General

When the head unit is first installed it is married to the vehicle. This is a process which is carried out using Tech 2. During the marriage the head unit identifies theft protection information from the vehicle. From that moment onwards the head unit will only function in that particular vehicle. It is therefore that no radio code is needed for the Saab 9-5.

This also means that a head unit and being removed from a Saab 9-5 must be divorced from the vehicle before removal unless it is to be refitted into the same car.

Note. If the head unit is DIVORCED, "NO VIN" is shown on the radio display during activation. If the head unit is still married to another Saab 9-5, "LOCKED" appears in the radio display upon activation.

See HEAD UNIT regarding removal and fitting of the radio head unit.

Head unit

Note. If the unit is removed but is to be re-installed in the same vehicle, the Tech2 divorce/marriage procedure is not required.

Note. To divorce/marry the head unit from/to the car requires security access from TIS 2000.

Scheme 5

Scheme 6

1. Connect «TECH2»(ref-278636-S35859646052008013000000) .
2. Establish communication with the audio system.
3. Select " «PROGRAMMING»(ref-278636-S15415482062008013000000) " from the system menu. The text "Marriage/Divorce" is displayed.
4. Press "ENTER".
5. Select DIVORCED with the change button and press "OK". "DIVORCED" must be selected when removing the head unit (to be installed in another car or to be returned for warranty repair).
6. The radio becomes silent and "NO VIN" is shown on the radio display.
7. Carefully remove the plugs by pressing a small screwdriver through the plugs. Pull out the plugs with the screwdriver.
8. Remove the bolts.
9. Pull out the unit
10. Undo the connector and the antenna connection.

Scheme 7

Scheme 8

1. Plug in the connector and the antenna. NOTE: Before the unit has been "MARRIED" to the car, "NO VIN" appears on the radio display.
2. Push the unit into the centre console.
3. Fit the bolts.
4. Fit new plugs, ensuring that the plugs are guided into the location grooves.
5. With Tech2 connected and communicating with the audio system, select " «PROGRAMMING»(ref-278636-S15415482062008013000000) " from the system menu. The text "Marriage/Divorce" is displayed.
6. Press "ENTER".
7. Select MARRIED with the change button and press "OK". "MARRIED" must be selected when installing a head unit into a Saab 9-5.
8. "NO VIN" disappears from the radio display and the sound returns.
9. Carry out spare parts programming using Tech 2.
10. Set the time and date on the unit's clock.

Scheme 9

Scheme 10

1. Remove the main unit. See «HEAD UNIT»(ref-278636-S14559316432008013000000) .
2. Remove the four screws in the front panel.
3. Undo the six locking tabs which hold the front panel in place.

Note. When refitting, ensure that the connector under the front panel is correctly positioned.

To fit

Fit the front panel on the main unit and slide in the main unit. See HEAD UNIT .

Steering wheel switch

Scheme 11

1. Remove the Airbag, driver.
2. Unplug the steering wheel switch connector.
3. Remove the screws. Remove the controls using Removal tool (82 93 474).
4. Remove the cable from the cable mounting.

Scheme 12

1. Fit the steering wheel controls.
2. Fit the cable in the cable mounting.
3. Fit the screws to the steering wheel controls.
4. Plug in the connector.
5. Fit the Airbag, driver

Scheme 13

Scheme 14

1. Remove the sill cover on the passenger side.
2. Remove the lower cover panel.
3. Fold the carpet to one side.
4. Remove the two lower nuts that hold the amplifier and loosen the upper.
5. Lift the amplifier out and unplug the connector.

Refit the parts removed in reverse order.

Note. Physically, the Prestige amplifiers for 4D and 5D cars are the same in appearance and connectors, so that it is possible to connect an amplifier intended for a 5D car into a 4D car. The sound quality from the sub-woofer will not be satisfactory, however, as it will be driven too hard. In the other case, if an amplifier for a 4D car is fitted into a 5D, the sub-woofer reproduction will sound washy.

Scheme 15

1. Remove the speaker grilles on the dashboard.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Scheme 16

1. Remove the speaker grille in the centre of the dashboard.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Scheme 17

1. Remove the door trim to gain access to the speakers.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Note. To obtain the best sound from the speakers, the doors should be air-tight.

Scheme 18

1. Remove the door trim to gain access to the speakers.
2. Remove the screws securing the speakers.
3. Take out the speakers and unplug the connectors.

Fit in reverse order.

Note. To obtain the best sound from the speakers, the doors should be air-tight.

Scheme 19

1. Lower the rear seat.
2. Undo the clips on the protective cover and remove the cover.
3. Remove the four screws holding the speaker.
4. Lift out the speaker and disconnect the connector.

Fit in reverse order.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. Fold down the right-hand rear seat backrest and remove the side bolster between the rear right door and the backrest.
2. Lift out the concealing panel.
3. Remove the right-hand storage compartment in the floor.
4. Remove the scuff plate by first removing the covers on the right and left-hand sides. Undo the screws securing the scuff plate to the sill. Pull off the scuff plate, it is fastened with clips.
5. Remove the rear roof cover and unplug the connections for the lighting.
6. Remove the right-hand D-pillar trim and the right-hand concealing panel support (3 screws).
7. Remove the five screws in the top of the right-hand side trim and lift out the trim.
8. Remove the bass speaker and unplug the connector.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Plug in the connector to the bass speaker and fit the speaker.
2. Position the side trim and tighten the five screws at the top.
3. Refit the concealing panel support (3 screws) and the D-pillar trim.
4. Fit the rear roof cover and plug in the lighting.
5. Press in the scuff plate clips and screw on the scuff plate. Fit the covers over the screws and position the sealing strip over the scuff plate.
6. Fit the storage compartment in the floor.
7. Lift in the concealing panel.
8. Fit the side bolster between the rear right door and the backrest and fold up the rear seat backrest.

Scheme 30

Scheme 31

1. Remove the speaker grille on the right-hand side of the parcel shelf.
2. Remove the sealing strip.
3. Remove the trim on the right-hand C pillar to gain access to the antenna amplifier.
4. Undo all connections to the antenna amplifier.
5. Remove the screws holding the antenna amplifier and remove the unit.

Fit in reverse order.

Scheme 32

Scheme 33

1. Remove the speaker grille on the left-hand side of the parcel shelf.
2. Remove the sealing strip.
3. Remove the trim on the left-hand C pillar to gain access to the antenna filter.
4. Undo the connection to the antenna filter.
5. Remove the screws holding the antenna filter and remove the unit.

Fit in reverse order.

Scheme 34

Scheme 35

1. Remove the rear roof cover and unplug the connectors for the lighting.
2. Remove the D-pillar trim and the roof covers over the rear side windows.
3. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
4. Remove the two clips in the roof and carefully bend down the headlining.
5. Undo all connections to the antenna amplifier. There are two types of antenna amplifier: 1-channel with 2 connectors 2-channel (with diversity function) with 3 connectors
6. Remove the nuts securing the antenna amplifier and remove the unit.

Scheme 36

Scheme 37

1. Fit the antenna amplifier and tighten the nuts.
2. Plug in all cables to the antenna amplifier.
3. Carefully lift up the headlining and fit the two clips in the roof.
4. Refit the C-pillar trims and fasteners over the rear side windows.
5. Fit the roof covers over the rear side windows and refit the D-pillar trim.
6. Plug in the lighting and fit the rear roof cover.

Scheme 38

Scheme 39

1. Remove the rear roof cover and unplug the connectors for the lighting.
2. Remove the D-pillar trim and the roof covers over the rear side windows.
3. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
4. Remove the two clips in the roof and carefully bend down the headlining.
5. Undo all connections to the antenna amplifier. There are two types of antenna amplifier: 1-channel with 2 connectors 2-channel (with diversity function) with 3 connectors
6. Remove the nuts securing the antenna amplifier and remove the unit.

Scheme 40

Scheme 41

1. Fit the antenna amplifier and tighten the nuts.
2. Plug in all cables to the antenna amplifier.
3. Carefully lift up the headlining and fit the two clips in the roof.
4. Refit the C-pillar trims and fasteners over the rear side windows.
5. Fit the roof covers over the rear side windows and refit the D-pillar trim.
6. Plug in the lighting and fit the rear roof cover.

Scheme 42

Scheme 43

1. Remove the rear roof cover and unplug the connectors for the lighting.
2. Remove the D-pillar trim and the roof covers over the rear side windows.
3. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
4. Remove the two clips in the roof and carefully bend down the headlining.
5. Unplug the antenna cable from the antenna amplifier and remove the antenna cable with clips.

