Glass, Windows and Mirrors: Removal & Installation Saab 9-4X I

Windows 62 illustrations ~3779 words

Installation Procedure

  1. Install the windshield into the opening. Refer to «ADHESIVE INSTALLATION OF WINDSHIELDS»(ref-652259-S35709059142014082300000) .
  2. Install the rearview mirror. Refer to «INSIDE REARVIEW MIRROR REPLACEMENT»(ref-652259-S28031005452014082300000) .
  3. Install the interior windshield pillar garnish moldings. Refer to «WINDSHIELD GARNISH MOLDING REPLACEMENT»(ref-652235-S03156074192014082300000) .
  4. Install the windshield side reveal moldings. Refer to «WINDSHIELD SIDE REVEAL MOLDING REPLACEMENT»(ref-652259-S32659193822014082300000) .
  5. Install the air inlet grille. Refer to «AIR INLET GRILLE PANEL REPLACEMENT»(ref-652257-S38899253992014082300000) .
  6. Install the windshield wipers arms and blades. Refer to «WINDSHIELD WIPER ARM REPLACEMENT»(ref-652257-S20933135622014082300000) .
  7. Remove the double layer of masking tape around the perimeter of the painted surfaces and the interior trim.
  8. Close the hood.

Scheme 1

Scheme 1: Windshield Side Reveal Molding Replacement
CalloutComponent Name
1Windshield Side Reveal Molding Screws to Pillar (Qty: 5) Refer to CAUTION: RETAINER Procedure Open the front side door to the full open position. Using a suitable tool, remove the side pillar retainers. NOTE: It may be necessary to push down on the weatherstrip to expose the retainers.
2Windshield Side Reveal Molding Upper Retainer Clips to Pillar (Qty: 5) Procedure Grasp the windshield reveal molding, rock the molding from side to side while pulling upward releasing the retainers from under the pillar molding to pillar. Clean the double face tape from the molding and windshields and replace as needed. Refer to EMBLEM/NAMEPLATE REPLACEMENT . NOTE: Do Not push or pry on the windshield to release the reveal molding from the pillar.
3Windshield Side Reveal Molding
NOTE
It may be necessary to push down on the weatherstrip to expose the retainers.
NOTE
Do Not push or pry on the windshield to release the reveal molding from the pillar.

Scheme 2

Scheme 2: Removal Procedure
  1. Run the window to the fully closed position.
  2. Refer to «WARNING: HANDLING GLASS AND SHEET METAL»(ref-652229-S08961136482014082300000) . Refer to «WARNING: WINDOW FUNCTION EXPRESS DOWN»(ref-652229-S21471558472014082300000) . Remove the front side door trim panel. Refer to «FRONT SIDE DOOR TRIM REPLACEMENT»(ref-652235-S04922236752014082300000) .
  3. Remove the front side door garnish molding. Refer to «FRONT SIDE DOOR WINDOW REPLACEMENT»(ref-652259-S38106407482014082300000) .
  4. Remove the water deflector.
  5. Remove the front side window inner sealing strip. Refer to «FRONT SIDE DOOR WINDOW INNER SEALING STRIP REPLACEMENT»(ref-652259-S36774397662014082300000) .
  6. Tape the window in the closed position.
  7. Loosen the window regulator guide nuts 4 revolutions.
  8. Connect the door trim panel electrical connector.
  9. Using the power window switch, lower the window regulator to separate the window from the regulator guides.
  10. Remove the tape.
  11. Remove the window by tilting the window forward then pulling the window up and out of the door.

Scheme 3

Scheme 3: Installation Procedure
  1. NOTE: The window regulator should be at least 1/2 way down before installing the window. Install the window down into the door.
  2. Position the window into the 2 window regulator guides.
  3. NOTE: Start the vehicle to ensure maximum power to the window motor. This is required in order to fully seat the window for adjustment. Start the vehicle.
  4. Refer to «CAUTION: RETAINER»(ref-652229-S20487768742014082300000) . Using the power window switch, raise the window to the fully closed position. Tighten the window regulator guide nuts to 11 Nm (98 lb in).
  5. Install the front side window inner sealing strip. Refer to «FRONT SIDE DOOR WINDOW INNER SEALING STRIP REPLACEMENT»(ref-652259-S36774397662014082300000) .
  6. Inspect the window for proper operation and a tight seal.
  7. Shut off the vehicle.
  8. Install the water deflector.
  9. Install the front side door garnish molding. Refer to «FRONT SIDE DOOR WINDOW REPLACEMENT»(ref-652259-S38106407482014082300000) .
  10. Install the front side door trim panel. Refer to «FRONT SIDE DOOR TRIM REPLACEMENT»(ref-652235-S04922236752014082300000) .

