Z Trim Height
| Suspension | Service Preferred | Tolerance |
|---|---|---|
| FWD Standard (GNC) | 399-401 mm (15.7-15.8 in) | 20/+0 mm (-0.8/±0 in) |
| FWD Sport (GNC & XJ2) | 390-391 mm (15.3-15.4 in) | 20/+0 mm (-0.8/±0 in) |
| FWD Standard (GNE) | 400 mm (15.7 in) | 10/+10 mm (-0.4/±0.4 in) |
| AWD Sport (GNE & XJ2) | 10/+10 mm (-0.4/±0.4 in) | |
| FWD Sport (GNE & XJ2) | 390 mm (15.4 in) | 10/+10 mm (-0.4/±0.4 in) |
| Condition: Full tank, no passengers and placed on plane ground. NOTE: Vehicle tilting that has been determined due to different left and right trim heights must be compensated for by putting additional weights in the boot. The height difference between the left and right sides of the vehicle must not exceed 1 mm. | ||
| NOTE |
|---|
| Vehicle tilting that has been determined due to different left and right trim heights must be compensated for by putting additional weights in the boot. The height difference between the left and right sides of the vehicle must not exceed 1 mm. |
Suspension Control Module
The suspension control module controls the system functions and detects failures. The suspension control module receives input information by vertical acceleration sensors that are directly connected to the module and by other systems through the serial data line. The suspension control module commands variable levels of current to each shock absorber actuator.
Vertical Acceleration Sensors
The suspension control module supplies a common 5 V reference and a ground circuit to each of the five vertical acceleration sensor. The vertical acceleration sensors supply a signal of 0.5-4.5 V to the suspension control module.
The three body vertical acceleration sensors are mounted left front, right front and rear. The two front wheel vertical acceleration sensors are mounted at the strut.
Shock Absorber Actuators
The shock absorber actuators are integrated within the shock absorbers. The electronic suspension control system uses a proportional valve that is located in the external bypass of the displacement module.
Adjustment is performed by current control. The current consumption is 0-1.8 A. The actuators respond to commands of the suspension control module within milliseconds.
Driver Information Center Message
The electronic suspension control system does not have a malfunction indicator, but uses the instrument cluster for the display functions instead. When the suspension control module detects a fault that sets a DTC, it sends a message on the serial data line to the instrument cluster, which will display the following message
SERVICE SUSPENSION SYSTEM
The suspension control module has the ability to store DTCs as current or history codes. Most electronic suspension control system malfunctions will display a message in the instrument cluster and set a DTC. As long as the DTC is present, the message will be displayed.
The suspension control module uses an ignition cycling diagnostic approach. Actions taken when a fault is detected will remain until the ignition is turned OFF, even if the fault condition is not present anymore.
If a fault is no longer present, the DTC will be stored as a history code. After 41 consecutive malfunction-free ignition cycles the DTC will be deleted.
Vehicle Leads/Pulls
| Step | Action | Yes | No |
|---|---|---|---|
| DEFINITION: At a constant highway speed on a typical straight road, lead/pull is the amount of effort required at the steering wheel to maintain the vehicle straight path. IMPORTANT: Vehicles will tend to lead/pull in the direction of the road slope as part of normal operation. | |||
| 1 | Did you review the General Description and perform the visual/physical inspections? | Go to Step 2 | Go to SYMPTOMS - SUSPENSION GENERAL DIAGNOSIS |
| 2 | Road test the vehicle in order to verify the complaint. Does the vehicle operate normally? | System OK | Go to Step 3 |
| 3 | Inspect the tire/wheel assemblies for: Correct tire pressure-Refer to the tire placard. Correct tire size-Refer to the tire placard. Abnormal tire wear or damage Did you find and correct the condition? | Go to Step 9 | Go to Step 4 |
| 4 | Inspect and correct/adjust the suspension and steering systems for: Vehicle trim height-Refer to TRIM HEIGHT SPECIFICATIONS . Excessively worn, loose, or damaged components Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 5 | Inspect the brake system for brake drag. With the vehicle suspended on a hoist, brake drag can be identified by rotating each wheel several times and observing whether more force is needed to rotate the left wheel or the right wheel. Did you find and correct the condition? | Go to Step 9 | Go to Step 7 |
| 6 | Inspect the wheel alignment and adjust as necessary. Refer to WHEEL ALIGNMENT MEASUREMENT . Did you correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Inspect the steering gear for unequal effort. The vehicle must be suspended on a hoist, the engine running, and the transmission in park or neutral. Grasp the tire assembly and manually simulate a turn from the left of center and the right of center observing whether more force is needed to turn to the left or to the right. If this condition exists, replace the steering gear. Re-calibrate the steering position and torque sensors if the vehicle is equipped with programmable electronic power steering (EPS). Refer to CONTROL MODULE REFERENCES . Did you correct the condition? | System OK | Go to Step 3 |
| 8 | Drive the vehicle in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
| IMPORTANT |
|---|
| Vehicles will tend to lead/pull in the direction of the road slope as part of normal operation. |
Body Leans or Sways in Corners
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Did you review the General Description and perform the necessary inspections? | Go to Step 2 | Go to SYMPTOMS - SUSPENSION GENERAL DIAGNOSIS |
| 2 | Verify the vehicle leans or sways in corners. Does the vehicle operate normally? | System OK | Go to Step 3 |
| 3 | Inspect the following components for wear or damage: Rear coil springs Front coil springs Are the components worn or damaged? | Go to Step 5 | Go to Step 4 |
| 4 | Inspect the stabilizer shaft link for wear or damage. Repair as required. Did you find and correct the condition? | Go to Step 6 | Go to Step 2 |
| 5 | Replace the springs as necessary. Did you complete the repair? | Go to Step 6 | |
| 6 | Drive the vehicle in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Suspension Bottoms
| Step | Action | Yes | No |
|---|---|---|---|
| DEFINITION: A loud bang or thump that can usually be felt and/or heard when the vehicle is driven over bumps. This condition is commonly noticed when the vehicle trim height is too low. | |||
| 1 | Did you review the General Description and perform the necessary inspections? | Go to Step 2 | Go to SYMPTOMS - SUSPENSION GENERAL DIAGNOSIS |
| 2 | Verify that the suspension bottoms. Does the vehicle operate normally? | System OK | Go to Step 3 |
| 3 | Inspect for vehicle overloading and correct the overloading condition as necessary. Refer to VEHICLE CERTIFICATION, TIRE PLACARD, ANTI-THEFT, AND SERVICE PARTS ID LABEL for specifications. Did you find and correct the condition? | Go to Step 6 | Go to Step 4 |
| 4 | Inspect the following components: Inspect the shock absorbers. Refer to SUSPENSION STRUT AND SHOCK ABSORBER TESTING - ON VEHICLE Inspect for damaged coil springs, torsion bar or leaf springs and replace as necessary. Did you find and correct the condition? | Go to Step 6 | Go to Step 5 |
| 5 | Inspect the vehicle trim height. Refer to TRIM HEIGHT INSPECTION . Did you complete the trim height inspection procedure? | Go to Step 6 | |
| 6 | Drive the vehicle in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
Memory Steer
| Step | Action | Yes | No |
|---|---|---|---|
| DEFINITION: A lead or pull in the direction the driver previously turned the vehicle. Additionally, after turning in the opposite direction, the vehicle will want to lead or pull in that direction. | |||
