VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 2
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Normal Service
- Driven More Than 10 Miles Daily
- No Operating Conditions From Severe Service Schedule
Severe Service (Unique Driving Conditions)
- Short Trips In Freezing Temperatures
- Towing Or Commercial Use
- Frequent Mountain Driving
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
SERVICE LABOR TIMES
Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
TIRE SPECIFICATIONS
Tire specifications are imprinted on the tire sidewall. When using snow tires, they must be mounted on all four wheels for safety and maneuverability. Ordinary snow chains (avoid clamp-on types) may be used on both front and rear wheels. Compact spare tires are intended for temporary use only. They are limited to 50 MPH (80 km/h) and must be inflated to 60 psi (4.2 Kg/cm 2 ).
| CAUTION | DO NOT mix tires of different design such as radial with bias or bias-belted tires, etc. Mixing tire types will adversely affect road handling and may lead to loss of vehicle control. |
| Application | Ft. lbs. (N.m.) |
|---|---|
| 1983-87 Models | 65-80 (88-108) |
| 1988-93 Models | 80-90 (108-122) |
WHEEL TORQUE SPECIFICATIONS
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
Battery is located in the engine compartment. The electrolyte level in battery should be checked regularly to ensure adequate fluid level. Use only distilled water to fill battery cell should it become necessary to add water to battery. Battery charge condition should also be checked frequently. This is especially important in low temperature areas. For vehicles equipped with maintenance-free battery, the electrolyte level does not require checking and water need never be added.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
ANTI-LOCK BRAKE SYSTEM (ABS)
| CAUTION | Never mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors. |
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below. |
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C) |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
TURBOCHARGED MODELS
| CAUTION | Do not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
BASIC NEW CAR LIMITED WARRANTY (1989-90)
Covers the cost of repair or replacement of parts on vehicle that have been proven defective in material or workmanship under normal use for 3 years/36,000 miles.
BASIC NEW CAR LIMITED WARRANTY 1991-94
Coverage is 3 years/40,000 miles. Frictional wear items (wiper blades, drive belts, brake pads, clutch discs, etc.) are covered for 16,000 miles. Original batteries are covered by this warranty for its full term. Thereafter, they are covered under the Parts and Accessories Limited Warranty on a pro-rated basis. Warranty begins on date vehicle is delivered or first put in use, whichever occurs first. Tires are warranted under a separate tire manufacturers warranty.
MAJOR SYSTEMS COVERAGE
The following systems/components are warranted for 6 years or 80,000 miles whichever occurs first and (except for SRS system) are subject to a 150 deductible on every repair.
- Engine: block, cylinder head, internal parts, exhaust manifold, turbocharger, water pump, alternator/voltage regulator, power steering pump, AC compressor, starter and fuel pump.
- Transmission: main case, internal parts, and differential assembly.
- Electronic Control Units: fuel injection, ignition, ABS, ACC.
- Other Major Systems: rack & pinion steering assembly, ABS servo/hydraulic control unit and pump, air bag (SRS) components and occupant seat belts.
PARTS & ACCESSORIES LIMITED WARRANTY
Warrants all Saab parts and accessories to be free of defects in material or workmanship under normal use. Covers any repairs or replacement of parts necessary to correct defects at manufacturer's option. Warranty begins on date of original purchase of each item. The following replacement parts are warranted for 1 year unlimited mileage or for term of Basic New Car Warranty, whichever is longer.
- Audio And Alarm Systems
- Speed Control
- Sport Exhaust
- Engine And Chassis Tuning Kits
- Road Wheels
- Spoilers
- Accessory Gauges
- DCC Trip Computer
- Foglights
- Trailer Hitch
- Air Flow Kits
- Wooden Dash Insert
- Rear Decor Panel
- Cellular Telephone
PERFORATION WARRANTY
Any body part that becomes perforated due to corrosion is warranted for 6 years unlimited mileage. Does not cover exhaust system components.
EMISSION CONTROL SYSTEM DEFECT WARRANTY (EXCEPT CALIFORNIA)
Manufacturer warrants its emission components in vehicle to be free of defects in material and workmanship and that vehicle is designed, built and equipped to conform at the time of sale to all applicable (except California) standards for emission control system. Warranty begins on the date vehicle is delivered or first put in use, whichever occurs first and is effective for 5 years/50,000 miles.
EMISSION PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)
Vehicle is warranted to comply to all applicable emissions standards as judged by an EPA-approved emissions test, which may be subjected to changes, for 5 years/50,000 miles, provided the vehicle is maintained and used in accordance with the instructions for care and used in the Saab Owner's Manual. Warranty begins on Warranty Start Date and the primary components listed below are covered for 5 years/50,000 miles, with a few exceptions. Refer to customer's copy of warranty information for specific details.