Scheme 44

Scheme 45

1. Plug the antenna cable into the antenna amplifier and fit the clips in the roof.
2. Carefully lift up the headlining and fit the two clips in the roof.
3. Refit the C-pillar trims and fasteners over the rear side windows.
4. Fit the roof covers over the rear side windows and refit the D-pillar trim.
5. Plug in the lighting and fit the rear roof cover.

Scheme 46

Do not remove the existing antenna cable without fitting a new one.

1. Remove the sill covers and cable conduit cover on the right-hand side (front and rear doors). Lower the seat cushion and backrest.
2. Remove the speaker grille from the right-hand side of the parcel shelf.
3. Remove the trim on the right-hand C pillar to gain access to the antenna amplifier.
4. Undo the nut securing the luggage compartment trim. Fold the right-hand section to one side.
5. Detach the antenna cable from the antenna amplifier.
6. Cut the antenna cable (the loose part).
7. Connect the new antenna cable to the antenna amplifier.
8. Place the antenna cable in the cable conduit on the right-hand door side. (Attach with a cable tie to prevent rattling.)
9. Fold up the carpet on the right-hand side and pass the cable under the carpet.
10. Remove the main unit (radio) and radio compartment.
11. Push the cable up towards the rear of the compartment.
12. Detach the old antenna cable and cut off the loose part.
13. Connect the new antenna cable.
14. Secure with cable ties to prevent rattling.
15. Refit the removed components.

Scheme 47

Do not remove the existing antenna cable without fitting a new one.

1. Remove the sill covers and cable conduit cover on the right-hand side (front and rear doors). Lower the seat cushion and backrest.
2. Fold down the rear right seat (backrest and seat cushion) and remove the right-hand side bolster.
3. Remove the right-hand side trim in the luggage compartment.
4. Remove the rear roof cover and unplug the connectors for the lighting.
5. Remove the D-pillar trim and the roof covers over the rear side windows.
6. Remove the fasteners in the roof trim over the rear side windows and undo the top of both C-pillar trims.
7. Remove the two clips in the roof and carefully bend down the headlining.
8. Detach the antenna cable from the antenna amplifier.
9. Cut the antenna cable (the loose part).
10. Connect the new antenna cable to the antenna amplifier.
11. Place the antenna cable into the cable duct on the side of the right hand door. (Secure with a cable tie to prevent rattling.)
12. Fold up the carpet on the right-hand side and pass the cable under the carpet.
13. Remove the main unit (radio) and radio compartment.
14. Push the cable up towards the rear of the compartment.
15. Detach the old antenna cable and cut off the loose part.
16. Connect the new antenna cable.
17. Secure with cable ties to prevent rattling.
18. Refit the removed components.

Scheme 48

1. Turn the ignition key to position ON and activate the electrically heated rear window.
2. Get into the rear seat.
3. Have someone cover the entire rear window with a blanket, tarpaulin or similar object. It should be dark (black) inside the car.
4. Check the rear window to see where the break is located. A point of light (spark) should be seen.
5. Mark the point on the window that is damaged.
6. Remove the blanket from the car.
7. Clean around the damaged point carefully and scrape away a few millimetres with a razor blade.
8. Apply (brush on) contact paint 45-3007499 to the damaged point.
9. Cut away surplus contact paint with a razor blade. Use a ruler as a guide.
10. Check antenna performance for good reception.

Scheme 49

Scheme 50

1. Remove the parcel shelf trim.
2. Slightly loosen the screws (A) for the satellite radio receiver.
3. Remove the satellite radio receiver: Unplug the connectors (A) for the satellite radio receiver. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-278636-S16650852252008013000000) . Unhook the bracket from the screws (B). Remove the bracket from the satellite radio receiver (C).

Scheme 51

1. Fit the satellite radio receiver: Fit the bracket for the satellite radio receiver (C). Hook the bracket into the screws (B). Plug in the connectors (A) for the satellite radio receiver. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-278636-S16650852252008013000000) .
2. Tighten the screws (A) for the satellite radio receiver.
3. Fit the parcel shelf trim.
4. Carry out spare parts programming using Tech 2.
5. Activate the satellite radio receiver.

Scheme 52

1. Fold up the luggage compartment trim, floor panel and lift out the storage box.
2. Remove the satellite radio receiver: Unplug the connectors (A) for the satellite radio receiver. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-278636-S16650852252008013000000) . Remove the bracket's nuts (B). Remove the bracket (C) from the satellite radio receiver.

Refitting

1. Fit the satellite radio receiver: Fit the bracket (C) for the satellite radio receiver. Fit the bracket's nuts (B). Plug in the connectors (A) for the satellite radio receiver. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-278636-S16650852252008013000000) .
2. Fit the storage box and fold down the luggage compartment trim, floor panel.
3. Carry out spare parts programming using Tech 2.
4. Activate the satellite radio receiver.

Satellite radio receiver, activation

1. Acivate the audio system head unit.
2. Set XM radio to channel 1 and not the radio ID. NOTE: The radio receiver ID is needed to activate the receiver.
3. Call XM at 1-800-556-3600 to activate the receiver.
4. Park the car outdoors in a area with nothing blocking the sky southwards.
5. Allow the car to remain outdoors for 30 minutes with the ignition in the ON position and the radio activated in order to activate the XM service.
6. The satellite radio receiver will receive the remaining XM channels after activation.

Scheme 53

1. Head unit (353)
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Amplifier (354)
5. Speaker, centre dashboard (266FC)
6. Speaker, left dashboard (266LF)
7. Speaker, right dashboard (266FR)
8. Speaker, driver's door (266D)
9. Speaker, passenger door (266P)
10. Speaker, left rear door (266RPL)
11. Speaker, right rear door (266RPR)
12. Antenna, satellite radio (364a)
13. Antenna, window glass, radio (625)
14. Antenna filter (644)
15. Radio aerial amplifier (624)
16. Steering wheel switches (633)

Scheme 54

1. Head unit (353)
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Amplifier (354)
5. Speaker, centre dashboard (266FC)
6. Speaker, left dashboard (266LF)
7. Speaker, right dashboard (266FR)
8. Speaker, driver's door (266D)
9. Speaker, passenger door (266P)
10. Speaker, left rear door (266RPL)
11. Speaker, right rear door (266RPR)
12. Speaker, left parcel shelf (266RL)
13. Speaker, right parcel shelf (266RR)
14. Antenna, satellite radio (364a)
15. Antenna, window glass, radio (625)
16. Antenna filter (644)
17. Radio aerial amplifier (624)
18. Steering wheel switches (633)

Scheme 55

1. Head unit (353)
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Speaker, left dashboard (266LF)
5. Speaker, right dashboard (266FR)
6. Speaker, left rear door (266RPL)
7. Speaker, right rear door (266RPR)
8. Antenna, satellite radio (364a)
9. Antenna, window glass, radio (625)
10. Antenna filter (644)
11. Radio aerial amplifier (624)
12. Steering wheel switches (633)

Scheme 56

Scheme 57

1. Head unit (353)
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Amplifier (354)
5. Speaker, centre dashboard (266FC)
6. Speaker, left dashboard (266LF)
7. Speaker, right dashboard (266FR)
8. Speaker, driver's door (266D)
9. Speaker, passenger door (266P)
10. Speaker, left rear door (266RPL)
11. Speaker, right rear door (266RPR)
12. Antenna, window glass, radio (625RR) or (625RR and 625RL)
13. Antenna amplifier, radio (624RR) alt. (624RR and 624RL)
14. Antenna, satellite radio (364a)
15. Steering wheel switches (633)

Scheme 58

1. Head unit (353)
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Amplifier (354)
5. Speaker, centre dashboard (266FC)
6. Speaker, left dashboard (266LF)
7. Speaker, right dashboard (266FR)
8. Speaker, driver's door (266D)
9. Speaker, passenger door (266P)
10. Speaker, left rear door (266RPL)
11. Speaker, right rear door (266RPR)
12. Speaker, luggage compartment, left (266RL)
13. Speaker luggage compartment, right (266RR)
14. Antenna, window glass, radio (625RR) or (625RR and 625RL)
15. Antenna amplifier, radio (624RR) alt. (624RR and 624RL)
16. Antenna, satellite radio (364a)
17. Steering wheel switches (633)

Scheme 59

1. Head unit (353)
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Speaker, left dashboard (266LF)
5. Speaker, right dashboard (266FR)
6. Speaker, left rear door (266RPL)
7. Speaker, right rear door (266RPR)
8. Antenna, window glass, radio (625RR)
9. Antenna amplifier, radio (624RR)
10. Antenna, satellite radio (364a)
11. Steering wheel switches (633)

Scheme 60

The Saab Audio System is a complete sound system for the car, including radio reception and a number of other functions.

