicle brake switchInspect for operation of vehicle brake switch. Replace brake switch if faulty.
Transmission control moduleInspect for proper function of TCM and replace if faulty.
Transmission oil temperature switch (32)Perform function check on the transmission oil temperature switch (32). Replace the automatic transmission wiring harness assembly (78).
Lock-up control solenoid (SLU) (310)Perform electrical function check on the lock-up control solenoid (SLU) (310). Replace the valve body if the lock-up control solenoid (SLU) (310) is faulty.
Torque converter (1)Replace the torque converter (1).
Valve body (39)Replace valve body (39).

Torque Converter Housing Removal

  1. Remove the 15 torque converter housing bolts (801, 802, 813).
  2. Remove the torque converter housing (10) with a plastic hammer.
  3. Remove the 2 fluid passage seals (89) and 1 fluid passage seal (85).

Scheme 33

Scheme 33: Front Differential Assembly Removal

Remove the front differential assembly (13).

Torque Converter Housing Disassemble

Special Tools

  1. J 26941 Bushing and Bearing Remover - 3-4 in. See «Special Tools»(ref-302327-S19281598062008102100000) .
  2. SA9133T Axle Seal Puller. See «Special Tools»(ref-302327-S19281598062008102100000) .
  3. SA9133T-1 Axle Seal Puller Adapter. See «Special Tools»(ref-302327-S19281598062008102100000) .

Torque Converter Housing Assemble

Special Tools

  1. DT 46414 Driver. See «Special Tools»(ref-302327-S19281598062008102100000) .
  2. EN 46342 Driver Handle. See «Special Tools»(ref-302327-S19281598062008102100000) .

Torque Converter Housing Installation

  1. Install the NEW 2 transmission fluid passage seals (89) and 1 transmission fluid passage seal (85).
  2. Remove any gasket material and be careful that no oil is on the contacting surfaces of the torque converter housing (10).
  3. Apply a 3 mm (1/8 in) bead of sealant GM P/N 89020326 (Canadian P/N 89021188) to the torque converter housing as shown.
  4. Install the torque converter housing (10).
  5. Install thread locker GM P/N 12345382 (Canadian P/N 10953489) on the torque converter bolts (801, 802, 813).
  6. Install the 15 torque converter bolts (801, 802, 813). Tighten: Tighten bolts to 30 N.m (22 lb ft).

Torque Converter Assembly Installation

Install the torque converter assembly (1).
