Traffic Safety System: Other Saab 9-5 II

Vehicle Direction Camera Control Module

If the vehicle is driving, the camera observes the road borders inside its field of view. The camera is able to see the scene inside it's field of view, which is 40° horizontal and 26° vertical. The camera is designed in a kind, that it can see traffic signs up to a distance of 10 m (33 ft) in front of the vehicle. It can also see traffic signs up to a horizontal distance of 8.5 m (28 ft) and a height of 6 m (20 ft). Traffic signs which are not in the field of view can not be detected.

Inside the field of view the camera constantly searches for traffic signs. If the camera detects a traffic sign, it will permanently check the quality of the detection, when the traffic sign is coming closer. The position of the traffic sign is calculated and computed with other information like vehicle speed, lane information and other seen traffic signs. By this the camera is able to estimate, whether the seen traffic sign is a valid one. If the traffic sign is a valid one, it will be reported to the driver in the moment when it leaves the field of view, i.e. 10 m (33 ft) in front of the car.

Instrument Panel Cluster

The control unit for camera monitoring of vehicle direction sends messages to the instrument group via the CAN bus. For this reason the traffic signs are shown in the driver information center. On the page TRAFFIC SIGN DETECTION the last recognized traffic sign will be displayed. Speed limits and no passing signs are displayed as popup on each page of the driver information center menu.

TRAFFIC SIGN DETECTION FAILURE

The driver information center displays TRAFFIC SIGN DETECTION FAILURE when the parking assist control module detects a malfunction in the traffic sign assist and the system is disabled.

NO TRAFFIC SIGN DETECTION DUE TO WEATHER or NO TRAFFIC SIGN DETECTION - SENSOR BLOCKED

These messages are displayed if the windshield is not clean or there are bad environmental conditions like strong rain, snow, direct sun or shadows.

Parking Assist Control Module

The parking assist system is made up of the following components

1. Parking assist control module
2. Front object alarm sensors
3. Rear object alarm sensors
4. Parking aid side sensors
5. Parking assist switch
6. Parking assist switch indicator
7. Parallel Parking assist switch indicator
8. Parking assist indicator in the instrument panel cluster

Parking Assist Components

The parking assist control module provides an 8 V reference and a low reference to the eight object alarm sensors. The parking assist control module receives individual signals from each of the eight sensors and determines the location and distance of an object based on these inputs. When an object is detected, the parking assist control module will send a data message via CAN-Bus to the radio requesting an audible alert.

Object Alarm Sensors and Parking Aid Side Sensors

The object alarm sensors are located in the front and rear bumpers of the vehicle. The sensors are used to determine the distance between an object and the bumper. Each sensor emits an ultrasonic frequency which is reflected off any object located in front of or behind the vehicle. These reflections are received by the sensors. The time difference between the emission of the frequency and when the reflection is received is known as sensor ring time, it is used to determine the distance to the object. The sensors report this information to the parking assist control module.

Parking assist switch

The parking assist can be activated and deactivated by pressing the parking assist switch. By engaging the reverse gear the parking assist can also be activated. By subsequently pressing the parking assist switch the parking assist can be disabled again.

Parking assist switch indicator

The indicator in the parking assist switch shows the status of the parking assist. If the lamp is ON, the parking assist is activated.

Parallel Parking Assist Switch

The parallel parking assist can be activated and deactivated by pressing the parallel parking assist switch.

Parking Assist Indicator

The parking assist indicator in the instrument panel cluster is activated if the object detection detects a malfunction. If the indicator is ON, the parking assist is disabled.

SERVICE PARK ASSIST

The driver information center displays SERVICE PARK ASSIST when the parking assist control module detects a malfunction in the parking assist system and the system is disabled. The driver information center also displays SERVICE PARK ASSIST when a loss of communication occurs with the parking assist control module.

