Tcs/esp: Adjustments Saab 9-5 II

Anti-Lock/traction Control 3 illustrations ~132 words

Brake Pressure Modulator Valve Pressure Sensor Calibration

The brake pressure sensor does not require calibration often. Calibration of the brake pressure sensor might be required after certain service procedures are performed. Some of these procedures are as follows

  1. Electronic brake control module (EBCM) replacement
  2. Brake pressure modulator valve assembly replacement

The Brake Pressure Sensor Calibration procedure can be completed with a scan tool using the following steps

  1. Apply the parking brake, or set the transmission in the P position.
  2. Release the brake pedal.
  3. Connect the scan tool to the data link connector.
  4. Ignition ON, engine OFF
  5. Select Brake Pressure Sensor Calibration in the EBCM Configuration/Reset Functions list.
  6. Follow the scan tool directions to complete the calibration procedure.
  7. Clear any DTCs that may be set.

Scheme 1

Scheme 1: Front Wheel Speed Sensor Replacement (GNA)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE . Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION .
1Speed Sensor Bolt Refer to FASTENER CAUTION . Tighten 9 Nm (80 lb in)
2Front Wheel Speed Sensor Procedure Disconnect the wire connection and remove the front wheel speed sensor from the steering gear knuckle.

Scheme 2

Scheme 2: Front Wheel Speed Sensor Replacement (GNB)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE . Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION .
1Speed Sensor Bolt Refer to FASTENER CAUTION . Tighten 9 Nm (80 lb in)
2Front Wheel Speed Sensor Procedure Disconnect the wire connection and remove the front wheel speed sensor from the steering gear knuckle.

Scheme 3

Scheme 3: Rear Wheel Speed Sensor Replacement
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE . Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION .
1Speed Sensor Bolt Refer to FASTENER CAUTION . Tighten 9 Nm (80 lb in)
2Rear Wheel Speed Sensor Clip (Qty: 4)
3Rear Wheel Speed Sensor Procedure Remove the nut from the wheel shield to get access. Disconnect the speed sensor electrical connector.
