General

The main unit and CD changer (CDC) in the Saab 9-5 have a new type of theft protection. The main unit and the CD changer are both connected to the I bus. When the main unit and CD changer are installed for the first time, they are married to the vehicle. This is a process that is carried out using Tech 2. During the marriage, the main unit and CD changer identify theft protection information from the car. As from now, the main unit and CD changer will only work in this vehicle. Therefore, the Saab 9-5 does not need a radio code.

This also means that a main unit and CD changer being removed from a Saab 9-5 must be divorced from the vehicle before removal unless it is to be refitted into the same car.

Note. If the main unit or CD changer is DIVORCED, SID shows "RADIO CODE" or "CDC CODE" on activation. MAIN UNIT CD CHANGER, OPTION (4D) CD CHANGER, OPTION (5D) If the main unit or CD changer is still married to another Saab 9-5, SID will display "RADIO LOCKED" or "CDC LOCKED" on activation. To be able to divorce any of the units with Tech 2, the procedure must be performed in the vehicle to which the unit is married. MAIN UNIT CD CHANGER, OPTION (4D) CD CHANGER, OPTION (5D)

Scheme 27

1. Connect Tech 2.
2. Initiate communication with the audio system.
3. Select "PROGRAMMING" in the system menu. The message "MARRIAGE/DIVORCE" is displayed.
4. Press "ENTER".
5. Select DIVORCED with the change button and press "OK". "DIVORCED" must be selected when removing the main unit (to be installed in another car or to be returned for warranty repair).
6. The radio will now stop playing after a delay and "RADIO CODE" will be shown on SID.
7. Press both special tools into the holes provided for them in the main unit. Press the tools in until they lock, at which point a click will be heard.
8. Extract the main unit using the tool handles. Remove the special tools.

To fit

Note. Check that the attaching hooks on the ends of the main unit are not damaged (bent in).

1. Push the main unit into the space provided for it in the center console until a click is heard.
2. With Tech 2 connected and communication established with the Audio system, select "PROGRAMMING" from the system menu. The message "MARRIAGE/DIVORCE" is displayed.
3. Press "ENTER".
4. Select MARRIED with the change button and press "OK". "MARRIED" must be selected when installing a main unit into a Saab 9-5.
5. "RADIO CODE" disappears from SID and the sound returns after a slight delay. WARNING: The CD player in the main unit is a Class 1 laser product. The CD player in the main unit should be serviced and repaired by a qualified technician only. If the casing on the main unit is damaged, laser radiation can occur with risk of injury.

Scheme 28

Scheme 29

1. Remove the main unit as described on the previous page. «MAIN UNIT»(ref-212233-S08422148582005122200000)
2. Remove the four screws in the front panel.
3. Undo the six locking tabs which hold the front panel in place.

Note. When refitting, ensure that the connector under the front panel is correctly positioned.

Fit the front panel on the main unit and slide in the main unit. MAIN UNIT

Scheme 30

Scheme 31

1. Remove the sill cover on the passenger side.
2. Remove the lower cover panel.
3. Fold the carpet to one side.
4. Remove the two lower nuts that hold the amplifier and loosen the upper.
5. Lift the amplifier out and unplug the connector.

Refit the parts removed in reverse order.

Note. Physically, the Prestige amplifiers for 4D and 5D cars are the same in appearance and connectors, so that it is possible to connect an amplifier intended for a 5D car into a 4D car. The sound quality from the sub-woofer will not be satisfactory, however, as it will be driven too hard. In the other case, if an amplifier for a 4D car is fitted into a 5D, the sub-woofer reproduction will sound washy.

Scheme 32

1. Remove the speaker grilles on the dashboard.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Scheme 33

1. Remove the speaker grille in the center of the dashboard.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Scheme 34

1. Remove the door trim to gain access to the speakers.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Note. To obtain the best sound from the speakers, the doors should be air-tight.

Scheme 35

1. Remove the door trim to gain access to the speakers.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Note. To obtain the best sound from the speakers, the doors should be air-tight.

Scheme 36

1. Lower the rear seat.
2. Undo the clips on the protective cover and remove the cover.
3. Remove the four screws holding the speaker.
4. Lift out the speaker and disconnect the connector.

Fit in reverse order.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. Fold down the right-hand rear seat backrest and remove the side bolster between the rear right door and the backrest.
2. Lift out the concealing panel.
3. Remove the right-hand storage compartment in the floor.
4. Remove the scuff plate by first removing the covers on the right and left-hand sides. Undo the screws securing the scuff plate to the sill. Pull off the scuff plate, it is fastened with clips.
5. Remove the rear roof cover and unplug the connections for the lighting.
6. Remove the right-hand D-pillar trim and the right-hand concealing panel support (3 screws).
7. Remove the five screws in the top of the right-hand side trim and lift out the trim.
8. Remove the bass speaker and unplug the connector.

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Plug in the connector to the bass speaker and fit the speaker.
2. Position the side trim and tighten the five screws at the top.
3. Refit the concealing panel support (3 screws) and the D-pillar trim.
4. Fit the rear roof cover and plug in the lighting.
5. Press in the scuff plate clips and screw on the scuff plate. Fit the covers over the screws and position the sealing strip over the scuff plate.
6. Fit the storage compartment in the floor.
7. Lift in the concealing panel.
8. Fit the side bolster between the rear right door and the backrest and fold up the rear seat backrest.

Scheme 47

Scheme 48

1. Remove the speaker grille on the right-hand side of the parcel shelf.
2. Remove the sealing strip.
3. Remove the trim on the right-hand C pillar to gain access to the antenna amplifier.
4. Undo all connections to the antenna amplifier.
5. Remove the screws holding the antenna amplifier and remove the unit. IMPORTANT: Be careful with the contact (4). When undoing the Fuba GO-NOGO HF contact, care is required to ensure that it is done correctly without damaging the connection. See the instructions (4).

Fit in reverse order.

Scheme 49

Scheme 50

1. Remove the speaker grille on the left-hand side of the parcel shelf.
2. Remove the sealing strip.
3. Remove the trim on the left-hand C pillar to gain access to the antenna filter.
4. Undo the connection to the antenna filter.
5. Remove the screws holding the antenna filter and remove the unit.

Fit in reverse order.

Scheme 51

Scheme 52

1. Remove the rear roof cover and unplug the connectors for the lighting.
2. Remove the D-pillar trim and the roof covers over the rear side windows.
3. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
4. Remove the two clips in the roof and carefully bend down the headlining.
5. Undo all connections to the antenna amplifier. There are two types of antenna amplifier: 1-channel with 2 connectors 2-channel (with diversity function) with 3 connectors
6. Remove the nuts securing the antenna amplifier and remove the unit. IMPORTANT: Handle the HF connector (5) with care. Exercise care when undoing the high frequency connector, Fuba GO-NOGO. Disconnection must be performed correctly so as not to damage the connector. See «ANTENNA AMPLIFIER (4D)»(ref-212233-S09932909622005122200000)

Scheme 53

Scheme 54

1. Fit the antenna amplifier and tighten the nuts.
2. Plug in all cables to the antenna amplifier.
3. Carefully lift up the headlining and fit the two clips in the roof.
4. Refit the C-pillar trims and fasteners over the rear side windows.
5. Fit the roof covers over the rear side windows and refit the D-pillar trim.
6. Plug in the lighting and fit the rear roof cover. IMPORTANT: Handle the HF connector (2) with care. Exercise care when undoing the high frequency connector, Fuba GO-NOGO. Disconnection must be performed correctly so as not to damage the connector. See «ANTENNA AMPLIFIER (4D)»(ref-212233-S09932909622005122200000)

Scheme 55

Scheme 56

1. Remove the rear roof cover and unplug the connectors for the lighting.
2. Remove the D-pillar trim and the roof covers over the rear side windows.
3. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
4. Remove the two clips in the roof and carefully bend down the headlining.
5. Undo all connections to the antenna amplifier. There are two types of antenna amplifier: 1-channel with 2 connectors 2-channel (with diversity function) with 3 connectors
6. Remove the nuts securing the antenna amplifier and remove the unit. IMPORTANT: Handle the HF connector (5) with care. Exercise care when undoing the high frequency connector, Fuba GO-NOGO. Disconnection must be performed correctly so as not to damage the connector. See «ANTENNA AMPLIFIER (4D)»(ref-212233-S09932909622005122200000)