The audio system is equipped with an electronic theft protection system that interacts with the car by means of the audio system being "married" to the car and accordingly linked to the car in which it was first installed. Each time the audio system is turned on a check is carried out to make sure the correct audio system is being used.

The audio system is available in three models: Popular, Premium and Prestige.

Each system contains the following units

1. Main unit: Radio CD Player/changer
2. Satellite radio receiver (349)
3. SID, control module (541)
4. Amplifier (Premium and Prestige only)
5. Speakers
6. Antenna system
7. Steering wheel controls

The head unit is mounted in the centre console. The radio and CD player/changer are built into the head unit. On the head unit there is a display and control buttons for controlling the different functions of the audio system.

The head unit communicates with the various other units and systems via the car's bus and wiring harnesses.

Radio

The radio section of the audio system is an AM/FM receiver with PLL frequency synthesis for exact station tuning. The frequency bands of the radio are pre-programmed in the factory to suit the different markets. In the event of a loss of power (e.g. due to disconnection of the battery) the programmed settings are not lost.

CD Player/CD changer

In the head unit there is either a CD player or a CD changer installed.

The CD player/CD changer is front loading with an indicator that shows when a CD is loaded. The CD player's disc drawer accommodates 1 compact disc (dia.8 or 12 cm). The CD changer's magazine accommodates 6 compact discs.

Display

The head unit of the audio system has its own display to show the current settings for the chosen source.

Amplifier

The Premium and Prestige audio systems both have external amplifiers. The amplifier in the Prestige system has a higher output power than the Premium. It is available in two models, one for the 4D and one for the 5D.

Premium has 7 output channels and Prestige 9 output channels for speakers. The two additional output channels on the Prestige system are for bass speakers in the parcel shelf on the 4D or on the right-hand side of the luggage compartment on 5D.

The amplifier has a separate power supply. It is not connected to the bus.

Speakers

The Premium and Prestige audio systems have side and centre speakers in the dashboard and speakers in the front and rear doors. The Prestige system also includes bass speakers in the parcel shelf on 4D cars and one bass speaker on the right-hand side of the luggage compartment on 5D cars.

The Popular audio system has side speakers in the dashboard and speakers in the rear doors.

Antenna system AM/FM (4D)

There are two different types of antenna system for radio reception

1. Antenna system 1 consists of an AM and an FM antenna with an antenna amplifier. System 1 is fitted to the car as standard in the EU and PA markets. Antenna system 1 is also used for a make of radio different to that used by Saab in the Saab Audio System.
2. Antenna system 2 consists of an AM, an FM1 and an FM2 antenna with an antenna amplifier. System 2 is fitted as standard in cars for the US and JP markets. Antenna system 2 can only be used for the main units of the Premium and Prestige systems.

The antennas are fitted to the rear window. The AM antenna forms a separate loop and the FM antennas are integrated with the heating element on the rear window. The rear window is the same for both antenna systems, which allows the option of upgrading from antenna system 1 to 2.

The antenna amplifier is powered from the head unit and the amplified antenna signal is supplied to the radio via a coaxial cable.

Antenna system AM/FM (5D)

There are two different types of antenna system for radio reception

1. Antenna system 1 is intended for audio system: Popular, Premium and Prestige and comprises: an AM and FM antenna with antenna amplifier and coaxial cable for connecting between the amplifier and the head unit.
2. Antenna system 2 is intended for audio systems: Premium and Prestige and comprises: an AM and FM antenna with antenna amplifier and coaxial cable for connecting between the amplifier and the head unit. an FM antenna with antenna amplifier and a coaxial cable for connecting between the two antenna amplifiers.

The AM/FM antenna is located in the rear right side window and its antenna amplifier in the roof above the rear right side window.

The FM antenna is located in the rear left side window and its antenna amplifier in the roof above the rear left side window.

The antenna system can be upgraded to antenna system 2 on markets where antenna system 1 is fitted as standard.

The antenna amplifier is powered from the head unit and the amplified antenna signal is supplied to the radio via a coaxial cable.

Satellite radio reception (certain markets)

Within the audio system there is a receiver for satellite radio reception which is located under the parcel shelf in four door cars or under the forward luggage compartment floor in five door cars. The antenna is located on the roof and is a combined antenna for radio, telephone and GPS.

Steering wheel controls

The steering wheel is fitted with special switches to enable the most important functions of the audio system to be operated simply and reliably.

The switches are connected to the SID control module which senses the switch positions and transmits information, via the bus, to the head unit.

Scheme 61

1. Power supply +30 (1)
2. Ground (G42/G40)
3. Antenna signal, HF (624, 625)
4. Audio signal On Star (673)
5. Audio signal telephone (375)
6. Audio signal satellite radio receiver (349)

Scheme 62

1. Ignition +B (on/off) from DICE (628)
2. Vehicle speed (km/h, mph) from MIU (540)
3. Rheostat value (0-100%) from SID (541)
4. Rheostat Night Panel (0-100%) from SID (541)
5. Night Panel (on/off) from SID (541)
6. Display illumination (0-100%) from SID (541)
7. Steering wheel switches from SID (541)
8. Key Correct (on/off) from TWICE (632)
9. Wheel speed RL (km/h) from ESP (671)
10. Diagnostics communication, see «BUS AND DIAGNOSTICS COMMUNICATION»(ref-278620) .

Scheme 63

1. Trigger voltage (624)
2. Mute control, external amplifier (354)
3. Line output, right-hand channel +/- (front) (354)
4. Line output, left-hand channel +/- (front) (354)
5. Line output, right-hand channel +/- (rear) (354)
6. Line output, left-hand channel +/- (rear) (354)
7. Speaker, right-hand channel +/- (front) (266)
8. Speaker, left-hand channel +/- (front) (266)
9. Speaker, right-hand channel +/- (rear) (266)
10. Speaker, left-hand channel +/- (rear) (266)

Scheme 64

1. Time RDS (hr, min, sec) used by SID (541)
2. Date RDS (0 - 31) used by SID (541)
3. Month RDS (Jan-Dec) used by SID (541)
4. Diagnostics communication, see «BUS AND DIAGNOSTICS COMMUNICATION»(ref-278620) .

Scheme 65

Scheme 66

Power supply +30

From fuse 9 to the head unit, pin 1(K14).

Scheme 67

Scheme 68

Ground connection

The head unit is grounded (main ground) at grounding point G42 (LHD) and G40 (RHD) via pin 8 (K14).

Scheme 69

The head unit is connected to the wiring harness and the bus via one 14 pin and one 16 pin connector.

The purpose of the main unit is to control the system units and functions of the audio system as follows

1. To activate the audio system units by sending "wake-up" information. "Wake-up" can be information sent via the bus or logic voltage (trigger voltage) via the wiring harness. When the "wake-up" signal is received, the unit is switched on and becomes active. Wake-up with trigger voltage (12 V) Amplifier (Premium/Prestige) Antenna amplifier Wake-up with bus information SID Satellite radio receiver Control module, DICE
2. To receive audio and antenna signals from the units in the system. Audio signals are sent on via the main unit outputs to the amplifier and speakers.

Activation

The audio system is turned on/off by pressing the volume control knob. When switched on, the system starts with the last settings that were active.

The system can be activated irrespective of the position of the ignition switch, even if the key has been removed (+B information goes via the bus).

If the ignition is turned OFF and the key remains in the lock, the audio system will automatically stop one hour after the button was last activated. This applies even if the audio system is turned on when the key is not in the ignition.

Control functions

The audio system is controlled using buttons on both the steering wheel and the control panel.

Control panel buttons.

Scheme 70

1. Switching the Audio system on and off. Adjusting the volume.
2. Information about the artist, album and song title. Display of the radio text.
3. The tone control is used for adjustment of the tone and loudspeaker settings. Change of track/file on a CD or MP3 disc and manual frequency setting.
4. Settings menu.
5. Scroll between preset pages.
6. The menu alternatives shown on the display are selected with the appropriate menu selection button directly underneath.
7. Traffic messages on/off
8. Activation and selection of programme type.
9. cars with CD changer: Loading of CD or MP3 discs. Cars without CD changer: Setting the time and date.
10. Loading a CD or MP3 disc.
11. Activating the radio and changing the frequency band.
12. Automatic frequency searching downwards and change of track/file backwards on a CD or MP3 disc.
13. Automatic frequency searching upwards and change of track/file forwards on a CD or MP3 disc.
14. Automatic frequency searching and rapid play backwards of a track/file on a CD or MP3 disc.
15. Automatic frequency searching and rapid play forwards of a track/file on a CD or MP3 disc.
16. Activation of CD media or a portable player.

