Connected components Saab 9-5 I рестайлинг 2

Telephone System 1 illustration

Connected components

502ATCM control module, connector A (LHD)
Via Crimp J43, instrument wiring
25Hazard light switch
61Windscreen wiper switch
61aRear window wiper switch
91Lamp, lighting, selector lever position indicator
252RSwitch, heated rear seat
375Connection, mobile phone / Connector OnStar
439Solenoid, selector lever, SHIFT LOCK
445Data link connector, 16-pin, CARB
673Control module, OnStar
Via Crimp J45, instrument wiring
48FCigarette lighter, front
48RCigarette lighter, rear (LHD)
148FLamp, lighting, front ashtray/cigarette lighter
148RLamp, lighting, rear cigarette lighter (LHD)
216Control module, ACC
220Ventilation fan control

TCM CONTROL MODULE SPECIFICATIONS

Scheme 90

Scheme 90: Main unit, Audio System
Scheme 90: Main unit, Audio System
LocationIn the centre console
Number of pins26
Power supply (+30 circuit)Pin no.8
Power supply (+15 circuit)Pin no.2
GroundPin no.4
Trigger voltagePin no.7
Instrument bus, I-BUS (+)Pin no.18
Instrument bus, I-BUS (-)Pin no.17
Closed-circuit current consumptionMA<0.1
Max. current consumptionA<3