Scheme 57

Scheme 58

1. Fit the antenna amplifier and tighten the nuts.
2. Plug in all cables to the antenna amplifier.
3. Carefully lift up the headlining and fit the two clips in the roof.
4. Refit the C-pillar trims and fasteners over the rear side windows.
5. Fit the roof covers over the rear side windows and refit the D-pillar trim.
6. Plug in the lighting and fit the rear roof cover. IMPORTANT: Handle the HF connector (2) with care. Exercise care when undoing the high frequency connector, Fuba GO-NOGO. Disconnection must be performed correctly so as not to damage the connector. See «ANTENNA AMPLIFIER (4D)»(ref-212233-S09932909622005122200000)

Scheme 59

Scheme 60

1. Remove the rear roof cover and unplug the connectors for the lighting.
2. Remove the D-pillar trim and the roof covers over the rear side windows.
3. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
4. Remove the two clips in the roof and carefully bend down the headlining.
5. Unplug the antenna cable from the antenna amplifier and remove the antenna cable with clips. IMPORTANT: Handle the HF connector (5) with care. Exercise care when undoing the high frequency connector, Fuba GO-NOGO. Disconnection must be performed correctly so as not to damage the connector. See «ANTENNA AMPLIFIER (4D)»(ref-212233-S09932909622005122200000)

Scheme 61

Scheme 62

1. Plug the antenna cable into the antenna amplifier and fit the clips in the roof.
2. Carefully lift up the headlining and fit the two clips in the roof.
3. Refit the C-pillar trims and fasteners over the rear side windows.
4. Fit the roof covers over the rear side windows and refit the D-pillar trim.
5. Plug in the lighting and fit the rear roof cover. IMPORTANT: Be careful with connector (2). Exercise care when undoing the high frequency connector, Fuba GO-NOGO. Disconnection must be performed correctly so as not to damage the connector. See «ANTENNA AMPLIFIER (4D)»(ref-212233-S09932909622005122200000)

Steering wheel switches

Scheme 63

1. Remove the airbag on the driver's side. See «AIR BAG RESTRAINT SYSTEMS»(ref-150008)
2. Undo the steering switch connector.
3. Remove the steering switch.

Scheme 64

1. Refit the steering switches.
2. Reconnect the steering switch connector.
3. Refit the airbag. See «AIR BAG RESTRAINT SYSTEMS»(ref-150008)

Scheme 65

Do not remove the existing antenna cable without fitting a new one.

1. Remove the sill covers and cable conduit cover on the right-hand side (front and rear doors). Lower the seat cushion and backrest.
2. Remove the speaker grille from the right-hand side of the parcel shelf.
3. Remove the trim on the right-hand C pillar to gain access to the antenna amplifier.
4. Undo the nut securing the luggage compartment trim. Fold the right-hand section to one side.
5. Detach the antenna cable from the antenna amplifier.
6. Cut the antenna cable (the loose part).
7. Connect the new antenna cable to the antenna amplifier.
8. Place the antenna cable in the cable conduit on the right-hand door side. (Attach with a cable tie to prevent rattling.)
9. Fold up the carpet on the right-hand side and pass the cable under the carpet.
10. Remove the main unit (radio) and radio compartment.
11. Push the cable up towards the rear of the compartment.
12. Detach the old antenna cable and cut off the loose part.
13. Connect the new antenna cable.
14. Secure with cable ties to prevent rattling.
15. Refit the removed components.

Scheme 66

Do not remove the existing antenna cable without fitting a new one.

1. Remove the sill covers and cable conduit cover on the right-hand side (front and rear doors). Lower the seat cushion and backrest.
2. Fold down the rear right seat (backrest and seat cushion) and remove the right-hand side bolster.
3. Remove the right-hand side trim in the luggage compartment.
4. Remove the rear roof cover and unplug the connectors for the lighting.
5. Remove the D-pillar trim and the roof covers over the rear side windows.
6. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
7. Remove the two clips in the roof and carefully bend down the headlining.
8. Detach the antenna cable from the antenna amplifier.
9. Cut the antenna cable (the loose part).
10. Connect the new antenna cable to the antenna amplifier.
11. Place the antenna cable into the cable duct on the side of the right hand door. (Secure with a cable tie to prevent rattling.)
12. Fold up the carpet on the right-hand side and pass the cable under the carpet.
13. Remove the main unit (radio) and radio compartment.
14. Push the cable up towards the rear of the compartment.
15. Detach the old antenna cable and cut off the loose part.
16. Connect the new antenna cable.
17. Secure with cable ties to prevent rattling.
18. Refit the removed components.

Scheme 67

1. Turn the ignition key to position ON and activate the electrically heated rear window.
2. Get into the rear seat.
3. Have someone cover the entire rear window with a blanket, tarpaulin or similar object. It should be dark (black) inside the car.
4. Check the rear window to see where the break is located. A point of light (spark) should be seen.
5. Mark the point on the window that is damaged.
6. Remove the blanket from the car.
7. Clean around the damaged point carefully and scrape away a few millimeters with a razor blade.
8. Apply (brush on) contact paint 45-3007499 to the damaged point.
9. Cut away surplus contact paint with a razor blade. Use a ruler as a guide.
10. Check antenna performance for good reception.

Scheme 68

1. Connect Tech 2.
2. Establish communication with the CD changer (CDC).
3. Select "PROGRAMMING" in the system menu. The message "Marriage/Divorce" will be displayed.
4. Press "ENTER".
5. Select "DIVORCED" with the change button and press "OK". "DIVORCED" must be selected when removing the CD changer (to be installed in another car or to be returned for warranty repair).
6. The sound should now cease and "CDC CODE" be displayed on SID.
7. Remove the four bolts holding the CD changer and the CD magazine.
8. Unplug the connector.

Scheme 69

1. Remove 4 transit screws (2 marked red on each side) from the new CD changer.
2. Fit the CD changer with the four screws and plug in the connector. IMPORTANT: Check that the vertical/horizontal setting on the short side of the CD changer is in the vertical (V) position.
3. While Tech 2 is still connected and communicating, select "Programming" in the system menu. The message "Marriage/Divorce" will be displayed.
4. Press "ENTER".
5. Select "MARRIED" with the change button and press "OK".
6. "CDC CODE" disappears from SID and the sound returns. WARNING: The CD changer is a Class 1 laser product The CD changer should be serviced and repaired by a qualified technician only. If the casing of the CD changer is damaged, laser radiation can occur with a risk of injury.

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. Connect Tech 2.
2. Establish communication with the CD changer (CDC).
3. Select "PROGRAMMING" in the system menu. The message "Marriage/Divorce" will be displayed.
4. Press "ENTER".
5. Select "DIVORCED" with the change button and press "OK". "DIVORCED" must be selected when removing the CD changer (to be installed in another car or to be returned for warranty repair).
6. The sound should now cease and "CDC CODE" be displayed on SID.
7. Fold down the left-hand rear seat backrest and remove the side bolster.
8. Lift out the concealing panel.
9. Remove the left-hand storage compartment in the floor.
10. Remove the scuff plate by first removing the covers on the right and left-hand sides. Undo the screws securing the scuff plate to the sill. Pull off the scuff plate, it is fastened with clips.
11. Remove the rear roof cover and unplug the connections for the lighting.
12. Remove the left-hand D-pillar trim and the left-hand concealing panel support (3 screws).
13. Remove the five screws in the top of the left-hand side trim and lift out the trim.
14. Remove the four bolts with washers that hold the CD changer and CD magazine.
15. Unplug the connector.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Remove 4 transit screws (2 marked red on each side) from the new CD changer.
2. Fit the CD changer with the four screws and washers, plug in the connector. Fit the CD magazine. IMPORTANT: Check that the vertical/horizontal setting on the short side of the CD changer is in the vertical (V) position.
3. Connect Tech 2. Establish communication, select "PROGRAMMING" from the system menu. The message "Marriage/Divorce" will be displayed.
4. Press "ENTER".
5. Select "MARRIED" with the change button and press "OK".
6. "CDC CODE" disappears from SID and the sound returns.
7. Position the side trim and tighten the four screws.
8. Refit the concealing panel support (3 screws) and the D-pillar trim.
9. Plug in the lighting and press on the rear roof cover.
10. Press in the scuff plate clips and screw on the scuff plate. Fit the covers over the screws and position the sealing strip over the scuff plate.
11. Fit the storage compartment in the floor.
12. Lift in the concealing panel.
13. Fit the side bolster between the rear left door and the backrest and fold up the rear seat backrest. WARNING: The CD changer is a Class 1 laser product The CD changer should be serviced and repaired by a qualified technician only. If the casing of the CD changer is damaged, laser radiation can occur with a risk of injury.