| 1 | Did you review the General Description and perform the necessary inspections? | Go to Step 2 | Go to SYMPTOMS - SUSPENSION GENERAL DIAGNOSIS |
| 2 | Verify that memory steer is present. Does the system operate normally? | System OK | Go to Step 3 |
| 3 | Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE . Lubricate the tie rod ends and the ball joints if applicable. Inspect the suspension system for worn or damaged components. Repair as required. Did you find and correct the condition? | Go to Step 7 | Go to Step 4 |
| 4 | Inspect for binding strut bearings. Disconnect the strut from the steering knuckle. If the strut is abnormally difficult to rotate, repair or replace the upper bearing mount. Did you find and complete the repair? | Go to Step 7 | Go to Step 5 |
| 5 | Inspect for binding in the lower ball joints. If joint is binding, replace the joint. Did you find and complete the repair? | Go to Step 7 | Go to Step 6 |
| 6 | Inspect the wheel alignment and adjust as necessary. Refer to WHEEL ALIGNMENT MEASUREMENT . Did you complete the wheel alignment? | Go to Step 7 | |
| 7 | Drive the vehicle in order to verify the repair. Did you correct the condition? | System OK | |
| DTC | Description |
|---|---|
| DTC C0000 | Vehicle Speed Information Circuit Invalid Data |
| DTC C0575 | Left Front Damper Actuator Circuit |
| DTC C0580 | Right Front Damper Actuator Circuit |
| DTC C0585 | Left Rear Damper Actuator Circuit |
| DTC C0590 | Right Rear Damper Actuator Circuit |
| DTC C0595 | Left Front Acceleration Sensor Circuit |
| DTC C0600 | Right Front Acceleration Sensor Circuit |
| DTC C0605 | Left Rear Acceleration Sensor Circuit |
| DTC C0670 | Left Front Acceleration or Position Sensor Circuit |
| DTC C0675 | Right Front Acceleration or Position Sensor Circuit |
| DTC C0720 | Engine Torque Management Feedback Signal Invalid Data |
| DTC C0870 | Control Module Voltage Reference Output Circuit |
ELECTRONIC CHASSIS CONTROL DTC INDEX
Electrical Information Reference
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Circuit/System Verification
Ignition ON, observe the scan tool EBCM Wheel Speed Sensor parameters. The reading should be the same speed on all sensors when driving in a straight line at a speed greater than 20 km/h (13 MPH).
Repair Instructions
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure. CONTROL MODULE REFERENCES for control module replacement, setup and programming
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Ignition ON, command the Damper Actuator Increase and Decrease with a scan tool while observing the Damper Actuator Command parameter. The reading should vary between 0-1 600 mA. Listen/feel the damper actuator. The component should activate when changing between the commanded states.
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «STRUT, STRUT COMPONENT, OR SPRING REPLACEMENT»(ref-653655-S20655703192014090100000)
- «SHOCK ABSORBER REPLACEMENT (GNC)»(ref-653665-S42297137832014090100000) «SHOCK ABSORBER REPLACEMENT (GNE)»(ref-653665-S17980671432014090100000)
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for suspension control module replacement, setup, and programming
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Ignition ON, observe the scan tool Vertical Body Acceleration parameters. The readings should be 0 m/s 2 .
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «ELECTRONIC SUSPENSION FRONT VERTICAL ACCELEROMETER REPLACEMENT - UPPER»(ref-653640-S19882376002014090100000)
- «ELECTRONIC SUSPENSION REAR POSITION SENSOR REPLACEMENT»(ref-653640-S08918209202014090100000)
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for suspension control module replacement, setup, and programming
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Ignition ON, observe the scan tool Vertical Wheel Acceleration parameters. The readings should be 0 m/s 2 when the vehicle is parked on a level surface.
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «ELECTRONIC SUSPENSION FRONT VERTICAL ACCELEROMETER REPLACEMENT - LOWER»(ref-653640-S25713708862014090100000)
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for suspension control module replacement, setup, and programming
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
CONTROL MODULE REFERENCES for control module replacement, setup and programming
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Ignition ON, observe the scan tool Suspension Position Sensor 5 V Reference parameter. The reading should be 5 V.
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «ELECTRONIC SUSPENSION FRONT VERTICAL ACCELEROMETER REPLACEMENT - UPPER»(ref-653640-S19882376002014090100000)
- «ELECTRONIC SUSPENSION FRONT VERTICAL ACCELEROMETER REPLACEMENT - LOWER»(ref-653640-S25713708862014090100000)
- «ELECTRONIC SUSPENSION REAR POSITION SENSOR REPLACEMENT»(ref-653640-S08918209202014090100000)
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for suspension control module replacement, setup, and programming
Suspension System Mode
| Circuit | Short to Ground | Open | Short to Voltage |
|---|---|---|---|
| Operating Conditions: Engine running, normal operating temperature Parameter Normal Range: Comfort/Sport Mode/Normal/Hard | |||
| Sport Mode Switch Signal Circuit | Undefined | Undefined | |
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
- Verify no communication related DTC is set.
- If any communication DTC is set, diagnose those first.
- Ignition ON, observe the scan tool Suspension System Mode parameter while switching one after the other sport mode, comfort mode and intelligent mode. Verify the reading changes between Normal/Comfort/Sport/Hard.
- If the parameter does not change between the specified values, go to «CIRCUIT/SYSTEM TESTING»(ref-653640-S35460878972014090100000) .
- Observe the sport mode LED, comfort mode LED and intelligent mode LED while switching one after the other sport mode, comfort mode and intelligent mode. The appropriate LED and the tour mode LED should turn ON and OFF.
- If the LED does not change between the specified values, go to «CIRCUIT/SYSTEM TESTING»(ref-653640-S35460878972014090100000) .
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «SPORT MODE SWITCH REPLACEMENT»(ref-653642-S32049141402014090100000)
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for BCM replacement, setup and programming
Symptoms - Suspension General Diagnosis
Note. The following steps must be completed before using the symptom tables.
Review the system description and operation in order to familiarize yourself with the system functions. Refer to the appropriate description and operation
- «GENERAL DESCRIPTION (GNA)»(ref-653655-S36883659772014090100000) or «GENERAL DESCRIPTION (GNB)»(ref-653655-S34317004292014090100000) for the front suspension
- «GENERAL DESCRIPTION»(ref-653636-S38151325352014090100000) for tires and wheels
Trim Height Measurement
Trim height is a predetermined measurement relating to vehicle ride height. Incorrect trim heights can cause the vehicle to bottom out over bumps, damage to the suspension components, and symptoms similar to wheel alignment problems. Check the trim heights when diagnosing suspension concerns and before checking the wheel alignment.
Perform the following before measuring the trim heights
- Set the tire pressure to the specifications shown on the certification label. Refer to «VEHICLE CERTIFICATION, TIRE PLACARD, ANTI-THEFT, AND SERVICE PARTS ID LABEL»(ref-653635-S11706836282014090100000) .
- Check the fuel level. Add additional weight if necessary to simulate a full tank.
- Make sure the passenger and rear compartments are empty except for the spare tire.
- Make sure the vehicle is on a flat and level surface such as an alignment rack.
- Check that all the vehicle doors are securely closed.
- Check that the vehicle hood and rear deck lids are securely closed.
- Check for after market accessories or modifications that could affect trim height measurement.