Scheme 4

Scheme 4: Removal Procedure
  1. Refer to «WARNING: HANDLING GLASS AND SHEET METAL»(ref-652229-S08961136482014082300000) Lower the window all the way down.
  2. Remove the rear side door trim panel. Refer to «REAR SIDE DOOR TRIM REPLACEMENT»(ref-652235-S19750649592014082300000)
  3. Remove the rear side door garnish molding. Refer to «REAR SIDE DOOR WINDOW REPLACEMENT»(ref-652259-S17992680722014082300000)
  4. Remove the rear side door water deflector.
  5. Remove the rear side door window inner sealing strip. Refer to «REAR SIDE DOOR WINDOW INNER SEALING STRIP REPLACEMENT»(ref-652259-S26692395242014082300000)
  6. Remove the rear side door window belt reveal molding. Refer to «REAR SIDE DOOR WINDOW BELT REVEAL MOLDING REPLACEMENT»(ref-652259-S04864251302014082300000)
  7. Connect the rear side door trim panel electrical connector.
  8. Run the window to the fully up position.
  9. Tape the window in the up position.
  10. Loosen rear side door front window run channel bolt.
  11. Loosen the window regulator guide nuts 4 revolutions.
  12. Using the power window switch, lower the window regulator to the fully down position.
  13. Remove the tape.
  14. Slide the window down past the window regulator guides and out of the front window run channel.
  15. Lift the rear side door window out of the door.

Scheme 5

Scheme 5: Installation Procedure
  1. Install the window down into the door, past the window regulator guides.
  2. Raise the window past the window regulator guides.
  3. Lower the window into the window regulator guides.
  4. Push the glass forward into the front glass run channel.
  5. NOTE: Start the vehicle to ensure maximum power to the window motor. This is required in order to fully seat the window for adjustment. Start the vehicle.
  6. Refer to «CAUTION: RETAINER»(ref-652229-S20487768742014082300000) Using the power window switch, raise the window to the fully up position. Tighten the window regulator guide nuts to 11 Nm (98 lb in).
  7. Install the window into the rear side door front window run channel, tighten the bolts to 9 Nm (80 lb in).
  8. Inspect the window for proper operation and a tight seal.
  9. Shut off the vehicle.
  10. Install the rear side door window belt reveal molding. Refer to «REAR SIDE DOOR WINDOW BELT REVEAL MOLDING REPLACEMENT»(ref-652259-S04864251302014082300000)
  11. Install the rear side door window inner sealing strip. Refer to «REAR SIDE DOOR WINDOW INNER SEALING STRIP REPLACEMENT»(ref-652259-S26692395242014082300000)
  12. Install rear side door water deflector.
  13. Install the rear side door garnish molding. Refer to «REAR SIDE DOOR WINDOW REPLACEMENT»(ref-652259-S17992680722014082300000)
  14. Install the rear side door trim panel. Refer to «REAR SIDE DOOR TRIM REPLACEMENT»(ref-652235-S19750649592014082300000)
  1. Install the quarter window in the opening. Refer to «ADHESIVE INSTALLATION OF QUARTER WINDOWS»(ref-652259-S01199446302014082300000)
  2. Connect the electrical connector to the window.
  3. Install the rear quarter trim panel. Refer to «QUARTER UPPER TRIM PANEL REPLACEMENT»(ref-652235-S41761675372014082300000)
  4. Remove the protective coverings and tape from the vehicle quarter.
  1. Install the liftgate window into the opening. Refer to «ADHESIVE INSTALLATION OF LIFTGATE WINDOWS»(ref-652259-S39132237332014082300000) .
  2. Install the liftgate side appliques. Refer to «LIFTGATE SIDE APPLIQUE REPLACEMENT»(ref-652246-S40208767802014082300000) .
  3. Install the rear spoiler. Refer to «REAR END SPOILER REPLACEMENT»(ref-652246-S18217274822014082300000) .
  4. Install the rear window wiper arm. Refer to «REAR WINDOW WIPER ARM REPLACEMENT»(ref-652257-S36545856382014082300000) .
  5. Connect the liftgate window rear defogger electrical connectors.
  6. Install the liftgate lower trim. Refer to «LIFTGATE LOWER TRIM FINISH PANEL REPLACEMENT»(ref-652235-S33464764352014082300000) .
  7. Remove the double layer of masking tape around the perimeter of the painted surfaces and the interior trim.
  8. Close the liftgate.

Scheme 6

Scheme 6: Front Side Door Window Frame Rear Applique Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door window belt reveal molding. Refer to FRONT SIDE DOOR WINDOW BELT REVEAL MOLDING REPLACEMENT .
1Front Side Door Window Frame Rear Applique Rivets (Qty: 3) Refer to WARNING: HANDLING GLASS AND SHEET METAL Procedure Lower the window to the fully down position. Pull the front side door window weatherstrip from the rear applique to expose the rivets. When drilling cover/protect the interior trim and door from the metal shavings. Using a suitable tool, drill out the rivets from the rear of the front door frame applique.
2Front Side Door Window Frame Rear Applique Procedure Use a suitable tool, install the rivets in the front side door frame.

Scheme 7

Scheme 7: Rear Side Door Window Frame Front Applique Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear side door window. Refer to REAR SIDE DOOR WINDOW REPLACEMENT .
1Rear Side Door Window Frame Front Applique Fastener (Qty: 3) Refer to WARNING: HANDLING GLASS AND SHEET METAL Procedure Pull the rear side door window weatherstrip from the front applique to expose the rivets. When drilling cover/protect the interior trim and door from the metal shavings. Using a suitable tool, drill out the rivets from the front of the rear door frame applique.
2Rear Side Door Window Frame Front Applique Procedure Use a suitable tool, install the rivets in the front side door frame.