Steering wheel controls, audio system

Scheme 71

1. "Arrow up"/"Arrow down": Change of preset for radio stations, change of track on the CD or MP3 disc.
2. "NXT": Automatic frequency searching upwards, choice of next track on a CD or MP3 disc. Activation of test listening of radio stations
3. SRC: Push to change between Radio, CD, MP3, CD changer or portable player.
4. VOL: Adjusts the volume. IMPORTANT: In the service manual the normal handling of the audio system is not dealt with. Detailed information regarding handling can be found in the owner's manual.

Bus messages, Audio

For a further description of the car's bus system, see SYSTEM OVERVIEW, BUS AND DIAGNOSTICS COMMUNICATION, PETROL and SYSTEM OVERVIEW, BUS AND DIAGNOSTICS COMMUNICATION, DIESEL .

The head unit uses the following information

INFORMATION CHART

The head unit transmits the following information

INFORMATION CHART

Integrated in the main radio unit is an amplifier which drives the loudspeakers in the Popular audio system. The Premium and Prestige audio systems are fitted with separate amplifier units which drive the speakers in each system.

Twisted pair cables are used for all speakers which means that they are less susceptible to interference from other cables.

4D

In the Popular audio system there are two speakers in the outer edges of the dashboard and two in the rear doors.

Scheme 72

In the Premium audio system there are also speakers in the front doors and a central speaker in the dashboard.

Scheme 73

In the Prestige audio system there are two further speakers in the parcel shelf.

Scheme 74

5D

In the Popular audio system there are two speakers in the outer edges of the dashboard and two in the rear doors.

Scheme 75

In the Premium audio system there are also speakers in the front doors and a central speaker in the dashboard.

Scheme 76

In the Prestige audio system there is also a bass speaker located in the luggage compartment.

Scheme 77

The radio receiver is integrated in the head unit. The radio section is an AM/FM receiver with PLL frequency synthesis for exact station tuning (frequency locking).

Function

The antenna signal is fed from the antenna amplifier via coaxial cable and a separate connector to the head unit. For further information about the car antenna system. See ANTENNA SYSTEM, RADIO (4D) and ANTENNA SYSTEM, RADIO (5D) .

The radio is activated with the RADIO BAND button on the head unit. When the radio is active information is sent on the bus.

RDS

The RDS (Radio data System) is an information system that transmits in parallel with radio programmes on the FM network. The signals from such a FM station make it possible to search for the most powerful transmitter for that particular station and thus to maintain the best reception. The automatic transmission of traffic messages and programme type vigilance are examples of functions made possible through RDS. A precondition for the proper functioning of RDS is the existence of normal reception conditions.

RDS, functions

1. Alternative frequency (AF)
2. Regional frequencies (REG)
3. Rolling advertisements
4. Radio text
5. Programme type, seeking and vigilance (PTY)
6. Interruption for traffic messages (TP/TA)

CD player/CD changer/MP3 player

In the head unit there is either a CD player or a CD changer installed.

Scheme 78

The CD player is front-loading. The disc drawer accepts one compact disc.

The CD player is activated either by loading a disc in the disc drawer or by pressing the CD AUX button if a disc has already been loaded.

When all tracks have been played the disc will play again from the beginning. The CD player is switched off either by selecting another audio source or by pressing the ON/OFF button to shut down the audio system.

The CD is unloaded by pressing the EJECT button. If the ejected disc is not removed, the player will, for safety reasons, re-load the disc after 10 s.

Scheme 79

The CD changer is front-loading. The disc magazine accommodates six CD discs.

The CD changer is activated either by loading one or more CD/MP3 discs in the disc magazine or by the CD AUX button if a disc is already loaded. In order to load a disc push the LOAD button and follow the instructions on the display.

When all tracks have been played the CD will play again from the beginning. The CD changer is switched off either by selecting another audio source or by pressing the ON/OFF button to shut down the audio system.

The CD is unloaded by pressing the EJECT button. If the ejected disc is not removed, the player will, for safety reasons, re-load the disc after 10 s.

MP3 player

The audio system can play MP3 files that have been recorded on a compact disc with a bit speed of 32 - 320 kbps. The sound quality can vary depending on the quality of the recording disc, the recording method or the quality of the recorded music. The audio system can read and play a maximum of 50 MP3 folders, 50 play lists, 10 sessions and 255 MP3 files. Discs that contain more folders, play lists sessions and files will be played up to the maximum limit but everything over the limit will be ignored.

The MP3 player is activated either by loading a CD-R disc with MP3 files in the disc drawer or by pressing the CD AUX button if a disc with MP3 files has already been loaded.

The MP3 player is switched off either by selecting another audio source or by pressing the ON/OFF button to shut down the audio system.

The MP3 disc is unloaded by pressing the EJECT button. If the ejected disc is not removed, the player will, for safety reasons, re-load the disc after 10 s.

Scheme 80

The AUX input is located at the bottom right of the head unit. A portable unit such as a MP3 player can be connected to the audio system via this input. The sound is adjusted on the control panel or on the steering wheel. Other operations such as track changing, fast reeling etc. are selected with the controls on the portable unit.

Audio system with CD changer

1. Push the clock button
2. Press the menu selection button directly below the menu alternative you wish to change.
3. Push the menu selection button to increase the time or date one step at a time. The time and date can also be adjusted by pushing the SEEK, FWD or REV buttons.

Audio system without CD changer

1. Push the MENU button.
2. Press the menu selection button directly below the clock symbol on the display.
3. Press the menu selection button directly below the menu alternative you wish to change.
4. Push the menu selection button to increase the time or date one step at a time. The time and date can also be adjusted by pushing the SEEK, FWD or REV buttons.

RDS time

For RDS time to be available, radio reception must be normal and the current radio station must be transmitting RDS time signals, (CT Clock Time).

1. In the clock menu, press the menu selection button directly below the arrow symbol on the display.
2. Press the menu selection button directly below the RDS time menu alternative.
3. The clock is now adjusted automatically and the display shows: "Adjusting to RDS time...". If no time information is available or the RDS reception is poor, the display shows: "No RDS time accessible".

Scheme 81

Normally the navigation system receives the correct time and date via GPS signals.

Press the button indicating time at the top right of the screen to display today's date for 5 seconds.

Manual setting

If the GPS time is incorrect or if there is no GPS signal then the time and date can be adjusted manually.

1. Hold the button indicating time, at the top right of the screen, depressed for more than 2 seconds to switch to the menu for setting time.
2. Adjust the time and date.

Scheme 82

Scheme 83

The Premium and Prestige audio systems each contain a separate amplifier unit which supplies the speakers in the system. The amplifier is connected to the wiring harness via a 39-pin connector.

The amplifier for Prestige is available in two models, one for 4D and one for 5D cars. As the sub-woofer system for 5D cars is different, having another speaker element and location, the power amplifier outputs for the sub-woofer system require other characteristics.

The difference compared with Prestige for the 4D is that another type of signal filtering is required in the amplifier in order to drive the speaker element in the sub-woofer cabinet on the 5D.

Note. Physically, the Prestige amplifiers for 4D and 5D cars are the same in appearance and connectors, so that it is possible to connect an amplifier intended for a 5D car into a 4D car. The sound quality from the sub-woofer will not be satisfactory, however, as it will be driven too hard. In the other case, if an amplifier for a 4D car is fitted into a 5D, the sub-woofer reproduction will sound washy.

1. The amplifier unit is powered separately (+30) from fuse 13 to pins 1 and 2 in the amplifier connector. When the audio system is activated, a trigger voltage is simultaneously supplied from pin 6(K14) of the head unit to pin 12 of the amplifier connector. The trigger voltage then activates the amplifier.
2. Audio - the input signal (four channels) is supplied by the head unit line outputs to the amplifier. Two channels are used for the front speaker and two for the rear (fader function).
3. Audio Premium - the output signal (6 + 1 channels) from the amplifier to the front and rear speakers.
4. Audio Prestige - the output signal (8 + 1 channels) from the amplifier to the front and rear speakers.
5. Mute control - is supplied by pin 8(K16) of the head unit to pin 11 in the amplifier connector to disconnect the sound. It prevents a clicking sound from being heard in the speakers when the ignition is switched on or off.

See TEST READINGS, AMPLIFIER CONNECTIONS .

Scheme 84

Scheme 85

Antennas

The antennas for radio reception are integrated in the rear window and are located as follows

1. AM - antenna positioned at the top of the rear window.
2. FM - antenna (antennae) integrated in the heating element.

The rear window is the same on all markets.

The antenna signal is amplified by an amplifier located on the right-hand C-pillar. The Premium and

Prestige systems have one of two different antenna amplifiers, red or black, depending on the market. The black amplifier is used for the Popular system.

The antenna amplifier is supplied with trigger voltage from pin 12(K14) of the head unit and is grounded by being bolted to the chassis.