Z Height Measurement
Use the following procedure to check the Z dimension
Scheme 6
- Lift the rear bumper of the vehicle up about 38 mm (1.5 in).
- Gently remove your hands and let the vehicle settle.
- Repeat this operation 2 more times for a total of 3.
- Z height is measured vertically from the rear axle center point to the bottom lip of the wheel opening.
- Push the rear bumper of the vehicle down about 38 mm (1.5 in).
- Gently remove your hands and let the vehicle settle.
- Repeat this operation 2 more times for a total of 3.
- Measure the Z height as in step 4.
- The true Z height measurement is the average of the measurements taken in step 4 and 8. Refer to «TRIM HEIGHT SPECIFICATIONS»(ref-653640-S23568320712014090100000) for correct value.
Time studies - Suspension, rear
| Object code - ID | Description | Condition | Variant | Model year | Correction | Pos | Time (hrs) |
|---|---|---|---|---|---|---|---|
| 73211-01 | Spring | 2010 | 01 | 05 | 0.6 | ||
| 73211-02 | Spring | 2010 | 01 | 0304 | 0.3 | ||
| 73211-03 | Spring | 4WD | 2010 | 01 | 05 | 0.5 | |
| 73212-01 | Spring support, lower | Both sides | 2010 | 01 | 0608 | 0.6 | |
| 73212-02 | Spring support, lower | Both sides | 4WD | 2010 | 01 | 0608 | 1.0 |
| 73212-03 | Spring support, lower | One side | 2010 | 01 | 0608 | 0.3 | |
| 73212-04 | Spring support, lower | One side | 4WD | 2010 | 01 | 0608 | 0.5 |
| 76115-01 | Sensor CDC system | 2010 | 01 | 02 | 0.1 | ||
| 76115-02 | Sensor CDC system | 2010 | 01 | 0108 | 0.1 | ||
| 76115-03 | Sensor CDC system | 2010 | 01 | 0106 | 0.1 | ||
| 76116-01 | Electronic unit, CDC | 2010 | 01 | 0.3 | |||
| 76117-01 | Bracket, electronic unit, CDC | 2010 | 01 | 0.1 | |||
| 76131-01 | Shock absorber, rear | 2010 | 01 | 05 | 0.4 | ||
| 76131-02 | Shock absorber, rear | 2010 | 01 | 0304 | 0.2 | ||
| 76214-01 | Link | 2010 | 01 | 0304 | 0.2 | ||
| 76214-02 | Link | 4WD | 2010 | 01 | 0304 | 0.3 | |
| 76220-01 | Antiroll bar, rear | 4WD | 2010 | 01 | 0.6 | ||
| 76220-02 | Antiroll bar, rear | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 1.4 | ||
| 76223-01 | Rubber bushing, clamp, rear | 4WD | 2010 | 01 | 0.9 | ||
| 76223-02 | Rubber bushing, clamp, rear | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 1.6 | ||
| 76250-04 | Rear axle, comp. | 4WD | 2010 | 02 | 1.4 | ||
| 76251-01 | Rear axle tube | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 2.1 | ||
| 76251-02 | Rear axle tube | Measure wheel angles, 4-wheel measurement not included | 4WD | 2010 | 01 | 4.3 | |
| 76251-03 | Rear axle tube | Measure wheel angles, 4-wheel measurement not included | A20NHT/A20NFT, FWD | 2010 | 01 | 3.2 | |
| 76253-01 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNC FWD | 2010 | 01 | 0508 | 0.8 |
| 76253-02 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 0508 | 2.0 |
| 76253-03 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNC FWD | 2010 | 01 | 030408 | 0.4 |
| 76253-04 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 030408 | 1.0 |
| 76253-05 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE FWD | 2010 | 01 | 030408 | 0.9 |
| 76253-06 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE FWD | 2010 | 01 | 0508 | 1.9 |
| 76253-07 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 0506 | 0.7 |
| 76253-08 | Transverse link | GNC FWD | 2010 | 01 | 0506 | 1.2 | |
| 76253-09 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 030406 | 0.4 |
| 76253-10 | Transverse link | GNC FWD | 2010 | 01 | 030406 | 0.6 | |
| 76253-11 | Transverse link | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 030406 | 0.4 |
| 76253-12 | Transverse link | Toe-in link, Measure wheel angles, 4-wheel measurement not included | GNC | 2010 | 01 | 0304 | 0.3 |
| 76253-13 | Transverse link | Toe-in link, Measure wheel angles, 4-wheel measurement not included | GNE | 2010 | 01 | 0304 | 0.4 |
| 76254-01 | Bush, subframe | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 05 | 3.0 |
| 76254-02 | Bush, subframe | Measure wheel angles, 4-wheel measurement not included | GNE FWD | 2010 | 01 | 05 | 2.4 |
| 76256-01 | Longitudinal link | 2010 | 01 | 05 | 0.5 | ||
| 76256-02 | Longitudinal link | 2010 | 01 | 0304 | 0.3 | ||
| 76258-01 | Bush, longitudinal link | GNC FWD | 2010 | 01 | 05 | 0.7 | |
| 76258-02 | Bush, longitudinal link | GNC FWD | 2010 | 01 | 0304 | 0.3 | |
| 76263-01 | Steering swivel member | GNC FWD | 2010 | 01 | 05 | 2.0 | |
| 76263-02 | Steering swivel member | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 05 | 2.9 |
| 76263-03 | Steering swivel member | GNC FWD | 2010 | 01 | 0304 | 1.0 | |
| 76263-04 | Steering swivel member | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 0304 | 1.5 |
| 76263-05 | Steering swivel member | GNC FWD | 2010 | 01 | 0304 | 1.0 | |
| 76263-06 | Steering swivel member | Measure wheel angles, 4-wheel measurement not included | GNE 4WD | 2010 | 01 | 0304 | 1.5 |
Correction
- 01 - Replacement
- 02 - Removal - Refit
- 03 - Renovate
- 04 - Paint
- 05 - Adjust
- 06 - Change comp. unit
- 07 - Lubricate - Clean - Polish
- 08 - Check/Fault search
- 09 - Expose
- 10 - Install new
- 11 - Transfer
Master Electrical Component List
Link to end views of connectors: COMPONENT CONNECTOR END VIEWS
| Code | Name | Option | Location | Locator View |
|---|---|---|---|---|
| A10 | Inside Rearview Mirror | In the passenger compartment, mounted to top center of windshield | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| A11 | Radio | In the passenger compartment, on the center of the instrument panel, above the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| A12 | Digital Radio Receiver Control Module | U2K or UBT | In the passenger compartment behind the center of the Instrument Panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| A13 | Rear Audio Control Module | ULD | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| A20 | Radio/HVAC Controls | In the passenger compartment, in the center console, below of the radio controls | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| A23D | Door Latch Assembly - Driver | In the passenger compartment, at the rear of the driver door | DOOR COMPONENT VIEWS | |
| A23LR | Door Latch Assembly - Left Rear | In the passenger compartment, at the rear of the left rear door | DOOR COMPONENT VIEWS | |
| A23P | Door Latch Assembly - Passenger | In the passenger compartment, at the rear of the passenger door | DOOR COMPONENT VIEWS | |
| A23RR | Door Latch Assembly - Right Rear | In the passenger compartment, at the rear of the right rear door | DOOR COMPONENT VIEWS | |
| A25A | Glow Plug/Pressure Sensor Cylinder 1 Assembly | LBS | In the engine compartment on top of the engine near the number 1 cylinder | POWERTRAIN COMPONENT VIEWS |
| A25B | Glow Plug/Pressure Sensor Cylinder 2 Assembly | LBS | In the engine compartment on top of the engine near the number 2 cylinder | POWERTRAIN COMPONENT VIEWS |
| A25C | Glow Plug/Pressure Sensor Cylinder 3 Assembly | LBS | In the engine compartment on top of the engine near the number 3 cylinder | POWERTRAIN COMPONENT VIEWS |
| A25D | Glow Plug/Pressure Sensor Cylinder 4 Assembly | LBS | In the engine compartment on top of the engine near the number 4 cylinder | POWERTRAIN COMPONENT VIEWS |
| A7 | Fuel Pump and Level Sensor Assembly | Under the vehicle, in the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| A9A | Outside Rearview Mirror - Driver | Left side of the vehicle, on the outside of the driver door | DOOR COMPONENT VIEWS | |
| A9B | Outside Rearview Mirror - Passenger | Right side of the vehicle, on the outside of the passenger door | DOOR COMPONENT VIEWS | |
| B1 | A/C Refrigerant Pressure Sensor | At front of vehicle, at right side of condenser | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B10B | Ambient Light/Sunload Sensor | In the passenger compartment, in the center instrument panel speaker grill | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B107 | Accelerator Pedal Position Sensor | In the passenger compartment, below the instrument panel on the driver side, mounted to the top of the accelerator pedal assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B108 | Air Quality Sensor | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B116 | Water in Fuel Sensor | LBS | Under the vehicle, in the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B117 | Rain Sensor | CE1 | Top center of the windshield | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| B119 | Multi-Axis Acceleration Sensor | In the passenger compartment, mounted to the floor, under floor console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B12A | Transmission Fluid Pressure Manual Valve Position Switch | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B129 | Cruise Control Vehicle Distance Sensor Module | KSG | At front of vehicle, behind grille | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B13 | Transmission Fluid Temperature Sensor | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B14A | Transmission Output Shaft Speed Sensor | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B14C | Transmission Input Shaft Speed Sensor | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B15 | Transmission Internal Mode Switch | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B150 | Fuel Tank Pressure | NT7 | Under the rear of the vehicle, on top of the fuel tank, mounted to the fuel pump and sender assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B150 | Fuel Tank Pressure | NU6 | Under the rear of the vehicle, on top of the fuel tank, mounted to the fuel pump and sender assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B153D | Seat Belt Buckle - Driver | In the passenger compartment, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B153P | Seat Belt Buckle - Passenger | In the passenger compartment, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B16 | Backup Lamp Switch | MR6 or MK6 | Front of the transmission | POWERTRAIN COMPONENT VIEWS |
