Time studies - Suspension, front
| Object code - ID | Description | Variant | Model year | Correction | Terminal | Time (hrs) |
|---|---|---|---|---|---|---|
| 71100-01 | Front vehicle frame | FWD A30YH | 2011 | 01 | 3.0 | |
| 71100-02 | Front vehicle frame | 4WD A30YH | 2011 | 01 | 3.6 | |
| 71100-04 | Front vehicle frame | A28NER | 2011 | 01 | 3.6 | |
| 71100-05 | Front vehicle frame | 2011 | 03 | 1.0 | ||
| 71123-01 | Link | 2011 | 01 | 0304 | 0.5 | |
| 71123-02 | Link | 2011 | 01 | 05 | 0.5 | |
| 73130-01 | Strut, comp. | 2011 | 01 | 0304 | 0.9 | |
| 73130-02 | Strut, comp. | 2011 | 01 | 0304 | 0.7 | |
| 73130-03 | Strut, comp. | 2011 | 01 | 05 | 1.7 | |
| 73131-01 | Spring strut | 2011 | 01 | 05 | 1.2 |
Correction
- 01 - Replacement
- 02 - Removal - Refit
- 03 - Renovate
- 04 - Paint
- 05 - Adjust
- 06 - Change comp. unit
- 07 - Lubricate - Clean - Polish
- 08 - Check/Fault search
- 09 - Expose
- 10 - Install new
- 11 - Transfer
Tools Required
J 43631 Ball Joint Remover
Scheme 34
- Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
- Remove the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
- Remove the brake rotor. Refer to «FRONT BRAKE ROTOR REPLACEMENT»(ref-652270-S00837745982014082300000) .
- Using J 43631 remove the wheel stud at the inner most notch.
Scheme 35
- Install the new stud from the back side of the hub.
- Install flat washers on the wheel stud.
- IMPORTANT: Ensure that the wheel stud is fully seated against the wheel hub flange. With the flat side of a wheel nut against the washers, tighten the wheel nut until the wheel stud head seats against the wheel hub flange.
- Install the brake rotor. Refer to «FRONT BRAKE ROTOR REPLACEMENT»(ref-652270-S00837745982014082300000) .
- Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) . Lower the vehicle.