Programming the main unit

MAIN UNIT PROGRAMMER DESCRIPTION

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Location: In luggage compartment under LH light cluster.

Connected components 4D

CONNECTED COMPONENTS 4D

Connected components 5D

CONNECTED COMPONENTS 5D

Scheme 118

Scheme 119

Location: In passenger compartment on left-hand side of knee member.

A. Connected components in LHD car

LHD CAR CONNECTED COMPONENTS

B. Connected components in RHD car

RHD CAR CONNECTED COMPONENTS

Scheme 120

Scheme 121

Location: On right-hand side of knee member

LHD CAR CONNECTED COMPONENTS

RHD CAR CONNECTED COMPONENTS

Conditions

The control module's self-diagnosis has found an internal error.

Conditions; B2605

Diagnostic trouble code B2605 is generated if the CD changer magazine cannot be loaded or ejected correctly.

Diagnostic trouble codes B2625, B2755, B2760, B2762, B2765, B2767 and B2780 are generated if there is dirt on the disc, if the disc is the wrong way up or if there is a faulty disc in the CD changer or CD player.

The codes can also be generated if there is a mechanical fault with the CD changer or CD player.

Diagnostic trouble code B2615 is generated if a faulty magazine is used or if there is a mechanical fault in the CD changer.

Diagnostic trouble code B2620 is generated if the CD player is exposed to extreme vibrations or if there is a mechanical fault in the CD changer.

Diagnostic trouble code B2767 can be generated if the main unit or CD changer is exposed to extreme vibrations.

The main unit is reading incorrect potentiometer values for one or more of the Balance, Fader, Bass and Treble controls.

B2670

1. The main unit receives theft protection information over the bus from DICE and TWICE. If the theft protection information is incorrect, diagnostic trouble code B2670 will be generated.
2. If theft protection is programmed into the main unit (marriage or divorce) without DICE and TWICE being on the bus, diagnostic trouble code B2670 will be generated.

B2750

Diagnostic trouble code B2750 is generated if a disc does not load or eject, or if there is mechanical failure in the CD player.

B2770

Diagnostic trouble code B2770 is generated if the cassette is broken or jammed, if it does not eject or if there is mechanical failure in the cassette player.

B2790

1. The CD player/CD changer stops working if the temperature in the CD player exceeds 76° C.
2. The CD player/CD changer starts to work again when the temperature falls below 69°C.

The main unit receives theft-protection information over the bus from DICE and TWICE. If the theft-protection information is not correct, diagnostic trouble code B2785 will be generated.

If theft protection is programmed into the main unit (marriage or divorce) without DICE and TWICE being on the bus, diagnostic trouble code B2785 will be generated.

The diagnostic trouble code is generated if the main unit is communicating with DICE.

The diagnostic trouble code is generated if the main unit has not received the message KEY CORRECT when programming "marriage/divorce".

Control module

When the control module is supplied with current, the processor in it is tripped. The processor then reads the instructions stored in the control module's memory.

The control module is programmed to read the inputs and activate the outputs. If the control module program is faulty, the diagnostic trouble code "Internal Control Module Fault" will be generated.

The control module must be supplied with current before the system will function. The control module is supplied with current and the processor tripped when the control module can be contacted by the diagnostics instrument.

Outputs

The purpose of the system is to control a number of functions by means of various actuators, such as an injector or lamp. For the system to be capable of performing its functions, it must be possible to activate the actuators. For this reason the actuators must be connected to the control module and have a proper power supply or ground connection.

Inputs

A condition for the control module's capability of controlling its actuators is that the system's sensors supply it with correct values.

Sensor performance can be checked with the diagnostics instrument.

Menu "Read Values"

MENU - READ VALUES

Menu "Programming"

PROGRAMMING MENU

Menu "System Information"

SYSTEM INFORMATION MENU

Scheme 122

It is our experience that the majority of control modules returned to us for repair or replacement under warranty are in perfect working order. In these cases, fitting a new control module has obviously not cured the fault. Therefore, go through all the following points carefully before changing the control module

Scheme 123

1. Check whether the problem can be solved with a control module software update (for control modules that can be reprogrammed). IMPORTANT: Avoid SPS programming unless it is absolutely necessary. It is extremely important to follow the instructions for SPS programming to avoid damaging the control module.
2. Check all grounding points and the power supply to the control module.
3. Check with a diagnostic tool that all the readings are plausible (several readings can affect one function).
4. Check with the diagnostics tool that all activations function normally. (Malfunction in one output circuit can affect another output circuit).
5. If the fault persists, the control module must be changed. Fill in the "Checklist for changing turbocharger and engine control module" before changing the control module and attach it when the control module is returned.
6. Control modules are sensitive to electrostatic discharges. Great care must be taken to follow the following procedure to avoid damaging internal components in the control module: Keep the control module in its packaging for as long as possible. Never touch the pins of a control module with your hands or clothing. Ground yourself by touching part of the car's body/engine. Unplug the connector from the car's control module. Place the exchanged control module in its return packaging without touching the pins. Ground yourself by touching part of the car's body/engine. Plug in the connector to the car's control module.

Scheme 124

It is our experience that the majority of control modules returned to us for repair or replacement under warranty are in perfect working order. In these cases, fitting a new control module has obviously not cured the fault. Therefore, go through all the following points carefully before changing the control module

Scheme 125

1. Check whether the problem can be solved with a control module software update (for control modules that can be reprogrammed). IMPORTANT: Avoid SPS programming unless it is absolutely necessary. It is extremely important to follow the instructions for SPS programming to avoid damaging the control module.
2. Check all grounding points and the power supply to the control module.
3. Check with a diagnostic tool that all the readings are plausible (several readings can affect one function).
4. Check with the diagnostics tool that all activations function normally. (Malfunction in one output circuit can affect another output circuit).
5. If the fault persists, the control module must be changed. Fill in the "Checklist for changing turbocharger and engine control module" before changing the control module and attach it when the control module is returned.
6. Control modules are sensitive to electrostatic discharges. Great care must be taken to follow the following procedure to avoid damaging internal components in the control module: Keep the control module in its packaging for as long as possible. Never touch the pins of a control module with your hands or clothing. Ground yourself by touching part of the car's body/engine. Unplug the connector from the car's control module. Place the exchanged control module in its return packaging without touching the pins. Ground yourself by touching part of the car's body/engine. Plug in the connector to the car's control module.

Scheme 126

A suitable instrument to use is a multimeter.

The ohmmeter must not be used to test components containing semi-conductors, e.g. control modules and relay with timing functions, etc.

When measuring resistance, the power supply to the system being tested must be disconnected as the measuring instrument generates a weak current in the circuit in question.

This is done to ensure that there is no current already in the tested circuit and that the correct reading is obtained.

