Auxiliary Power Outlet - Rear
| Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series Unsealed (BK) |
|---|
| Terminal Part Information Pins: A, C Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet - Rear - Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | OG | 1040 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 2250 | Ground |
Auxiliary Power Outlet - Rear - Connector Terminal Identification
Tools Required
J 42059 Cigarette Lighter Socket Remover. See Special Tools .
Scheme 194
Scheme 195
Scheme 196
Scheme 197
- Remove the 12-volt power supply or cigar lighter fuse.
- Remove the socket by placing one side of the "T" portion of the tool J 42059 into the socket and into the square window tab. See «Special Tools»(ref-268167-S11402016832007101800000) .
- Position the opposite "T" portion of the tool into the opposing square window tab.
- Pull the socket straight out of the retaining ring.
- Remove the tool from the socket.
- Disconnect the electrical connector from the socket.
- Using your finger, remove the socket retaining ring by pulling the retaining ring out of the mounting hole.
Scheme 198
Scheme 199
- Position the retaining ring to the mounting hole.
- Index the key to the retaining ring to the slot in the mounting hole.
- Install the retaining ring by pressing the retaining ring into the mounting hole until fully seated.
- Connect the electrical connector to the socket.
- Position the socket to the retaining ring.
- Install the socket into the retaining ring by pressing in the socket until fully seated.
- Install the 12-volt power supply or cigar lighter fuse.
