Lighting: Specifications Saab 9-7X I

Exterior Lights 33 illustrations ~198 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Backup Lamp to Fascia Nuts10 N.m88 lb in
Front Fog Lamp Bolts10 N.m88 lb in
High Mount Stop Lamp Lens Screws2.5 N.m22 lb in
Instrument Panel Compartment Lamp Screws1.9 N.m17 lb in
License Plate Lamp Lens to Liftgate Screws1.4 N.m12 lb in
Tail Lamp Assembly to Vehicle Screws1.9 N.m17 lb in

Fastener Tightening Specifications

Lighting Systems Schematic Icons Icon Icon Definition CAUTION: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to Sir Disabling And Enabling. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Lighting Systems Schematic Icons
Scheme 1: Lighting Systems Schematic Icons

Scheme 2

Scheme 2: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 2: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Fog Lights Schematics
Scheme 5: Fog Lights Schematics

Scheme 6

Scheme 6: Exterior Lights Schematics
Scheme 6: Exterior Lights Schematics

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15: Interior Lights Schematics
Scheme 15: Interior Lights Schematics

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18: Interior Lights Dimming Schematics
Scheme 18: Interior Lights Dimming Schematics

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20: Lighting Systems Component Views
Scheme 20: Lighting Systems Component Views
CalloutComponent Name
1Outside Rearview Mirror - Passenger
2Headlamp - Low Beam - Right
3Headlamp - High Beam - Right
4Headlamp - High Beam - Left
5Headlamp - Low Beam - Left
6Outside Rearview Mirror - Driver
7Marker Lamp - LF
8Park/Turn Signal Lamp - LF
9Fog Lamp - LF
10Fog Lamp - RF
11Park/Turn Signal Lamp - RF
12Marker Lamp - RF

Scheme 21

Scheme 21
Scheme 21
CalloutComponent Name
1Vanity Mirror Lamp - Left

Scheme 22

Scheme 22
Scheme 22
CalloutComponent Name
1Courtesy/Reading Lamp - Front
2Sunroof Switch (CF5)
3Garage Door Opener

Scheme 23

Scheme 23
Scheme 23
CalloutComponent Name
1Vanity Mirror Lamp - Right

Scheme 24

Scheme 24
Scheme 24
CalloutComponent Name
1Speaker - LF I/P (UQA)
2Ambient Light/Sunload Sensor Assembly
3Speaker - RF I/P (UQA)

Scheme 25

Scheme 25
Scheme 25
CalloutComponent Name
1Rear Window Wiper/Washer Switch
2I/P Dimmer Switch
3Interior Lamp Defeat Switch
4Instrument Panel Cluster (IPC)
5Driver Information Center (DIC) Switch
6Radio
7Inflatable Restraint I/P Module
8HVAC Control Module

Scheme 26

Scheme 26
Scheme 26
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Windshield Wiper/Washer Switch
3C201

Scheme 27

Scheme 27
Scheme 27
CalloutComponent Name
1Turn Signal/Hazard Flasher Module
2Instrument Panel Harness
3Data Link Connector (DLC)
4Splice Pack SP205

Scheme 28

Scheme 28
Scheme 28
CalloutComponent Name
1Instrument Panel Harness
2Accelerator Pedal Position (APP) Sensor
3Accelerator Pedal
4Brake Pedal
5Stop Lamp Switch

Scheme 29

Scheme 29
Scheme 29
CalloutComponent Name
1Cargo Lamp
2Courtesy/Reading Lamp - Center

Scheme 30

Scheme 30
Scheme 30
CalloutComponent Name
1Trailer Stop/Turn Relay - Left
2Trailer Stop/Turn Relay - Right
3Trailer Connector

Scheme 31

Scheme 31
Scheme 31
CalloutComponent Name
1Rear Window Defogger Grid C2
2C905
3C900
4C904
5Rear Window Defogger Grid C1
6S901
7Liftglass Ajar Switch
8Liftgate Harness
9Liftgate Module (LGM)
10C901
11License Lamp Harness
12Liftgate Latch Assembly
13Rear Window Wiper Motor

Scheme 32

Scheme 32
Scheme 32
CalloutComponent Name
1Center High Mounted Stop Lamp (CHMSL)
2Backup Lamp - Right
3Turn Signal Lamp - RR
4Stop/Park Lamp - RR
5Marker Lamp - RR
6License Lamp - Right
7License Lamp - Left
8Marker Lamp - LR
9Stop/Park Lamp - LR
10Turn Signal Lamp - LR
11Backup Lamp - Left

Scheme 33

Scheme 33: Backup Lamp - Left
Scheme 33: Backup Lamp - Left
Connector Part Information OEM: 1012404 Service: See Catalog Description: 2-Way F CIC W2 Socket (GY)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Backup Lamp - Left Connector Parts Information

PinWire ColorCircuit No.Function
ABKGround
BKGround
BYEBackup Lamp Supply Voltage

Backup Lamp - Left Connector Terminal Identification
