Electronic Chassis Control: Component Locations

Electronic Chassis Control: Component Locations Saab 9-5 II

Location (pos)

Scheme 2: Electronic Suspension Front Vertical Accelerometer Replacement - Upper

Callout	Component Name
1	Electronic Suspension Front Upper Position Sensor Fasteners (Qty: 2) Refer to FASTENER CAUTION . Tighten 9 Nm (80 lb in)
2	Electronic Suspension Front Vertical Accelerometer Procedure Disconnect the connector from the sensor.

Scheme 3: Electronic Suspension Front Vertical Accelerometer Replacement - Lower

Callout	Component Name
Preliminary Procedure Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE . Remove the front tire and wheel assemblies.
1	Electronic Suspension Front Position Sensor Fastener Refer to FASTENER CAUTION . Tighten 9 Nm (80 lb in)
2	Electronic Suspension Front Vertical Accelerometer Procedure Remove the connector from the strut. Detach the connector from the sensor. The connector has a secondary lock that must be released before the connector is turned and detached.

Scheme 4: Electronic Suspension Control Module Replacement

Callout	Component Name
Preliminary Procedure Remove the left side luggage compartment trim. Refer to REAR COMPARTMENT SIDE TRIM PANEL REPLACEMENT . Remove the rear electrical center. Refer to REAR ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT .
1	Electronic Suspension Control Module Procedure Remove the control module from the bracket. Disconnect the connectors. Program the electronic suspension control module. Refer to CONTROL MODULE REFERENCES for programming and set up.

Scheme 5: Electronic Suspension Rear Position Sensor Replacement

Callout	Component Name
Preliminary Procedure Folder the back on left side of the backseat. Lift the front left side of the luggage compartment trim floor panel and also the damping material.
1	Electronic Suspension Rear Position Sensor Replacement Fastener (Qty: 2) Refer to FASTENER CAUTION . Tighten 6 Nm (53 lb in)
2	Electronic Suspension Rear Position Sensor
