Component list
COMPONENTS LIST No. Name Location Illustration Components 19 Lamp, glove compartment lighting, in sidewall of glove compartment 22a Main fuse board, dashboard, on end of dashboard by driver's door 50C Lamp, center roof lighting, in center roof console 50F Lamp, front roof lighting, in front of roof console 53 Switch, cabin lighting in front of roof console 225 Reading lamp, rear, in center roof console 225FC Reading lamp, front center, in front of roof console 359LH Lamp, LH vanity mirror lighting in sun visor 359RH Lamp, RH vanity mirror lighting in sun visor 613FL Lamp, LH front floor lighting, under dashboard at front of floor area 613FR Lamp, RH front floor lighting, under dashboard at front of floor area 628 Control module, DICE, LHD: above dashboard relay board RHD: behind dashboard relay board 685C Unit, dome light, rear, in the center section of the ceiling 685F Unit, dome light, front, in the ceiling by the windscreen 10-pin connectors H10-1 Grey connector in roof by front light console H10-8 Black connector to roof console for front roof lamp 16-pin connectors H16-6 Grey connector in cable channel in front of airbag control module 80-pin connectors H80-1 In connector console under left-hand A-pillar Crimp connectors J46 LHD: Approx. 90 mm from branching of grounding point G42 towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard flasher switch J62 LHD: Approx. 155 mm from LH front floor lighting branching point, towards DICE control module RHD: Approx. 50 mm from the data link connector branching point, towards the steering wheel switches J90 Approx. 100 mm from LH side direction indicator branching towards grounding point G33 J107 Approx. 420 mm from branching of LH sun visor towards roof console Grounding points G33 In cabin under left-hand A-pillar G40 In the cabin on the left-hand side of the knee beam G42 In the cabin on the right-hand side of the knee beam
Scheme 648
Scheme 649
Scheme 650
Scheme 651
Scheme 652
Scheme 653
Scheme 654
Scheme 655
Scheme 656
Scheme 657
Scheme 658
Scheme 659
Scheme 660
Scheme 661
Scheme 662
Scheme 663
Scheme 664
Scheme 665
COMPONENTS LIST No. Name Location Illustration Components 22a Main fuse board, dashboard, on end of dashboard by driver's door 209D Lamp, courtesy lighting, driver in the door 209P Lamp, courtesy lighting, passenger in the door 628 Control module, DICE, LHD: above dashboard relay board RHD: behind dashboard relay board 42-pin connector H42-1 On leading edge of driver's door (LHD) H42-2 On leading edge of passenger door (LHD) H42-3 On leading edge of driver's door (RHD) H42-4 On leading edge of passenger door (RHD) 80-pin connectors H80-1 In connector console under left-hand A-pillar Crimp connectors J66 LHD: Approx. 320 mm from branching of MIU/SID towards DICE control module RHD: Approx. 30 mm from branching of MIU/SID towards the radio J90 Approx. 100 mm from LH side direction indicator branching towards grounding point G33 J95 Approx. 150 mm from RH seat branching point, towards RH front door J98 Approx. 180 mm from branching of connector H43-2 towards front left door J130 Approx. 160 mm from cable tie on 42-pin connector J131 Approx. 160 mm from cable tie on 42-pin connector Grounding points G24 Behind seat member under right-hand seat G33 In cabin under left-hand A-pillar
Scheme 666
Scheme 667
Scheme 668
Scheme 669
Scheme 670
Scheme 671
Scheme 672
Scheme 673
Scheme 674
Scheme 675
Scheme 676
Scheme 677
COMPONENTS LIST No. Name Location Illustration Components 22a Main fuse board, dashboard, on end of dashboard by driver's door 55 Lamp, luggage compartment lighting, 4D: under the parcel shelf 5D: in rear roof console 56 Switch, boot/cargo compartment lighting, in boot lid/tailgate lock 184H motor, central locking, boot lid/tailgate, in boot lid/tailgate 540 Main instrument unit, in dashboard in front of the driver 628 Control module, DICE, LHD: above dashboard relay board RHD: behind dashboard relay board 632 Control module, TWICE under left-hand seat 8-pin connectors H8-2 Grey connector by LH tailgate hinge 10-pin connectors H10-1 Grey connector in roof by front light console H10-2 Between rear LH light cluster and boot lid. 80-pin connectors H80-1 In connector console under left-hand A-pillar Crimp connectors J66 LHD: Approx. 320 mm from branching of MIU/SID towards DICE control module RHD: Approx. 30 mm from branching of MIU/SID towards the radio J90 Approx. 100 mm from LH side direction indicator branching towards grounding point G33 J91 Approx. 30 mm from grounding point G3 branching point, towards LH rear light cluster J132 Approx. 60 mm from branching of engine for boot lid locking towards number plate lighting Grounding points G3 In luggage compartment under LH light cluster G33 In cabin under left-hand A-pillar