| B160 | Windscreen Temperature and Inside Moisture Sensor | ASV | Top center of the windshield | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| B161LF | Vertical Suspension Acceleration Sensor - Left Front | F45 | Near the top of the left front steering knuckle | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B161RF | Vertical Suspension Acceleration Sensor - Right Front | F45 | Near the top of the right front steering knuckle | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B162LF | Vertical Body Acceleration Sensor - Left Front | F45 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B162R | Vertical Body Acceleration Sensor - Rear | F45 | In the rear compartment, rearward of left rear seat | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B162RF | Vertical Body Acceleration Sensor - Right Front | F45 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B166LF | Parking Aid Side Sensor - Left Front | UD5 or UDP | At front of vehicle, mounted to front bumper cover, on left side | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B166RF | Parking Aid Side Sensor - Right Front | UD5 or UDP | At front of vehicle, mounted to front bumper cover, on right side | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B18 | Battery Current Sensor | At front of vehicle, mounted to battery (-) cable | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B19B | Brake Booster Vacuum Sensor | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B19C | Brake Booster Vacuum Switch | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B5LF | Wheel Speed Sensor - Left Front | Mounted to the left front steering knuckle assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B5LR | Wheel Speed Sensor - Left Rear | Mounted to the left rear upper control arm | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B5RF | Wheel Speed Sensor - Right Front | Mounted to the right front steering knuckle assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B5RR | Wheel Speed Sensor - Right Rear | Mounted to the right rear upper control arm | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B7B | Air Temperature Sensor - Duct Lower | In the passenger compartment, mounted to the HVAC module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B7F | Air Temperature Sensor - Duct Upper | In the passenger compartment, mounted to the HVAC module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B9 | Ambient Air Temperature Sensor | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B20 | Brake Fluid Level Switch | At front of vehicle, mounted to brake fluid reservoir | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B22 | Brake Pedal Position Sensor | In the passenger compartment, below the instrument panel, in the driver side footwell, near the top of the accelerator pedal assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B23A | Camshaft Position Sensor - Bank 1 Exhaust | LAU | Rear of the engine, left side of the engine block | POWERTRAIN COMPONENT VIEWS |
| B23B | Camshaft Position Sensor - Bank 1 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| B23C | Camshaft Position Sensor - Bank 2 Exhaust | LAU | Rear of the engine, at the right side | POWERTRAIN COMPONENT VIEWS |
| B23D | Camshaft Position Sensor - Bank 2 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| B23E | Camshaft Position Sensor - Exhaust | LDK | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B23F | Camshaft Position Sensor - Intake | LDK | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B23 | Camshaft Position Sensor | LBS | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B24 | Cellular Phone Microphone | UE1 or UPH or UPJ | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B25B | Clutch Pedal Position Sensor | MR6 or MK6 | In the passenger compartment, below the instrument panel, in the driver side footwell, near the top of the clutch pedal assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| B26 | Crankshaft Position Sensor | In the engine compartment, on the lower left front of the engine | POWERTRAIN COMPONENT VIEWS | |
| B27A | Door Handle Switch - Driver Exterior | ATH | In the passenger compartment, at the driver door handle | DOOR COMPONENT VIEWS |
| B27B | Door Handle Switch - Passenger Exterior | ATH | In the passenger compartment, at the passenger door handle | DOOR COMPONENT VIEWS |
| B27E | Door Handle Switch - Driver Interior | ATH | On the driver door, trim panel | DOOR COMPONENT VIEWS |
| B27F | Door Handle Switch - Passenger Interior | ATH | On the passenger door, trim panel | DOOR COMPONENT VIEWS |
| B27LR | Door Handle Switch - Left Rear Exterior | ATH | In the passenger compartment, at the left rear door handle | DOOR COMPONENT VIEWS |
| B27RR | Door Handle Switch - Right Rear Exterior | ATH | In the passenger compartment, at the right rear door handle | DOOR COMPONENT VIEWS |
| B34 | Engine Coolant Temperature Sensor | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS | |
| B35B | Engine Oil Level Sensor | Bottom center of the engine oil pan | POWERTRAIN COMPONENT VIEWS | |
| B37B | Engine Oil Pressure Sensor | Front right side of the engine | POWERTRAIN COMPONENT VIEWS | |
| B46A | Fuel Level Sensor - Primary | LAU or LDK | Under the vehicle, on top of the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B46B | Fuel Level Sensor - Secondary | F46 | Under the vehicle, on top of the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B47B | Fuel Rail Pressure Sensor | LBS or LDK | Top of the engine | POWERTRAIN COMPONENT VIEWS |
| B47 | Fuel Pressure Sensor | LAU or LDK | Under the vehicle, on top of the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B48 | Fuel Temperature Sensor | LBS | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B51F | Headlamp Leveling Sensor - Front | TR7 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B51R | Headlamp Leveling Sensor - Rear | TR7 | In the rear compartment, rearward of left rear seat | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B52A | Heated Oxygen Sensor 1 | LAU or LDK | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B52B | Heated Oxygen Sensor 2 | LAU or LDK | Middle rear of the engine | POWERTRAIN COMPONENT VIEWS |
| B52 | Heated Oxygen Sensor | LBS | Center rear of the engine compartment, on the rear exhaust manifold | POWERTRAIN COMPONENT VIEWS |
| B55 | Bonnet Switch | UTJ | At front of vehicle, part of the hood latch | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B59L | Front Impact Sensor - Left | At front of vehicle, mounted to the radiator support, left of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B59R | Front Impact Sensor - Right | At front of vehicle, mounted to the radiator support, right of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B59 | Front Impact Sensor | At front of vehicle, mounted to the radiator support, near center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B60 | Passenger Presence Detection Sensor | UH0 or UH1 | In the passenger compartment, part of the passenger presence detection module, in the passenger seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B63L | Side Impact Sensor - Left | In the passenger compartment, at base of left b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63LF | Side Impact Sensor - Left Front | In the passenger compartment, at base of left b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63LR | Side Impact Sensor - Left Rear | AW7 | In the passenger compartment, at base of left c-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B63R | Side Impact Sensor - Right | In the passenger compartment, at base of right b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63RF | Side Impact Sensor - Right Front | In the passenger compartment, at base of right b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63RR | Side Impact Sensor - Right Rear | AW7 | In the passenger compartment, at base of right c-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B65 | Intake Manifold Pressure and Air Temperature Sensor | Right front top side of the intake manifold | POWERTRAIN COMPONENT VIEWS | |
| B67 | Ultrasonic Intrusion Sensor | UTV | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B68A | Knock Sensor 1 | LAU or LDK | In the engine compartment, on the front middle of the engine block | POWERTRAIN COMPONENT VIEWS |
| B68B | Knock Sensor 2 | LAU or LDK | In the engine compartment, on the front middle of the engine block | POWERTRAIN COMPONENT VIEWS |
| B74 | Manifold Absolute Pressure Sensor | LDK | On the engine, at the top left front | POWERTRAIN COMPONENT VIEWS |
