Fixed and Moveable Windows: Specifications Saab 9-7X I

Heated Glass/defoggers 13 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Door Outer Belt Sealing Strip1.2 N.m10 lb in
Liftgate Window Handle Bolts5 N.m44 lb in
Liftgate Window Latch Bolts10 N.m89 lb in
Liftgate Window Striker Bolts10 N.m89 lb in
Side Pillar Reveal Molding Screws2 N.m18 lb in
Striker Retaining Nuts6 N.m53 lb in
Weatherstrip Run/Channel Bolts10 N.m89 lb in
Window Regulator Bolts10 N.m89 lb in
Window Regulator Clamp Nuts10 N.m89 lb in
Window Regulator Motor Bolt5 N.m44 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Moveable Window Schematics
Scheme 1: Moveable Window Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Defogger Schematics
Scheme 3: Defogger Schematics

Scheme 4

Scheme 4: Window Systems Component Views
Scheme 4: Window Systems Component Views
CalloutComponent Name
1Window Lockout Switch
2Passenger Window Switch
3Right Rear Window Switch
4Door Lock Switch - Driver
5Memory Seat Switch - Driver
6Heated Seat Switch - Driver
7Left Rear Window Switch
8Driver Window Switch

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Door Latch Assembly - Driver C3
2Left Front Door Harness
3Window Motor Connector - Driver
4Window Motor - Driver
5Door Latch Assembly - Driver C2
6Door Latch Assembly - Driver
7Door Latch Assembly - Driver C1

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Window Switch - Passenger
2Door Lock switch - Passenger
3Heated Seat Switch - Passenger

Scheme 7

Scheme 7
Scheme 7
CalloutComponent Name
1Window Motor Connector - Front Passenger
2Right Front Door Harness
3Door Latch Assembly - Passenger C1
4Door Latch Assembly - Passenger
5Door Latch Assembly - Passenger C2
6Window Motor - Front Passenger

Scheme 8

Scheme 8
Scheme 8
CalloutComponent Name
1Window Switch - LR
2Left Rear Door Harness
3LR Door

Scheme 9

Scheme 9
Scheme 9
CalloutComponent Name
1C700
2Window Motor - LR
3Door Latch Assembly - LR C2
4Door Latch Assembly - LR
5Door Latch Assembly - LR C1

Scheme 10

Scheme 10
Scheme 10
CalloutComponent Name
1RR Door
2Right Rear Door Harness
3Window Switch - RR

Scheme 11

Scheme 11
Scheme 11
CalloutComponent Name
1C800
2Door Latch Assembly - RR C1
3Door Latch Assembly - RR
4Door Latch Assembly - RR C2
5Window Motor - RR

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Rear Window Defogger Grid C2
2C905
3C900
4C904
5Rear Window Defogger Grid C1
6S901
7Liftglass Ajar Switch
8Liftgate Harness
9Liftgate Module (LGM)
10C901
11License Lamp Harness
12Liftgate Latch Assembly
13Rear Window Wiper Motor

Scheme 13

Scheme 13: Rear Window Defogger Grid C1
Scheme 13: Rear Window Defogger Grid C1
Connector Part Information OEM: 12092133 Service: 12167133 Description: 1-Way F Metri-Pack 630 Series Unsealed (BK)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Rear Window Defogger Grid C1 Connector Parts Information

PinWire ColorCircuit No.Function
APU293Rear Defogger Element Supply Voltage

Rear Window Defogger Grid C1 Connector Terminal Identification