Scheme 678
Scheme 679
Scheme 680
Scheme 681
COMPONENTS LIST No. Name Location Illustration Components 19 Lamp, glove compartment lighting, in sidewall of glove compartment 22a Main fuse board, dashboard, on end of dashboard by driver's door 359 Lamp, vanity mirror lighting 628 Control module, DICE, LHD: above dashboard relay board RHD: behind dashboard relay board Crimp connectors J46 LHD: Approx. 90 mm from branching of grounding point G42 towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard flasher switch J62 LHD: Approx. 155 mm from LH front floor lighting branching point, towards DICE control module RHD: Approx. 50 mm from the data link connector branching point, towards the steering wheel switches Grounding points G40 In the cabin on the left-hand side of the knee beam G42 In the cabin on the right-hand side of the knee beam
Scheme 682
Scheme 683
Scheme 684
COMPONENTS LIST No. Name Location Illustration Components 10 Switch, lights, on dashboard between the steering wheel and driver's door 16 Rheostat, instrument lighting, in light switch panel between steering wheel and driver's door 22a Main fuse board, dashboard, on end of dashboard by driver's door 25 Switch, hazard flashers by the center dashboard air vent 88 Switch, fog lights, in 3-switch panel between steering wheel and driver's door 91 Lamp, selector lever position indicator illumination, in floor console by selector lever 148F Lamp, ashtray/cigarette lighter lighting, front by front ashtray in center console 148R Lamp, ashtray/cigarette lighter lighting, rear, on rear edge of floor console between the front seats 216 Control module, ACC in center of dashboard 252R Switch, heating pad, rear seat, on rear edge of floor console between the front seats 282 Switch, headlamp levelling, in 3-switch panel between steering wheel and driver's door 386 Switch unit, electric window lifts, in the floor console between the seats 514a Switch, simultaneous central locking, to the left of the gear lever 538 Switch, door mirror retraction, in switch shaft between steering wheel and driver's door 540 Main instrument unit, on rear of main instrument unit 541 SID in center of dashboard 628 Control module, DICE, LHD: above dashboard relay board RHD: behind dashboard relay board 660 Switch, ESP, on dashboard between steering wheel and center dashboard vent 698 Switch, Night panel, on dashboard between steering wheel and center dashboard vent 6-pin connectors H6-4 By selector lever console 80-pin connectors H80-1 In connector console under left-hand A-pillar Crimp connectors J65 LHD: Approx. 100 mm from branching of MIU towards the radio RHD: Approx. 260 mm from branching of grounding point G41S towards MIU/SID J66 LHD: Approx. 320 mm from branching of MIU/SID towards DICE control module RHD: Approx. 30 mm from branching of MIU/SID towards the radio J88 LHD: Approx. 10 mm from branching of grounding point G41S towards MIU/SID RHD: Approx. 160 mm from branching of grounding point G41S towards MIU/SID
Scheme 685
Scheme 686
Scheme 687
Scheme 688
Scheme 689
Scheme 690
Scheme 691
Scheme 692
Scheme 693
Scheme 694
Scheme 695
Scheme 696
Scheme 697
Scheme 698