- Modulating Valve (Lambda System, 8-Valve Engines) (1983-89)
- Lambda Electronic Control Unit (8-Valve Engines) (1983-89)
- Transient Enrichment System Relays (8-Valve Engines) (1983-89)
- Deceleration Shut-Off Solenoid And Relay (1983-89) (8-Valve And Manual Transmission Engines)
- LH-Jetronic Control Unit (16-Valve Engines) (1983-89)
- Deceleration Dashpot (1983-89) (16-Valve Automatic Transmission And Turbo Engines)
- Water Heated Crankcase Ventilation Hose (16-Valve Engines)
- Oxygen Sensor
- Vapor Storage Canister
- PCV Nipple With Orifice
- Three-Way Catalytic Converter
- Fuel Filler Neck Restrictor
- EGR Valve (If Equipped)
- EGR Control Valve (If Equipped)
EMISSION CONTROL SYSTEM WARRANTY (CALIFORNIA)
Manufacturer warrants that vehicle is designed, built and equipped to conform at time of sale to all applicable requirements of the U.S. EPA and the California Air Resources Board (CARB) for 5 years/50,000 miles. Listed below are the primary components which affect vehicle's emission performance and are warranted to be free of defects in material and workmanship which would cause it to fail to conform to all applicable U.S. EPA and/or CARB requirements. The components listed are warranted for 5 years/50,000 miles on all 1983-89 vehicles. For 1990-94 vehicles, this warranty period is good for 3 years/50,000 miles, except for some items, which have an extended warranty for 7 years/70,000 miles. Refer to customer's copy of warranty information for details on specific model application and/or limitations. Warranty begins on date vehicle is delivered or first put in use, whichever occurs first.
5 Years/50,000 Miles (1983-89 Vehicles)
3 Years/50,000 Miles (1990-94 Vehicles)
8-Valve Engines
- Decel Fuel Shut-Off Solenoid, Relay And Contact
- Modulating Valve For Lambda System
- Lambda Electronic Control Unit
- Vacuum Advance Capsule And Hoses
- Auxiliary Air Valve Air Hoses
16-Valve Engines
- Decel Fuel Shut-Off Solenoid, Relay And Contact (Manual Transmission)
- Decel Dashpot (Automatic Transmission And Turbo Engines)
- Turbocharger (Turbo Engines)
- Intercooler, Hoses And Clamps (Turbo Engines)
- Throttle Bypass Valve (Turbo Engines)
- Automatic Idle Control Actuator, Hoses And Clamps
- Vacuum Advance/Pressure Retard Capsule And Hoses
- Ignition Retard Knock Control Module (Non-Turbo Engines)
- Throttle Body Water Manifold
- Water Heated Crankcase Ventilation Hose And Clamps
- PCV Hose Clamps (Turbo Engines)
All Engines
- Oxygen Sensor
- Intake Air Preheater Valve Unit
- Intake Manifold
- Ignition Coil
- Breakerless Ignition Control Unit
- Vapor Storage Canister And Purge Valve
- Fuel Tank And Fuel Filler Cap
- Oil Filler Cap Seal
- Three-Way Catalytic Converter
- Fuel Filler Housing With Restriction
- Exhaust Manifold-To-Catalytic Converter
- Throttle Body Vacuum Port
- PCV Nipple With Orifice
- PCV Hoses
- Fuel Filler Hose
- Evaporative System Vapor Lines And Fittings
- Miscellaneous Sealing, Gaskets And Mounting Hardware
7 Years/70,000 Miles (1990-94 Vehicles)
- LH Fuel Injection System Electronic Control Unit
- Fuel Tank
- Three Way Catalytic Converter
- Intake Manifold
- Exhaust Manifold (Turbo Engines)
- Turbocharger (Turbo Engines)
- EZK Electronic Control Module (Non-Turbo Engines)
FUSE PANEL LOCATION
The electrical system is protected against shorts by fuses that are designed to fail to prevent damage to the wire harness. The main fuse/relay box is located in the engine compartment. If a fuse is blown, locate the cause before replacing the fuse. Spare fuses are contained in the fuse block. A separate relay box can be found under the back seat for convertible models. On vehicles with 8 valve engine, a additional relay box is located in front of the left front wheelhouse.