Scheme 8

Scheme 8: Rear Side Door Window Frame Rear Applique Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear side door window belt reveal molding. Refer to REAR SIDE DOOR WINDOW BELT REVEAL MOLDING REPLACEMENT .
1Rear Side Door Window Frame Rear Applique Fastener (Qty: 2) Refer to WARNING: HANDLING GLASS AND SHEET METAL Procedure Lower the window to the fully down position. Pull the rear side door window weatherstrip from the front applique to expose the rivets. When drilling cover/protect the interior trim and door from the metal shavings. Using a suitable tool, drill out the rivets from the rear door frame applique.
2Rear Side Door Window Frame Rear Applique Procedure Use a suitable tool, install the rivets in the rear side door frame.

Scheme 9

Scheme 9: Front Side Door Window Switch Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side accessory switch mount plate. Refer to FRONT SIDE DOOR ACCESSORY SWITCH MOUNT PLATE REPLACEMENT .
1Front Side Door Window Switch Assembly Procedure Refer to CONTROL MODULE REFERENCES for programming and set up procedures.

Scheme 10

Scheme 10: Front Side Door Window and Multifunction Switch Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door accessory switch mount plate. Refer to FRONT SIDE DOOR ACCESSORY SWITCH MOUNT PLATE REPLACEMENT .
1Front Side Door Window and Multifunction Switch Assembly Procedure Refer to CONTROL MODULE REFERENCES for programming and set up procedures.

Scheme 11

Scheme 11: Rear Side Door Window Switch Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear side door accessory switch mount plate. Refer to REAR SIDE DOOR ACCESSORY SWITCH MOUNT PLATE REPLACEMENT .
1Rear Side Door Window Switch Assembly Procedure Refer to CONTROL MODULE REFERENCES for programming and set up procedures.

Scheme 12

Scheme 12: Front Side Door Window Regulator Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT
1Front Side Door Window Regulator Guide Nuts to Window (Qty: 2) Refer to CAUTION: RETAINER Procedure Remove the front side door water deflector. Tighten 11 Nm (98 lb in)
2Front Side Door Window Regulator Bolts (Qty: 5) Procedure Position window to access the front side door window regulator guide bolts. Loosen the nuts on the window regulator guide. Raise the window to the fully up position, tape in place. Tighten 10 Nm (89 lb in)
3Front Side Door Window Regulator Procedure Disconnect the electrical connector from the motor. When installing a new window regulator, remove the two window regulator guides bolts. The window regulator guides must be raised to meet the window before installing the window regulator guides bolts.

Scheme 13

Scheme 13: Front Side Door Window Regulator Motor Replacement
CalloutComponent Name
WARNING: Disconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury. Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT Release the door window from the guide retaining clips. Refer to FRONT SIDE DOOR WINDOW REPLACEMENT Remove the front side door window regulator. FRONT SIDE DOOR WINDOW REGULATOR REPLACEMENT
1Front Side Door Window Regulator Motor Fastener (Qty: 3) Refer to CAUTION: RETAINER Procedure After releasing the window guide retainers, tape the window to the upper door frame before removing the regulator bolts. Tighten 10 Nm (89 lb in)
2Front Side Door Window Regulator Motor Procedure Disconnect the electrical connector. Transfer all parts as necessary.
WARNING
Disconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.

Scheme 14

Scheme 14: Rear Side Door Window Regulator Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear side door trim panel. Refer to REAR SIDE DOOR TRIM REPLACEMENT
1Rear Side Door Window Regulator Guide Fasteners (Qty: 3) Refer to CAUTION: RETAINER Procedure Remove the rear side door water deflector. Position window to access the rear side door window regulator guide bolts. Loosen the nuts on the window regulator guide. Raise the window to the fully up position, tape in place. Tighten 11 Nm (98 lb in)
2Rear Side Door Window Regulator Refer to CAUTION: RETAINER Procedure Disconnect the electrical connector from the motor.

Scheme 15

Scheme 15: Rear Side Door Window Regulator Motor Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear side door trim panel. Refer to REAR SIDE DOOR TRIM REPLACEMENT . Remove the rear side door window regulator. Refer to REAR SIDE DOOR WINDOW REGULATOR REPLACEMENT .
1Rear Side Door Window Regulator Motor Fastener (Qty: 3) Refer to CAUTION: RETAINER . Tighten 10 Nm (89 lb in)
2Rear Side Door Window Regulator Motor Procedure Disconnect the electrical connector from the motor.

Scheme 16

Scheme 16: Front Side Door Window Inner Sealing Strip Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT
1Front Side Door Window Inner Sealing Strip Procedure Lift the front door window inner belt sealing strip off the pinch-weld flange. Position the window belt inner sealing strip to the door flange. Ensure the front end of the window inner belt sealing strip is flush to the front door frame weatherstrip. Use hand pressure in order to firmly seat the front door window inner belt sealing strip on the pinchweld flange. NOTE: Inspect the front door window for proper operation before installing the trim panel.
NOTE
Inspect the front door window for proper operation before installing the trim panel.

