Wash/wipe Systems: Other Saab 9-5 II

Wiper/Washer System Components

The wiper/washer system consists of the following electrical components

1. Windshield Wiper Relay
2. Windshield Wiper Speed Control Relay
3. Windshield Washer Pump Relay
4. Windshield Outside Moisture Sensor
5. Windshield Washer Pump
6. Windshield Wiper Motor
7. Window Wiper/Washer Switch
8. Windshield Wiper Motor Fuse
9. Windshield Washer Fluid Pump Fuse
10. Body Control Module (BCM)
11. Headlamp Washer Fluid Pump Relay
12. Headlamp Washer Fluid Pump 25 A Fuse
13. Windshield Washer Fluid Level Switch

Windshield Wiper System Module

The body control module (BCM) determines the front wipe/wash system mode of operation by monitoring several signals from the front wipe/wash switch as indicated in the wiper switch

The windscreen wiper/washer switch receives a reference ground signal from BCM. Each input signal from BCM provides a battery connection for each output signal it receives from the windscreen wiper/washer switch. All the BCM inputs are recognized as active when the wiper switch provides a path to the referenced ground signal. The first signal received by the BCM is the result of 6 resistors in the front wiper switch configured as a resistor ladder network. This signal is connected to an analogue to digital input signal from BCM. Depending on function selected (high, low, interval 1 to 5, fog, off) the windscreen wiper switch connects different sets of resistors to the circuit which provides different voltages in BCM's A/D input signal. By monitoring this voltage, the BCM determines how to control the wiper motor On/Off relay. It should be noted that High, Low, and Mist all have the same value on this signal circuit. The second signal received from the front wiper switch is active only when the front wiper switch is in the high speed wiper position. When the wiper switch is not in the high speed position, the switch is open and the signal circuit is pulled to battery by the BCM. When the wiper switch is in the high speed position, the switch pulls the circuit low. The BCM determines how to control the wiper high/low speed relay from this input. The third signal received from the front wiper switch is from the momentary windshield wash control switch. When the washer switch is not active the switch is open and the signal circuit is pulled to battery by the BCM. When the washer switch is active, the switch pulls the circuit low. The BCM controls the windshield wash and windshield wash activated wiper operation based on this input.

The BCM controls front wiper motor operation through two output signals and the monitoring of one input signal. The two outputs (one high side drive, one low side drive) are used to control two external wiper motor relays: front wiper motor on/off relay: which provides the wiper motor with battery power when it is activated by the high side drive signal (switched battery) from the BCM. When left deactivated, the normally closed contacts provide a ground to the wiper motor. Wiper high/low speed relay: when activated by a low side drive signal (ground) from the BCM, it switches the power supplied by the wiper motors on/off relay to the motors high speed input. When left deactivated, the normally closed contacts connect the power supplied by the wiper motors on/off relay to the motors low speed input. The input used by the BCM is from the park switch located in the wiper motor assembly. When the wiper blades are not in the park position, the wiper park switch is open and the circuit is pulled up to battery by the BCM. When the wiper blades are in the park position at the bottom of the glass, the wiper park switch closes to ground pulling the park signal circuit low.

To initiate low speed operation, the BCM only energizes the front wiper motor on/off relay. This allows battery voltage from the wiper fuse to be applied through the switched contacts of the wiper motor on/off relay, through the normally closed contacts of the wiper high/low speed relay, to the low speed control circuit of the windshield wiper motor.

Redundant high speed switch pass through. The BCM provides redundant circuitry which places battery power on its wiper motor on/off relay output with activation of its low assertion high speed wiper switch input. The BCM shall be capable of doing this, even if the module has lost all microprocessor control. This redundant circuit shall supply power while in the RUN and CRANK power modes. however; while in the CRANK power mode, the pass through shall only be active if the BCM is NOT in a computer operating properly state.

