Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Air Nipple | 10 Nm | 88 lb in |
| Brake and Accelerator Pedal Assembly Fastener | 22 Nm | 16 lb ft |
| Brake Hose Fitting Bolt | 40 Nm | 30 lb ft |
| Brake Master Cylinder Nut | 50 Nm | 37 lb ft |
| Brake Pipe Fitting | 18 Nm | 13 lb ft |
| Heat Shield Assembly Fasteners | 9 Nm | 80 lb in |
| Master Cylinder Reservoir Bolt | 3, 5 Nm | 40 lb in |
| Power Brake Booster Vacuum Pump Nut | 10 Nm | 88 lb in |
| Power Vacuum Brake Booster Bolt | 19 Nm | 14 lb ft |
Scheme 1
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Brake Pedal Travel Without vacuum and pedal force 450 Nm (101 lb ft) Distance between (1) and (2) | 48-58 mm | 1.9-2.3 in |