| B75B | Mass Air Flow/Intake Air Temperature Sensor | LBS or LDK | On the top right side of the engine, at the air cleaner | POWERTRAIN COMPONENT VIEWS |
| B75 | Mass Air Flow Sensor | LAU | On the top right side of the engine, at the air cleaner | POWERTRAIN COMPONENT VIEWS |
| B78A | Front Object Sensor - Left Outer | UD5 or UDP | At front of vehicle, mounted to front bumper cover, at left corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78B | Front Object Sensor - Right Outer | UD5 or UDP | At front of vehicle, mounted to front bumper cover, at right corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78C | Front Object Sensor - Left Middle | UD5 or UDP | At front of vehicle, mounted to front bumper cover, left of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78D | Front Object Sensor - Right Middle | UD5 or UDP | At front of vehicle, mounted to front bumper cover, right of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78E | Rear Object Sensor - Left Middle | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, left of center | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B78F | Rear Object Sensor - Right Middle | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, right of center | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B78G | Rear Object Sensor - Left Outer | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, at left corner | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B78H | Rear Object Sensor - Right Outer | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, at right corner | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B80 | Park Brake Switch | Under the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B87 | Rearview Camera | UVC | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B88D | Seat Belt Switch - Driver | In the passenger compartment, part of the seat belt buckle - driver, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B88LR | Seat Belt Switch - Left Rear | UH5 | In the passenger compartment, part of the seat belt buckle - left rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B88MR | Seat Belt Switch - Rear Middle | UH5 | In the passenger compartment, part of the seat belt buckle - rear middle, mounted to the seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B88P | Seat Belt Switch - Passenger | In the passenger compartment, part of the seat belt buckle - passenger, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B88RR | Seat Belt Switch - Right Rear | UH5 | In the passenger compartment, part of the seat belt buckle - right rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B94L | Side Object Sensor - Left | UFT | At the rear of vehicle, mounted behind left side of rear bumper cover | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B94R | Side Object Sensor - Right | UFT | At the rear of vehicle, mounted behind right side of rear bumper cover | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B99 | Steering Wheel Angle Sensor | In the steering column, behind the inflatable restraint steering wheel module coil | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| C1 | Battery | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| C3 | Telematics Communication Interface Control Module Battery | UE1 | In the passenger compartment, rear of the vehicle, at the center of the rear window shelf | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E1C | Accent Lamp - Driver Door Handle | In the passenger compartment, in the driver door trim panel, below the armrest | DOOR COMPONENT VIEWS | |
| E1D | Accent Lamp - Driver Door | TSQ | In the passenger compartment, in the driver door trim panel, near the inside door handle | DOOR COMPONENT VIEWS |
| E1E | Accent Lamp - Left Rear Door Handle | TSQ | In the passenger compartment, mounted to the left rear door panel, near the door handle | DOOR COMPONENT VIEWS |
| E1F | Accent Lamp - Right Rear Door Handle | TSQ | In the passenger compartment, mounted to the right rear door panel, near the door handle | DOOR COMPONENT VIEWS |
| E1J | Accent Lamp - Left Lower Instrument Panel | TSQ | In the passenger compartment, on the left side, below of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E1K | Accent Lamp - Right Lower Instrument Panel | TSQ | In the passenger compartment, on the right side, below of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E1LR | Accent Lamp - Left Rear Door | TSQ | In the passenger compartment, in the left rear door trim panel, below the armrest | DOOR COMPONENT VIEWS |
| E1M | Accent Lamp - Passenger Door Handle | In the passenger compartment, in the passenger door trim panel, below the armrest | DOOR COMPONENT VIEWS | |
| E1P | Accent Lamp - Passenger Door | TSQ | In the passenger compartment, in the passenger door trim panel, near the inside door handle | DOOR COMPONENT VIEWS |
| E1RR | Accent Lamp - Right Rear Door | TSQ | In the passenger compartment, in the right rear door trim panel, below the armrest | DOOR COMPONENT VIEWS |
| E13L | Headlamp - Left | At front of vehicle, at left corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E13R | Headlamp - Right | At front of vehicle, at right corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E14A | Seat Heating Element - Driver Back | KA1 | In the passenger compartment, driver seat back cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E14B | Seat Heating Element - Driver Cushion | KA1 | In the passenger compartment, driver seat cushion cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E14C | Seat Heating Element - Passenger Back | KA1 | In the passenger compartment, passenger seat back cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E14D | Seat Heating Element - Passenger Cushion | KA1 | In the passenger compartment, passenger seat cushion cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E18 | Rear Defogger Grid | At the rear of vehicle, part of rear window | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E19 | Coolant Heater | LBS | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E2LF | Side Marker Lamp - Left Front | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E2LR | Side Marker Lamp - Left Rear | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E2RF | Side Marker Lamp - Right Front | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E2RR | Side Marker Lamp - Right Rear | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E27 | Instrument Panel Compartment Lamp | In the passenger compartment, inside the instrument panel compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E28 | Centre Console Compartment Lamp | In the passenger compartment, inside the center console compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E29LF | Fog Lamp - Left Front | T96 | At front of vehicle, below headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E29R | Fog Lamp - Rear | T79 | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| E29RF | Fog Lamp - Right Front | T96 | At front of vehicle, below headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E31LF | Sunshade Mirror Lamp - Left Front | In the passenger compartment, in the left front sunshade | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E31RF | Sunshade Mirror Lamp - Right Front | In the passenger compartment, in the right front sunshade | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E32 | Cigarette Lighter Receptacle | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E37F | Dome/Reading Lamps - Front | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E37M | Dome/Reading Lamps - Middle | In the passenger compartment, mounted to the headliner above rear seats | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E4C | Daytime Running Lamp - Left | TR7 | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E4D | Daytime Running Lamp - Right | TR7 | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E4E | Headlamp - Left High Beam | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4F | Headlamp - Right High Beam | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4G | Headlamp - Left Low Beam | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4H | Headlamp - Right Low Beam | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4J | Park Lamp - Left Front | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4K | Park Lamp - Right Front | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4LF | Turn Signal Lamp - Left Front | At front of vehicle, below headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4LR | Turn Signal Lamp - Left Rear | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E4N | Park/Turn Signal Lamp - Left | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4P | Park/Turn Signal Lamp - Right | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4RF | Turn Signal Lamp - Right Front | At front of vehicle, below headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4RR | Turn Signal Lamp - Right Rear | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E40 | Electrical Auxiliary Heater | C32 | Part of HVAC module, behind I/P | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E42L | Tail Lamp Assembly - Left | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E42R | Tail Lamp Assembly - Right | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5A | Backup Lamp - Left | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5B | Backup Lamp - Right | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5L | Stop Lamp - Left | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5R | Stop Lamp - Right | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E6 | Centre High Mounted Stop Lamp | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E7 | License Plate Lamp | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E8D | Door Courtesy Lamp - Driver | In the passenger compartment, bottom edge of the left front door trim panel | DOOR COMPONENT VIEWS | |