COMPONENTS LIST No. Name Location Illustration Components 16 Rheostat, instrument lighting in light switch panel between steering wheel and driver's door 22a Fuse box, dashboard on end of dashboard next to driver's door 282 Switch, headlamp beam adjustment, in 3-switch panel between steering wheel and driver's door 541 SID, on the rear of the main instrument unit 628 Control module, DICE, LHD: above the dashboard relay box RHD: behind the dashboard relay box 663FL LH headlamp to the left of the radiator 663FR RH headlamp to the right of the radiator 43-pin connector H43-1 White connector in the connector console under the LH A-pillar Crimp connectors J48 LHD: Approx. 100 mm from branching point DICE control module towards engine bay grommet RHD: Approx. 250 mm from branching of grounding point G42 towards DICE control module J65 LHD: Approx. 100 mm from branching of MIU towards the radio RHD: Approx. 260 mm from branching of grounding point G41S towards MIU/SID J88 LHD: Approx. 10 mm from branching of grounding point G41S towards MIU/SID RHD: Approx. 160 mm from branching of grounding point G41S towards MIU/SID J140 LHD: Approx. 120 mm from branching DICE control module towards main fuse box RHD: Approx. 330 mm from branching of grounding point G42 towards DICE control module Grounding points G30 In engine bay on side panel in front of LH wheel housing G40 In cabin on LH side of knee member G42 In cabin on RH side of knee member
Scheme 699
Scheme 700
Scheme 701
Scheme 702
Scheme 703
COMPONENTS LIST No. Name Location Illustration Components 8 Dipped beam relay, on main relay board in engine bay 10 Light switch, on the instrument panel between the steering wheel and the driver's door 11a Xenon lamp, in headlamp FL FR 22a Fuse box, dashboard on the short edge of the instrument panel by the driver's door 280 Motor, headlamp beam adjustment, in headlamp FL FR 342a Main fuse box, engine bay, behind the battery 445 Data link connector, 16-pin, CARB under dashboard by steering column 540 Main instrument unit, in dashboard in front of driver 663FL Headlamp, LH to the left of the radiator 663FR Headlamp, RH to the right of the radiator 682 Control module, headlamp, in headlamp FL FR 704F Load angle sensor, front, by RH front axle 704R Load angle sensor, rear, by RH rear axle 4-pin connector H4-9 In engine bay by right MacPherson strut tower 16-pin connector H16-5 Under dashboard by steering column 43-pin connector H43-1 White connector in the connector console under the A-pillar H43-2 Blue connector in connector bracket under LH A-pillar Crimp connectors J1 Approx. 120 mm from the branching point of grounding point G31 towards the RH headlamp. J2 Approx. 50 mm from grounding point G30 branching point towards the radiator fan J58 LHD: Approx. 280 mm from branching of MIU/SID towards DICE control module RHD: Approx. 280 mm from branching of MIU/SID towards DICE control module J89 LHD: Approx. 260 mm from branching of MIU/SID towards DICE RHD: Approx. 110 mm from branching of grounding point G41S towards MIU/SID J93 Approx. 300 mm from the branching point of grounding point G5 towards the LH rear door. J203 Approx. 70 mm from branching connector H33-1 towards engine bay J206 In the engine bay approximately 200 mm from the cabin grommet towards the RH indicator lamp J208 in main fuse box in engine bay J216 In the engine bay approximately 150 mm from the cabin grommet towards the RH indicator lamp J219 Approx. 530 mm from branching point of fuel pump/EVAP pressure switch towards rear left door J220 Approx. 555 mm from branching point of fuel pump/EVAP pressure switch towards rear left door J221 Approx. 505 mm from branching point of fuel pump/EVAP pressure switch towards rear left door Grounding points G5 Under LH corner of rear seat G30 In the engine compartment on the side plate in front of the LH wheel housing G31 On RH structural member behind headlamp
Scheme 704
Scheme 705
Scheme 706
Scheme 707
Scheme 708
Scheme 709
Scheme 710
Scheme 711
Scheme 712
Scheme 713
Scheme 714
Scheme 715
COMPONENTS LIST No. Name Location Illustration Components 40LH Horn LH on LH side behind grille 40RH Horn RH on RH side behind grille 41 Horn button in steering wheel rim 68 Relay, horn on main relay board in engine bay 336b Contact unit, steering wheel horn/switches behind steering wheel pad 342a Fuse box, engine compartment, behind the battery 541 SID, on the rear of the main instrument unit 633 Switch unit, steering wheel on steering wheel rim 43-pin connector H43-1 White connector in the connector console under the A-pillar Crimp connectors J3 Approx. 100 mm from grounding point G30 branching point towards the radiator fan Grounding points G30 In the engine compartment on the side plate in front of the LH wheel housing G40 In the cabin on the LH side of the knee beam G42 In the cabin on the RH side of the knee beam