Scheme 127

Scheme 128

1. Turn on the load.
2. Set the multimeter for measuring voltage and connect the negative lead of the voltmeter to a good grounding point.
3. Connect the positive lead of the voltmeter to the point where the voltage is to be read.
4. On the output side of switches/control modules, it is better to start checking from these and gradually work your way towards the load. When there is no longer a voltage reading, you will have gone past the break point.
5. On the input side of switches/control modules/consumers, it is better to start at the power source (normally a fuse) and then move gradually towards the switch/control module/consumer. When there is no longer a voltage reading, you will have gone past the break point.

Scheme 129

Scheme 130

1. Make sure the component or lead to be tested is not under tension (e.g. by removing the relevant fuse).
2. Set the multimeter for measuring ohms and connect the ohmmeter to each end of the component/lead to be tested.
3. Jiggle the relevant wiring harness while observing the ohmmeter. Normally, the resistance of a wiring harness is less than 1 ohm. Specified values apply to components.

Scheme 131

Scheme 132

1. Make sure the lead being tested is not under tension (e.g. remove the relevant fuse) and that any loads are disconnected.
2. Set the multimeter for measuring ohms.
3. Connect one test lead to a good ground and the other to the point to be tested.
4. Carefully jiggle the wiring harness and make sure the multimeter reading shows infinite resistance (OL) all the time.

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

1. When unplugging a connector that has a catch, the catch must be undone first before parting the connector. Make sure the connector catch engages properly when plugging in the connector. Examples of some of the different types of connector in the car: 1.A. Pull out the sheath to undo the connector catch. After plugging the connector in, press in the sheath to lock the connector. NOTE: Use a small screwdriver to help undo the catch on the connector. 1.B. Press in the catch to release the connector. Make sure the connector is securely locked when plugged back in. 1.C. Pull out the sheath to undo the connector catch. After plugging the connector in, press in the sheath to lock the connector. 1.D. Press in the catch on the wire clamp and tip the wire forward. Plug in the connector and lock it by raising the wire clamp. NOTE: Make sure the wire clamp is locked in the correct position, to ensure good contact in the connector. 1.E. Raise the catch to release the connector. Make sure the connector is securely locked when plugged back in. 1.F. Press in the catch on the connector to release the wire clamp. Release the connector sheath and fold forward the wire clamp. NOTE: Using greater force than necessary attempting to fold the wire clamp forward before the sheath has been released can damage the connector. Plug in the connector and lock it by raising the wire clamp.
2. Ground yourself, by touching the car's body or engine, when unplugging or plugging in the connectors on the car's control modules.
3. Never unplug a connector by pulling the wiring.
4. Never touch the pins on a control module with your hands or clothes. IMPORTANT: Incorrect handing or the use of the wrong tool can damage the sleeves in the connector. Use a test cable (part no. 86 12 731) of the correct size to avoid damaging the sleeves in the connector.
5. When taking measurements, use only probes designed for this purpose to avoid damaging the contacts. Use a test cable (part. no. 86 12 731) of the correct size.
6. For repairs to connectors, the correct special tools and spare parts must be used.
7. The following connectors may not be repaired: Screened cables/coaxial cable (e.g. ABS sensor cable) Airbag system and pyrotechnic belt pretensioner system High-tension cables (e.g. ignition system, xenon headlamps).

Scheme 141

Scheme 142

1. Check that there are no problems with contact on connection.
2. Check contacts, connectors and crimps for oxidation, withdrawn pins and pin clamping force. IMPORTANT: Incorrect handing or the use of the wrong tool can damage the sleeves in the connector. Use a test cable (part no. 86 12 731) of the correct size to avoid damaging the sleeves in the connector.
3. To check the clamping force, use a test cable with the correct size pins (from set 86 12 731). NOTE: A test cable with too large pins will damage the sleeves in the connector. Insert the test cable pin into the connector to check the pin clamping force. Poor clamping force can cause intermittent contact. Check also that the pin is aligned with the other pins in the connector. A pin that is recessed (pushed out) can cause intermittent breaks.
4. Check the wiring and connections for breaks.
5. Check the wiring harness, connectors and ground connections.

Scheme 143

None

Probable cause of fault

Blown fuse for the amplifier.

Break in the lead (mute control) from the main unit to the amplifier.

1. The main unit is not properly inserted in the radio compartment.
2. The antenna cable is poorly connected into the radio compartment/main unit.
3. Poor coaxial cable connection.
4. The antenna amplifier's power supply (trigger voltage) or ground connection is faulty.
5. Break in glass antenna (rear window) 4D, or rear side window 5D.
6. Bad connection between the antenna amplifier and glass antenna.

There is a break in one of the wires in the demister matrix/antennas.

Break in a speaker coil.

Break in a speaker circuit or in the connection between the main unit and the amplifier.

Radio

RADIO TECHNICAL DATA

Cassette Player

CASSETTE PLAYER TECHNICAL DATA

CD Player

CD PLAYER TECHNICAL DATA

1. The CD player in the main unit should be serviced and repaired by a qualified technician only.
2. If the casing on the main unit is damaged, laser radiation can occur with risk of injury.

Scheme 144

Scope

Values and instructions for testing the voltage levels of the control modules are found under the relevant headed sections.

Scheme 145

1. Observe the conditions set for testing and use common sense when assessing the results.
2. The test values presented apply when the ignition is in the ON position unless otherwise stated.
3. First make sure that the control module is receiving power and that it is grounded.
4. Then check all the sensor inputs and signals from other systems.
5. Finally, check the control module outputs. Remember that the test values do not indicate whether the module is working.
6. If a test value is incorrect, consult the wiring diagram to trace which leads, connectors and components should be checked more thoroughly.
7. The specified test values refer to those obtained with calibrated Fluke 88/97.
8. Test values in % (+) and ms (+) show the pulse ratio and pulse duration of the signal. A test instrument capable of giving pulse ratio and pulse duration readings should be used. The (+) symbol indicates a positive trigger pulse, TRIG+.

Scheme 146

= greater than; < = less than; ~ = AC voltage (LP: LOGIC PROBE P = select pulse; p = visible pulses)

PINOUT REFERENCE

Scheme 147

MAIN UNIT (POPULAR) TECHNICAL DATA

Amplifier, internal

AMPLIFIER (INTERNAL)TECHNICAL DATA

RADIO TECHNICAL DATA

Scheme 148

Values and instructions for testing the voltage levels of the control modules are found under the relevant headed sections.

Scheme 149

1. Observe the conditions set for testing and use common sense when assessing the results.
2. The test values presented apply when the ignition is in the ON position unless otherwise stated.
3. First make sure that the control module is receiving power and that it is grounded.
4. Then check all the sensor inputs and signals from other systems.
5. Finally, check the control module outputs. Remember that the test values do not indicate whether the module is working.
6. If a test value is incorrect, consult the wiring diagram to trace which leads, connectors and components should be checked more thoroughly.
7. The specified test values refer to those obtained with calibrated Fluke 88/97.
8. Test values in % (+) and ms (+) show the pulse ratio and pulse duration of the signal. A test instrument capable of giving pulse ratio and pulse duration readings should be used. The (+) symbol indicates a positive trigger pulse, TRIG+.

Scheme 150

= greater than; < = less than; ~ = AC voltage (LP: LOGIC PROBE P = select pulse; p = visible pulses)

PINOUTS REFERENCE

Scheme 151

AMPLIFIER (PREMIUM) TECHNICAL DATA

Scheme 152

AMPLIFIER (PRESTIGE)TECHNICAL DATA

Scheme 153

PINOUTS REFERENCE

Scheme 154

SPEAKERS (PREMIUM) TECHNICAL DATA

Scheme 155

SPEAKER (PRESTIGE)TECHNICAL DATA

Scheme 156

SPEAKER (PRESTIGE (5D))TECHNICAL DATA

Scheme 157

SPEAKERS (POPULAR) TECHNICAL DATA

Scheme 158

ANTENNA AMPLIFIER TECHNICAL DATA

Scheme 159

ANTENNA AMPLIFIER (RADIO, SYSTEM 2 (4D)) TECHNICAL DATA

Scheme 160

ANTENNA AMPLIFIER (RADIO, SYSTEM 1 (5D)) TECHNICAL DATA

Scheme 161

ANTENNA AMPLIFIER (AM/FM RADIO, SYSTEM 2 (5D)) TECHNICAL DATA

Scheme 162

ANTENNA AMPLIFIER (FM RADIO, SYSTEM 2 (5D)) TECHNICAL DATA

Scheme 163

ANTENNA (RADIO (4D)) TECHNICAL DATA

Scheme 164

RADIO ANTENNA (SYSTEM 1/2 (5D)) TECHNICAL DATA

Scheme 165

RADIO ANTENNA (SYSTEM 2 (5D)) TECHNICAL DATA

Scheme 166

ANTENNA FILTER (RADIO (4D)) TECHNICAL DATA

STEERING WHEEL SWITCHES TECHNICAL DATA

Tolerance 5%.