| E8E | Rear Compartment Courtesy Lamp - Left | In the rear compartment, on left side | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E8F | Rear Compartment Courtesy Lamp - Right | In the rear compartment, on right side | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E8J | Instrument Panel Courtesy Lamp - Left | In the passenger compartment, in the left kick panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E8K | Instrument Panel Courtesy Lamp - Right | In the passenger compartment, in the right kick panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E8P | Door Courtesy Lamp - Passenger | In the passenger compartment, bottom edge of the right front door trim panel | DOOR COMPONENT VIEWS | |
| F105L | Roof Rail Air Bag - Left | In the passenger compartment, behind the headliner, mounted to the roof, at left side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F105R | Roof Rail Air Bag - Right | In the passenger compartment, behind the headliner, mounted to the roof, at right side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F105 | Passenger instrument panel airbag | In the passenger compartment, in the left side of the instrument panel, above the instrument panel compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| F106LF | Side Air Bag - Left Front | In the passenger compartment, mounted to the outboard side of the left front seat back frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F106LR | Side Air Bag - Left Rear | AW7 | In the passenger compartment, mounted to the outboard side of the left rear seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| F106RF | Side Air Bag - Right Front | In the passenger compartment, mounted to the outboard side of the right front seat back frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F106RR | Side Air Bag - Right Rear | AW7 | In the passenger compartment, mounted to the outboard side of the right rear seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| F107 | Steering wheel air bag | In the passenger compartment, mounted in the center of the steering wheel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| F109E | Seat Belt Buckle Pretensioner - 2nd Row Left | In the passenger compartment, part of the seat belt buckle - left rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F109F | Seat Belt Buckle Pretensioner - 2nd Row Right | In the passenger compartment, part of the seat belt buckle - right rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F112D | Seat Belt Retractor Pretensioner - Driver | In the passenger compartment, mounted to the base of the driver b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F112P | Seat Belt Retractor Pretensioner - Passenger | In the passenger compartment, mounted to the base of the passenger b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F113D | Seat Belt Anchor Pretensioner - Driver | In the passenger compartment, mounted to the outboard side of the driver seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F113P | Seat Belt Anchor Pretensioner - Passenger | In the passenger compartment, mounted to the outboard side of the passenger seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| G10L | Cooling Fan Motor - Left | At front of vehicle, behind radiator, left of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| G10R | Cooling Fan Motor - Right | At front of vehicle, behind radiator, right of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| G12 | Fuel Pump | LAU or LDK | Under the vehicle, in the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| G13 | Alternator | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS | |
| G16 | Headlamp Washer Fluid Pump | CE4 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| G18 | High Pressure Fuel Pump | In the engine compartment, mounted to engine | POWERTRAIN COMPONENT VIEWS | |
| G21 | Secondary Air Injection Pump | LAU with NU6 | Lower left front of the engine | POWERTRAIN COMPONENT VIEWS |
| G24 | Windscreen Washer Pump | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| K17 | Electronic Brake Control Module | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| K19 | Suspension Control Module | F45 | In the rear compartment, on left side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| K20 | Engine Control Module | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| K26 | Headlamp Control Module | TR7 | In the passenger compartment, at the lower left of the instrument panel, behind the body control module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K27 | Fuel Pump Control Module | LAU or LDK | In the rear compartment, on right side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| K29D | Seat Heating Control Module - Driver | KA1 without A45 | In the passenger compartment, mounted to the bottom of the driver seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K33 | HVAC Control Module | In the passenger compartment, in the center of the instrument panel, behind the HVAC and radio controls | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K34 | Glow Plug Control Module | LBS | Left side of the engine compartment, in front of the battery | POWERTRAIN COMPONENT VIEWS |
| K36 | Inflatable Restraint Sensing and Diagnostic Module | In the passenger compartment, mounted to the floor, under floor console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| K40D | Seat Memory Control Module - Driver | A45 | In the passenger compartment, mounted to the bottom of the driver seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K41 | Parking Assist Control Module | UD5 or UDP | In the rear compartment, on left side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| K43 | Power Steering Control Module | NXC or NV7 | In the passenger compartment, lower left side of the instrument panel, to the left of the steering column, behind the body control module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K46 | Radio Antenna Module | In the passenger compartment, mounted to the right c-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| K47 | Rear Differential Clutch Control Module | Under rear of the vehicle, mounted to the rear differential | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| K60 | Steering Column Lock Control Module | ULS | In the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K61 | Sunroof Control Module | C3U | In the passenger compartment, mounted to the roof | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K62 | Sunroof Sunshade Motor Module | C3U | In the passenger compartment, mounted to the roof | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K65 | Tyre Pressure Indicator Module | UJN | Left rear of the vehicle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K71 | Transmission Control Module | M36 | At front of vehicle, mounted to the top of the transmission assembly | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| K73 | Telematics Communication Interface Control Module | UE1 | In the passenger compartment, rear of the vehicle, at the center of the rear window shelf, between speakers | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K74 | Vehicle Direction Camera Control Module | UVL or UVT | Above the headliner | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K77 | Remote Control Door Lock Receiver | In the passenger compartment, above the inside rearview mirror, behind the outside moisture sensor cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K8 | Blower Motor Control Module | In the passenger compartment, below the right side of the instrument panel, on the bottom of the blower unit | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K8A | Blower Motor Control Module - Auxiliary | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K82 | Mobile Telephone Control Module | UPH or UPJ | In the center of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K83 | Parking Brake Control Module | Outside left rear of the vehicle, behind left rear wheel liner | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| K84 | Keyless Entry Control Module | In the passenger compartment, below the right side of the instrument panel, behind the passenger kick panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K85 | Passenger Presence Detection Module | AL0 | In the passenger compartment, in the passenger seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K89 | Immobilizer Control Module | In the passenger compartment, in the center console, below the cup holders | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K9 | Body Control Module | In the passenger compartment, at the lower left