Scheme 17

Scheme 17: Rear Side Door Window Upper Reveal Molding Replacement
CalloutComponent Name
Refer to WARNING: HANDLING GLASS AND SHEET METAL Preliminary Procedures Remove the rear side door window. Refer to REAR SIDE DOOR WINDOW REPLACEMENT . Remove the rear side door front window frame applique. REAR SIDE DOOR WINDOW FRAME FRONT APPLIQUE REPLACEMENT . Remove the rear side door rear window frame applique. REAR SIDE DOOR WINDOW FRAME REAR APPLIQUE REPLACEMENT .
1Rear Side Door Window Upper Reveal Molding Rivets (Qty: 4) Procedure Lower the run channel weatherstrip, by grasping both upper inner corners and pull downward to expose the rivets. Do Not remove it from the door. When drilling cover/protect the interior trim and door from the metal shavings. The rivets are located in the inner upper door frame. Use a suitable tool, drill out the rivets from around the upper door frame.
2Rear Side Door Window Upper Reveal Molding Retainers (Qty: 2)
3Rear Side Door Window Upper Reveal Molding Procedure Using a suitable tool, install the rivets in the upper door frame. NOTE: After drilling out the rivets check the door and the upper door frame for loose rivets ends. This will prevent rattles.
NOTE
After drilling out the rivets check the door and the upper door frame for loose rivets ends. This will prevent rattles.

Scheme 18

Scheme 18: Rear Side Door Window Belt Reveal Molding Replacement
CalloutComponent Name
1Rear Side Door Window Belt Reveal Molding Screws (Qty: 2) Refer to CAUTION: RETAINER Tighten 1.5 Nm (13 lb in)
2Rear Side Door Window Belt Reveal Molding Procedure Remove the belt reveal molding by lifting up at one end, working from the rear of the door. When re-installing, align belt reveal fastener location with hole in door structure and outer panel retaining tabs. Start at rear of belt reveal molding, push down onto flange until fully seated.

Scheme 19

Scheme 19: Front Side Door Window Belt Reveal Molding Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT Remove the outside rearview mirror. Refer to OUTSIDE REARVIEW MIRROR REPLACEMENT
1Front Side Door Window Belt Reveal Molding Screw Refer to CAUTION: RETAINER NOTE: The screw is located in the lower rear of the door frame. Tighten 1.5 Nm (13 lb in)
2Front Side Door Window Belt Reveal Molding Procedure Remove the belt reveal molding by lifting up on the front of the seal and working rearward. When re-installing the belt reveal molding, align the fastener with the locating hole in the door frame.
NOTE
The screw is located in the lower rear of the door frame.

Scheme 20

Scheme 20: Front Side Door Window Upper Reveal Molding Replacement
CalloutComponent Name
Refer to WARNING: HANDLING GLASS AND SHEET METAL Preliminary Procedures Remove the outside rearview mirror. Refer to OUTSIDE REARVIEW MIRROR REPLACEMENT . Remove the front side door window garnish molding. Refer to FRONT SIDE DOOR WINDOW REPLACEMENT . Remove the front side door window frame rear applique. Refer to FRONT SIDE DOOR WINDOW FRAME REAR APPLIQUE REPLACEMENT .
1Front Side Door Window Upper Reveal Molding Rivets (Qty: 8) Procedure Lower the window to the fully down position. Lower the run channel weatherstrip, by grasping both upper inner corners and pull downward to expose the rivets. Do Not remove it from the door. When drilling cover/protect the interior trim and door from the metal shavings. The rivets are located in the inner upper door frame. Use a suitable tool, drill out the rivets from around the upper door frame.
2Front Side Door Upper and Lower Reveal Molding Retainers (Qty: 2)
3Front Side Door Window Upper Reveal Molding Procedure Using a suitable tool, install the rivets in the upper door frame. NOTE: After drilling out the rivets check the door and the upper door frame for loose rivets ends. This will prevent rattles.
NOTE
After drilling out the rivets check the door and the upper door frame for loose rivets ends. This will prevent rattles.

Scheme 21

Scheme 21: Rear Side Door Window Inner Sealing Strip Replacement
CalloutComponent Name
Preliminary Procedures Remove rear door trim panel. Refer to REAR SIDE DOOR TRIM REPLACEMENT .
1Rear Side Door Inner Window Sealing Strip Procedure Start from the front edge of the door, pull upward on the inner window sealing strip to release it from the pinchweld flange. Install the inner window sealing strip to the front edge of the door, press firmly onto the pinch-weld flange and work it rearward. Inspect the operation of the window before installing the door trim panel.

Scheme 22

Scheme 22: Front Side Door Window Weatherstrip Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT Remove the front side window inner sealing strip. Refer to FRONT SIDE DOOR WINDOW INNER SEALING STRIP REPLACEMENT Remove the front side door window garnish molding. Refer to FRONT SIDE DOOR WINDOW REPLACEMENT Remove the front side door window. Refer to FRONT SIDE DOOR WINDOW REPLACEMENT .
1Front Side Door Window Weatherstrip Fastener (Qty: 2) Procedure Remove the water deflector. Refer to CAUTION: RETAINER Tighten 10 Nm (89 lb in)
2Front Side Door Window Weatherstrip Procedure Starting in the upper corner of the door frame, pull the weatherstrip away from the window frame and lower front channel. Center the weatherstrip in the center of the door frame. Work the weatherstrip towards the corner. Install the weatherstrip into door frame channel. Operate the window to ensure that the window seal properly into the inner door frame.