PARK ASSIST OFF

The PARK ASSIST OFF message is displayed in the driver information center when the parking assist system is disabled due to conditions that disable or inhibit the system. The parking assist control module requests the driver information center display PARK ASSIST OFF when it detects that one of the following conditions

1. The parking assist system is manually disabled using the park assist switch.
2. An object is attached to the vehicle which is interfering with the park assist system field of view. Example items are a trailer, bicycle rack, trailer hitch receiver, tow bar, aftermarket front license plate frame, or a bent front license plate.
3. The parking assist sensors are covered by snow, mud, dirt or ice.
4. The vehicle bumper is damaged.
5. Excessive paint thickness on a replacement parking assist sensor.
6. The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

Object Detection Components

The parking assist system is made up of the following components

1. Parking assist control module
2. Front object alarm sensors
3. Rear object alarm sensors
4. Parking assist switch
5. Parking assist switch indicator

The parking assist control module provides an 8 V reference and a low reference to the eight object alarm sensors. The parking assist control module receives individual signals from each of the eight sensors and determines the location and distance of an object based on these inputs. When an object is detected, the parking assist control module will send a data message via CAN-Bus to the radio requesting an audible alert.

Object Alarm Sensors

The object alarm sensors are located in the front and rear bumpers of the vehicle. The sensors are used to determine the distance between an object and the bumper. Each sensor emits an ultrasonic frequency which is reflected off any object located in front of or behind the vehicle. These reflections are received by the sensors. The time difference between the emission of the frequency and when the reflection is received is known as sensor echo time, it is used to determine the distance to the object. The sensors report this information to the parking assist control module.

The parking assist can be activated and deactivated by pressing the parking assist switch. By engaging the reverse gear the parking assist can also be activated. By subsequently pressing the parking assist switch the parking assist can be disabled again.

The indicator in the parking assist switch shows the status of the parking assist. If the lamp is ON, the parking assist is activated.

The driver information center displays SERVICE PARK ASSIST when the parking assist control module detects a malfunction in the parking assist system and the system is disabled. The driver information center also displays SERVICE PARK ASSIST when a loss of communication occurs with the parking assist control module.

The PARK ASSIST OFF message is displayed in the driver information center when the parking assist system is disabled due to conditions that disable or inhibit the system. The parking assist control module requests the driver information center display PARK ASSIST OFF when it detects that one of the following conditions

1. The parking assist system is manually disabled using the park assist switch or through the audio system personalization menu.
2. An object is attached to the vehicle which is interfering with the park assist system field of view. Example items are a trailer, bicycle rack, trailer hitch receiver, tow bar, aftermarket front license plate frame, or a bent front license plate.
3. The parking assist sensors are covered by snow, mud, dirt or ice.
4. The vehicle bumper is damaged.
5. Excessive paint thickness on a replacement parking assist sensor.
6. The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

The camera detects visual queues such as lane markings. When it is determined that the vehicle has unintentionally moved outside of the lane, a visual and audible warning is given to the driver. The vehicle direction camera control module receives an input from the lane departure warning switch and controls the lane departure warning LED output. The vehicle direction camera control module also communicates via serial data with the instrument cluster and radio to request visual and audible alerts.

Lane departure warning switch

The lane departure warning switch provides an input to the vehicle direction camera control module to turn the lane departure warning system ON and OFF. The lane departure warning switch is part of the multifunction switch at the instrument panel. The vehicle direction camera control module provides a signal voltage to the normally open momentary switch. When the switch is pressed, the signal circuit is pulled to ground, indicating to the vehicle direction camera control module that the system has been request to turn ON or OFF. The lane departure warning switch also contains the lane departure warning LED, which is controlled by the vehicle direction camera control module to indicate the ON and OFF status of the lane departure warning system. When the system is has been enabled by the lane departure warning switch, the vehicle direction camera control module applies ground to the switch indicator and illuminating the LED.

The instrument cluster contains the green and amber land departure warning indicators. These indicate to the driver the current status of the lane departure warning system and are controlled via serial data by the vehicle direction camera control module. When the system has detected the required lane markings and is ready to assist, the green indicator will be illuminated on the instrument cluster. If the vehicle has unintentionally left the lane, the amber indicator will flash.

Radio

The radio controls the audible alert for the lane departure indicator. If the vehicle has unintentionally left the lane, the radio will command 3 beeps as an audible alert to the driver.