of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| M27 | Fuel Door Unlatch Actuator | In the right side of the rear compartment | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| M29L | Headlamp Leveling Actuator - Left | TR7 | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| M29R | Headlamp Leveling Actuator - Right | TR7 | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| M40 | Rear Compartment Lid Latch | At the rear of vehicle, mounted to the rear compartment lid | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| M50D | Seat Front Vertical Motor - Driver | AG1 | In the passenger compartment, mounted to the bottom of the driver seat at front | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M50P | Seat Front Vertical Motor - Passenger | AG2 | In the passenger compartment, mounted to the bottom of the passenger seat at front | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M51D | Seat Horizontal Motor - Driver | AG1 | In the passenger compartment, mounted to the bottom of the driver seat at middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M51P | Seat Horizontal Motor - Passenger | AG2 | In the passenger compartment, mounted to the bottom of the passenger seat at middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M52D | Seat Lumbar Support Horizontal Motor - Driver | APG | In the passenger compartment, driver seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M52P | Seat Lumbar Support Horizontal Motor - Passenger | APH | In the passenger compartment, passenger seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M54D | Seat Lumbar Support Vertical Motor - Driver | APG | In the passenger compartment, driver seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M54P | Seat Lumbar Support Vertical Motor - Passenger | APH | In the passenger compartment, passenger seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M55D | Seat Rear Vertical Motor - Driver | In the passenger compartment, mounted to the bottom of the driver seat, forward of middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| M55P | Seat Rear Vertical Motor - Passenger | In the passenger compartment, mounted to the bottom of the passenger seat, forward of middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| M56D | Seat Recline Motor - Driver | AG1 | In the passenger compartment, mounted the driver seat back frame inboard side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M56P | Seat Recline Motor - Passenger | AG2 | In the passenger compartment, mounted the passenger seat back frame inboard side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M64 | Starter motor | In the engine compartment, on the left side of the engine | POWERTRAIN COMPONENT VIEWS | |
| M69 | Sunroof Motor | C3U | In the passenger compartment, mounted to the roof | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M7 | Transmission Shift Lock Control Solenoid Actuator | M36 | In the passenger compartment, part of the transmission shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| M72 | Variable Power Steering Solenoid Valve | NXC or NV7 | Lower rear of the engine compartment, behind the transmission, on the power steering rack at the column hook up | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| M73A | Seat Blower Motor - Driver Back | KU1 | In the passenger compartment, driver seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M73B | Seat Blower Motor - Passenger Back | KU3 | In the passenger compartment, passenger seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M73C | Seat Blower Motor - Driver Cushion | KU1 | In the passenger compartment, driver seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M73D | Seat Blower Motor - Passenger Cushion | KU3 | In the passenger compartment, passenger seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M74D | Window Motor - Driver | In the passenger compartment, in the driver door | DOOR COMPONENT VIEWS | |
| M74LR | Window Motor - Left Rear | In the passenger compartment, in the left rear door | DOOR COMPONENT VIEWS | |
| M74P | Window Motor - Passenger | In the passenger compartment, in the passenger door | DOOR COMPONENT VIEWS | |
| M74RR | Window Motor - Right Rear | In the passenger compartment, in the right rear door | DOOR COMPONENT VIEWS | |
| M75 | Windscreen Wiper Motor | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| M8 | Blower Motor | In the passenger compartment, below the right side of the instrument panel, on the bottom of the HVAC module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| M9 | Brake Booster Pump Motor | LAU | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| P4 | Security Siren | UTR | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| P9 | Driver Information Center Display | In the passenger compartment, part of the instrument cluster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P12 | Horn | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| P14 | Passenger Air Bag Disable Indicator | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P16 | Instrument Panel Cluster | In the passenger compartment, driver side of the instrument panel, above the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P17 | Info Display Module | In the passenger compartment, in the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P19A | Speaker - Centre Console | U63 | Center of instrument panel below upper dash pad | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| P19AA | Speaker - Right Subwoofer | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on right side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19AD | Speaker - Left Surround | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on right of center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19AE | Speaker - Right Surround | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on left of center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19B | Speaker - Centre Instrument Panel | UQS | In the center of the instrument panel cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| P19G | Speaker - Left Front | Behind the left front door trim panel | DOOR COMPONENT VIEWS | |
| P19H | Speaker - Left Front Tweeter | Behind the left A-pillar trim panel | DOOR COMPONENT VIEWS | |
| P19K | Speaker - Left Rear | Behind the left rear door trim panel | DOOR COMPONENT VIEWS | |
| P19N | Speaker - Left Subwoofer | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on left side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19U | Speaker - Right Front | Behind the right front door trim panel | DOOR COMPONENT VIEWS | |
| P19V | Speaker - Right Front Tweeter | Behind the left A-pillar trim panel | DOOR COMPONENT VIEWS | |
| P19X | Speaker - Right Rear | Behind the right rear door trim panel | DOOR COMPONENT VIEWS | |
| P2 | Transmission Shift Lever Position Indicator | M36 | In the passenger compartment, in the center console, below the automatic transmission shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| P22E | Video Display - Driver Seatback | UWG | In the passenger compartment, on rear side of driver seatback | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P22F | Video Display - Passenger Seatback | UWG | In the passenger compartment, on rear side of driver seat headrest | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P29 | Head Up Display | In the passenger compartment, left side of the instrument panel, to the rear of the instrument cluster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P4 | Security Siren | UTR | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| P9 | Driver Information Center Display | In the passenger compartment, part of the instrument cluster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| Q2 | A/C Compressor Clutch | LLU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q12 | Evaporative Emission Purge Solenoid Valve | LAU or LDK | In the engine compartment, on the front middle of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q13 | Evaporative Emission Vent Solenoid Valve | NT7 | Under the vehicle, on the left side of the fuel tank, mounted to the evaporative emission canister | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q14 | Exhaust Gas Recirculation Valve | LBS | Middle rear of the engine | POWERTRAIN COMPONENT VIEWS |
| Q17A | Fuel Injector 1 | In the engine compartment near the number 1 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17B | Fuel Injector 2 | In the engine compartment near the number 2 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17C | Fuel Injector 3 | In the engine compartment near the number 3 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17D | Fuel Injector 4 | In the engine compartment near the number 4 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17E | Fuel Injector 5 | LAU | In the engine compartment near the number 5 cylinder | POWERTRAIN COMPONENT VIEWS |
| Q17F | Fuel Injector 6 | LAU | In the engine compartment near the number 6 cylinder | POWERTRAIN COMPONENT VIEWS |