Scheme 23

Scheme 23: Rear Side Door Window Weatherstrip Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear side door trim panel. Refer to REAR SIDE DOOR TRIM REPLACEMENT Remove the rear side door window inner sealing strip. Refer to REAR SIDE DOOR WINDOW INNER SEALING STRIP REPLACEMENT . Remove the rear side door window garnish molding. Refer to REAR SIDE DOOR WINDOW REPLACEMENT Remove the rear side door window. Refer to REAR SIDE DOOR WINDOW REPLACEMENT .
1Rear Side Door Window Weatherstrip Front Fasteners (Qty: 2) Refer to CAUTION: RETAINER . Procedure Remove the water deflector. Tighten 10 Nm (89 lb in)
2Rear Side Door Window Weatherstrip Rear Fasteners (Qty: 2) Tighten 10 Nm (89 lb in)
3Rear Side Door Window Weatherstrip Procedure Starting in the upper corner of the door frame, pull the weatherstrip out of the window frame. Center the weatherstrip in door frame. Work the weatherstrip towards the corners of the door frame. Operate the window to ensure that the window seal properly into the inner door frame.

Scheme 24

Scheme 24: Adhesive Installation of Windshields

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38
  1. Refer to «WARNING: HANDLING GLASS AND SHEET METAL»(ref-652229-S08961136482014082300000) . Use a urethane adhesive systems which meet GM Specification GM 3651G.
  2. Remove all mounds or loose pieces of urethane adhesive from the pinchweld area.
  3. If the original window is being reused, remove all but approximately 2 mm (3/64 in) of the existing bead of urethane adhesive from the pinch-weld flange surface by using a clean utility knife or razor blade scraper.
  4. Inspect the pinch weld flange of the window opening for causes of a broken window.
  5. Inspect for any of the following problems in order to help prevent future breakage of the window: High weld Solder spots Hardened sealer Any other obstruction or irregularity in the pinch-weld flange
  6. NOTE: If corrosion of the pinch-weld flange is present or if sheet metal repairs or replacements are required, the pinch-weld flange must be refinished in order to restore the bonding area strength. If paint repairs are required, mask the flange bonding area prior to applying the color coat in order to provide a clean primer only surface. Materials such as BASF DE15®, DuPont 2610®, Sherwin-Williams PSE 4600 and NP70® and Martin-Semour 5120 and 5130® PPG DP90LF SPIES/HECKER 3688/8590 - 3688/5150 - 4070/5090 STANDOX 11158/13320 - 14653/14980 products are approved for this application. After repairing the opening as indicated, perform the following steps: 6.1. Remove all traces of broken glass from the outer cowl panel, seats, floor, and defroster ducts. 6.2. Clean around the edge of the inside surface of the window with a 50/50 mixture of isopropyl alcohol and water by volume on a dampened lint free cloth.
  7. Verify all primers and urethane adhesive are within expiration dates.
  8. WARNING: Failure to prep the area prior to the application of primer may cause insufficient bonding of urethane adhesive. Insufficient bonding of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle resulting in personal injury. NOTE: Do not apply the black #3 primer to the existing bead (1) of the urethane adhesive on the pinch-weld flange. Apply the primer only to nicks, scratches, or the primed surfaces. Shake the pinch-weld primer black #3 for at least 1 minute.
  9. Use a new dauber in order to apply the primer to the surface of the pinchweld flange (1).
  10. Allow the pinch-weld primer to dry for approximately 10 minutes.
  11. Dry fit the window (1) into the opening in order to determine the correct position. Get help from an assistant.
  12. If equipped, ensure that the windshield locator pins are positioned into the locator slots on the upper pinch-weld flange.
  13. Use masking tape in order to mark the locations (1) of the window (2) in the opening.
  14. Cut the masking tape in the center and remove the window from the opening.
  15. NOTE: Use care when applying window prep clear #1 on the window. This primer dries almost instantly, and may stain the viewing area of the window if not applied evenly. Use a new dauber in order to apply window prep clear #1 to the area approximately 18 mm (0.71 in) around the entire perimeter of the window inner surface. Immediately wipe the window primed area using a clean, lint-free cloth.
  16. Apply a second coat of the window prep clear #1 to the same area of the window.
  17. NOTE: The window primer black #2 is effective up to 8 hours after applying it to the window. The primed surface of the window must be kept clean. Shake the window primer black #2 for at least 1 minute.
  18. Use a new dauber in order to apply the window primer black #2 to the same areas (2) that window prep clear #1 was applied.
  19. Allow the window primer to dry for approximately 10 minutes.
  20. Cut the applicator nozzle in order to provide a minimum urethane bead of 14 mm (0.55 in) wide and 14 mm (0.55 in) high.
  21. Use a cartridge-type caulking gun in order to apply a smooth, continuous bead of urethane adhesive.
  22. Use the edge of the window as a guide for the nozzle in order to apply the urethane adhesive (1) to the inner surface of the window (3).
  23. With the aid of an assistant, place the window (1) in the opening.
  24. Align the masking tape (1) lines on the window (2) and the body.
  25. NOTE: To prevent damage to the window due to objects impacting an exposed edge, upon installation, the window must rest 1 mm (0.04 in) below the surface of the sheet metal. Press firmly around the entire periphery of the windshield in order to wet-out the urethane bead.
  26. Tape the window to the body in order to minimize movement until the urethane adhesive cures.
  27. Clean any excess urethane adhesive from the body.
  28. NOTE: Do not direct a hard stream of high pressure water to the freshly applied urethane adhesive. Use a soft spray of warm water in order to immediately water test the window.
  29. Inspect the window for leaks.
  30. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point.
  31. Retest the window for leaks.
  32. WARNING: Insufficient curing of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle resulting in personal injury. For the moisture-curing type of urethane adhesive, allow a minimum of 6 hours at 21°C (70°F) or greater and with at least 30 percent relative humidity. Allow at least 24 hours for the complete curing of the urethane adhesive. For the chemical-curing type of urethane adhesive, allow a minimum of 1 hour. Do NOT physically disturb the repair area until after these minimum times have elapsed. Maintain the following conditions in order to properly cure the urethane adhesive: Partially lower a door window in order to prevent pressure buildups when closing doors before the urethane adhesive cures. Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing times. Do not use compressed air in order to dry the urethane adhesive.
  33. Complete the window installation. Refer to «WINDSHIELD REPLACEMENT»(ref-652259-S22165941002014082300000) .

