Maintenance Information: Component Locations Saab 900 II

Procedures 4 illustrations ~757 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

FUSE PANEL LOCATION

The electrical system is protected against shorts by fuses that are designed to fail to prevent damage to the wire harness. The main fuse/relay box is located in the engine compartment. If a fuse is blown, locate the cause before replacing the fuse. Spare fuses are contained in the fuse block. A separate relay box can be found under the back seat for convertible models. On vehicles with 8 valve engine, a additional relay box is located in front of the left front wheelhouse.

Scheme 2

Scheme 2: MAIN FUSE PANEL IDENTIFICATION (1983)
Scheme 2: MAIN FUSE PANEL IDENTIFICATION (1983)

Fuse & Circuit Breaker Identification

  1. 1 - 8 Amp - Right High Beam Headlight
  2. 2 - 8 Amp - Left High Beam Headlight
  3. 3 - 8 Amp - Right Low Beam Headlight
  4. 4 - 8 Amp - Left Low Beam Headlight
  5. 5 - 25 Amp - Radiator Fan
  6. 6 - 16 Amp - Electric Rear Window Defogger
  7. 7 - 5 Amp - Interior Lights
  8. 8 - 16 Amp - Fuel Pump
  9. 9 - 8 Amp - Hazard Warning Flasher
  10. 10 - 8 Amp - Brakelights
  11. 11 - 8 Amp - A/C Fan
  12. 12 - 5 Amp - Right Side Parking & Taillights
  13. 13 - 5 Amp - Left Side Parking & Taillights
  14. 14 - 16 Amp - Horn, Power Windows (If Equipped)
  15. 15 - 8 Amp - Electric Side View Mirrors
  16. 16 - 16 Amp - Electric Seat Heating
  17. 17 - 25 Amp - Heating & Ventilation Fan
  18. 18 - 16 Amp - Air Conditioning
  19. 19 - 8 Amp - Warning Lights
  20. 20 - 8 Amp - Direction Indicators
  21. 21 - 8 Amp - Windshield Wipers
  22. 22 - 16 Amp - Cornering Lights

Scheme 3

Scheme 3: MAIN FUSE PANEL IDENTIFICATION (1984-93)
Scheme 3: MAIN FUSE PANEL IDENTIFICATION (1984-93)

Fuse & Circuit Breaker Identification

  1. 1 - Blank (1984-88) 10 Amp (1989-93) - Lambda Sensor
  2. 2 - Blank (1984-88) 30 Amp (1989-90) - Rear Windows (Convertible Models) Blank (1991-93)
  3. 3 - Blank (1984-87) 15 Amp (1989-93) - Ignition System
  4. 4 - Blank (1984) 10 Amp (1984-90) - Shift Indicator Light Blank (1991-93)
  5. 5 - 15 Amp - Windshield Wipers/Washers, Brake Fluid Warning Light (1989-90), Seat Belt Warning Lights (1989-93)
  6. 6 - 30 Amp - A/C System
  7. 7 - 15 Amp - Turn Signal Indicators, Tachometer (1987-93), Alternator (1989-93), Oil Pressure Warning Lights (1989-93), Shift-Up Light (1992-93), CHECK Engine/SRS Lights (1993)
  8. 8 - 10 Amp - Electrically Adjusted Rear-View Mirrors, Cruise Control, Headlight Wipers (1993)
  9. 9 - 30 Amp - Ventilation Fan
  10. 10 - 10 Amp - APC Boost Pressure System
  11. 11 - 30 Amp - Power Windows, Sun Roof Blank (1991-93)
  12. 12 - 15 Amp (1984-86) - Seat Heaters 20 Amp (1987-90) - Seat Heaters, Pump Relay Supply Voltage (Convertible Models) Blank (1991-93)
  13. 13 - 20 Amp 10 Amp (1993) - Back-Up Lights, Cigarette Lighter, Seat Belt & Alternator Warning Lights (1984-88)
  14. 14 - 15 Amp - Right High Beam Headlight
  15. 15 - 15 Amp - Left High Beam Headlight, High Beam Indicator
  16. 16 - 15 Amp - Right Low Beam Headlight
  17. 17 - 15 Amp - Left Low Beam Headlight
  18. 18 - 10 Amp - Right Side Parking & Taillights, License Plate, Glove Compartment (1984-88), Ashtray & Instrument Panel Lights (1984-88)
  19. 19 - 10 Amp - Left Side Parking & Taillights
  20. 20 - 15 Amp (1984-90) - Radio/Cassette Player, Cornering Light (1987-90) Blank (1991-93)
  21. 21 - 15 Amp - Foglights
  22. 22 - 15 Amp (1984-90) - Relay Trigger (Include Fuel Pump, Rear Demist, Cooling Fan Time Relays) 10 Amp (1991-93) - Fuel System & Gauge, Temp Gauge, Brake Warning Lights, ABS, Fuel Reserve Warning Light (1992-93)
  23. 23 - Blank (1984-88) 10 Amp (1989-93) - Instrument Panel Lighting, Glove Box & Ashtray Lights (1992-93)
  24. 24 - 10 Amp - Central Locking Blank (1991-93)
  25. 25 - 30 Amp - Radiator Cooling Fan
  26. 26 - 25 Amp - Horn
  27. 27 - 15 Amp - Hazard Warning Lights
  28. 28 - 15 Amp - Interior Lights (1984-90), Clock, Electric Antenna (1984-90), Radio Memory &/Or Amplifier(s) (1984-90)
  29. 29 - 20 Amp (1984-88) - Heated Rear Windows 25 Amp (1989-90) - Heated Rear Windows Blank (1991-93)
  30. 30 - 20 Amp - Fuel Pumps
  31. 31 - 15 Amp (1984-86) - Brakelights 15/5 Amp (1987-93) - Brakelights/Oxygen Sensor Wire

Scheme 4

Scheme 4: ABS FUSE PANEL IDENTIFICATION (1984-93)
Scheme 4: ABS FUSE PANEL IDENTIFICATION (1984-93)

Scheme 5

Scheme 5
Scheme 5

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp - Anti-Lock Brake System (ABS - If Equipped)
  2. 2 - 30 Amp - ABS (If Equipped)
  3. 3 - 30 Amp - ABS Pump (If Equipped)