| Q22 | Intake Manifold Tuning Solenoid Valve | LBS | Under the intake manifold on the left side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q23 | Line Pressure Control Solenoid Valve | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27A | Pressure Control Solenoid Valve 1 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27B | Pressure Control Solenoid Valve 2 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27C | Pressure Control Solenoid Valve 3 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27D | Pressure Control Solenoid Valve 4 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q37LF | Shock Absorber Actuator - Left Front | F45 | Left front of the vehicle, in the front strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q37LR | Shock Absorber Actuator - Left Rear | F45 | Left rear of the vehicle, in the rear strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q37RF | Shock Absorber Actuator - Right Front | F45 | Right front of the vehicle, in the front strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q37RR | Shock Absorber Actuator - Right Rear | F45 | Right rear of the vehicle, in the rear strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q38 | Throttle Body | Top left side of the engine, on the throttle body | POWERTRAIN COMPONENT VIEWS | |
| Q40 | Turbocharger Bypass Solenoid Valve | LAU or LDK | Top left front of engine | POWERTRAIN COMPONENT VIEWS |
| Q42 | Turbocharger Wastegate Solenoid Valve | LAU or LDK | Top right front side of the engine | POWERTRAIN COMPONENT VIEWS |
| Q46 | A/C Compressor Solenoid Valve | Without LLU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q47 | Exhaust Gas Recirculation Cooling Bypass Valve | LBS | In the engine compartment, on the left side of the engine | POWERTRAIN COMPONENT VIEWS |
| Q6A | Camshaft Position Actuator Solenoid Valve - Bank 1 Exhaust | LAU | Rear of the engine, left side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q6B | Camshaft Position Actuator Solenoid Valve - Bank 1 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q6C | Camshaft Position Actuator Solenoid Valve - Bank 2 Exhaust | LAU | Rear of the engine, at the right side | POWERTRAIN COMPONENT VIEWS |
| Q6D | Camshaft Position Actuator Solenoid Valve - Bank 2 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q6E | Camshaft Position Actuator Solenoid Valve - Exhaust | LDK | Front right side of the engine | POWERTRAIN COMPONENT VIEWS |
| Q6F | Camshaft Position Actuator Solenoid Valve - Intake | LDK | Top right side, to the rear of the engine | POWERTRAIN COMPONENT VIEWS |
| Q8 | Control Solenoid Valve Assembly | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| R6 | Data Link Resistor | Upper center of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S109 | Sport Mode Switch | In the passenger compartment, in the center console, next to the shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S2 | Transmission Manual Shift Switch | M36 | In the passenger compartment, part of the transmission shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| S25 | Garage Door Opener | UG1 | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S27 | Head-Up Display Switch | In the passenger compartment, left side of the instrument panel, near the headlamp switch | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S3 | Transmission Shift Lever | M36 | In the passenger compartment, mounted to the floor under the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| S30 | Headlamp Switch | In the passenger compartment, at the left side of the instrument panel, to the left of the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S33 | Horn Switch | In the passenger compartment, in the steering wheel behind the inflatable restraint steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S38 | Ignition Mode Switch | In the passenger compartment, center of the instrument panel, to the right of the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S40 | Passenger Air Bag Disable Switch | C99 | Upper right side of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| S43 | Ultrasonic Intrusion Sensor Disable Switch | UTV | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S47D | Seat Memory Switch - Driver | A45 | In the passenger compartment, on the outboard side of driver seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S48A | Multi-Function Switch - Instrument Panel | In the passenger compartment, in the center console, below radio/HVAC control | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S48B | Multi-Function Switch - Overhead Console | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| S48E | Multi-Function Switch - Center Console | In the passenger compartment, in the center console, next to the shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S51 | Telematics Button Assembly | UE1 | In the passenger compartment, part of the inside rearview mirror, mounted to top center of windshield | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S52 | Outside Rearview Mirror Switch | In the passenger compartment, on the driver door, in front of the window switch | DOOR COMPONENT VIEWS | |
| S64D | Seat Adjuster Switch - Driver | In the passenger compartment, on the outboard side of driver seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| S64P | Seat Adjuster Switch - Passenger | In the passenger compartment, on the outboard side of passenger seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| S65D | Seat Lumbar Support Switch - Driver | APG | In the passenger compartment, on the outboard side of driver seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S65P | Seat Lumbar Support Switch - Passenger | APH | In the passenger compartment, on the outboard side of passenger seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S70L | Steering Wheel Controls Switch - Left | Left center of the steering wheel to the left of the inflatable restraint steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S70R | Steering Wheel Controls Switch - Right | Right center of the steering wheel to the left of the inflatable restraint steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S72 | Sunroof Switch | C3U | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S78 | Turn Signal/Multi-Function Switch | On the left side of the steering column, to the rear of the inflatable restraint steering wheel module coil | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S79D | Window Switch - Driver | In the passenger compartment, in the driver door armrest | DOOR COMPONENT VIEWS | |
| S79LR | Window Switch - Left Rear | In the passenger compartment, in the left rear door armrest | DOOR COMPONENT VIEWS | |
| S79P | Window Switch - Passenger | In the passenger compartment, in the passenger door armrest | DOOR COMPONENT VIEWS | |
| S79RR | Window Switch - Right Rear | In the passenger compartment, in the right rear door armrest | DOOR COMPONENT VIEWS | |
| S82 | Windscreen Wiper/Washer Switch | Mounted to the steering column to the right of the steering wheel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S88 | Sunroof Tilt Switch | C3U | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S90 | Sunroof Sunshade Switch | C3U | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S111 | Night Panel Switch | In the passenger compartment, in the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| T1 | Accessory DC/AC Power Inverter Module | KI6 | In the passenger compartment, below the center console, under the shift lever assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T3 | Audio Amplifier | UQS | In the rear compartment, on right side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| T4F | Cellular Phone Antenna | UPJ without UDT | Outside the vehicle, at the rear center of the roof | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T4G | Cellular Phone, Navigation, and Digital Radio Antenna | U2K or UBT or UE1 with UDT | On the roof at rear center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| T4H | Digital Radio Antenna | U2K or UBT |
List of components
| No | Name Location |
|---|---|
| Components | |
| P16 | Instrument Panel |
| P9 | Driver Information Central Display |
| A90 | Logic |
| X51A | Instrument Panel Electrical Centre |
| K19 | Suspension Control Module |
Scheme 7
| No | Name Location |
|---|---|
| Components | |
| B161LF | Vertical Suspension Acceleration Sensor - Left Front |
| B161RF | Vertical Suspension Acceleration Sensor - Right Front |
| B162LF | Vertical Body Acceleration Sensor - Left Front |
| B162RF | Vertical Body Acceleration Sensor - Right Front |
| B162R | Vertical Body Acceleration Sensor - Rear |
| K19 | Control unit, suspension |
| Q37LR | Shock Absorber Actuator - Left Rear |
| Q37RR | Shock Absorber Actuator - Right Rear |
| Q37LF | Shock Absorber Actuator - Left Front |
| Q37RF | Shock Absorber Actuator - Right Front |
Scheme 8
| No | Name Location |
|---|---|
| Components | |
| B161LF | Vertical Acceleration Sensor, Suspension - Left Front |
| B161RF | Vertical Acceleration Sensor, Suspension - Right Front |
| B162LF | Vertical Body Acceleration Sensor - Left Front |
| B162RF | Vertical Body Acceleration Sensor - Right Front |
| B162R | Vertical Body Acceleration Sensor - Rear |
| K19 | Control unit, suspension |
| Q37LR | Shock Absorber Actuator - Left Rear |
| Q37RR | Actuator shock absorber - right rear |
| Q37LF | Actuator shock absorber - left front |
| Q37RF | Actuator shock absorber - right front |