Scheme 39

Scheme 39: Adhesive Installation of Quarter Windows

Scheme 40

Scheme 40

Scheme 41

Scheme 41
  1. Refer to «WARNING: HANDLING GLASS AND SHEET METAL»(ref-652229-S08961136482014082300000) . Use a urethane adhesive systems which meet GM Specification GM 3651G.
  2. Remove all mounds or loose pieces of urethane adhesive from pinch-weld flange areas.
  3. If the original window assembly is being reused, remove all but 2 mm (3/64 in) of the existing urethane adhesive from the pinch-weld flange and the window frame surface by using a clean utility knife or razor blade scraper.
  4. NOTE: If corrosion of the pinch-weld flange is present or if sheet metal repairs or replacements are required, the pinch-weld flange must be refinished in order to restore the bonding area strength. If paint repairs are required, mask the flange bonding area prior to applying the color coat in order to provide a clean primer only surface. Materials such as BASF DE15, Dupont 2610, Sherwin-Williams PSE 4600 and NP70, Martin-Semour 5120, PPG DP90LF, Spies/Hecker 3688/8590 3688/5150 4070/5090, and Standox 11158/13320 14653/14980 are approved for this application. Clean around the inside edge of the window assembly with a 50/50 mixture of isopropyl alcohol and water on a dampened lint-free cloth.
  5. Verify all primers and urethane adhesive are within expiration dates.
  6. Refer to «WARNING: WINDOW RETENTION»(ref-652229-S15761778372014082300000) . Failure to prep the area prior to the application of primer may cause insufficient bonding of urethane adhesive. Insufficient bonding of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle resulting in personal injury.
  7. NOTE: Do not apply the black #3 primer to the existing bead of urethane adhesive on the pinch-weld flange. Apply the primer only to nicks, scratches, or the primed surfaces. Shake the black #3 primer for at least 1 minute.
  8. Use a dauber in order to apply the primer to the surface of the pinch-weld flange.
  9. Allow the pinch-weld primer to dry for approximately 10 minutes.
  10. Dry fit the window into the opening in order to determine the correct position. Get help from an assistant.
  11. Using masking tape, mark the location of the window assembly to the opening.
  12. Apply window Prep #1 followed by window Primer #2 on the encapsulation material. Allow to dry for 6-10 minutes.
  13. Cut the applicator nozzle in order to provide a bead of 10 mm (0.39 in) high (1) and 6 mm (0.24 in) wide (2).
  14. Use a cartridge-type caulking gun in order to apply a smooth, continuous bead of urethane adhesive.
  15. Use the inside edge of the window frame (1) as a guide for the nozzle in order to apply the urethane adhesive bead (2) to the window frame (3) bonding surface.
  16. Place the window into the opening. Make sure the window frame alignment pins (1) are properly located.
  17. Press the window (2) firmly into place.
  18. Tape the window to the body in order to minimize movement until the urethane adhesive cures.
  19. Clean any excess urethane adhesive from the body.
  20. NOTE: Do not direct a stream of high pressure water to the freshly applied urethane adhesive. Use a soft spray of warm water in order to immediately water test the window.
  21. Inspect the window for leaks.
  22. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point.
  23. Retest the window for leaks.
  24. WARNING: Insufficient curing of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle resulting in personal injury. For the moisture-curing type of urethane adhesive, allow a minimum of 6 hours at 21°C (70°F) or greater and with at least 30 percent relative humidity. Allow at least 24 hours for the complete curing of the urethane adhesive. For the chemical-curing type of urethane adhesive, allow a minimum of 1 hour. Do NOT physically disturb the repair area until after these minimum times have elapsed. Maintain the following conditions in order to properly cure the urethane adhesive. Partially lower a door window in order to prevent pressure buildups when closing doors before the urethane cures. Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing times. Do not use compressed air in order to dry the urethane adhesive.