To initiate high speed operation, the BCM energizes both the front wiper motor on/off relay and the wiper high/low speed relay. This allows battery voltage from the wiper fuse to be applied through the switched contacts of the wiper motor on/off relay, through the switched contacts of the wiper high/low speed relay, to the high speed control circuit of the windshield wiper motor.

Parking the wiper motor. In order to perform an accurate read of the park switch and to ensure the wipers will come to rest while still in the park position, parking of the wipers only occurs while in a low speed wiper mode. This requires that if the wipers are performing a high speed wiper operation at the time they are required to park, the BCM shall transition the wipers to low speed by deactivating the wiper high/low relay before attempting to park. In order to park the wipers, the BCM monitors the park circuit until the park switch pulls the park circuit to ground. At this time, the BCM will immediately deactivate the wiper motor on/off relay. The relay contacts will switch back to their normally closed position and will apply ground to the wiper motor power inputs through the normally closed contacts of the wiper high/low relay. This deactivates and dynamically brakes the wiper motor in the park position. When the wiper switch is turned to the OFF position while the wiper motor is somewhere in mid-cycle, the BCM will continue to operate the motor until the wipers reach the park position. If the BCM is running the wiper motor and does not see a state transition of the park switch after 8 s, the wipers will stop immediately when the wiper switch is turned to OFF. If the ignition is turned OFF while the wipers are in mid-cycle, the wipers will stop immediately, regardless of position. The BCM will park the wipers next time the ignition is turned ON.

The windshield wiper system MIST operation is identical to LOW speed operation, except that the MIST switch is a press and release type switch. When the wiper switch is moved to the MIST position and released, low speed wiper motor operation is started and will continue until 1 cycle is complete. If the wiper switch is moved to the MIST position and held, the wiper motor will operate in the LOW speed mode until the switch is released.

Windshield wiper intermittent operation is a low speed wiper motor function with a variable delay interval between the wiper motor cycles. The duration of the delay is controlled by the front wiper control switch's intermittent 1 thru intermittent 5 settings. The wiper operation is as follows

1. The BCM will initiate a single wipe by activating its front wiper ON/OFF relay output.
2. At the completion of a single wipe, the BCM will park the wipers as described above.
3. The BCM will then pause the wipers in their park position for the time duration associated with intermittent delay switch setting.
4. When the delay time expires repeat Steps 1 and 3 until the system is turned off or taken out of intermittent mode. If the wiper switch is moved from a longer delay interval to a shorter delay interval, the BCM will command an immediate wipe cycle and reset the delay timer to the shorter delay interval.

Intermittent wiper operation may be vehicle speed sensitive. When enabled, the speed compensated intermittent feature causes the intermittent wiper delay intervals to become shorter as a function of increased speed. As vehicle speed is reduced the intervals will become closer to the predetermined

Windshield Washer System

The BCM controls the windshield wash operation and windshield wash activated wiper operation. When the BCM detects the activation of the momentary windshield wash control switch, it activates its washer pump relay drive output which supplies battery power to the coil of the washer pump relay. This energizes the relay, which switches battery power to the pump motor. The BCM will also activate continuous low speed windshield wipes as described above. Upon deactivation of the windshield wash control switch, the wiper control module (BCM) shall deactivate the wash motor and will also park the wiper motor as described above unless the drip wipe feature is enabled. On some vehicles the drip wipe feature will be enabled and cause the system to provide additional wiping of the windshield after the switch has been released and fluid is no longer being applied. The front wash feature may attempt to detect a stuck switch. When enabled, activation of the wash feature shall be limited to 10 seconds.

Headlamp Washer System

When Headlamp Wash Equipped, the headlamps shall be sprayed with wash fluid as a result of an extended Windshield Wash Switch Activation. In order to preserve wash fluid, the feature shall only be allowed to activate if the Low or High Beam Headlamps are active. In addition, after the initial Headlamp Wash operation has been performed, additional headlamp washes shall not be performed for the next 4 Windshield Wash activations or for 48 hours whichever comes first. In the event that the system has detected a stuck front wash switch condition, the headlamp wash feature shall be disabled.