Lane Crossing Alerts

1. When one of the following conditions are met within the last 3 s, the system will not give alerts: The correct turn signal is activated. An activated turn signal is interpreted as an intentional lane crossing. The operator makes a sharp maneuver. The operator makes a significant acceleration change or significant steering change during a lane crossing. The operator pushes the brake pedal.
2. Lane crossing alert consists of the following: Three chimes are activated through the radio. The amber lane departure warning indicator will flash.

Lane Departure Warning System Driver Information Center Messages

The vehicle direction camera control module system commands the driver information center to display the following messages to alert the driver of a system concern or status information

1. LANE DEPARTURE SYSTEM UNAVAILABLE
2. SERVICE LANE DEPARTURE SYSTEM

Side Object Sensors

The side object sensors are each located behind the rear fascia, positioned so that the sensor is pointing out toward the opposite lane. Each sensor is supplied B+ and ground. The right sensor receives an additional ground. Both sensors communicate independently on the serial data line. The serial data enters the left sensor in a pass-thru configuration, that connects to the right sensor. The scan tool is able to communicate with each sensor independently.

When a vehicle or object is detected by a side object sensor, the sensor will illuminate the indicator located in the appropriate outside rearview mirror.

Outside Rearview Mirror

The outside rearview mirrors each contain an indicator that is controlled by the appropriate side object sensor. This indicator is illuminated when a vehicle or object is positioned in the vehicle's blind spot.

SIDE BLIND ZONE ALERT SYSTEM OFF

This message indicates that the system has been disabled through the Vehicle Personalization located in the radio. Refer to the vehicle owners manual for instructions on how to set personalization options on the driver information center.

SIDE BLIND ZONE SYSTEM UNAVAILABLE

This message indicates that the system has been disabled because the sensor is blocked or can otherwise not accurately detect vehicles or objects. Such instances may be mud, dirt, snow, ice, or slush build-up on the rear fascia, heavy rainfall, or excessive road spray.

SERVICE SIDE BLIND ZONE ALERT SYSTEM

This message indicates that the system requires service. When the message is displayed, the indicators will remain illuminated at all times, notifying the driver that the side blind zone alert system should not be relied upon when changing lanes.

Electrical Information Reference

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Circuit/System Verification

1. Verify that DTC B1405 is not present.
2. If DTC is set, refer to «DTC B1405»(ref-653674-S24484731942014090100000) .
3. Verify that DTC B0954 01, B0955 01, B0956 01 or B0957 01 is not present.
4. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, refer to «CIRCUIT/SYSTEM TESTING»(ref-653674-S25007172552014090100000) .
5. Verify that DTC B0954 21, B0955 21, B0956 21 or B0957 21 is not present.
6. If DTC is present, check the respective sensor for contamination by mud, ice or snow. If no contamination is diagnosed, replace the sensor.
7. Verify that DTC B0954 3A, B0955 3A, B0956 3A or B0957 3A is not present.
8. If DTC is present, replace the respective sensor with a sensor of correct sensor type.
9. Ignition ON, transmission in REVERSE, verify the scan tool Parking Assist System Status parameter displays Enabled.

Repair Instructions

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT OBJECT ALARM SENSOR REPLACEMENT»(ref-653674-S24557136202014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify that DTC B1405 is not present.
2. If DTC is set, refer to «DTC B1405»(ref-653674-S24484731942014090100000) .
3. Verify that DTC B0958 01, B0959 01, B0960 01 or B0961 01 is not present.
4. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, refer to «CIRCUIT/SYSTEM TESTING»(ref-653674-S23033559892014090100000) .
5. Verify that DTC B0958 21, B0959 21, B0960 21 or B0961 21 is not present.
6. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, replace the sensor.
7. Verify that DTC B0958 3A, B0959 3A, B0960 3A or B0961 3A is not present.
8. If DTC is present, replace the appropriate sensor with a sensor of correct sensor type.
9. Ignition ON, transmission in REVERSE, verify the scan tool Parking Assist System Status parameter displays Enabled.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «REAR OBJECT SENSOR REPLACEMENT»(ref-653674-S24613559012014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, programming and setup