Scheme 42

Scheme 42: Adhesive Installation of Liftgate Windows

Scheme 43

Scheme 43

Scheme 44

Scheme 44
  1. Refer to «WARNING: HANDLING GLASS AND SHEET METAL»(ref-652229-S08961136482014082300000) . Use a urethane adhesive systems which meet GM Specification GM 3651G.
  2. Remove all mounds or loose pieces of urethane adhesive from pinch-weld flange areas.
  3. If the original window assembly is being reused, remove all but 2 mm (3/64 in) of the existing urethane adhesive from the pinch-weld flange and the window frame surface by using a clean utility knife or razor blade scraper.
  4. NOTE: If corrosion of the pinch-weld flange is present or if sheet metal repairs or replacements are required, the pinch-weld flange must be refinished in order to restore the bonding area strength. If paint repairs are required, mask the flange bonding area prior to applying the color coat in order to provide a clean primer only surface. Materials such as BASF DE15, Dupont 2610, Sherwin-Williams PSE 4600 and NP70, Martin-Semour 5120, PPG DP90LF, Spies/Hecker 3688/8590 3688/5150 4070/5090, and Standox 11158/13320 14653/14980 are approved for this application. Clean around the inside edge of the window assembly with a 50/50 mixture of isopropyl alcohol and water on a dampened lint-free cloth.
  5. Verify all primers and urethane adhesive are within expiration dates.
  6. Refer to «WARNING: WINDOW RETENTION»(ref-652229-S15761778372014082300000) . Failure to prep the area prior to the application of primer may cause insufficient bonding of urethane adhesive. Insufficient bonding of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle resulting in personal injury.
  7. NOTE: Do not apply the black #3 primer to the existing bead of urethane adhesive on the pinch-weld flange. Apply the primer only to nicks, scratches, or the primed surfaces. Shake the black #3 primer for at least 1 minute.
  8. Use a dauber in order to apply the primer to the surface of the pinch-weld flange.
  9. Allow the pinch-weld primer to dry for approximately 10 minutes.
  10. Dry fit the window into the opening in order to determine the correct position. Get help from an assistant.
  11. Using masking tape, mark the location of the window assembly to the opening.
  12. Apply window Prep #1 followed by window Primer #2 on the encapsulation material. Allow to dry for 6-10 minutes.
  13. Cut the applicator nozzle in order to provide a bead of 10 mm (0.39 in) high (1) and 6 mm (0.24 in) wide (2).
  14. Use a cartridge-type caulking gun in order to apply a smooth, continuous bead of urethane adhesive.
  15. Use the inside edge of the window frame (1) as a guide for the nozzle in order to apply the urethane adhesive bead (2) to the window frame (3) bonding surface.
  16. Place the window into the opening. ensure that the window frame alignment pins (1) are properly located.
  17. Press the window (2) firmly into place.
  18. Tape the window to the body in order to minimize movement until the urethane adhesive cures.
  19. Clean any excess urethane adhesive from the body.
  20. NOTE: Do not direct a stream of high pressure water to the freshly applied urethane adhesive. Use a soft spray of warm water in order to immediately water test the window.
  21. Inspect the window for leaks.
  22. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point.
  23. Retest the window for leaks.
  24. WARNING: Insufficient curing of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle resulting in personal injury. For the moisture-curing type of urethane adhesive, allow a minimum of 6 hours at 21°C (70°F) or greater and with at least 30 percent relative humidity. Allow at least 24 hours for the complete curing of the urethane adhesive. For the chemical-curing type of urethane adhesive, allow a minimum of 1 hour. Do NOT physically disturb the repair area until after these minimum times have elapsed. Maintain the following conditions in order to properly cure the urethane adhesive. Partially lower a door window in order to prevent pressure buildups when closing doors before the urethane cures. Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing times. Do not use compressed air in order to dry the urethane adhesive.
  25. Install the liftgate trim. Refer to «LIFTGATE WINDOW REPLACEMENT»(ref-652259-S31550048262014082300000) .

Scheme 45

Scheme 45: Outside Rearview Mirror Replacement
CalloutComponent Name
Refer to WARNING: HANDLING GLASS AND SHEET METAL . Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT .
1Outside Rearview Mirror Bolts (Qty: 3) Refer to CAUTION: RETAINER . Procedure Disconnect the electrical connector. Tighten 10 Nm (89 lb in)
2Outside Rearview Mirror

Scheme 46

Scheme 46: Outside Remote Control Rearview Mirror Switch Replacement
CalloutComponent Name
Preliminary Procedures Remove the outside rearview mirror remote control switch bezel. Refer to OUTSIDE REARVIEW MIRROR REMOTE CONTROL SWITCH BEZEL REPLACEMENT .
1Outside Remote Control Rearview Mirror Switch Assembly Procedure Refer to CONTROL MODULE REFERENCES .

Scheme 47

Scheme 47: Outside Rearview Mirror Folding Control Module Replacement
CalloutComponent Name
Preliminary Procedures Remove the front side door trim panel. Refer to FRONT SIDE DOOR TRIM REPLACEMENT .
1Outside Rearview Mirror Folding Control Module Bolts (Qty: 2) Refer to CAUTION: RETAINER Tighten 2.5 Nm (22 lb ft)
2Outside Rearview Mirror Folding Control Module Procedure Disconnect electrical connector.

