Frame and Underbody: Removal & Installation Saab 9-7X I

Installation Procedure

1. Install the tow hook to the impact bar, ensuring that the locating pin is properly indexed to the impact bar. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the bolt which retains the tow hook to the impact bar. Tighten: Tighten the bolt to 50 N.m (37 lb ft).
3. Install the impact bar. Refer to «Front Bumper Impact Bar Replacement»(ref-268089-S11332973252007101800000) .
4. Install the fascia. Refer to «Front Bumper Upper Fascia Replacement»(ref-268089-S41188511302007101800000) .
5. Install the grille. Refer to «Grille Replacement»(ref-268086-S31050323502007101800000) .

Scheme 2

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the radiator support shield mounting nuts and bolts.
3. Remove the radiator support shield.

1. Install the radiator support shield. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the radiator support shield mounting nuts and bolts. Tighten: Tighten the radiator support shield mounting nuts to 20 N.m (15 lb ft).
3. Lower the vehicle.

Scheme 3

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the engine shield mounting bolts.
3. Remove the engine shield.

1. Install the engine shield. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the engine shield mounting bolts. Tighten: Tighten the engine shield mounting bolts to 20 N.m (15 lb ft).
3. Lower the vehicle.

Scheme 4

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the transfer case shield mounting bolts (3) from the transmission support.
3. Remove the transfer case shield (2) from transmission support.

1. Install the transfer case shield (2) to the transmission support. Ensure that the J-nuts (1) are in place. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the transfer case shield mounting bolts (3). Tighten: Tighten the transfer case shield mounting bolts to 16 N.m (12 lb ft).
3. Lower the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .

Scheme 5

Scheme 6

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the frame brace mounting bolts.
3. Remove the frame brace.
4. Remove the fuel tank shield to the frame retaining bolts and nut.
5. Remove the fuel tank shield from the frame.

1. Install the fuel tank shield to the frame. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the fuel tank shield to the frame retaining bolts and nut. Tighten: Tighten the fuel tank shield to the frame retaining bolts and nut to 32 N.m (24 lb ft).
3. Install the frame brace.
4. Install the frame brace mounting bolts. Tighten: Tighten the frame brace mounting bolts to 50 N.m (37 lb ft).
5. Lower the vehicle.

Scheme 7

Scheme 8

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the engine shield mounting bolts.
3. Remove the engine shield.
4. Remove the rear lower control arm bracket to frame mounting bolts.
5. Remove the steering gear crossmember mounting bolts.
6. Remove the steering gear crossmember.

1. Install the steering gear crossmember. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the steering gear crossmember mounting bolts. Tighten: Tighten the steering gear crossmember mounting bolts to 50 N.m (37 lb ft).
3. Install the rear lower control arm bracket to frame mounting bolts. Tighten: Tighten the rear lower control arm bracket to frame mounting bolts to 240 N.m (177 lb ft).
4. Install the engine shield.
5. Install the engine shield mounting bolts. Tighten: Tighten the engine shield mounting bolts to 20 N.m (15 lb ft).
6. Lower the vehicle.

Scheme 9

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the front steering gear crossmember rear mounting bolts.
3. Remove the rear steering gear crossmember mounting bolts.
4. Remove the rear steering gear crossmember from the vehicle.

1. Install the rear steering gear crossmember to the vehicle. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the rear steering gear crossmember mounting bolts. Tighten: Tighten the rear steering gear crossmember mounting bolts to 50 N.m (37 lb ft).
3. Install the front steering gear crossmember rear mounting bolts. Tighten: Tighten the front steering gear crossmember mounting bolts to 50 N.m (37 lb ft).
4. Lower the vehicle.

Removal Procedure

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the 2 mounting bolts from the frame brace.
3. Remove the frame brace from the frame.

Note. Refer to Fastener Notice .

1. Install the frame brace to the frame using the 2 mounting bolts. Tighten: Tighten the bolts to 50 N.m (37 lb ft).
2. Lower the vehicle.

Properly support the frame when you change the body mounts. If only one mount is changed, lower the entire side on which the mount in placed in order to provide clearance for the mount.