Rain Sense Mode and Rain Sense Indicator

When this feature is activated on rain sense equipped vehicles, the wiper subsystem performs front windshield wipes according to the amount of moisture detected on the windshield. The BCM will control the wiper motor speed, as indicated above, based on wipe requests that it receives from a moisture sensor (rain sense module) which is mechanically attached to the windshield through a windshield mounted optic coupler. The system uses a master/slave configuration utilizing a local interconnect network (LIN) based serial data communication system. The BCM is designated as the master, while the rain sense module is designated the slave. As the system master, the BCM uses the LIN serial communication bus to enable or disable rain sense module operation, communicate wiper control switch settings, and wiper motor position information to the rain sense module. The rain sense module requests wiper motor function, and provides the BCM with system status and diagnostic information for diagnostic reporting. When this feature is present, the BCM uses the front wiper control switch's intermittent 1 thru intermittent 5 settings to activate the system and to act as the automatic wiper sensitivity control. This allows the driver to adjust the moisture level at which the rain Sensor requests the BCM to automatically wipe the windshield. The intermittent 1 setting corresponds to the lowest sensitivity and intermittent 5 the highest sensitivity.

Some vehicles (if calibrated) shall display an AUTO front wiper indicator when the feature is active. This indicator shall notify the driver of the vehicle that the rain sensor is ready to perform automatic wiping of the windshield upon detection of moisture.

This indicator shall be requested when all of the following are true

1. Power mode is RUN
2. If single steering column switch equipped: The front wiper switch is SENSITIVITY 1 through SENSITIVITY 5.
3. If dual steering column stalk equipped: The front wiper switch stalk angle is SENSITIVITY.

The above indicator shall be turned OFF when any of the following become true

1. Power mode becomes OFF, CRANK or ACCESSORY.
2. Front wiper switch is changed to OFF, MIST, LOW or HIGH.

WASH/WIPE SYSTEMS DTC INDEX

Electrical Information Reference

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Circuit/System Verification

Ignition ON, S80 Window Wiper/Washer Switch in the LOW position. Spray some water on the windshield. The wipers should operate at low speed.

Repair Instructions

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «WINDSHIELD OUTSIDE MOISTURE AND HEADLAMP AUTOMATIC CONTROL AMBIENT LIGHT SENSOR REPLACEMENT»(ref-653643-S26248207932014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for information on BCM replacement, setup, and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Ignition ON, S80 Window Wiper/Washer Switch in LOW position. Verify the front wipers are cycling at the low speed.

Ignition ON, S80 Window Wiper/Washer Switch in the HIGH position. Verify the front wipers are cycling at the high speed.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for BCM replacement, setup and programming.
2. «RELAY REPLACEMENT (ATTACHED TO WIRE HARNESS)»(ref-653659-S31726074922014090100000)

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for information on BCM replacement, setup, and programming
2. «WINDSHIELD WIPER MOTOR REPLACEMENT»(ref-653673-S13200676312014090100000)

Headlamp Washer

The Body Control Module (BCM) controls the washer motor based on an input from the windshield wiper washer switch. The BCM monitors the washer switch through the windshield washer switch signal circuit. When the WASH switch is closed, ground is supplied to the front washer switch signal circuit. When this is seen, the BCM will command the front washer fluid pump and the low speed wipers on. When Headlamp Wash Equipped, the headlamps shall be sprayed with wash fluid as a result of an extended Windshield Wash Switch Activation. In order to preserve wash fluid, the feature shall only be allowed to activate if the Low or High Beam Headlamps are active. In addition, after the initial Headlamp Wash operation has been performed, additional headlamp washes shall not be performed for the next 4 Windshield Wash activations or for 48 hours whichever comes first.

