TSL unlocking
When the car doors are unlocked with remote control button B after being TSL locked, the tailgate lock motor will go to its locked position.
The tailgate is unlocked using button C on the remote control, at which time the other doors go to their locked position. To TSL lock the car once again, press remote control button A two times.
Scheme 418
Scheme 419
When button C on the remote control is pressed, it sends a signal to the receiver, which processes the signal and sends it on to the TWICE control module.
A short voltage pulse (0.8 sec.) is fed from TWICE control module pin 67, whereby the lock motor will go from TSL locked position to locked position.
The lock motor is grounded to the TWICE control module by pin 62 via relay 594, which is inactive.
Once the voltage pulse (0.8 sec.) has ceased, TWICE will output B+ on pin 67 and the lock motor will go from locked position to unlocked position.
The lock motor is grounded on pins 44 and 62 of the TWICE control module.
Scheme 420
- Options: Disconnected or 2-14 km/h
- Factory setting: Disconnected
If the setting Disconnected is selected, the tailgate will not be locked automatically.
However, if a value between 2-14 km/h is selected, the tailgate will be locked when this speed is exceeded for 1 second or more.
- Options: No locking/Immediate locking - 240 second delay
- Factory setting: No locking
If the setting No locking is selected, the tailgate will remain unlocked if it has been unlocked but not opened. If the car is locked with the remote control, the button on the centre console or with a key, the tailgate will be locked.
If instead a value between Immediate locking and 5-240 seconds is selected, the tailgate will be locked automatically after the set time.
The setting Immediate locking means that the tailgate will lock immediately after being closed.
For example, if 30 seconds is selected, the tailgate will lock 30 seconds after it was unlocked.
- Options: No locking/Immediate locking - 240 second delay
- Factory setting: No locking
If the setting No locking is selected, the tailgate will remain unlocked when it has been closed. If the car is locked with the remote control, the button on the centre console or with a key, the tailgate will be locked.
If instead a value between Immediate locking and 5-240 seconds is selected, the tailgate will be locked automatically after the set time.
The setting Immediate locking means that the tailgate will lock immediately after being closed.
If, for example, 30 seconds is selected, the tailgate will be locked 30 seconds after it has been closed.