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify that DTC B0967 02 is not present.
2. If DTC is present, refer to «PARKING ASSIST SWITCH MALFUNCTION»(ref-653674-S02726877192014090100000) .
3. Verify that B0968 01 or B0968 06 is not present.
4. If DTC is present, refer to «PARKING ASSIST SWITCH INDICATOR MALFUNCTION»(ref-653674-S13537827112014090100000) .
5. Activate and deactivate the parking assist switch and verify the scan tool Park Assist Switch parameter changes between Active and Inactive.

Parking Assist Switch Malfunction

1. Ignition OFF, disconnect the X1 harness connector at the K41 Parking Assist Control Module.
2. Test for infinite resistance between the input signal circuit terminal 8 X1 at the K41 Parking Assist Control Module harness connector and ground.
3. If less than the specified value, test input signal circuit for a short to ground. If the circuit tests normal, replace the S48E Multifunction Switch - Center Console.
4. If all circuits test normal, replace the K41 Parking Assist Control Module.

Parking Assist Switch Indicator Malfunction

1. Ignition OFF, disconnect the X1 harness connector at the K41 Parking Assist Control Module and the harness connector at the S48E Multifunction Switch - Center Console.
2. Ignition ON, test for greater than 11 V between the ignition circuit terminal 3 and ground.
3. If less than the specified value, test the ignition circuit for a short to ground or an open/high resistance.
4. Test for less than 0.3 V between the control circuit terminal 3 X1 at the K41 Parking Assist Control Module harness connector and ground.
5. If greater than the specified value, test the control circuit for a short to voltage.
6. Ignition OFF, test for infinite resistance between the control circuit terminal 3 X1 at the K41 Parking Assist Control Module harness connector and ground.
7. If less than the specified value, test control circuit for a short to ground.
8. Test for less than 5 ohms between the S48E Multifunction Switch - Center Console control circuit terminal 6 and the control circuit terminal 3 X1 at the K41 Parking Assist Control Module harness connector
9. If greater than the specified value, test the control circuit for an open/high resistance.
10. If all circuits test normal, connect the X1 harness connector to the K41 Parking Assist Control Module, replace the S48E Multifunction Switch - Center Console and verify the DTC does not reset.
11. If the DTC resets, replace the K41 Parking Assist Control Module.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT FLOOR CONSOLE MULTIFUNCTION SWITCH REPLACEMENT»(ref-653659-S02347184552014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Activate and deactivate the parallel park assist switch and verify the scan tool Advanced Park Assist Switch parameter changes between Active and Inactive.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT FLOOR CONSOLE MULTIFUNCTION SWITCH REPLACEMENT»(ref-653659-S02347184552014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify that DTC B1405 is not present.
2. If DTC is set, refer to «DTC B1405»(ref-653674-S24484731942014090100000) .
3. Verify that DTC B096C 01 or B096D 01 is not present.
4. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, refer to «CIRCUIT/SYSTEM TESTING»(ref-653674-S30973249512014090100000) .
5. Verify that DTC B096C 3A or B096D 3A is not present.
6. If DTC is present, replace the appropriate sensor with a sensor of correct sensor type.
7. Verify that DTC B096C 21 or B096D 21 is not present.
8. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, replace the sensor.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT OBJECT ALARM SENSOR REPLACEMENT»(ref-653674-S24557136202014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify DTC B356A is not set.
2. If DTC is set, refer to «DTC B356A»(ref-653674-S14993327542014090100000) .
3. Verify DTC B0987 is not set.
4. If DTC is set, refer to «CIRCUIT/SYSTEM TESTING»(ref-653674-S06123543942014090100000) .