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Operate the washers using the S80 Window Wiper/Washer Switch. Verify the G16 Headlamp Washer Fluid Pump activates.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for information on BCM replacement, setup, and programming
2. «RELAY REPLACEMENT (ATTACHED TO WIRE HARNESS)»(ref-653659-S31726074922014090100000)

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Output Control Tests

Ignition ON, command the Windshield Washer Relay Command ON and OFF with a scan tool. Observe that the KR11 windshield washer pump relay clicks and the G24 windshield washer pump runs.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for information on BCM replacement, setup, and programming
2. «WINDSHIELD WASHER PUMP REPLACEMENT (SEDAN)»(ref-653673-S41810021062014090100000)

Symptoms - Wiper/Washer Systems

Note. The following steps must be completed before using the symptom tables.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The control module(s) can communicate via the serial data link.
2. Refer to «WIPER/WASHER SYSTEM DESCRIPTION AND OPERATION»(ref-653673-S41544303922014090100000) in order to familiarize yourself with the system functions.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. S80 Window Wiper/Washer Switch in the LOW position, verify the windshield wipers are cycling at low speed.
2. S80 Window Wiper/Washer Switch in the HIGH position, verify the windshield wipers are cycling at high speed.
3. S80 Window Wiper/Washer Switch in the INT position, cycling the delay adjustment switch from long delay to short delay. Verify the wiper delay time decreases from long delay to short delay as each delay position is selected. If equipped with Rain Sensor, spray some water on the windshield.

Multifunction Switch Malfunction

1. Ignition OFF, disconnect the X1 harness connector at the S80 Window Wiper/Washer Switch.
2. Ignition OFF, test for less than 5 ohms between the ground circuit terminal 2 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
4. If all circuits test normal, test or replace the S80 Window Wiper/Washer Switch.

Windshield Wiper Motor Malfunction

1. Ignition OFF, disconnect the KR12B Windshield Wiper Relay.
2. Test for less than 5 ohms between the ground circuit terminal 85 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Test for less than 5 ohms between the ground circuit terminal 87A and ground.
5. If greater than the specified range, test the ground circuit for an open/high resistance.
6. Ignition ON, verify a test lamp illuminates between the B+ circuit terminal 87 and ground.
7. If the test lamp does not illuminate, test or replace the X50A Fuse Block - Underhood.
8. Install a test lamp between the control circuit terminal 86 and the ground circuit terminal 85.
9. Using the S80 Window Wiper/Washer Switch, command the low speed wipers ON and OFF. The test lamp should turn ON and OFF, as commanded.
10. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the K9 Body Control Module.
11. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
12. Ignition OFF, disconnect the KR12C Windshield Wiper Speed Control Relay.
13. Test for less than 5 ohms between the control circuit terminal 30 at the KR12B Windshield Wiper Relay socket and the control circuit terminal 30 at the KR12C Windshield Wiper Speed Control Relay socket.
14. If greater than the specified range, replace the X50A Fuse Block - Underhood.
15. Connect the KR12B Windshield Wiper Relay.
16. Test for less than 5 ohms between the control circuit terminal 30 from the KR12C Windshield Wiper Speed Control Relay socket and ground.
17. If greater than the specified range, test or replace the KR12B Windshield Wiper Relay.
18. Ignition ON, verify a test lamp illuminates between the B+ circuit terminal 85 from the KR12C Windshield Wiper Speed Control Relay socket and ground.
19. If the test lamp does not illuminate, test or replace the X50A Fuse Block - Underhood.
20. Install a test lamp between the control circuit terminal 30 from the KR12C Windshield Wiper Speed Control Relay socket and ground.
21. Using the S80 Window Wiper/Washer Switch, command the low speed wipers ON. The test lamp should turn ON.
22. If the test lamp does not illuminate, replace the KR12B Windshield Wiper Relay.
23. Install a test lamp between the B+ circuit terminal from the KR12C Windshield Wiper Speed Control Relay socket and the control circuit terminal 86 from the KR12C Windshield Wiper Speed Control Relay socket.
24. Using the S80 Window Wiper/Washer Switch, command the high speed wipers ON and OFF. The test lamp should turn ON and OFF, as commanded.
25. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the K9 Body Control Module.
26. If the test lamp is always OFF, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
27. Ignition OFF, connect the KR12C Windshield Wiper Speed Control Relay. Disconnect the harness connector X1 at the M75 Windshield Wiper Motor.
28. Test for less than 5 ohms between the ground circuit terminal A and ground.
29. If greater than the specified range, test the ground circuit for an open/high resistance.
30. Connect a test lamp between the control circuit terminal D and ground.
31. Using the S80 Window Wiper/Washer Switch, command the low speed wipers ON and OFF. The test lamp should turn ON and OFF, as commanded.
32. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, test or replace the KR12C Windshield Wiper Speed Control Relay.
33. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, test or replace the KR12C Windshield Wiper Speed Control Relay
34. Connect a test lamp between the control circuit terminal C and ground.
35. Using the S80 Window Wiper/Washer Switch, command the high speed wipers ON and OFF. The test lamp should turn ON and OFF, as commanded.
36. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, test or replace the KR12C Windshield Wiper Speed Control Relay.
37. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, test or replace the KR12C Windshield Wiper Speed Control Relay.
38. Ignition ON, wipers OFF, test for greater than 11 V between the signal circuit terminal B and ground.
39. If less than 1 V, test the signal circuit for a short to ground or an open high resistance. If the circuit tests normal, replace the K9 Body Control Module.
40. If all circuits test normal, test or replace the M75 Windshield Wiper Motor.