The black amplifier is used on all markets for retrofitted radios.

The left-hand C-pillar has an antenna filter that grounds the heating element but prevents the antenna signal from going to ground. The antenna filter is fitted as standard on all cars.

Scheme 86

1. Separate AM antenna loop at top of rear window.
2. FM1 antenna on same connection as the heating element. A filter in the antenna amplifier prevents the antenna signal from going to the heating element's power supply. An antenna filter on the ground side of the heating element prevents the antenna signal from going to ground.
3. The heated rear window is connected to the antenna amplifier and antenna filter. A capacitor prevents the voltage from reaching the antenna amplifier. The rear window heating is grounded via the antenna filter.

The amplified signal is fed via a coaxial cable to the radio.

Scheme 87

1. Separate AM antenna loop at top of rear window.
2. FM1 antenna on same connection as the heating element. A filter in the antenna amplifier prevents the antenna signal from going to the heating element's power supply. An antenna filter on the ground side of the heating element prevents the antenna signal from going to ground.
3. FM2 antenna on the same connector as the AM antenna on the rear window. It is connected to a loop above the AM antenna and to the heating element.
4. The heated rear window is connected to the antenna amplifier and antenna filter. A capacitor prevents the voltage from reaching the antenna amplifier. The rear window heating is grounded via the antenna filter.

The antenna amplifier has a switching function that, working with the radio, selects the best FM signal (selects FM1 or FM2).

The amplified signal is fed via a coaxial cable to the radio.

Scheme 88

Scheme 89

Two types of antenna are available for the audio system

1. Antenna system 1 with an AM/FM antenna and antenna amplifier is intended for audio systems Popular, Premium and Prestige.
2. Antenna system 2 with an AM/FM antenna and an FM antenna with antenna amplifier for each antenna is intended for audio systems Premium and Prestige.

The antennas for radio reception are integrated in the rear side windows and are located as follows

1. The AM/FM antenna is located in the rear right side window.
2. The FM antenna is located in the rear left side window.

The rear side windows are the same on all markets.

Antenna amplifier

The antenna amplifiers are located in the roof above the respective rear side window and are available in three models, one for antenna system 1 and two for antenna system 2.

The antenna signal is amplified in the antenna amplifier and passed via the coaxial cable to the head unit (radio). The amplifier is powered with a trigger voltage from pin 12(K14) on the head unit and is grounded by being bolted to the body.

Scheme 90

Antenna system 1 comprises

1. AM/FM antenna integrated in the rear right side window.
2. AM/FM antenna amplifier, on right-hand side
3. coaxial cable between the antenna amplifier and the head unit (radio)

Scheme 91

Antenna system 2 comprises

1. AM/FM antenna integrated in the rear right side window.
2. AM/FM antenna amplifier, on right-hand side
3. FM antenna integrated in the rear left side window
4. FM antenna amplifier on the left-hand side
5. coaxial cable between the FM amplifier on the left-hand side and the AM/FM amplifier on the right-hand side
6. coaxial cable between the AM/FM amplifier and the head unit (radio)

Antenna system 2 has a diversity functions, which means that whichever of the two antennas is giving the best signal is used by the radio receiver. The diversity function works only together with the Saab audio systems Premium and Prestige.

Audio system without navigation.

Scheme 92

Audio system with navigation

Scheme 93

Scheme 94

The audio system can also be operated with the steering wheel controls (control buttons on the steering wheel). The steering wheel controls which are used for the audio system comprise 2 units (6 switches). Full instructions for their use are given in the owner's manual.

The steering wheel switches are connected to SID control module which communicates information defining which switches are active. SID sends information about the buttons on the bus which is then read by the head unit.

The SID control module supplies +5V to the steering wheel controls via pin 25 and grounds them via pin 26.

The steering wheel control switches incorporate resistors connected in series. When a button is pressed, the activated switch is grounded, see the table.

The value of the total resistance in the circuit changes according to which switch is depressed and there is a corresponding change in the voltage which is sensed by the SID control module.

Automatic volume control is controlled by the car's speed to compensate for background noise that occurs when the car is being driven. The function is active at speeds over 25 km/h (16 mph).

One of the following sensitivity levels can be selected for the function

1. Off (no compensation)
2. Low (low compensation)
3. Med (medium compensation)
4. High (high compensation)

The ESP control module transmits a speed signal on the P-bus. This is read by the MIU. The MIU then transmits the information on the I-bus, which the head unit can read to regulate volume. The level is increased when speed increases and is lowered when speed decreases.

Scheme 95

Scheme 96

The audio system is equipped with electronic theft protection. Information concerning the theft protection device is connected in the form of a code to the audio system of the car in which it is installed. Programming is performed with the diagnostic tool.

Theft protection is effected by "marrying" the head unit to the car. If such a "marriage" has not occurred, "LOCKED" will be displayed when attempting to activate the audio system.

The audio system checks at regular intervals that the theft protection information is correct (if "marriage" has occurred). This applies also if +30 is temporarily disconnected. If the information is not correct the display shows "LOCKED".

Scheme 97

For satellite radio reception there is a receiver unit connected to the audio system head unit (EHU) and to the roof mounted satellite radio antenna.

The digital receiver unit is placed under the parcel shelf in 4D cars or under the forward luggage compartment floor in 5D cars. The antenna is located on the roof and is a combined antenna for radio, telephone and GPS. The satellite radio receiver receives signals from satellites and slave transmitters. The receiver has a frequency range of 2332 to 2345 MHz.

A special subscription is required in order to listen to satellite radio via the receiver.

Scheme 98

Main fuse board 22a in the dashboard

Location: On the short side of dashboard beside driver's door.

Upper socket is input current.

LHD

Scheme 99

Scheme 100

RHD

MAIN FUSE BOARD 22A REFERENCE No. Value Type Function Illustration A 30 A +30 Prepared pull installation B 10 A +15 TCM C 7.5 A +54 Electrically adjustable door mirror DICE Manual beam length control 1 15 A +30 Brake light switch Brake light 2 15 A +54 Rear light 3 10 A Parking light LH 4 10 A Parking light RH 5 7.5 A +B DICE/TWICE 6 30 A +54 Electric window lifts, right Prepared pull installation 6B 10 A Brake light, prepared pull installation 7 10 A Injection valves, petrol engine Solenoid valve, turbo by-pass Solenoid valve, EVAP shut-off EVAP canister purge valve, evaporative emission canister 8 15 A +30 SID Interior lighting Courtesy lights SPA Engine, pump, coolant circulation 9 15 A +30 Audio System CD changer Diagnostics socket 10 15 A +30 Heated rear seat Sunroof Antenna remote control central locking 11 30 A +30 Electrically adjustable passenger seat 12 7.5 A +30 TCM 13 20 A +30 Amplifier 14 30 A Engine control module DI Mass air flow sensor Solenoid valve, charge air Solenoid valve unit, EGR Solenoid valve, swirl throttle Actuator, throttle body Control module, glow plug 15 20 A Pre-heating oxygen sensor Fuel pump, petrol 16 20 A +30 DICE/Direction indicators 16B 7.5 A +30 Road-toll fee, prepared installation OnStar 17 20 A +30 MIU Trionic DICE/TWICE 18 40 A +30 Electrically heated rear- mirrors Electrically heated rear window 19 10 A +15 Telephone/OnStar 20 15 A +30 ACC Interior lighting Rear fog light 21 10A +15 Audio/Navigation system ADM Automatic beam length control Pedal switches, cruise control 22 40 A +30 Ventilation fan motor 23 15 A +30 Central locking system Telephone PMM 24 20A +X Light switch 25 30 A +30 Electrically adjustable driver's seat 26 7.5 A +15 SPA Sunroof PSM PMM Seatbelt reminder lamp ACC 27 10 A +15 Engine control module MIU SID DICE Parking Heater Solenoid valve, charge air Unit, mass air flow sensor Unit, fuel filter, diesel 28 7.5 A +15 Airbag/SRS Indicator lamp Passenger Airbag ON/OFF 29 10 A +15 ESP 30 7.5 A +50 Control voltage, start relay 31 7.5 A +54 Switch, cruise control Solenoid valve, heat exchanger Fog light Rain sensor 32 - - 33 7.5 A +54 Switch, Direction indicators 34 30 A +54 Cigarette lighter 35 15 A +54 Running lights 36 30 A +54 Electric window lifts, left 37 30 A +54 Windscreen wipers 38 30 A +30 Electrically heated, seats (ACC) 39 20 A (petrol) 30 A (diesel) +30 Limp-home solenoid Heating element, fuel filter, diesel

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Radio, satellite reception (349)

4D

Scheme 157

5D

Scheme 158

Main unit, audio system (353)

K14

Scheme 159

K16

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

K12

Scheme 171

K16

Scheme 172

K12

Scheme 173

K16

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Location: In passenger compartment on left-hand side of knee member.

