UNDERHOOD MAXI-FUSE PANEL IDENTIFICATION (1995-96)
- 1 - 60 Amp - Power Supply for Fuses: 1,4,13,23,25,33 & 34
- 2 - 60 Amp - Power Supply for Fuses: 2,5,10,12,16,27,28, & 35
- 3 - 60 Amp - Power Supply for Ignition Switch Directly
- 4 - 60 Amp - Power Supply for Ignition Switch Relay
- 5 - 60 Amp - Power Supply for Cabriolet Hood Control System
Scheme 1
Relay Identification
- A - Not Used
- B - Reversing Lights
- C - Shift Lock
- D - Rear Window Wiper, Intermittent Operation
- E - Ignition Switch
- F - Overheated 3-Way Catalytic Converter EXH
- G - Windscreen Wipers, Intermittent Operation
- I - Fuel Pump
- J - Not Used
- K - Starter Relay
- L - Sequential Multiport Fuel Injection System