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT FLOOR CONSOLE MULTIFUNCTION SWITCH REPLACEMENT»(ref-653659-S02347184552014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for vehicle direction camera control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Verify DTC B0988 is not set.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

CONTROL MODULE REFERENCES for vehicle direction camera control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Ignition ON, program the K41 Parking Assist Control Module and verify the DTC does not reset.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

CONTROL MODULE REFERENCES for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Ignition ON, activate the parking assist, observe the scan tool Park Assist Sensor Reference Voltage parameter. The reading should be between 6.3-10.4 V.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT OBJECT ALARM SENSOR REPLACEMENT»(ref-653674-S24557136202014090100000)
2. «REAR OBJECT SENSOR REPLACEMENT»(ref-653674-S24613559012014090100000)
3. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Ignition ON, observe the scan tool Vehicle Direction Camera Switch Status parameter while pressing and releasing the lane departure warning switch. The parameter should change between Open and Closed.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT FLOOR CONSOLE MULTIFUNCTION SWITCH REPLACEMENT»(ref-653659-S02347184552014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for vehicle direction camera control module replacement, setup and programming

Symptoms - Object Detection

Note. The following steps must be completed before using the symptom tables

1. Perform the «DIAGNOSTIC SYSTEM CHECK - VEHICLE»(ref-653639-S05362277832014090100000) before using the Symptom Tables in order to verify that all of the following are true: before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «OBJECT DETECTION DESCRIPTION AND OPERATION (TRAFFIC SIGN ASSIST)»(ref-653674-S16131285452014090100000) , «OBJECT DETECTION DESCRIPTION AND OPERATION (PARKING ASSIST WITH PARALLEL PARKING)»(ref-653674-S38426152582014090100000) , «OBJECT DETECTION DESCRIPTION AND OPERATION (PARKING ASSIST)»(ref-653674-S20898788012014090100000) , «OBJECT DETECTION DESCRIPTION AND OPERATION (LANE DEPARTURE WARNING)»(ref-653674-S30985213892014090100000) , «OBJECT DETECTION DESCRIPTION AND OPERATION (UFT)»(ref-653674-S33840098692014090100000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS .

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ignition ON, verify the park assist system is enabled through the parking assist switch.
2. If the park assist system is manually disabled, enable the system.
3. Observe the scan tool Park Assist Switch parameter while pressing and releasing the parking assist switch. The parameter should change between Active and Inactive.
4. If the parameter does not change between the specified values, refer to «PARKING ASSIST SWITCH CIRCUIT MALFUNCTION»(ref-653674-S24822348962014090100000) .
5. Command the Park Assist Switch LED output control ON and OFF with the scan tool. The parking assist switch indicator should turn ON and OFF when changing between the commanded states.
6. If the indicator does not turn ON and OFF, refer to «PARKING ASSIST SWITCH INDICATOR CIRCUIT MALFUNCTION»(ref-653674-S40175140762014090100000) .
7. For vehicles with manual transmission: Transmission in reverse, verify the Engine Control Module (ECM) scan tool Reverse Position Switch parameter is Active.
8. If not the specified value, refer to «BACKUP LAMPS MALFUNCTION»(ref-653643-S20437969582014090100000) .
9. NOTE: After completing the next step the vehicle might need to be driven in the forward direction at speed greater than 40 km/h (25 MPH). Transmission in REVERSE, verify the scan tool Park Assist System Status parameter displays Enable.
10. If not the specified value, refer to «DIAGNOSTIC AIDS»(ref-653674-S23892126232014090100000) to determine the cause of the inhibit.

Parking Assist Switch Circuit Malfunction

1. Ignition OFF, disconnect the X1 harness connector at the K41 Parking Assist Control Module and the harness connector at the S48E Multifunction Switch - Center Console.
2. Test for less than 10 ohms between the S48E Multifunction Switch - Center Console ground circuit terminal 2 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Ignition ON, test for less than 0.3 V between the signal circuit terminal 8 X1 at the K41 Parking Assist Control Module harness connector and ground.
5. If greater than the specified range, test the signal circuit for a short to voltage.
6. Ignition OFF, connect the harness connector at the S48E Multifunction Switch - Center Console.
7. Ignition ON, verify that a test lamp does not illuminate between the B+ circuit terminal 1 X1 at the K41 Parking Assist Control Module harness connector and signal circuit terminal 8 X1.
8. If the test lamp illuminates, test signal circuit for a short to ground. If the circuit tests normal, replace the S48E Multifunction Switch - Center Console.
9. Verify that the test lamp illuminates between the B+ circuit terminal 1 X1 at the K41 Parking Assist Control Module harness connector and signal circuit terminal 8 X1 while pressing the parking assist switch.
10. If the test lamp does not illuminate, test the signal circuit for an open/high resistance. If all circuits test normal, replace the S48E Multifunction Switch - Center Console.
11. If all circuits test normal, replace the K41 Parking Assist Control Module.