A. Connected components of LHD car

COMPONENTS OF LHD CAR

B. Connected components of RHD car

COMPONENTS OF RHD CAR

Scheme 191

Scheme 192

Location: Left-hand grounding screw in centre of knee protection bar (in cabin)

Connected components

MAIN INSTRUMENT UNIT REFERENCE

Scheme 193

Scheme 194

Location: On right-hand side of knee member.

COMPONENTS OF LHD CAR

COMPONENTS OF RHD CAR

Scheme 195

Scope

Nominal values and instructions for measuring voltages on the control module can be found under the respective headings below.

Remember

1. Note the test conditions and use common sense when assessing the test result.
2. The nominal test readings shown apply with the ignition switched ON unless otherwise stated.
3. First check that the control module has a power supply and is grounded.
4. Then check all sensor inputs and signals from other systems.
5. Finally, check the outputs. Remember that the test readings do not tell us whether or not the module is functioning properly.
6. If any reading is not OK, consult the wiring diagram to trace the leads, connectors or components which should be checked more thoroughly.
7. The specified test readings refer to those obtained with a calibrated Fluke 88/97.
8. Test readings % (+) and ms (+) show the pulse ratio and pulse duration of the signal. The test instrument used must be able to measure pulse ratio and pulse width. The (+) sign denotes a positive trigger pulse, TRIG+ .

Scheme 196

Connections, head unit

> = greater than; < = less than; ~ = AC voltage (LP: LOGIC PROBE P = select pulse; p = visible pulses)

K14

Scheme 197

HEAD UNIT REFERENCE

K16

Scheme 198

HEAD UNIT REFERENCE

Scheme 199

RADIO RECEIVER, SATELLITE RADIO REFERENCE

Scheme 200

MANUFACTURER CHART

Scheme 201

MANUFACTURER CHART

Scheme 202

DIAGNOSIS PROCEDURE

Scheme 203

MANUFACTURER CHART

Scheme 204

MANUFACTURER CHART

Scheme 205

MANUFACTURER CHART

Scheme 206

MANUFACTURER CHART

Scheme 207

MANUFACTURER CHART

Scheme 208

MANUFACTURER CHART

Scheme 209

MANUFACTURER CHART

Scheme 210

MANUFACTURER CHART

Scheme 211

MANUFACTURER CHART

Scheme 212

INTEGRAL GLASS ANTENNA CHART

Scheme 213

INTEGRAL GLASS ANTENNA CHART

Scheme 214

INTEGRAL GLASS ANTENNA CHART

Scheme 215

MANUFACTURER CHART

Scheme 216

ANTENNA, MOBILE PHONE/GPS/ONSTAR/SATELLITE RADIO REFERENCE

Scheme 217

VOLTAGE AND RESISTANCE CHART

Scheme 218

VOLTAGE AND RESISTANCE CHART

Scheme 219

HEAD UNIT SPECIFICATIONS

RADIO SPECIFICATIONS

CD Player

CD PLAYER SPECIFICATIONS

CD changer

CD CHANGER SPECIFICATIONS

Nominal values and instructions for measuring voltages on the control module can be found under the respective headings below.

1. Note the test conditions and use common sense when assessing the test result.
2. The nominal test readings shown apply with the ignition switched ON unless otherwise stated.
3. First check that the control module has a power supply and is grounded.
4. Then check all sensor inputs and signals from other systems.
5. Finally, check the outputs. Remember that the test readings do not tell us whether or not the module is functioning properly.
6. If any reading is not OK, consult the wiring diagram to trace the leads, connectors or components which should be checked more thoroughly.
7. The specified test readings refer to those obtained with a calibrated Fluke 88/97.
8. Test readings % (+) and ms (+) show the pulse ratio and pulse duration of the signal. The test instrument used must be able to measure pulse ratio and pulse width. The (+) sign denotes a positive trigger pulse, TRIG+ .

> = greater than; < = less than; ~ = AC voltage (LP: LOGIC PROBE P = select pulse; p = visible pulses)

K14

DIAGNOSIS PROCEDURE

K16

DIAGNOSIS PROCEDURE

Amplifier, Premium

MANUFACTURER CHART

Scheme 220

See service manual 1:4 TECH2

Group: Test equipment

TECH2 SPECIFICATIONS

Scheme 221

Group: Body

BODY SPECIFICATIONS

Scheme 222

ACC

Saab 9-5 Audio System, power amplifier

Group: Test equipment

TEST EQUIPMENT SPECIFICATIONS

Scheme 223

Group: Test equipment

TEST EQUIPMENT SPECIFICATIONS

Scheme 224

Group: Test equipment

TEST EQUIPMENT SPECIFICATIONS

Scheme 225

Group: Test equipment

TEST EQUIPMENT SPECIFICATIONS

Scheme 226

Voltage range 8-16V

Group: Test equipment

TEST EQUIPMENT SPECIFICATIONS

Scheme 227

1. The customer's description of the problem constitutes a basis for the fault diagnosis strategy. If necessary, the customer must demonstrate the trouble on the car to avoid misunderstandings.
2. In certain cases, the function may be correct. 2.a. Good product knowledge is required to decide this. 2.b. If the function is correct, this must be explained to the customer.
3. If the function is judged to be faulty, the car should be repaired. Saab's fault diagnosis strategy assumes that the technician is familiar with the customer's description of the problem. So note the customer's complaint and any other observations on the job sheet.
4. The technician obtains a readout of the diagnostic trouble codes from all systems. A malfunction in one system can often be caused by a fault in another system.
5. The car may contain diagnostic trouble codes which are secondary faults or which have been incorrectly generated. 5.a. Compare the customer complaint with the symptom description for the various diagnostic trouble codes. WIS has a quick search function for this purpose. 5.b. If the symptom description for a diagnostic trouble code matches the customer's complaint, this diagnostic trouble code is probably caused by the primary fault. Repair as per instructions.
6. If there is no match with diagnostic trouble codes or symptoms, the technician must diagnose the fault himself. 6.a. Search in WIS under fault diagnosis for symptoms in the system where the fault exists. Also check whether there is a TSB/MI in force. 6.b. If the symptom description in the current system matches the complaint, the right fault diagnosis description has probably been found. Repair as per instructions.
7. Certain fault symptoms can be remedied by reprogramming the control module. 7.a. Does the customer complaint stem from a known software problem in a programmable control module? 7.b. Reprogram the control module following the instructions in SPS.
8. If there is no match with diagnostic trouble codes or symptoms, the technician must diagnose the fault himself. Good technical product knowledge is required to solve this type of problem.
9. A final check must be carried out after the repair.
10. The car is ready.

Control module

When the control module is supplied with current, the processor in it is tripped. The processor then reads the instructions stored in the control module's memory.

The control module is programmed to read the inputs and activate the outputs. If the control module program is faulty, the diagnostic trouble code "Internal Control Module Fault" will be generated.

The control module must be supplied with current before the system will function. The control module is supplied with current and the processor tripped when the control module can be contacted by the diagnostics instrument.

Outputs

The purpose of the system is to control a number of functions by means of various actuators, such as an injector or lamp. For the system to be capable of performing its functions, it must be possible to activate the actuators. For this reason the actuators must be connected to the control module and have a proper power supply or ground connection.

The performance of the majority of the actuators can be checked with the diagnostics instrument.

Inputs

A condition for the control module's capability of controlling its actuators is that the system's sensors supply it with correct values.

Sensor performance can be checked with the diagnostics instrument.

Scheme 228

Menu "Read Values"

READ VALUES CHART

Menu "Programming"

PROGRAMMING CHART

Menu "System Information"

SYSTEM INFORMATION CHART

Scheme 229

It is our experience that the majority of control modules returned to us for repair or replacement under warranty are in perfect working order. In these cases, fitting a new control module has obviously not cured the fault. Therefore, go through all the following points carefully before changing the control module

Scheme 230

1. Check the latest edition of TIS2000 to see whether the problem can be solved with a control module software update (for control modules that can be reprogrammed). IMPORTANT: Avoid SPS programming unless it is absolutely necessary. It is extremely important to follow the instructions for SPS programming to avoid damaging the control module.
2. Check all grounding points and the power supply to the control module.
3. Check with a diagnostic tool that all the readings are plausible (several readings can affect one function).
4. Check with the diagnostics tool that all activations function normally. (Malfunction in one output circuit can affect another output circuit).
5. If the fault persists, the control module must be changed. Fill in the "Checklist for changing turbocharger and engine control module" before changing the control module and attach it when the control module is returned.
6. Control modules are sensitive to electrostatic discharges. Great care must be taken to follow the following procedure to avoid damaging internal components in the control module: Keep the control module in its packaging for as long as possible. Never touch the pins of a control module with your hands or clothing. Ground yourself by touching part of the car's body/engine. Unplug the connector from the car's control module. Place the exchanged control module in its return packaging without touching the pins. Ground yourself by touching part of the car's body/engine. Plug in the connector to the car's control module.