Steering wheel switches with the above specifications apply to cars with the Saab Audio System only. The steering wheel switch without the Saab Audio System consists of a horn button only.

Scheme 167

CD CHANGER TECHNICAL DATA

The CD changer is a Class 1 laser product

1. The CD changer should be serviced and repaired by a qualified technician only.
2. If the casing of the CD changer is damaged, laser radiation can occur with a risk of injury.

Scheme 168

TEST VALUES

Scheme 169

1. Main Unit (353)
2. SID (541)
3. Amplifier (354)
4. Speaker, center dashboard (266FC)
5. Speaker, left dashboard (266LF)
6. Speaker, right dashboard (266FR)
7. Speaker, driver's door (266D)
8. Speaker, passenger door (266P)
9. Speaker, left rear door (266RPL)
10. Speaker, right rear door (266RPR)
11. Antenna (625)
12. Antenna filter (644)
13. Antenna amplifier (624)
14. Steering wheel switches (633)
15. CD changer, option (355)

Scheme 170

1. Main Unit (353)
2. SID (541)
3. Amplifier (354)
4. Speaker, center dashboard (266FC)
5. Speaker, left dashboard (266LF)
6. Speaker, right dashboard (266FR)
7. Speaker, driver's door (266D)
8. Speaker, passenger door (266P)
9. Speaker, left rear door (266RPL)
10. Speaker, right rear door (266RPR)
11. Speaker, left parcel shelf (266RL)
12. Speaker, right parcel shelf (266RR)
13. Antenna (625)
14. Antenna filter (644)
15. Antenna amplifier (624)
16. Steering wheel switches (633)
17. CD changer, option (355)

Scheme 171

1. Main Unit (353)
2. SID (541)
3. Speaker, left dashboard (266LF)
4. Speaker, right dashboard (266FR)
5. Speaker, left rear door (266RPL)
6. Speaker, right rear door (266RPR)
7. Antenna (625)
8. Antenna filter (644)
9. Antenna amplifier (624)
10. Steering wheel switches (633)
11. CD changer, option (355)

Scheme 172

1. Main Unit (353) Radio - Cassette - CD player (Premium/Prestige) Radio/CD player (Popular)
2. SID (display) (541)
3. Amplifier, Premium/Prestige (354)
4. Speaker(266)
5. Antenna (625)
6. Antenna filter (644)
7. Antenna amplifier (624)
8. Steering wheel switches (633)
9. CD changer, option (355)

Scheme 173

1. Main Unit (353)
2. SID (541)
3. Amplifier (354)
4. Speaker, center dashboard (266FC)
5. Speaker, left dashboard (266LF)
6. Speaker, right dashboard (266FR)
7. Speaker, driver's door (266D)
8. Speaker, passenger door (266P)
9. Speaker, left rear door (266RPL)
10. Speaker, right rear door (266RPR)
11. Antenna (625RR) alt. (625RR 625RL)
12. Antenna amplifier (624RR) alt. (624RR and 624RL)
13. Steering wheel switches (633)
14. CD changer, option (355)

Scheme 174

1. Head unit (353)
2. SID (541)
3. Amplifier (354)
4. Speaker, center dashboard (266FC)
5. Speaker, left dashboard (266LF)
6. Speaker, right dashboard (266FR)
7. Speaker, driver's door (266D)
8. Speaker, passenger door (266P)
9. Speaker, left rear door (266RPL)
10. Speaker, right rear door (266RPR)
11. Speaker, luggage compartment, left (266RL)
12. Speaker luggage compartment, right (266RR)
13. Antenna (625RR) alt. (625RR 625RL)
14. Antenna amplifier (624RR) alt. (624RR and 624RL)
15. Steering wheel switches (633)
16. CD changer, option (355)

Scheme 175

1. Main Unit (353)
2. SID (541)
3. Speaker, left dashboard (266LF)
4. Speaker, right dashboard (266FR)
5. Speaker, left rear door (266RPL)
6. Speaker, right rear door (266RPR)
7. Antenna (625RR)
8. Antenna amplifier (624RR)
9. Steering wheel switches (633)
10. CD changer, option (355)

Scheme 176

1. Main Unit (353) Radio - Cassette - CD player (Premium/Prestige) Radio/CD player (Popular)
2. SID (display) (541)
3. Amplifier, Premium/Prestige (354)
4. Speaker(266)
5. Antenna (625)
6. Antenna amplifier (624)
7. Steering wheel switches (633)
8. CD changer, option (355)

The Saab Audio System is a complete sound system for the car, including radio reception and a number of other functions.

The audio system is equipped with an electronic theft protection system that interacts with the car by the audio system being "married" to the car and accordingly linked to the car it was first installed in. A check is carried out each time the audio system is turned on to make sure the correct audio system is being used.

The audio system is available in three models: Premium, Prestige and Popular.

Each system contains the following units

1. Main unit: Radio Cassette player (Premium and Prestige only) CD Player
2. SID (display)
3. Amplifier (Premium and Prestige only)
4. Speakers
5. Antenna system
6. Steering wheel switches
7. CD changer (option)

Main unit

The main unit is central to the Saab Audio System and is located in the center console. The radio, cassette player and CD player are integrated with the main unit. The main unit also contains the controls for the various functions of the audio system.

The main unit communicates with the various other units and systems via the car's bus and wiring harnesses.

The radio module in the audio system is an AM/FM receiver with PLL frequency synthesis for the precise tuning of stations. It is factory-programmed to the frequency bands (2 x 6 AM and 3 x 6 FM) used in the various markets. If there is a loss of power (e.g., the battery is removed), none of the preset stations will be lost.

The audio system fitted to cars for the EU market incorporates RDS radio based on the double tuner system, which improves the quality of RDS reception and RDS radio services.

The cassette player is front-feed. The mechanical functions are fully microprocessor-controlled to reduce the load on the tape. Auto-reverse, track search and blank skip are included.

The CD player is front-feed with display for the compact disc inserted. The disc drawer holds 1 disc (diam. 8 or 12 cm). Random play and scan functions are included.

Display

The audio system uses the SID to show the current settings for the selected source.

The main unit transmits the display information on the bus, from where SID reads it.

Amplifier

The Premium and Prestige audio systems both have external amplifiers. The amplifier in the Prestige system has a higher output power than the Premium. It is available in two models, one for the 4D and one for the 5D.

Premium has 7 output channels and Prestige 9 output channels for speakers. The two additional output channels on the Prestige system are for bass speakers in the parcel shelf on the 4D or on the right-hand side of the luggage compartment on 5D.

The amplifier has a separate power supply. It is not connected to the bus.

Speakers

The Premium and Prestige audio systems have side and center speakers in the dashboard and speakers in the front and rear doors. The Prestige system also includes bass speakers in the parcel shelf on 4D cars and one bass speaker on the right-hand side of the luggage compartment on 5D cars.

The Popular audio system has side speakers in the dashboard and speakers in the rear doors.

Antenna system (4D)

There are two different types of antenna system for radio reception

1. Antenna system 1 consists of an AM and an FM antenna with an antenna amplifier. System 1 is fitted to the car as standard in the EU and PA markets. Antenna system 1 is also used for a make of radio different to that used by Saab in the Saab Audio System.
2. Antenna system 2 consists of an AM, an FM1 and an FM2 antenna with an antenna amplifier. System 2 is fitted as standard in cars for the US and JP markets. Antenna system 2 can only be used for the main units of the Premium and Prestige systems.