1. Disconnect the harness connector at the S80 Window Wiper/Washer Switch.
2. With the S80 Window Wiper/Washer Switch in the HIGH position, test for less than 5 ohms between the terminal 2 and the signal terminal 1.
3. If greater than the specified value, replace the S80 Window Wiper/Washer Switch.
4. While cycling the S80 Window Wiper/Washer Switch through each delay and speed position, test for the specified resistance between the low reference terminal 2 and the signal terminal 3.

Note. If the switch tests open in any switch position other than OFF, test the signal circuits for a short to voltage before replacing the switch.

Wiper Switch Values

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for BCM replacement, setup and programming.
2. «WINDSHIELD WIPER AND WASHER SWITCH REPLACEMENT»(ref-653673-S08215343302014090100000)
3. «WINDSHIELD WIPER MOTOR REPLACEMENT»(ref-653673-S13200676312014090100000)
4. «RELAY REPLACEMENT (ATTACHED TO WIRE HARNESS)»(ref-653659-S31726074922014090100000)

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ignition ON, observe the scan tool Windshield Washer Switch parameter while activating the S80 Window Wiper/Washer Switch. The parameter should change between Active and Inactive.
2. If the value does not change, refer to «MULTIFUNCTION SWITCH MALFUNCTION»(ref-653673-S34265903612014090100000) .
3. Operate the windshield washer using the S80 Window Wiper/Washer Switch. Verify the G24 Windshield Washer Pump activates. Verify the washer fluid reservoir is filled up.
4. If the G24 Windshield Washer Pump does not run, refer to «WASHER PUMP MALFUNCTION»(ref-653673-S24626855002014090100000) .

1. Ignition OFF, disconnect the X3 harness connector at the K9 Body Control Module.
2. Test for less than 5 ohms between the ground circuit terminal 10 and the signal circuit terminal 25 while activating the wash function.
3. If greater than the specified value, test the signal circuit and the ground circuit for open circuit/high resistance. If the circuit tests normal, replace the S80 Window Wiper/Washer Switch.
4. If all circuits test normal, test or replace the K9 Body Control Module.

Washer Pump Malfunction

1. Ignition OFF, disconnect the harness connector X1 at the G24 Windshield Washer Pump.
2. Test for less than 5 ohms between the ground circuit terminal 2 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance. If all circuits test normal, replace the X50A Fuse Block - Underhood.
4. Ignition ON, verify a test lamp does not illuminate between the control circuit terminal 1 and the ground circuit terminal 2.
5. If the test lamp illuminates, test the control circuit for a short to voltage.
6. Verify a test lamp illuminates between the control circuit terminal 1 and the ground circuit terminal 2 while activating the wash function.
7. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance.

