Traffic Safety System: Component Locations Saab 9-5 II

Collision/avoidance 6 illustrations

Location (pos)

  1. 01 - Front
  2. 02 - Rear
  3. 03 - Left
  4. 04 - Right
  5. 05 - All
  6. 06 - Upper
  7. 07 - Centre
  8. 08 - Lower
  9. 09 - Service Information

Scheme 2

Scheme 2: Front Object Alarm Sensor Replacement
Scheme 2: Front Object Alarm Sensor Replacement
CalloutComponent Name
Preliminary Procedure Remove the front bumper fascia. Refer to FRONT BUMPER FASCIA REPLACEMENT .
1Front Object Alarm Sensor Retainer (Qty: 2) Procedure Disconnect the front object alarm sensor electrical connector. Release the locking retainer from the front object alarm sensor support.
2Front Object Alarm Sensor

Scheme 3

Scheme 3: Side object sensor module, replace 4D
Scheme 3: Side object sensor module, replace 4D
CalloutComponent Name
Preliminary Procedure Remove the rear bumper fascia. Refer to REAR BUMPER FASCIA REPLACEMENT .
1Side Object Sensor Module Fastener (Qty: 1)
2Side Object Sensor Module Assembly Procedure Disconnect the electrical connectors. For programming and set up information, refer to CONTROL MODULE REFERENCES .

Scheme 4

Scheme 4: Rear Object Sensor Wiring Harness Replacement
Scheme 4: Rear Object Sensor Wiring Harness Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear bumper energy absorber. Refer to Rear Bumper Energy Absorber Replacement.
1Rear Object Sensor Wiring Harness Retainer (Qty: 1)
2Rear Object Sensor Wiring Harness Procedure Disconnect the rear object sensor wiring harness electrical connector from the rear object sensors.

Scheme 5

Scheme 5: Rear Object Sensor Replacement
Scheme 5: Rear Object Sensor Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear bumper fascia. Refer to REAR BUMPER FASCIA REPLACEMENT .
1Rear Object Sensor Retainer (Qty: 2) Procedure Disconnect the rear object sensor electrical connector. Release the locking retainer from the rear object sensor support.
2Rear Object Sensor

Scheme 6

Scheme 6: Front View Camera Replacement (Object Lens Cleaning)
Scheme 6: Front View Camera Replacement (Object Lens Cleaning)
CalloutComponent Name
Preliminary Procedure For cleaning the front view camera lens remove the front view camera. Refer to FRONT VIEW CAMERA REPLACEMENT (OBJECT LENS CLEANING) or FRONT VIEW CAMERA REPLACEMENT (BASE) .
1Front View Camera Procedure Blow off the dust from the lens and clean the lens only with a dampish cloth in order to avoid direct wetness and a damage of the lens. Clean the windscreen with glass cleaner and dry the screen until there are no cords. Install the camera and go for a functional test drive. Refer to VEHICLE DIRECTION ALERT ALARM WARNING MODULE PROGRAMMING AND SETUP . NOTE: Cleaning Supplies For the lens: glasses cleaner or microfiber cloth or kitchen roll. For the windscreen: water with dish liquid, glass cleaner for car screens.
NOTE
Cleaning Supplies

Scheme 7

Scheme 7: Front View Camera Replacement (Base)
Scheme 7: Front View Camera Replacement (Base)
CalloutComponent Name
1Cover Front View Camera NOTE: Use a flat-bladed tool to remove the cover from the camera bracket.
2Front View Camera Procedure Disconnect the electrical connector. Release the front view camera out of the windscreen bracket. After the installation of the new camera, refer to VEHICLE DIRECTION ALERT ALARM WARNING MODULE PROGRAMMING AND SETUP .
NOTE
Use a flat-bladed tool to remove the cover from the camera bracket.