Scheme 48

Scheme 48: Outside Rearview Mirror Inner Actuator Replacement
CalloutComponent Name
Preliminary Procedures Remove the outside rearview mirror glass. Refer to OUTSIDE REARVIEW MIRROR GLASS REPLACEMENT .
1Outside Rearview Mirror Motor Screws (Qty: 3) Refer to WARNING: HANDLING GLASS AND SHEET METAL . Refer to CAUTION: RETAINER . Procedure Disconnect the electrical connector. Tighten 2 Nm (18 lb in)
2Outside Rearview Mirror Motor

Scheme 49

Scheme 49: Outside Rearview Mirror Glass Replacement
CalloutComponent Name
1Outside Rearview Mirror Glass Retainers (Qty: 7) Refer to WARNING: HANDLING GLASS AND SHEET METAL . Procedure Apply several layers of masking tape to the top of the outside rearview mirror housing in order to protect the painted finish. Push the mirror glass (2) inward at the top of the mirror glass until full travel is reached. Grasp the bottom of the mirror face back and firmly pull it rearward away from the mirror motor and housing. It will be necessary to use a sharp jerking motion to release it from the motor. Disconnect electrical connectors from mirror, if equipped.
2Outside Rearview Mirror Glass Procedure Align the mirror glass retainers with the retaining tabs (1) on the actuator. Using a 9 cm (3 in) rubber sanding block placed in the center of the mirror glass, apply pressure until an audible click is heard. Inspect the power mirror for proper operation.

Scheme 50

Scheme 50: Outside Rearview Mirror Housing Replacement
CalloutComponent Name
Preliminary Procedures Remove the outside rearview mirror glass. Refer to OUTSIDE REARVIEW MIRROR GLASS REPLACEMENT .
1Outside Rearview Mirror Housing Retainers (Qty: 6) NOTE: Push the housing tabs upward releasing the housing cover from the mirror.
2Outside Rearview Mirror Housing
NOTE
Push the housing tabs upward releasing the housing cover from the mirror.

Scheme 51

Scheme 51: Inside Rearview Mirror Replacement
CalloutComponent Name
1Inside Rearview Mirror Cover NOTE: Slide the mirror cover apart to expose the electrical connector.
2Inside Rearview Mirror Refer to CAUTION: RETAINER . Procedure Disconnect the electrical connector. Adjust the mirror to the full upward position. Loosen the set screw located at the base of the mirror. Slide the mirror upward off of the rearview mirror button. Remove the windshield outside moisture sensor, if equipped. Refer to CONTROL MODULE REFERENCES for programming and setup information, if equipped. Tighten 2 Nm (18 lb in)
NOTE
Slide the mirror cover apart to expose the electrical connector.

Scheme 52

Scheme 52: Inside Rearview Mirror Bracket Installation

Scheme 53

Scheme 53

Scheme 54

Scheme 54
  1. NOTE: If the windshield is equipped with a blackout area around the mirror base bracket Care Must be used not to cut or scrape the blackout. Determine the location of the mirror mounting base by marking the outside/inside of the windshield with a wax pencil where the base was previously located. If it is not clear where the base was located, use the following steps to determine where the base should be installed: 1.1. Using a measuring tape, measure the distance between the windshield pillars at the windshield blackout line. 1.2. Using a marking pencil, halfway between the windshield pillars, draw a centerline (1) on the windshield from the roof panel to the windshield base. 1.3. Draw a perpendicular line intersecting the centerline (2) at that location. The bottom center of the mirror mounting base will be at the intersection of these lines.
  2. NOTE: Clean the inside windshield glass and the mounting surface of the mirror mounting base thoroughly with a clean cloth saturated with naphtha or a 50/50 mixture by volume of clean water and isopropyl alcohol. Clean the inside windshield glass thoroughly to remove all old adhesive.
  3. NOTE: If reinstalling the original mounting base, place the mirror mounting base in a suitable holding device, such as a vice. Clean mirror mounting base thoroughly to remove all of the old adhesive.
  4. Using the Inside Mirror Adhesive Kit, or equivalent to apply a small amount of activator to the mounting surface of the mirror mounting base. Refer to «ADHESIVES, FLUIDS, LUBRICANTS, AND SEALERS»(ref-652259-S28233140262014082300000) .
  5. Apply a small amount of activator to the windshield where the mounting base is to be installed.
  6. Allow the activator to dry 5 minutes.
  7. NOTE: Do not touch the mounting surface of the mirror mounting base or the glass. Apply 1 drop of adhesive to the center of the mirror mounting base.
  8. Immediately apply the mounting base to the windshield, ensuring that the mounting base aligns correctly to the marks made on the outside of the windshield.
  9. Hold the mounting base firmly in place for 1 minute.
  10. Allow the adhesive to set for 15 minutes before installing the rearview mirror.
  11. Clean the wax pencil lines from the exterior surface of the glass.
  12. Install the mirror to the mirror mounting base. Refer to «INSIDE REARVIEW MIRROR REPLACEMENT»(ref-652259-S28031005452014082300000) .

Scheme 55

Scheme 55: Driver Door

Scheme 56

Scheme 56: Passenger Door

Scheme 57

Scheme 57: Rear Doors

Scheme 58

Scheme 58: Rear Defogger

Scheme 59

Scheme 59: DD8

Scheme 60

Scheme 60: Outside Mirrors (DR4 or DR5 without AAB)

Scheme 61

Scheme 61: Driver (DR4 with AAB)

Scheme 62

Scheme 62: Passenger (DR4 with AAB)
