Maintenance Information: Overview Saab 9000 I рестайлинг

Procedures 2 illustrations ~804 words

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Automatic Climate Control (ACC)
  2. 2 - 10 Amp Cruise Control System, Door Mirrors
  3. 3 - 10 Amp Seat Belt Reminder Light, Reading Lights, Seat Belt Buckle Lock Light, Instrument
  4. 4 - 10 Amp A/C
  5. 5 - 10 Amp APC System
  6. 6 - 30 Amp Heating & Ventilation Fan
  7. 7 - 10 Amp Shift-Up Light
  8. 8 - 15 Amp Windshield Wipers
  9. 9 - 25 Amp Rear Power Windows, Sun Roof, Back-Up Lights
  10. 10 - 15 Amp Heated Seats
  11. 11 - 30 Amp Front Power Windows
  12. 12 - 15 Amp Turn Signal Indicators
  13. 13 - 10 Amp Instruments, Fuel Injection, Main Instrument Display Panel
  14. 14 - 20 Amp Fuel Pump
  15. 15 - 10 Amp Foglights (If Equipped)
  16. 16 - 10 Amp Central Locking, Interior Lights
  17. 17 - 10 Amp (1986) ACC, Clock 10 Amp (1987) ACC, Clock, Electronic Display
  18. 18 - 30 Amp Heated Rear Window
  19. 19 - 15 Amp Radio, Power Antenna
  20. 20 - 30 Amp A/C Fan, A/C Compressor
  21. 21 - 25 Amp Horn
  22. 22 - 15 Amp Hazard Warning Light
  23. 23 - 25 Amp (1986) Cooling Fan 30 Amp (1987) Cooling Fan
  24. 24 - 15 Amp Stoplights
  25. 25 - 15 Amp Right Low Beam Headlight
  26. 26 - 15 Amp Left Low Beam Headlight
  27. 27 - 15 Amp Right High Beam Headlight
  28. 28 - 15 Amp Left High Beam Headlight
  29. 29 - 10 Amp Right Parking Lights
  30. 30 - 10 Amp Left Parking Lights
  31. 31 - 10 Amp Cornering Lights
  32. 32 - Spare

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Power Distribution Panel Fuse Identification

  1. 1 - 10 Amp 5 Amp (1993-96) Automatic Climate Control (ACC)
  2. 2 - 10 Amp (1988)(1994-96) Cruise Control System, Door Mirrors 10 Amp (1989-93) Cruise Control (Manual Transmission), Door Mirrors
  3. 3 - 10 Amp Seat Belt Reminder Light, Reading Lights, Seat Belt Buckle Lock Light, Instrument, Cornering Lights (1993-96)
  4. 4 - 10 Amp (1988) A/C Blank (1989-91) 5 Amp (1992-96) Air Bag
  5. 5 - 10 Amp APC System
  6. 6 - 30 Amp Heating & Ventilation Fan
  7. 7 - 10 Amp Shift-Up Light, Headlight Wipers (1991-96), Horn (1993-96)
  8. 8 - 15 Amp Windshield Wipers Blank (1991) 20 Amp (1992-96) Windshield Wipers
  9. 9 - 25 Amp (1988)(1994-96) Rear Power Windows, Sun Roof, Back-Up Lights 25 Amp (1989-93) Rear Power Windows, Back-Up Lights, Cigarette Lighter, Sun Roof, Cruise Control (Automatic Transmission)
  10. 10 - 15 Amp (1988) Heated Seats 20 Amp (1989-91) Heated Seats 25 Amp (1992-96) Heated Seats, Rear A/C
  11. 11 - 30 Amp (1988)(1994-96) Front Power Windows 25 Amp (1989-93) Front Power Windows
  12. 12 - 15 Amp Turn Signal Indicators
  13. 13 - 10 Amp Instruments, Fuel Injection, Main Instrument Display Panel
  14. 14 - 20 Amp Fuel Pump
  15. 15 - Blank (1988-92) 5 Amp (1993-96) Electronic Throttle (if equipped)
  16. 16 - 15 Amp Central Locking, Interior Lighting, Trunk Light
  17. 17 - 10 Amp ACC, Clock, Electronic Display
  18. 18 - 30 Amp Heated Door Mirrors (If Equipped), Heated Rear Window
  19. 19 - 15 Amp (1988) Radio, Power Window 15 Amp (1989-96) Radio, Power Window, Alarm, Clock
  20. 20 - 30 Amp A/C Fan, A/C Compressor
  21. 21 - Blank (1988) 25 Amp (1989-96) Horn, Electronic Throttle (if equipped)
  22. 22 - 15 Amp Hazard Warning Light
  23. 23 - 30 (1988) Cooling Fan Blank (1989-90) 5 Amp (1991-96) Engine Electronics, Test Socket
  24. 24 - 15 Amp Stoplights
  25. 25 - Blank (1988) 30 Amp (1989-96) Electric Seat Adjustment (Driver)
  26. 26 - Blank (1988) 30 Amp (1989-96) Electric Seat Adjustment (Passenger)
  27. 27 - Blank (1988) 15 Amp (1989-92) 10 Amp (1993-96) Control Light, Radio
  28. 28 - Blank (1988) 10 Amp (1989-96) Heated Oxygen Sensor
  29. 29 - 10 Amp (1988) Right Parking Lights 10 Amp (1989-92) 15 Amp (1993-96) Right Parking & Engine Compartment Lights
  30. 30 - 10 Amp Left Parking Lights, Glove Compartment Light
  31. 31 - 10 Amp Cornering Lights, Daytime Running Lights (1993-96)
  32. 32 - Blank (1988-93) 15 Amp (1994-96) Rear Fog Light (if equipped)

Engine Compartment Fuse Identification

  1. 33 - 15 Amp Left Low Beam Headlight
  2. 34 - 15 Amp Right Low Beam Headlight
  3. 35 - 15 Amp Left High Beam Headlight
  4. 36 - 15 Amp Right High Beam Headlight
  5. 37 - 15 Amp Foglights (If Equipped)
  6. 38 - Blank (1988-89) 5 Amp (1990-96) Cooling Fan (Timer)
  7. 39 - 25 Amp (1988) Horn 20 Amp (1989-91) 30 Amp (1993-96) Cooling Fan
  8. 40 - Blank (1988-89) 30 Amp (1990-96) 2-Stage Cooling Fan (Automatic Transmission)
  9. 41 - 15 Amp (1991-96) Ignition Coil Blank (1988-90)
  10. 42 - Relay Lighting
  11. 43 - Relay Lighting
  12. 44 - Relay Bulb Check
  13. 45 - Relay Foglights (If Equipped)
  14. 46 - Blank (1988) Relay (1989-96) Cooling Fan
  15. 47 - Relay (1988) Horn Relay (1989-96) Cooling Fan

ABS Fuse Identification

  1. 48 - Relay ABS Main Relay
  2. 49 - 10 Amp ABS
  3. 50 - 30 Amp ABS
  4. 51 - 30 Amp ABS Pump
  5. 52 - Relay ABS Pump