Scheme 10

Scheme 11

1. Raise the vehicle slightly on a hoist. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Place jack stands under the body on the side of the vehicle that the mounts will be placed.
3. Remove the body mount bolt, retainer, and lower cushion (1) from the radiator support.
4. Remove the body mount bolts, retainers, and lower cushions (1) from the 5 other mount locations.
5. Lower the hoist enough in order to leave the body supported by the jack stands.
6. Remove the upper cushions (2) from the vehicle.

1. Install the upper cushions (2) to the vehicle.
2. Raise the frame slightly on the hoist. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) Fastener Notice.
3. Install the lower cushions, retainers, and bolts to the 5 body mount locations. Tighten: Tighten the bolts to 80 N.m (59 lb ft).
4. Install the lower cushion (1), retainer, and bolt to the radiator support. Tighten: Tighten the bolts to 80 N.m (59 lb ft).

Scheme 12

1. Remove the push-pins from the wheelhouse liner.
2. Remove the bolt that retains the wheelhouse liner to the rocker molding.
3. Remove the wheelhouse liner from the vehicle.

1. Install the wheelhouse liner to the vehicle.
2. Install the push-pins that retain the wheelhouse liner to the body. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
3. Install the bolt that retains the wheelhouse liner to the rocker molding. Tighten: Tighten the bolt to 10 N.m (89 lb in).

Scheme 13

1. Remove the bolt that retains the wheelhouse panel to the rocker panel molding.
2. Remove the screws that retain the wheelhouse panel to the rear fascia.
3. Remove the push-pins retaining the wheelhouse panel to the wheelhouse.
4. Remove the wheelhouse panel from the vehicle.

1. Install the wheelhouse panel to the vehicle.
2. Install the push-pins retaining the panel to the wheelhouse. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
3. Install the screws that retain the wheelhouse panel to the rear fascia. Tighten: Tighten the screw to 2 N.m (18 lb in).
4. Install the bolt that retains the wheelhouse panel to the rocker panel molding. Tighten: Tighten the bolt to 7 N.m (62 lb in).

Scheme 14

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Remove the nuts (1) that retain the assist step to the assist step support brackets.
3. Remove the assist step from the support brackets.
4. Place the assist step on a clean, prepared surface.
5. Release the fasteners (2) that retain the assist step pad to the assist step.
6. Remove the assist step pad from the assist step.

1. Install the assist step pad to the assist step, ensuring that the fasteners (2) are fully seated. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Position the assist step to the vehicle. Install the nuts (1) that retain the assist step to the assist step support brackets. Tighten: Tighten the nuts to 25 N.m (18 lb ft).
3. Lower the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .

Scheme 15

1. Remove the bolts that retain the assist step support brackets to the body.
2. Remove the assist step assembly from the vehicle.
3. Place the step assembly on a clean, prepared surface.
4. Remove the nuts (1) that retain the assist step to the support brackets.
5. Remove the support brackets from the assist step.

1. Position the assist step to the support brackets. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) . Install the nuts (1) that retain the assist step to the support brackets. Tighten: Tighten the nuts to 25 N.m (18 lb ft).
2. Position the assist step assembly to the vehicle.
3. Install the bolts that retain the support brackets to the body. Tighten: Tighten the bolts to 25 N.m (18 lb ft).

Scheme 16

Scheme 17

Scheme 18

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-268088-S13434065972007101800000) .
2. Support the transmission with a transmission jack.
3. Remove the transmission mount to the transmission support retaining nuts.
4. Remove the lower transmission support to the frame mounting bolts.
5. Remove the upper transmission support to the frame mounting bolts (1, 2).
6. Remove the transmission support from the frame.

1. Install the transmission support to the frame. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
2. Install the upper transmission support to the frame mounting bolts (1, 2). Tighten: Tighten the upper transmission support to the frame mounting bolts to 80 N.m (59 lb ft).
3. Install the lower transmission support to the frame mounting bolts. Tighten: Tighten the bolts to 50 N.m (37 lb ft).
4. Lower the transmission onto the transmission support.
5. Install the transmission mount to the transmission support retaining nuts. Tighten: Tighten the transmission mount to the transmission support retaining nuts to 46 N.m (35 lb ft).
6. Lower the vehicle.
