Lighting and Signalling Systems: Component Locations Saab 9-4X I

Horns 2 illustrations

Location (pos)

  1. 01 - Front
  2. 02 - Rear
  3. 03 - Left
  4. 04 - Right Hand
  5. 05 - All
  6. 06 - Upper
  7. 07 - Center
  8. 08 - Lower
  9. 09 - Service Information

Scheme 23

Scheme 23: Horn Replacement
Scheme 23: Horn Replacement
CalloutComponent Name
Preliminary Procedures Remove the front wheelhouse liner. Refer to FRONT WHEELHOUSE LINER REPLACEMENT .
1Horn Nut Refer to CAUTION: RETAINER Tighten 9 N m (80 lb in)
2Horn Procedure Disconnect the electrical connector.

Scheme 24

Scheme 24: Steering Wheel Horn Contact Replacement
Scheme 24: Steering Wheel Horn Contact Replacement
CalloutComponent Name
Refer to SIR WARNING . Preliminary Procedures Remove the inflatable restraint steering wheel module. Refer to STEERING WHEEL INFLATABLE RESTRAINT MODULE REPLACEMENT .
1Steering Wheel Horn Contact Bolt/Screw (Qty: 3) Refer to CAUTION: RETAINER Tighten 8 Nm (71 lb in)
2Steering Wheel Horn Contact Procedure Disconnect any electrical connectors as necessary.