Scheme 9
Fuse & Circuit Breaker Identification
- 1 - 8 Amp - Right High Beam Headlight
- 2 - 8 Amp - Left High Beam Headlight
- 3 - 8 Amp - Right Low Beam Headlight
- 4 - 8 Amp - Left Low Beam Headlight
- 5 - 25 Amp - Radiator Fan
- 6 - 16 Amp - Electric Rear Window Defogger
- 7 - 5 Amp - Interior Lights
- 8 - 16 Amp - Fuel Pump
- 9 - 8 Amp - Hazard Warning Flasher
- 10 - 8 Amp - Brakelights
- 11 - 8 Amp - A/C Fan
- 12 - 5 Amp - Right Side Parking & Taillights
- 13 - 5 Amp - Left Side Parking & Taillights
- 14 - 16 Amp - Horn, Power Windows (If Equipped)
- 15 - 8 Amp - Electric Side View Mirrors
- 16 - 16 Amp - Electric Seat Heating
- 17 - 25 Amp - Heating & Ventilation Fan
- 18 - 16 Amp - Air Conditioning
- 19 - 8 Amp - Warning Lights
- 20 - 8 Amp - Direction Indicators
- 21 - 8 Amp - Windshield Wipers
- 22 - 16 Amp - Cornering Lights
Scheme 10
Fuse & Circuit Breaker Identification
- 1 - Blank (1984-88) 10 Amp (1989-93) - Lambda Sensor
- 2 - Blank (1984-88) 30 Amp (1989-90) - Rear Windows (Convertible Models) Blank (1991-93)
- 3 - Blank (1984-87) 15 Amp (1989-93) - Ignition System
- 4 - Blank (1984) 10 Amp (1984-90) - Shift Indicator Light Blank (1991-93)
- 5 - 15 Amp - Windshield Wipers/Washers, Brake Fluid Warning Light (1989-90), Seat Belt Warning Lights (1989-93)
- 6 - 30 Amp - A/C System
- 7 - 15 Amp - Turn Signal Indicators, Tachometer (1987-93), Alternator (1989-93), Oil Pressure Warning Lights (1989-93), Shift-Up Light (1992-93), CHECK Engine/SRS Lights (1993)
- 8 - 10 Amp - Electrically Adjusted Rear-View Mirrors, Cruise Control, Headlight Wipers (1993)
- 9 - 30 Amp - Ventilation Fan
- 10 - 10 Amp - APC Boost Pressure System
- 11 - 30 Amp - Power Windows, Sun Roof Blank (1991-93)
- 12 - 15 Amp (1984-86) - Seat Heaters 20 Amp (1987-90) - Seat Heaters, Pump Relay Supply Voltage (Convertible Models) Blank (1991-93)
- 13 - 20 Amp 10 Amp (1993) - Back-Up Lights, Cigarette Lighter, Seat Belt & Alternator Warning Lights (1984-88)
- 14 - 15 Amp - Right High Beam Headlight
- 15 - 15 Amp - Left High Beam Headlight, High Beam Indicator
- 16 - 15 Amp - Right Low Beam Headlight
- 17 - 15 Amp - Left Low Beam Headlight
- 18 - 10 Amp - Right Side Parking & Taillights, License Plate, Glove Compartment (1984-88), Ashtray & Instrument Panel Lights (1984-88)
- 19 - 10 Amp - Left Side Parking & Taillights
- 20 - 15 Amp (1984-90) - Radio/Cassette Player, Cornering Light (1987-90) Blank (1991-93)
- 21 - 15 Amp - Foglights
- 22 - 15 Amp (1984-90) - Relay Trigger (Include Fuel Pump, Rear Demist, Cooling Fan Time Relays) 10 Amp (1991-93) - Fuel System & Gauge, Temp Gauge, Brake Warning Lights, ABS, Fuel Reserve Warning Light (1992-93)
- 23 - Blank (1984-88) 10 Amp (1989-93) - Instrument Panel Lighting, Glove Box & Ashtray Lights (1992-93)
- 24 - 10 Amp - Central Locking Blank (1991-93)
- 25 - 30 Amp - Radiator Cooling Fan
- 26 - 25 Amp - Horn
- 27 - 15 Amp - Hazard Warning Lights
- 28 - 15 Amp - Interior Lights (1984-90), Clock, Electric Antenna (1984-90), Radio Memory &/Or Amplifier(s) (1984-90)
- 29 - 20 Amp (1984-88) - Heated Rear Windows 25 Amp (1989-90) - Heated Rear Windows Blank (1991-93)
- 30 - 20 Amp - Fuel Pumps