Parking Assist Switch Indicator Circuit Malfunction

1. Ignition OFF, disconnect the harness connector at the S48E Multifunction Switch - Center Console.
2. Ignition ON, test for greater than 11 V between the ignition circuit terminal 3 and ground.
3. If less than the specified range, test the ignition circuit for a short to ground or an open/high resistance.
4. Command the Park Assist Switch LED output control ON with the scan tool. Test for greater than 11 V between the ignition circuit terminal 3 and the signal circuit terminal 6.
5. If less than the specified range, test the signal circuit for an open/high resistance. If all circuits test normal, replace the K41 Parking Assist Control Module.
6. Command the Park Assist Switch LED output control OFF with the scan tool. Test for less than 0.3 V between the ignition circuit terminal 3 and the signal circuit terminal 6.
7. If greater than the specified range, test the signal circuit for a short to ground. If all circuits test normal, replace the K41 Parking Assist Control Module.
8. If all circuits test normal, replace the S48E Multifunction Switch - Center Console.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT FLOOR CONSOLE MULTIFUNCTION SWITCH REPLACEMENT»(ref-653659-S02347184552014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify the correct function of the parking assist system.
2. If the parking assist system malfunctions, refer to «PARKING ASSIST SYSTEM MALFUNCTION»(ref-653674-S14169006252014090100000) .
3. Ignition ON, observe the scan tool Advanced Park Assist Switch parameter while pressing and releasing the parallel parking assist switch. The parameter should change between Active and Inactive.
4. If the parameter does not change between the specified values, refer to «CIRCUIT/SYSTEM TESTING»(ref-653674-S25477202612014090100000) .
5. Observe the Body Control Module (BCM) Brake Switch parameter while pressing and releasing the brake pedal. The parameter should change between Active and Inactive.
6. If the parameter does not change between the specified values, refer to «STOP LAMPS MALFUNCTION»(ref-653643-S21471608742014090100000) .
7. Transmission in REVERSE, verify the Engine Control Module (ECM) scan tool Reverse Switch parameter is Active.
8. If not the specified value, refer to «BACKUP LAMPS MALFUNCTION»(ref-653643-S20437969582014090100000) .
9. NOTE: After completing the next step the vehicle might need to be driven in the forward direction at speed greater than 40 km/h (25 MPH). Press the parallel parking assist switch, verify the scan tool Park Assist System Status parameter is Enable.
10. If not the specified value, refer to «DIAGNOSTIC AIDS»(ref-653674-S29999069222014090100000) to determine the cause of the inhibit.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT FLOOR CONSOLE MULTIFUNCTION SWITCH REPLACEMENT»(ref-653659-S02347184552014090100000)
2. «FRONT OBJECT ALARM SENSOR REPLACEMENT»(ref-653674-S24557136202014090100000)
3. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for parking assist control module replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Verify that DTC B2545 is not present.
2. If DTC is set, refer to «DTC B2545»(ref-653643-S33851609652014090100000) .
3. Inspect the rearview camera and verify there are no debris on the lens and that the bezel or bezel seal is not damaged.
4. If debris are found on the lens, clean the lens. If the lens, bezel, or bezel seal are damaged, replace as necessary.
5. Ignition ON, vehicle in PARK, verify the backup lamps are off.
6. If the backup lamps are illuminated, refer to «BACKUP LAMPS MALFUNCTION»(ref-653643-S20437969582014090100000) .
7. Vehicle in REVERSE, verify the backup lamps are on.
8. If the backup lamps are not illuminated, refer to «BACKUP LAMPS MALFUNCTION»(ref-653643-S20437969582014090100000) .
9. Engine running, transmission in REVERSE, verify a clear rear vision image is displayed on the radio.
10. If a clear image is not displayed, refer to «CIRCUIT/SYSTEM TESTING»(ref-653674-S32472013652014090100000) .