The antennas are fitted to the rear window. The AM antenna forms a separate loop and the FM antennas are integrated with the heating element on the rear window. The rear window is the same for both antenna systems, which allows the option of upgrading from antenna system 1 to 2.

The antenna amplifier is powered from the main unit and the amplified antenna signal is supplied to the radio via a coaxial cable.

Antenna system (5D)

There are two different types of antenna system for radio reception

1. Antenna system 1 is intended for audio system: Popular, Premium and Prestige and comprises: an AM and FM antenna with antenna amplifier and coaxial cable for connecting between the amplifier and the main unit.
2. Antenna system 2 is intended for audio systems: Premium and Prestige and comprises: an AM and FM antenna with antenna amplifier and coaxial cable for connecting between the amplifier and the main unit. an FM antenna with antenna amplifier and a coaxial cable for connecting between the two antenna amplifiers.

The AM/FM antenna is located in the rear right side window and its antenna amplifier in the roof above the rear right side window.

The FM antenna is located in the rear left side window and its antenna amplifier in the roof above the rear left side window.

The antenna system can be upgraded to antenna system 2 on markets where antenna system 1 is fitted as standard.

The antenna amplifier is powered from the main unit and the amplified antenna signal is supplied to the radio via a coaxial cable.

CD changer

A CD changer is available as an accessory for fitting in the luggage compartment of 4D and 5D models. The CD changer cartridge holds 6 CDs.

The CD changer is connected to the bus, via which it communicates with the main unit. It is activated (powered) when it receives a "Wake-up" signal from the main unit via the bus. The sound signal (balanced line output) from the CD changer is sent to the amplifier and speakers via the main unit.

The car is pre-wired for a CD changer as standard.

The steering wheel is fitted with special switches to enable the most important functions of the audio system to be operated simply and reliably.

The switches are connected to SID which reads their positions and sends information to the main unit via the bus.

Scheme 177

All control modules in the Saab 9-5 are connected to the bus with the exception of ABS and SRS. For cars with Traction Control, the TC/ABS control module is connected to the bus.

The bus allows large quantities of data to be sent between the control modules using only two cables. The bus is divided into a Powertrain bus (P-bus) and an Instrument bus (I-bus).

The Trionic, TCM and TC/ABS powertrain systems require fast data communication so that no noticeable delays occur, e.g. for torque limitation when changing gear.

Trionic, TCM and TC/ABS are connected to the P-bus, on which data transfer is ten times faster than on the I-bus.

The P-bus and I-bus are connected to MIU. MIU is responsible for making information on one bus available to the other bus.

The diagnostic instrument is not connected directly to the bus but communicates via the DICE, one of the control modules connected to the I-bus, and so has access to all control modules connected to the bus.

Vehicle speed data is important for many control modules. Since ABS is not connected to the bus, the vehicle speed signal is sent on a separate lead from ABS to MIU. MIU then sends the data over the buses. In cars with Traction Control, the TC/ABS sends vehicle speed data to the MIU via the P-bus.

Scheme 178

1. Power supply +15 (20)
2. Power supply +30 (1)
3. Ground (G42)
4. Antenna signal, HF (624, 625)
5. CD changer, line input right-hand channel (+/-) (355)
6. CD changer, line input left-hand channel (+/-) (355)

Scheme 179

1. Ignition +B (on/off) from DICE (628)
2. CD changer information from CD changer (355)
3. Vehicle speed (km/h, mph) from MIU (540)
4. Rheostat value (0 - 100%) from SID (541)
5. Rheostat Night Panel (0 - 100%) from SID (541)
6. Night Panel (on/off) from SID (541)
7. Display illumination (0 - 100%) from SID (541)
8. Steering wheel switches from SID (541)
9. Key Correct (on/off) from TWICE (632)
10. Wheel speed RL (km/h) from TC/ABS (382)
11. Diagnostics communication, see «BUS AND DIAGNOSTICS COMMUNICATION»(ref-212231) .

Scheme 180

1. Trigger voltage (624)
2. Mute control, external amplifier (354)
3. Line output, right-hand channel +/- (front) (354)
4. Line output, left-hand channel +/- (front) (354)
5. Line output, right-hand channel +/- (rear) (354)
6. Line output, left-hand channel +/- (rear) (354)
7. Speaker, right-hand channel +/- (front) (266)
8. Speaker, left-hand channel +/- (front) (266)
9. Speaker, right-hand channel +/- (rear) (266)
10. Speaker, left-hand channel +/- (rear) (266)

Scheme 181

1. Time RDS (hr, min, sec) used by SID (541)
2. Date RDS (0 - 31) used by SID (541)
3. Month RDS (Jan-Dec) used by SID (541)
4. Sound (sound information) used by SID (541)
5. Text message (text information for main unit) used by SID (541)
6. CD changer control (information for controlling CD changer) used by CD changer (353)
7. Diagnostics communication, see «BUS AND DIAGNOSTICS COMMUNICATION»(ref-212231) .

Scheme 182

The main unit is connected to the wiring harness and bus via a 26-pin connector.

The purpose of the main unit is to control the system units and functions of the audio system as follows

1. To activate the audio system units by sending "wake-up" information. "Wake-up" can be information sent via the bus or logic voltage (trigger voltage) via the wiring harness. When the "wake-up" signal is received, the unit is switched on and becomes active. Wake-up with trigger voltage (12 V) Amplifier (Premium/Prestige) Antenna amplifier Wake-up with bus information SID CD changer Control module, DICE
2. To receive audio and antenna signals from the units in the system. Audio signals are sent on via the main unit outputs to the amplifier and speakers.

Premium/Prestige AUDIO SYSTEM, PREMIUM/PRESTIGE .

Popular AUDIO SYSTEM, POPULAR

Scheme 183

Scheme 184

Power supply +15

From fuse 21 to the main unit, pin 2.

Power supply +30

From fuse 9 to the main unit, pin 8.

Scheme 185

Scheme 186

Ground connection

The main unit is grounded (main ground) at grounding point G42 (LHD) or G40 (RHD) via pin 4.

Scheme 187

1. Trionic, engine management system (TRIONIC)
2. TCM (Transmission Control Module), control module for automatic transmission (502)
3. TC/ABS (Traction Control) (382)
4. P-bus (Powertrain bus)
5. MIU (Main Instrument Unit) (540)
6. I-bus (Instrument bus)
7. SID (Saab Information Display) (541)
8. TWICE (Theft Warning Integrated Central Electronics) (632)
9. ACC (Automatic Climate Control) (216)
10. Audio, main unit (353)
11. CDC (CD Changer) (355)
12. PSM (Power Seat Memory) (357Dk)
13. PMM (Power Mirror Memory) (611)
14. DICE (Dashboard Integrated Central Electronics) (628)
15. Data link connector (H16-5/445)
16. Airbag (SRS) (331)
17. ABS (Anti-lock Brake System) (547)
18. SPA (Saab Parking Assistance) (630)

Scheme 188

A bus is understood to be the leads over which information is sent digitally and serially. Digital means that the voltage difference between the leads has only two values, roughly 0 V and 5 V. The information is coded so that different combinations of 0 V and 5 V pulses have different meanings.

Serial means that the information is sent in "packets" which are transmitted one after the other in rapid succession.

All control modules in the Saab 9-5 are connected to the bus with the exception of ABS and SRS. For cars with Traction Control, the TC/ABS control module is connected to the P-bus.

The buses consist of a P-bus (Powertrain Bus) and an I-bus (Instrument Bus). Both buses are connected to the MIU (Main Instrument Unit). The buses are electrically isolated from each other.

The diagnostic tool is not connected directly to the bus but communicates via the DICE, one of the control modules connected to the I-bus, and so has access to all control modules connected to the bus.