- 31 - 15 Amp (1984-86) - Brakelights 15/5 Amp (1987-93) - Brakelights/Oxygen Sensor Wire
Scheme 11
Scheme 12
Fuse & Circuit Breaker Identification
- 1 - 10 Amp - Anti-Lock Brake System (ABS - If Equipped)
- 2 - 30 Amp - ABS (If Equipped)
- 3 - 30 Amp - ABS Pump (If Equipped)
1992
- 4 - Relay - ABS (If Equipped)
- 5 - Relay - ABS Pump (If Equipped)
1993
- A - Relay - System Relay
- B - Relay - Pump Relay
Scheme 13
Relay Identification
- 1 - Headlight Relay
- 2 - Headlight Relay
- 3 - Rear Window Demist Time Relay
- 4 - A/C Relay (1986) Ignition Amp Relay (1987-88) Blank (1989-90)
- 5 - Ignition Lock Relay
- 6 - Fuel Pump/RPM Limiter Relay (1983-84 Turbo) Prewired For Foglights Option (1985-86 16-Valve Engines) Upshift Light Relay (1988 Manual Transmission) Blank (1989-90)
- 7 - Fuel Pump Relay (All 8-Valve Engines) Foglights Relay (1987-90 16-Valve Engines)
- 8 - Blank (1983-84) Shift Light Relay (1985-86 8-Valve Engines) A/C Relay (1987-88), Time Delay/Relay (1989-90)
- 9 - Cooling Fan (A/C) Relay
- 10 - Horn Relay
ENGINE COMPARTMENT RELAY ID (1983-88 W/8-VALVE ENGINE)
Note. Relay panel is located in front of left front wheelhouse in engine compartment.
Scheme 14
Relay Identification
- 1 - Prewired For Foglights Option (1983-84) Blank (1985-88)
- 2 - Acceleration Enrichment Time Relay (1983) Transient Enrichment Relay (1984-88)
- 3 - Acceleration Enrichment Time Relay (1983) Transient Enrichment Relay (1984-88)
- 4 - Acceleration Enrichment Pulse Relay (1983) Blank (1984) Prewired For Foglights Option (1985-88)
- 5 - Deceleration System Relay (Manual Transmission)
- 6 - Hot Relay
- 7 - Cold/Hot Start Ground Relay (1983) Engine Speed Relay (1984) Blank (1985-88)
- 8 - Engine Speed Relay (1983 Turbo) Blank (1984-88)
Scheme 15
Relay Identification
- 1 - Convertible Operating Relay
- 2 - Key/Belt Warning Relay
- 3 - Guard Alarm Relay
- 4 - Power Window Relay
- 5 - Time Relay
- 6 - Convertible Operating Relay
Scheme 16
Fuse & Circuit Breaker Identification
- 1 - Convertible, Operating
- 2 - Seat Heaters
- 3 - Heated Rear Window
- 4 - Interior Lighting
- 5 - Radio
- 6 - Electric Antenna
- 7 - Power Windows, Front
- 8 - Power Windows, Rear
- 9 - Elect - Adj - Driver Seat
- 10 - Elect - Adj - Passenger Seat
Relay Identification
- A - Belt/Key Warning
- B - Heated Rear Window
- C - Convertible, Operating
- D - Convertible, Operating
- E - Interior Lighting
- F - Ignition Lock
Scheme 17
Fuse & Circuit Breaker Identification
- 1 - 30 Amp - Electronically Heated Rear Window/Door Mirrors
- 2 - 15 Amp - ICE, Direction Indicator
- 3 - 30 Amp - ACC, Cabin Fan
- 4 - 7.5 Amp - Interior Lighting
- 5 - 30 Amp - Power Seat (RH)
- 6 - 30 Amp - Cigarette Lighter
- 7 - 30 Amp - Rear Power Windows
- 8 - 15 Amp - Rear Window Wiper
- 9 - 15 Amp - Radio
- 10 - Spare
- 11 - Spare
- 12 - 15 Amp - Brake Lights
- 13 - 15 Amp - Radio, Data Link Connector
- 14 - 30 Amp - Front Power Windows
- 15 - 20 Amp - Daytime Driving Lights
- 16 - 30 Amp - Power Front Seat (LH)
- 17 - 15 Amp - Mian Instrument, SID, Fuel Injection (Turbo)
- 18 - 15 Amp - Instruments, Air Bag
- 19 - 15 Amp - ABS, A/C Relay
- 20 - 20 Amp - Heated Front Seats, Central Locking
- 21 - 10 Amp - A/C ACC