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

CONTROL MODULE REFERENCES for body control module or radio replacement, setup and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

1. Ignition ON, verify the scan tool can communicate with left side object sensor.
2. If the scan tool can not communicate with the left side object sensor, refer to «LEFT SIDE OBJECT SENSOR MALFUNCTION»(ref-653674-S34931554132014090100000)
3. Verify the scan tool can communicate with right side object sensor.
4. If the scan tool can not communicate with the right side object sensor, refer to «RIGHT SIDE OBJECT SENSOR MALFUNCTION»(ref-653674-S06982808822014090100000)
5. Ignition ON, verify that the side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF during the system self test.
6. If both indicators do not briefly illuminate during the system self test, the side blind zone alert system has been disabled. Refer to «DIAGNOSTIC AIDS»(ref-653674-S01108441212014090100000) .
7. If only one indicator does not briefly illuminate during the self test, refer to «SIDE OBJECT INDICATOR MALFUNCTION»(ref-653674-S17747366572014090100000) .

Left Side Object Sensor Malfunction

1. Ignition OFF, disconnect the harness connector at the B94L Side Object Sensor - Left.
2. Test for less than 5 ohms between the ground circuit terminal 4 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Ignition ON, verify that a test lamp illuminates between the B+ circuit terminal 7 and ground.
5. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
6. If all circuits test normal, replace the B94L Side Object Sensor - Left.

Right Side Object Sensor Malfunction

1. Ignition OFF, disconnect the harness connector at the B94R Side Object Sensor - Right.
2. Test for less than 5 ohms between the ground circuit terminals listed below and ground: Terminal 3 Terminal 4
3. If greater than the specified value, test the appropriate ground circuit for an open circuit/high resistance.
4. Ignition ON, verify that a test lamp illuminates between the B+ circuit terminal 7 and ground.
5. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance.
6. Ignition OFF, disconnect the harness connector at the B94L Side Object Sensor - Left.
7. Ignition ON, test for less than 0.3 V between the serial data circuit terminal 5 and ground.
8. If greater than the specified value, test the serial data circuit for a short to voltage.
9. Test for infinite resistance between the serial data circuit terminal 5 and ground.
10. If not the specified value, test the serial data circuit for a short to ground.
11. Test for less than 5 ohms between the serial data circuit terminal 5 at the B94L Side Object Sensor - Left harness connector and the serial data circuit terminal 5 at the B94R Side Object Sensor - Right harness connector.
12. If the value is greater than the specified value, test the serial data circuit for an open circuit/high resistance.
13. If all circuits test normal, replace the B94R Side Object Sensor - Right.

Side Object Indicator Malfunction

1. Ignition OFF, disconnect the harness connector at the appropriate outside rearview mirror.
2. Test for less than 5 ohms between the ground circuit terminal 12 and ground.
3. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Connect a test lamp between the control circuit terminal 11 and the ground circuit terminal 12.
5. Ignition ON, verify the test lamp briefly illuminates during the system self test.
6. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuits test normal, replace the appropriate side object sensor.
7. If the test lamp remains illuminated at all time, test the control circuit for a short to voltage. If the circuits test normal, replace the appropriate side object sensor.
8. If all circuits test normal, replace the appropriate outside rearview mirror.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «OUTSIDE REARVIEW MIRROR REPLACEMENT»(ref-653668-S25665656962014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for the side object sensor replacement, setup, and programming

1. «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
2. «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
3. «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
4. «WIRING REPAIRS»(ref-653659-S03227166852014090100000)

Note. Refer to DIAGNOSTIC AIDS before performing Circuit/System Verification.