The data transfer rate of the P-bus is ten times faster than that of the I-bus. The reason for this is that the powertrain systems need information with the least possible delay, as for example when providing air mass compensation when the selector lever is moved from N to D or torque limitation in connection with gear changing.

All the information sent from one control module is accessible to all the other control modules on the bus. The MIU is responsible for ensuring that information available on one bus is also available on the other bus.

The control modules send out information on the bus at regular intervals. The time between two transmissions depends on the information being sent and varies between 10 milliseconds (0.010 seconds) and 1 second. Information is also sent out by the control modules whenever the information changes.

The transfer of information between control modules takes place on two leads, bus+ (green lead) and bus- (white lead). The leads are twisted to reduce susceptibility to electrical interference.

The main unit uses the following information

MAIN UNIT INFORMATION

Scheme 189

The audio system consists of the central main unit and several external units, and interacts with other systems in the car.

Activation

The audio system is turned on/off by pressing the volume control knob. When switched on, the system starts with the last settings that were active.

The system can be activated irrespective of the position of the ignition switch, even if the key has been removed (+B information goes via the bus).

If the ignition is turned OFF and the key remains in the lock, the audio system will automatically stop one hour after the button was last activated. This applies even if the audio system is turned on when the key is not in the ignition.

Scheme 190

Control functions

The main unit contains control buttons for the system. Some buttons are specific to each respective unit whereas others are general controls.

General control buttons

1. Audio system on/off
2. Source selection in audio system
3. Volume
4. Bass
5. Treble
6. Balance
7. Fader

Scheme 191

The audio system consists of the central main unit and several external units, and interacts with other systems in the car.

The audio system is turned on/off by pressing the volume control knob. When switched on, the system starts with the last settings that were active.

The system can be activated irrespective of the position of the ignition switch, even if the key has been removed (+B information goes via the bus).

If the ignition is turned OFF and the key remains in the lock, the audio system will automatically stop one hour after the button was last activated. This applies even if the audio system is turned on when the key is not in the ignition.

Scheme 192

The main unit contains control buttons for the system. Some buttons are specific to each respective unit whereas others are general controls.

General control buttons

1. Audio system on/off
2. Source selection in audio system
3. Volume
4. Bass
5. Treble
6. Balance
7. Fader
8. Mute

Scheme 193

The radio is an AM/FM receiver with PLL frequency synthesis for the precise tuning in of stations (frequency lock).

The radio is available with or without RDS. The RDS version of the radio is fitted to cars for the EU market. RDS is not used in other markets.

Function

The antenna signal for the radio is supplied from the antenna amplifier via a coaxial cable and a separate connector (HF connector) to the main unit.

The radio is activated with the RADIO button on the main unit. When the radio is active, information is sent to the bus. SID reads this information and displays the current setting.

1. Presets (1-6) for the direct selection of preset radio stations.
2. Band, for the selection of frequency band (AM/FM).
3. Manual tuning up/down on the frequency band.
4. Automatic station search, up/down on the frequency band.
5. Automatic search with storage (AS) of the 6 strongest radio stations on the AM or FM band.
6. RDS on/off.

Scheme 194

The radio is an AM/FM receiver with PLL frequency synthesis for the precise tuning in of stations (frequency lock).

The radio is available with or without RDS. The RDS version of the radio is fitted to cars for the EU market. RDS is not used in other markets.

The antenna signal for the radio is supplied from the antenna amplifier via a coaxial cable and a separate connector (HF connector) to the main unit.

The radio is activated with the RADIO button on the main unit. When the radio is active, information is sent to the bus. SID reads this information and displays the current setting.

1. Presets (1-6) for the direct selection of preset radio stations.
2. Band, for the selection of frequency band (AM/FM).
3. Manual tuning up/down on the frequency band.
4. Automatic station search, up/down on the frequency band.
5. Automatic search with storage (AS) of the 6 strongest radio stations on the AM or FM band.
6. RDS on/off.

Scheme 195

RDS (Radio Data System) is an information system transmitted in Europe in parallel with the radio programmer on the FM band. The RDS system ensures that reception is always optimal, irrespective of location. The RDS function automatically searches for the best transmitter.

The RDS radio contains a double tuner. This improves the quality of RDS reception, as one tuner is used solely to decode RDS information and the other solely for the reception of audio information. Changeover interruptions in reception remain, therefore, minimal, and changes in frequency inaudible.

Scheme 196

As well as receiving FM broadcasts with RDS, the RDS radio also allows use of the following radio services

1. TA/TP for traffic news
2. PTY for programmer type selection
3. EON - for NF, TA, TP and RDS data on the closest stations
4. REG - for reception of local radio stations.

TA/TP (Traffic Announcement/Traffic Programmer)

TA/TP is a function for receiving traffic news with RDS reception. The normal transmission/audio source is interrupted and the traffic news given.

The volume level for traffic news is programmable.

PTY (Program Type)

PTY is an RDS function for receiving programmer in the FM band which are coded by programmer type. With PTY reception, the normal transmission/audio source is interrupted and the selected programmer type heard.

EON (Enhanced Other Network)

EON ensures that the traffic news is received over station limits, i.e., if a traffic message is broadcast by one station while RDS reception of another station is in progress, the message will still be received.

EON is a function that automatically updates the current RDS station for best reception. This means that if, for instance, RDS reception of a station is updated during a journey, other RDS stations will also be updated for best reception at the same time.

REG (Regional)

REG is a function which can be used to receive a preprogrammed local radio station, i.e., to lock on to a local radio station without RDS changing the station in search of better signal quality.

Scheme 197

The cassette player is a front-feed unit. Its mechanical function is controlled entirely by a microprocessor. In the rest position (when no tapes are being played), the wheels are relieved from load so as to spare the mechanical parts and tapes. The cassette player reads the type of tape inserted and changes automatically from normal to chrome/metal and vice versa. Indication that 30 hours use has elapsed and that it is time to clean the recording heads is automatically shown on the SID display.

The cassette player is activated with the TAPE button in the main unit when a cassette is already inserted or by feeding a cassette into the player.

Information is sent to the bus when the cassette player is active. SID reads the information on the bus and shows the current setting on the display.

1. Playing pre-recorded cassettes.
2. Playback direction, manual/auto-reverse.
3. Fast forward/rewind.
4. Track search, forward/back.
5. Dolby B/C noise reduction, on/off.
6. Cassette eject.

Scheme 198

The CD player is a front feed unit. An indicator to the left of the CD slot lights up when a disc is inserted. The disc drawer holds one compact disc of diameter 8 or 12 cm.

The CD player is activated with the CD button on the main unit if a disc is already in the slot, or by inserting a disc into the slot. If a disc is left in the CD player and another source is selected, the CD player will automatically reactivate after ten seconds.

Information is sent to the bus when the CD player is active. SID reads the information on the bus and shows the current setting on the display.

1. Continuous play of a compact disc.
2. Track select for direct selection of track, forwards/backwards.
3. Track select, fast play with sound, forwards/backwards.
4. Random order of play with countdown.
5. Scan, introscan (1.2 secs.) or discs (2.4 secs.).
6. Eject disc.

Scheme 199

The CD player is a front feed unit. An indicator to the left of the CD slot lights up when a disc is inserted. The disc drawer holds one compact disc of diameter 8 or 12 cm.

The CD player is activated with the CD button on the main unit if a disc is already in the slot, or by inserting a disc into the slot. If a disc is left in the CD player and another source is selected, the CD player will automatically reactivate after ten seconds.

Information is sent to the bus when the CD player is active. SID reads the information on the bus and shows the current setting on the display.

1. Continuous play of a compact disc.
2. Track select for direct selection of track, forwards/backwards.
3. Track select, fast play with sound, forwards/backwards.
4. Random order of play with countdown.
5. Eject disc.

Scheme 200

Scheme 201

The car is pre-wired ready for fitting a CD changer that is available as an accessory. One extra cable is still required, which is included with the CD changer.

The CD changer is activated by

1. pressing the CD button on the main unit if the CD player is active
2. pressing the CD button twice if the audio system is in the RADIO or TAPE mode (Premium/Prestige).