- 22 - 15 Amp - Cruise Control System
- 23 - 20 Amp - Anti-Theft Alarm, Telephone
- 24 - 10 Amp - APC
- 25 - 30 Amp - Central Locking, Amplifier
- 26 - Not Used
- 27 - 15 Amp - Full & Dipped Beam
- 28 - 30 Amp - TCS, TRIONIC SFI, Motronic SFI
- 29 - 7.5 Amp - Parking Lights, RH Side Rheostat
- 30 - 10 Amp - Parking Lights, LH Side Rheostat
- 31 - 15 Amp - Reversing Lights, Windscreen Wipers
- 32 - 10 Amp - Fuel Pump
- 33 - 30 Amp - Direction Indicator
- 34 - 10 Amp - Instruments
- 35 - 10 Amp - ICE
- 36 - 10 Amp - Starter Motor
- 37 - 10 Amp - Rear Foglights
- 38 - 7.5 Amp - Heated Oxygen Sensor
- 39 - Not Used
Relay Holder Identification
- B - Relay - Reversing Lights
- C - Relay - Shift Lock
- D - Relay - Rear Window Wiper
- E - Relay - Ignition Switch
- G - Relay - Windshield Wipers
- H - Relay - Electrically Heated Rear Window
- I - Relay - Fuel Pump
- K - Relay - Starter Relay
- L - Relay - Fuel Injection System
Scheme 18
Fuse & Circuit Breaker Identification
- 1 - 10 Amp - Horn
- 2 - 15 Amp - Extra Foglights
- 3 - 40 Amp - Radiator Fan, Low Speed
- 4 - Not Used
- 5 - 15 Amp - Relay, A/C Compressor
- 6 - 15 Amp - Dipped Beam, LH Side
- 7 - 15 Amp - Dipped Beam, RH Side
- 8 - 15 Amp - Full Beam, LH Side
- 9 - 15 Amp - Full Beam, RH Side
- 10 - 7.5 Amp - Headlamp Wipers
- 11 - 10 Amp - Headlamp Beam Adjustment
- 12 - 10 Amp - Valve, Secondary Air
Maxi-Fuse Identification
- 1 - 30 Amp - Radiator Fan, High Speed
- 2 - 60 Amp - ABS
- 3 - 30 Amp - Secondary Air Injection Pump
Relay Identification - 1994
- A - Lighting Relay
- B - Full & Dipped Beam Relay
- C - Secondary Air Injection Pump Relay
- D - Radiator Fan, Low Speed
- E - Filament Monitor for Front Lights Relay
- F - Foglights Relay
- G - Horn Relay
- H - Radiator Fan, High Speed
- I - A/C and ACC Relay
Relay Identification - 1995-96
- A - Low Beam
- B - High Beam
- C - Secondary Air Pump
- D - Cooling Fan, Low Speed
- E - Lamp Test, Front (Filament Monitor)
- F - Fog Lights, Front
- G1 - Horn
- G2 - Secondary Air Pump Valve
- H2 - Maxi Fuse for Secondary Air Pump (30 Amp)
- I - Cooling Fan, High Speed
- J - A/C-ACC Compressor
Scheme 19
Main Fuse Distribution Box
- 1 - 60 Amp - Power Supply for Fuses: 1,4,11,13,17,23,24,25,26 & 34
- 2 - 60 Amp - Power Supply for Fuses: 2,5,10,12,16,27,28,33 & 35
- 3 - 60 Amp - Power Supply for Ignition Switch Fuse 20
- 4 - 60 Amp - Power Supply for Ignition Switch Fuse 21
- 5 - 60 Amp - Power Supply for Cabriolet Hood Control System
UNDERHOOD MAXI-FUSE PANEL IDENTIFICATION (1995-96)
- 1 - 60 Amp - Power Supply for Fuses: 1,4,13,23,25,33 & 34
- 2 - 60 Amp - Power Supply for Fuses: 2,5,10,12,16,27,28, & 35
- 3 - 60 Amp - Power Supply for Ignition Switch Directly
- 4 - 60 Amp - Power Supply for Ignition Switch Relay
- 5 - 60 Amp - Power Supply for Cabriolet Hood Control System
Scheme 20
Relay Identification
- A - Not Used
- B - Reversing Lights
- C - Shift Lock
- D - Rear Window Wiper, Intermittent Operation
- E - Ignition Switch
- F - Overheated 3-Way Catalytic Converter EXH
- G - Windscreen Wipers, Intermittent Operation
- I - Fuel Pump
- J - Not Used
- K - Starter Relay
- L - Sequential Multiport Fuel Injection System