1. Observe the scan tool Vehicle Direction Camera Switch Status parameter while pressing the lane departure warning switch. The parameter should change between Open and Closed.
2. If the parameter does not change between the specified values, refer to «LANE DEPARTURE WARNING SWITCH CIRCUIT MALFUNCTION»(ref-653674-S35657489052014090100000) .
3. Observe the mode LED while cycling the lane departure warning switch. The LED should turn ON and OFF when cycling between the commanded states.
4. If the LED does not turn ON and OFF, refer to «LANE DEPARTURE WARNING SWITCH LED CIRCUIT MALFUNCTION»(ref-653674-S27014373062014090100000) .
5. Inspect the lens of the vehicle direction camera control module for contamination.
6. If the lens needs to be cleaned, refer to «FRONT VIEW CAMERA REPLACEMENT (OBJECT LENS CLEANING)»(ref-653674-S04806028412014090100000) or «FRONT VIEW CAMERA REPLACEMENT (BASE)»(ref-653674-S08606564192014090100000) .

Lane Departure Warning Switch Circuit Malfunction

1. Ignition OFF, remove the ignition key, open the driver door and disconnect the scan tool.
2. Disconnect the harness connector at the S48E Multifunction Switch - Center Console.
3. Test for less than 10 ohms between the S48E Multifunction Switch - Center Console ground circuit terminal 2 and ground.
4. If greater than the specified range, test the ground circuit for an open/high resistance.
5. Ignition ON, verify the scan tool Vehicle Direction Camera Switch Status parameter is Open.
6. If not the specified value, test the signal circuit terminal 7 for a short to ground. If the circuit tests normal, replace the K74 Vehicle Direction Camera Control Module.
7. Install a 3 A fused jumper wire between the signal circuit terminal 7 and ground circuit terminal 2. Verify the scan tool Vehicle Direction Camera Switch Status parameter is Closed.
8. If not the specified value, test the signal circuit terminal for a short to battery or an open/high resistance. If the circuit tests normal, replace the K74 Vehicle Direction Camera Control Module.
9. If all circuits test normal, replace the S48E Multifunction Switch - Center Console.

Lane Departure Warning Switch LED Circuit Malfunction

1. Ignition OFF, disconnect the harness connector at the K74 Vehicle Direction Camera Control Module.
2. Ignition ON, observe the lane departure warning switch indicator. The indicator should be OFF.
3. If the indicator remains illuminated, test to see if there is a short circuit to ground in control circuit terminal 4. If the circuit tests normal, replace the S48E multifunction switch - center console.
4. Ignition OFF, disconnect the harness connector at the S48E Multifunction Switch - Center Console.
5. Ignition ON, test for greater than 11 V between the ignition circuit terminal 3 at the S48E Multifunction Switch - Center Console harness connector and ground.
6. If less than the specified value, test the ignition circuit for a short to ground or an open/high resistance.
7. Ignition OFF, connect the harness connector at the S48E Multifunction Switch - Center Console.
8. Install a 3 A fused jumper wire between the control circuit terminal 4 and ground. The indicator should be ON.
9. If the indicator is always OFF, test the control circuit terminal 4 for a short to battery or an open/high resistance. If the circuit tests normal, replace the S48E Multifunction Switch - Center Console.
10. If all circuits test normal, replace the K74 Vehicle Direction Camera Control Module.

Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.

1. «FRONT VIEW CAMERA REPLACEMENT (OBJECT LENS CLEANING)»(ref-653674-S04806028412014090100000) «FRONT VIEW CAMERA REPLACEMENT (BASE)»(ref-653674-S08606564192014090100000)
2. «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for vehicle direction camera control module replacement, setup and programming

Time studies - Control module, relays, sensors, switches

Correction

1. 01 - Replacement
2. 02 - Removal - Refit
3. 03 - Renovate
4. 04 - Paint
5. 05 - Adjust
6. 06 - Change comp. unit
7. 07 - Lubricate - Clean - Polish
8. 08 - Check/Fault search
9. 09 - Expose
10. 10 - Install new
11. 11 - Transfer

Master Electrical Component List

Link to end views of connectors: COMPONENT CONNECTOR END VIEWS

List of components

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12