Scheme 231

A suitable instrument to use is a multimeter.

The ohmmeter must not be used to test components containing semi-conductors, e.g. control modules and relay with timing functions, etc.

When measuring resistance, the power supply to the system being tested must be disconnected as the measuring instrument generates a weak current in the circuit in question.

This is done to ensure that there is no current already in the tested circuit and that the correct reading is obtained.

Scheme 232

Scheme 233

1. Turn on the load.
2. Set the multimeter for measuring voltage and connect the negative lead of the voltmeter to a good grounding point.
3. Connect the positive lead of the voltmeter to the point where the voltage is to be read.
4. On the output side of switches/control modules, it is better to start checking from these and gradually work your way towards the load. When there is no longer a voltage reading, you will have gone past the break point.
5. On the input side of switches/control modules/consumers, it is better to start at the power source (normally a fuse) and then move gradually towards the switch/control module/consumer. When there is no longer a voltage reading, you will have gone past the break point.

Scheme 234

Scheme 235

1. Make sure the component or lead to be tested is not under tension (e.g. by removing the relevant fuse).
2. Set the multimeter for measuring ohms and connect the ohmmeter to each end of the component/lead to be tested.
3. Jiggle the relevant wiring harness while observing the ohmmeter. Normally, the resistance of a wiring harness is less than 1 ohm. Specified values apply to components.

Scheme 236

Scheme 237

1. Make sure the lead being tested is not under tension (e.g. remove the relevant fuse) and that any loads are disconnected.
2. Set the multimeter for measuring ohms.
3. Connect one test lead to a good ground and the other to the point to be tested.
4. Carefully jiggle the wiring harness and make sure the multimeter reading shows infinite resistance (OL) all the time.

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

1. When detaching connectors with locks, it is essential that the lock is released before the connector is detached. Ensure the connector locks properly when connecting. Example of some different connector types used in the car: 1.A. Pull out the slide to unlock the connector. After attaching the connector lock it by pressing in the slide. NOTE: Using a small screwdriver will help to unlock the connector. 1.B. Press in the lock tab to unlock the connector. Make sure the connector is locked properly when connecting. 1.C. Pull out the slide to unlock the connector. After attaching the connector lock it by pressing in the slide. 1.D. Press in the brace catch and push forward the brace. Push back the brace to lock the connector after connecting. NOTE: Make sure the brace is locked in the right position to ensure good contact between connectors. 1.E. Lift up the lock tab to unlock the connector. Make sure the connector is locked properly when connecting. 1.F. Press in the connector lock tab to release the brace. Release the connector slide while pushing the brace forward. NOTE: The connector may be damaged if too much force is used to push forward the brace without first releasing the slide. Push back the brace to lock the connector after connecting.
2. Ground yourself by touching the car body/engine before removing or fitting any of the connectors on the car's control modules.
3. Never pull the wiring harness when removing a connector.
4. Never touch the pins on the control module with your hands or clothes. IMPORTANT: Incorrect handing or the use of the wrong tool can damage the sleeves in the connector. Use a test cable (part no. 86 12 731) of the correct size to avoid damaging the sleeves in the connector.
5. When testing only probe tips intended for the purpose are to be used to avoid damaging the contacts. Use a test cable (part no. 86 12 731) of the right size.
6. Connectors may only be repaired when using specified special tools and spare parts.
7. The following connectors must not be repaired: Screened wires/coaxial cables (e.g. ESP sensor cable) Airbag system and pyrotechnical seat-belt tensioner system High tension cable (e.g. ignition system, xenon lamp).

Scheme 246

Scheme 247

1. Check for any contact problems in connections.
2. Check contacts, connectors and crimp connections with respect to oxidation, loose pins and pin clamping force. IMPORTANT: Incorrect handing or the use of the wrong tool can damage the sleeves in the connector. Use a test cable (part no. 86 12 731) of the correct size to avoid damaging the sleeves in the connector.
3. To check the connector clamping force, use a test cable with the right pin size (from kit 86 12 731). NOTE: Using a test cable that is too big will damage connector sleeves. Insert the test cable pin into the connector pin to feel the clamping force of the pins in question. Poor clamping force of the connector pins can cause bad contact. Also check that the engagement height of the pin is the same as the other pins in the connector. An engagement height that is too low could be an indication of a loose pin in the connector, which could cause bad contact.
4. Check wires and connections for open circuits.
5. Check wiring harness, connectors and ground connections.

Scheme 248

Enable criteria

Ignition on.

Fault criteria

Control module is unmarried.

Ignition ON.

Radio/CD switched on

Battery voltage between 9 and 16V (+/- 1V).

01 Line/speaker output of the front left speaker is short circuited to B+.

02 Line/speaker output of the front left speaker is short circuited to ground.

Ignition ON.

Radio/CD switched on.

Battery voltage between 9 and 16V (+/- 1V).

01 Line/speaker output of the front right speaker is short circuited to B+.

02 Line/speaker output of the front right speaker is short circuited to ground.

Ignition ON.

Radio/CD switched on.

Battery voltage between 9 and 16V (+/- 1V).

01 Line/speaker output of the rear left speaker is short circuited to B+

02 Line/speaker output of the rear left speaker is short circuited to ground.

Ignition ON.

Radio/CD switched on.

Battery voltage between 9 and 16V (+/- 1V).

01 Line/speaker output of the rear right speaker is short circuited to B+.

02 Line/speaker output of the rear speaker is short circuited to ground.

Ignition ON.

Radio/CD switched on.

Battery voltage between 9 and 16V (+/- 1V).

(Pin 6 K14 on the control module must be connected to the amplifier pin 12)

01 Amplifier mute circuit short circuited to B+.

02 Amplifier mute circuit short circuited to ground.

04 Open circuit in the amplifier mute circuit.

Radio/CD switched on or ignition on.

No bus communication with SID.

Radio/CD switched on or ignition on.

No bus communication with SID.

Radio/CD switched on or ignition on.

Battery voltage between 9 and 16V (+/- 1V).

The control module diagnosis has discovered a fault in one of the following internal circuits: EEPROM; RAM; KAM; Tuner section, CDEC or DSP.

Radio/CD switched on or ignition on.

No bus communication with EHU.

Radio/CD switched on or ignition on.

02 Antenna circuit, short circuited to ground.

05 Antenna circuit, open circuit or short circuited to B+.

Conditions

None

Alternative 1: The head unit (EHU) is married with another car, the VIN does not correspond with the car in which it is fitted.

Alternative 2: The audio system locks after the replacement of SID in combination with incorrect/incomplete spare parts programming.

The radio/CD functions normally.

No diagnostic trouble codes stored relating to the current symptom.

No diagnostic trouble codes stored relating to the current symptom.

No diagnostic trouble codes stored relating to the current symptom.

Probable cause of fault

There is a break in one of the wires in the demister matrix/antennas.

No diagnostic trouble codes stored relating to the current symptom.

The radio/CD functions normally.

No diagnostic trouble codes stored relating to the current symptom.