The CD changer is powered separately (+30) from fuse 9 to pin 6 in the CD changer connector.

When the audio system has been activated, the CD changer will read the "wake-up" information from the main unit on pins 5 and 11 on the bus. The CD changer is then activated (switched on).

The sound signal (line outputs) from the CD changer to the main unit is supplied via

1. pins 3 and 8 for the left-hand channel
2. pins 2 and 7 for the right-hand channel.

The CD changer functions are controlled by commands from the main unit via the bus.

Information is sent to the bus when the CD changer is active. SID reads the information and shows the status on the display.

See TEST VALUES, CD CHANGER CONNECTIONS

The same buttons are used to control the CD changer and the CD player. To select a CD use the preset buttons 1-6 on the main unit.

Scheme 202

Scheme 203

The Premium and Prestige audio systems each contain a separate amplifier unit which supplies the speakers in the system. The amplifier is connected to the wiring harness via a 39-pin connector.

The amplifier for Prestige is available in two models, one for 4D and one for 5D cars. As the sub-woofer system for 5D cars is different, having another speaker element and location, the power amplifier outputs for the sub-woofer system require other characteristics.

The difference compared with Prestige for the 4D is that another type of signal filtering is required in the amplifier in order to drive the speaker element in the sub-woofer cabinet on the 5D.

Note. Physically, the Prestige amplifiers for 4D and 5D cars are the same in appearance and connectors, so that it is possible to connect an amplifier intended for a 5D car into a 4D car. The sound quality from the sub-woofer will not be satisfactory, however, as it will be driven too hard. In the other case, if an amplifier for a 4D car is fitted into a 5D, the sub-woofer reproduction will sound washy.

1. The amplifier unit is powered separately (+30) from fuse 13 to pins 1 and 2 in the amplifier connector. When the audio system is activated, trigger voltage is simultaneously supplied by pin 7 in the head unit to pin 12 in the amplifier connector. The trigger voltage activates the amplifier.
2. Audio - the input signal (four channels) is supplied by the head unit line outputs to the amplifier. Two channels are used for the front speaker and two for the rear (fader function).
3. Audio Premium - the output signal (6 + 1 channels) from the amplifier to the front and rear speakers.
4. Audio Prestige - the output signal (8 + 1 channels) from the amplifier to the front and rear speakers.
5. Mute control - is supplied by pin 5 in the head unit to pin 11 in the amplifier connector to disconnect the sound. It prevents a clicking sound from being heard in the speakers when the ignition is switched on and off.

See TEST READINGS, AMPLIFIER CONNECTIONS

Scheme 204

Scheme 205

Antennas

The antennas for radio reception are integrated in the rear window and are located as follows

1. AM - antenna positioned at the top of the rear window.
2. FM - antenna (antennae) integrated in the heating element.

The rear window is the same on all markets.

The antenna signal is amplified by an amplifier located on the right-hand C-pillar. The Premium and Prestige systems have one of two different antenna amplifiers, red or black, depending on the market. The black amplifier is used for the Popular system.

The antenna amplifier is supplied with trigger voltage from pin 7 on the head unit and is grounded by being bolted to the chassis.

The black amplifier is used on all markets for retrofitted radios.

The left-hand C-pillar has an antenna filter that grounds the heating element but prevents the antenna signal from going to ground. The antenna filter is fitted as standard on all cars.

Scheme 206

1. Separate AM antenna loop at top of rear window.
2. FM1 antenna on same connection as the heating element. A filter in the antenna amplifier prevents the antenna signal from going to the heating element's power supply. An antenna filter on the ground side of the heating element prevents the antenna signal from going to ground.
3. The heated rear window is connected to the antenna amplifier and antenna filter. A capacitor prevents the voltage from reaching the antenna amplifier. The rear window heating is grounded via the antenna filter.

The amplified signal is fed via a coaxial cable to the radio.

Scheme 207

1. Separate AM antenna loop at top of rear window.
2. FM1 antenna on same connection as the heating element. A filter in the antenna amplifier prevents the antenna signal from going to the heating element's power supply. An antenna filter on the ground side of the heating element prevents the antenna signal from going to ground.
3. FM2 antenna on the same connector as the AM antenna on the rear window. It is connected to a loop above the AM antenna and to the heating element.
4. The heated rear window is connected to the antenna amplifier and antenna filter. A capacitor prevents the voltage from reaching the antenna amplifier. The rear window heating is grounded via the antenna filter.

The antenna amplifier has a switching function that, working with the radio, selects the best FM signal (selects FM1 or FM2).

The amplified signal is fed via a coaxial cable to the radio.

Scheme 208

Scheme 209

Two types of antenna are available for the audio system

1. Antenna system 1 with an AM/FM antenna and antenna amplifier is intended for audio systems Popular, Premium and Prestige.
2. Antenna system 2 with an AM/FM antenna and an FM antenna with antenna amplifier for each antenna is intended for audio systems Premium and Prestige.

The antennas for radio reception are integrated in the rear side windows and are located as follows

1. The AM/FM antenna is located in the rear right side window.
2. The FM antenna is located in the rear left side window.

The rear side windows are the same on all markets.

Antenna amplifier

The antenna amplifiers are located in the roof above the respective rear side window and are available in three models, one for antenna system 1 and two for antenna system 2.

The antenna signal is amplified in the antenna amplifier and passed via the coaxial cable to the head unit (radio). The amplifier is powered with a trigger voltage from pin 7 on the head unit and is grounded by being bolted to the body.

Scheme 210

Antenna system 1 comprises

1. AM/FM antenna integrated in the rear right side window.
2. AM/FM antenna amplifier, on right-hand side
3. coaxial cable between the antenna amplifier and the head unit (radio)

Scheme 211

Antenna system 2 comprises

1. AM/FM antenna integrated in the rear right side window.
2. AM/FM antenna amplifier, on right-hand side
3. FM antenna integrated in the rear left side window
4. FM antenna amplifier on the left-hand side
5. coaxial cable between the FM amplifier on the left-hand side and the AM/FM amplifier on the right-hand side
6. coaxial cable between the AM/FM amplifier and the head unit (radio)

Antenna system 2 has a diversity functions, which means that whichever of the two antennas is giving the best signal is used by the radio receiver. The diversity function works only together with the Saab audio systems Premium and Prestige.

Scheme 212

Scheme 213

The audio system can also be controlled with the steering wheel switches (the control buttons are located on the steering wheel). The switches comprise two units (six connectors). Detailed information is given in the Owner's Manual.

The steering wheel switches are connected to SID and present information on the connectors that are active. SID sends information on the buttons to the bus which is then read by the main unit.

SID supplies +5 V to the steering wheel switches via pin 22, and grounds them via pin 9.

The six connectors comprise six resistors connected in series. When a button is pressed, the connector in question is grounded (see the table).

When a connector is pressed, the total resistance in the circuit changes, as does the voltage value which SID then reads.

Automatic volume control is controlled by the car's speed to compensate for background noise that occurs when the car is moving. The function is active at speeds over 60 kph.

The main instrument unit (MIU) receives a speed signal from the ABS. MIU sends the information out on the bus where it can be read by the main unit and the volume controlled. The level is raised as the vehicle's speed increases, and lowered as it drops.

Scheme 214

Scheme 215

The audio system is equipped with electronic theft protection. Information concerning the theft-protection device is connected in the form of a code to the audio system of the car in which it is installed. Programming is performed with the diagnostic tool.

The theft protection prevents theft by the main unit and CD changer being "married" to the car. If they have not been "married", RADIO CODE or CDC CODE will be displayed when the audio system is turned on.

The audio system checks the validity of the theft protection information (if they are "married") at regular intervals. This also applies if +30 has been temporarily disconnected. If the information is not correct, RADIO LOCKED will be displayed.

If a CD changer has been installed in the car, it will also have unique theft protection information. If the information on the CD changer is not correct (not "married"), CDC LOCKED will be displayed when the CD changer is selected.