Ignition OFF, disconnect the Harness Connector at the S80 Window Wiper/Washer Switch. Test for less than 5 ohms between the Wiper/Washer Switch terminal 2 and 5 while activating the washer function.

1. Ignition OFF, disconnect the harness connector at the G24 Windshield Washer Pump.
2. Install a 10 A fused jumper wire between the control terminal 1 and 12 V. Install a jumper wire between the ground terminal 2 and ground.
3. Verify the G24 Windshield Washer Pump is activated.
4. If the G24 Windshield Washer Pump does not activate, replace the G24 Windshield Washer Pump.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for information on BCM replacement, setup, and programming
2. «WINDSHIELD WIPER AND WASHER SWITCH REPLACEMENT»(ref-653673-S08215343302014090100000)
3. «WINDSHIELD WASHER PUMP REPLACEMENT (SEDAN)»(ref-653673-S41810021062014090100000)
4. «WINDSHIELD WASHER SOLVENT LEVEL SENSOR REPLACEMENT»(ref-653673-S22004028202014090100000)
5. «FRONT COMPARTMENT FUSE BLOCK HOUSING REPLACEMENT»(ref-653659-S06570866752014090100000)

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Ignition ON, S80 Window Wiper/Washer Switch in the low position. Spray some water on the windshield. The windshield wipers should operate at low speed.

If the windshield wipers do not work, refer to information in WINDSHIELD WIPER SYSTEM MALFUNCTION

Rain Sensor Malfunction

1. Ignition OFF, disconnect the harness connector at the B117 Rain Sensor.
2. Test for less than 5 ohms between the ground circuit terminal 2 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Ignition ON, verify that a test lamp illuminates between B+ voltage circuit terminal 1 and ground.
5. If the test lamp does not illuminate, test the B+ voltage circuit for a short to ground or an open/high resistance.
6. Ignition ON, test for 4-12 V between the signal circuit terminal 3 and ground.
7. If less than the specified range, test the signal circuit for an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
8. If all circuits test normal, replace the B117 Rain Sensor.

Rain Sensor Indicator Malfunction

1. Ignition ON, command the Driver Information Center Segments test ON and OFF with the scan tool, verify that the rain sensor display reacts to ON and OFF positions.
2. If the rain sensor display stays always ON or always OFF, replace the P16 Instrument Cluster.
3. If the rain sensor display changes between ON and OFF, replace the K9 Body Control Module.

Perform the DIAGNOSTIC REPAIR VERIFICATION

1. «WINDSHIELD OUTSIDE MOISTURE AND HEADLAMP AUTOMATIC CONTROL AMBIENT LIGHT SENSOR REPLACEMENT»(ref-653643-S26248207932014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000)

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIPER/WASHER SYSTEM DESCRIPTION AND OPERATION»(ref-653673-S41544303922014090100000)

Operate the headlamp washer using the S80 Window Wiper/Washer Switch. Verify the G16 Headlamp Washer Fluid Pump activates. The low or high beam headlamps are ON.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for BCM replacement, setup and programming.
2. «RELAY REPLACEMENT (ATTACHED TO WIRE HARNESS)»(ref-653659-S31726074922014090100000)
3. «WINDSHIELD WIPER AND WASHER SWITCH REPLACEMENT»(ref-653673-S08215343302014090100000)
4. «HEADLAMP WASHER PUMP REPLACEMENT»(ref-653673-S09565906122014090100000)

Correction

1. 01 - Replacement
2. 02 - Removal - Refit
3. 03 - Renovate
4. 04 - Paint
5. 05 - Adjust
6. 06 - Change comp. unit
7. 07 - Lubricate - Clean - Polish
8. 08 - Check/Fault search
9. 09 - Expose
10. 10 - Install new
11. 11 - Transfer

Master Electrical Component List

Link to end views of connectors: COMPONENT CONNECTOR END VIEWS .

List of components

Scheme 25