List of components

LIST OF COMPONENTS No. Name Location Illustration Components 22a Fuse box, dashboard on end of dashboard next to driver's door 266FL Speaker, dashboard LH to left in dashboard 266FR Speaker, dashboard RH to right in dashboard 266RPL Speaker, rear door LH in LH rear door 266RPR Speaker, rear door RH in RH rear door 353 Main unit, audio system in centre of dashboard 375 Connection, mobile telephone by radio console 624 Antenna amplifier, radio on RH C-pillar 624RR Antenna amplifier, radio, RH above RH rear side window 625 Antenna, window glass, radio in rear window glass 625RR Antenna, radio, RH glass in glass of RH rear side window 644 Filter, antenna ground on LH C-pillar 16-pin connector H16-1 In the LH B-pillar. H16-2 In the RH B-pillar. H16-6 Grey connector in cable conduit in front of airbag control module 80-pin connector H80-1 In the connector bracket under the LH A-pillar. Crimp connectors J46 LHD: Approx. 90 mm from grounding point G42 branching point towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard warning light switch J67 LHD: Approx. 200 mm from branching of MIU towards the radio RHD: Approx. 130 mm from branching of grounding point G41S towards MIU/SID J68 LHD: Approx. 310 mm from grounding point G42 branching point towards the radio RHD: Approx. 240 mm from the rear edge of control module DICE connector towards the amplifier Grounding points G40 In cabin on LH side of knee member G42 In cabin on RH side of knee member

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

LIST OF COMPONENTS No. Name Location Illustration Components 22a Fuse box, dashboard on the short edge of the instrument panel by the driver's door 41 Horn button in steering wheel rim 239 Transmission range switch 2, automatic transmission (31,77), on the automatic gearbox in the engine bay 336b Contact unit, steering wheel horn/switches in steering wheel behind crash pad 349 Radio receiver, satellite radio, under parcel shelf 353 Main unit, audio system in centre of dashboard 354 Amplifier, audio system below RH A-pillar 364a Antenna, satellite radio, on roof 375 Connection, mobile telephone by radio console 517 Relay, starter relay on the main relay board in the dashboard 541 SID, on the rear of the main instrument unit 624 Antenna amplifier, radio on RH C-pillar 625 Antenna, window glass, radio in rear window glass 632 Control module, TWICE under left-hand seat 633 Switch unit, steering wheel on steering wheel rim 633a Switch, preset radio tuning/CD disc to left on steering wheel rim 633b Switch, seek forward to left on steering wheel rim 633c Switch, seek backward to left on steering wheel rim 633d Switch, select radio/CD, to right on steering wheel rim 633e Switch, increase volume to right on steering wheel rim 633f Switch, decrease volume to right on steering wheel rim 644 Filter, antenna ground on LH C-pillar 673 Control module, OnStar, under parcel shelf 80-pin connector H80-1 In the connector console under the A-pillar Crimp connectors J46 LHD: Approx. 90 mm from grounding point G42 branching point towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard warning light switch J67 LHD: Approx. 200 mm from branching of MIU towards the radio RHD: Approx. 130 mm from branching of grounding point G41S towards MIU/SID J68 LHD: Approx. 310 mm from grounding point G42 branching point towards the radio RHD: Approx. 240 mm from the rear edge of control module DICE connector towards the amplifier J146 Approx. 55 mm from radio's 16-pin connector J172 Approx. 55 mm from radio's 16-pin connector J236 LHD: Approx. 40 mm from branching DICE control module towards the main relay board RHD: Approx. 180 mm from grounding point G42 branching point towards DICE control module Grounding points G40 In the cabin on the LH side of the knee beam G41S LH ground screw in the middle of the knee beam (in the cabin) G42 In the cabin on the RH side of the knee beam

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

LIST OF COMPONENTS No. Name Location Illustration Components 22a Fuse box, dashboard on the short edge of the instrument panel by the driver's door 41 Horn button in steering wheel rim 239 Transmission range switch 2, automatic transmission (31,77), on the automatic gearbox in the engine bay 336b Contact unit, steering wheel horn/switches in steering wheel behind crash pad 349 Radio receiver, satellite radio, under front floor panel in luggage compartment 353 Main unit, audio system in centre of dashboard 354 Amplifier, audio system below RH A-pillar 364a Antenna, satellite radio, on roof 375 Connection, mobile telephone by radio console 517 Relay, starter relay on the main relay board in the dashboard 541 SID, on the rear of the main instrument unit 624RL Antenna amplifier, radio, LH above LH rear side window 624RR Antenna amplifier, radio, RH above RH rear side window 625RL Antenna, radio, LH window pane in glass of LH rear side window 625RR Antenna, radio, RH glass in glass of RH rear side window 632 Control module, TWICE under left-hand seat 633 Switch unit, steering wheel on steering wheel rim 633a Switch, preset radio tuning/CD disc to left on steering wheel rim 633b Switch, seek forward to left on steering wheel rim 633c Switch, seek backward to left on steering wheel rim 633d Switch, select radio/CD, to right on steering wheel rim 633e Switch, increase volume to right on steering wheel rim 633f Switch, decrease volume to right on steering wheel rim 673 Control module, OnStar, in RH compartment under luggage compartment floor 80-pin connector H80-1 In the connector console under the A-pillar Crimp connectors J46 LHD: Approx. 90 mm from grounding point G42 branching point towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard warning light switch J67 LHD: Approx. 200 mm from branching of MIU towards the radio RHD: Approx. 130 mm from branching of grounding point G41S towards MIU/SID J68 LHD: Approx. 310 mm from grounding point G42 branching point towards the radio RHD: Approx. 240 mm from the rear edge of control module DICE connector towards the amplifier J146 Approx. 55 mm from radio's 16-pin connector J172 Approx. 55 mm from radio's 16-pin connector J236 LHD: Approx. 40 mm from branching DICE control module towards the main relay board RHD: Approx. 180 mm from grounding point G42 branching point towards DICE control module Grounding points G40 In the cabin on the LH side of the knee beam G41S LH ground screw in the middle of the knee beam (in the cabin) G42 In the cabin on the RH side of the knee beam

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

LIST OF COMPONENTS No. Name Location Illustration Components 22a Fuse box, dashboard on end of dashboard next to driver's door 266D Speaker, front door, driver's side in door 266P Speaker, front door, passenger side in door 266FC Speaker, dashboard centre top centre of dashboard 266FL Speaker, dashboard LH to left in dashboard 266FR Speaker, dashboard RH to right in dashboard 266RPL Speaker, rear door LH in LH rear door 266RPR Speaker, rear door RH in RH rear door 353 Main unit, audio system in centre of dashboard 354 Amplifier, audio system below RH A-pillar 16-pin connector H16-1 In the LH B-pillar. H16-2 In the RH B-pillar. H16-6 Grey connector in cable conduit in front of airbag control module 42-pin connector H42-1 On driver door front end LHD H42-2 On passenger door front end LHD H42-3 On driver door front end RHD H42-4 On passenger door front end RHD 80-pin connector H80-1 In the connector bracket under the LH A-pillar. Crimp connectors J46 LHD: Approx. 90 mm from grounding point G42 branching point towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard warning light switch Grounding points G40 In cabin on LH side of knee member G42 In cabin on RH side of knee member

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

LIST OF COMPONENTS No. Name Location Illustration Components 22a Fuse box, dashboard on end of dashboard next to driver's door 266D Speaker, front door, driver's side in door 266P Speaker, front door, passenger side in door 266FC Speaker, dashboard centre top centre of dashboard 266FL Speaker, dashboard LH to left in dashboard 266FR Speaker, dashboard RH to right in dashboard 266RPL Speaker, rear door LH in LH rear door 266RPR Speaker, rear door RH in RH rear door 266RL Speaker, parcel shelf, left to left in parcel shelf 266RR Speaker, parcel shelf, right to right in parcel shelf 353 Main unit, audio system in centre of dashboard 354 Amplifier, audio system below RH A-pillar 16-pin connector H16-1 In the LH B-pillar. H16-2 In the RH B-pillar. H16-6 Grey connector in cable conduit in front of airbag control module 42-pin connector H42-1 On driver door front end LHD H42-2 On passenger door front end LHD H42-3 On driver door front end RHD H42-4 On passenger door front end RHD 80-pin connector H80-1 In the connector bracket under the LH A-pillar. Crimp connectors J46 LHD: Approx. 90 mm from grounding point G42 branching point towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard warning light switch Grounding points G40 In cabin on LH side of knee member G42 In cabin on RH side of knee member

Scheme 293

Scheme 294

Scheme 295

Scheme 296

LIST OF COMPONENTS No. Name Location Illustration Components 22a Fuse box, dashboard on end of dashboard next to driver's door 266D Speaker, front door, driver's side in door 266P Speaker, front door, passenger side in door 266FC Speaker, dashboard centre top centre of dashboard 266FL Speaker, dashboard LH to left in dashboard 266FR Speaker, dashboard RH to right in dashboard 266RPL Speaker, rear door LH in LH rear door 266RPR Speaker, rear door RH in RH rear door 266RR Speaker, subwoofer at RH rear wheel housing 353 Main unit, audio system in centre of dashboard 354 Amplifier, audio system below RH A-pillar 16-pin connector H16-1 In the LH B-pillar. H16-2 In the RH B-pillar. H16-6 Grey connector in cable conduit in front of airbag control module 42-pin connector H42-1 On driver door front end LHD H42-2 On passenger door front end LHD H42-3 On driver door front end RHD H42-4 On passenger door front end RHD 80-pin connector H80-1 In the connector bracket under the LH A-pillar. Crimp connectors J46 LHD: Approx. 90 mm from grounding point G42 branching point towards the radio RHD: Approx. 110 mm from branching of grounding point G40 towards hazard warning light switch Grounding points G40 In cabin on LH side of knee member G42 In cabin on RH side of knee member

Scheme 297

Scheme 298
