Lighting and Signalling Systems: Adjustments

Calibration Criteria

Note. Do not apply the brake pedal during the brake pedal position sensor calibration procedure. Any movement of the brake pedal during this procedure will cause the calibration procedure to fail. If this occurs, the brake pedal position sensor calibration must be repeated.

Brake pedal position sensor calibration must be performed after the brake pedal position sensor or body control module (BCM) have been serviced. The calibration procedure will set the brake pedal position sensor home value. This value is used by the BCM to determine the action of the driver applying the brake system and to provide this information to the vehicle subsystems via serial data.

Calibration Procedure

Apply the parking brake.
Place the transmission in the PARK position.
Install a scan tool.
Clear all BCM DTCs before proceeding.
Navigate to the Module Diagnosis menu.
Select BCM menu item.
Select Configuration/Reset Functions menu item.
Select the Brake Pedal Position Sensor Learn procedure and follow the directions displayed on the screen.

Scheme 1

Scheme 1: Brake Pedal Position Sensor Replacement

Callout	Component Name
Preliminary Procedures Remove the instrument panel insulator panel. Refer to INSTRUMENT PANEL INSULATOR PANEL REPLACEMENT - LEFT SIDE .
1	Brake Pedal Position Sensor Bolt Refer to CAUTION: RETAINER Procedure Remove the sensor bolt. Tighten 9 N m (80 lb in)
2	Brake Pedal Position Sensor Procedure Disconnect the electrical connector. Pull the sensor away from the bracket. Recalibrate the brake pedal position sensor. Refer to BRAKE PEDAL POSITION SENSOR CALIBRATION .

Scheme 2

Scheme 2: Sun Load Temperature and Daytime Running Lamp Ambient Light Sensor Replacement

Callout	Component Name
Preliminary Procedures Remove the radio front speaker grille. Refer to RADIO FRONT SPEAKER GRILLE REPLACEMENT .
1	Sunload Temperature and Daytime Running Lamp and Ambient Light Sensor Mounting Bracket
2	Sunload Temperature and Daytime Running Lamp and Ambient Light Sensor Procedure Twist and pull up to remove. Disconnect electrical connector.

Scheme 3

Scheme 3: Headlamp Switch Replacement

Callout	Component Name
Preliminary Procedures Remove instrument panel side trim panel. Refer to INSTRUMENT PANEL SIDE TRIM PANEL REPLACEMENT .
1	Headlamp Switch Procedure Depress tabs to remove the switch assembly from the instrument panel. Disconnect the electrical connector.

Scheme 4

Scheme 4: Door Lock and Hazard Warning Switch Replacement

Callout	Component Name
Preliminary Procedures Remove the instrument panel center trim plate. Refer to INSTRUMENT PANEL LOWER CENTER TRIM PANEL REPLACEMENT .
1	Door Lock and Hazard Warning Switch Procedure Disconnect the electrical connector.

Scheme 5

Scheme 5: Dimmer Switch Replacement

Callout	Component Name
Preliminary Procedures Remove the radio control assembly. Refer to RADIO CONTROL ASSEMBLY REPLACEMENT .
1	Instrument Panel Lamp Dimmer Switch Procedure Depress the tabs on the switch to release.

Scheme 6

Scheme 6: Reading Lamp Switch Pushbutton Replacement

Callout	Component Name
Preliminary Procedures Remove the roof console. Refer to ROOF CONSOLE REPLACEMENT .
1	Reading Lamp Switch Pushbutton Procedure Press tabs together and remove switch.

Scheme 7

Scheme 7: Dome and Reading Lamp Switch Replacement

Callout	Component Name
Preliminary Procedures Remove the roof console. Refer to ROOF CONSOLE REPLACEMENT .
1	Dome and Reading Lamp Switch Disconnect the electrical connector. Release the tabs and remove the switch.

Scheme 8

Scheme 8: Dome Lamp Lens Replacement

Callout	Component Name
1	Dome Lamp Lens Procedure Using nylon flat bladed tool release the four integral tabs on the lens from the roof console.

Scheme 9

Scheme 9: Front Floor Console Flood Lamp Replacement

Callout	Component Name
Preliminary Procedures Remove the roof console. Refer to ROOF CONSOLE REPLACEMENT .
1	Front Floor Console Flood Lamp Procedure Disconnect electrical connector.

Scheme 10

Scheme 10: Instrument Panel Compartment Lamp Replacement

Callout	Component Name
1	Instrument Panel Compartment Lamp Procedure Use a plastic flat bladed trim tool in order to release the lamp assembly from the instrument panel compartment housing. Disconnect the electrical connection.

Scheme 11

Scheme 11: Instrument Panel Compartment Lamp Bulb Replacement

Callout	Component Name
Preliminary Procedures Remove the instrument panel compartment lamp. Refer to INSTRUMENT PANEL COMPARTMENT LAMP REPLACEMENT .
1	Instrument Panel Compartment Lamp Bulb

Scheme 12

Scheme 12: Roof Rail Courtesy and Reading Lamp Replacement

Callout	Component Name
Preliminary Procedures Remove the roof rail rear assist handle. Refer to ROOF RAIL REAR ASSIST HANDLE REPLACEMENT .
1	Roof Rail Courtesy and Reading Lamp Assembly
2	Roof Rail Courtesy and Reading Lamp Lens Procedure From the backside of the lamp assembly, using the appropriate tool, depress tab on indented side and then disengage the opposite side of the lens.
3	Light Plate Blocker Bolt Refer to CAUTION: RETAINER
4	Light Plate Blocker NOTE: Remove blocker, if equipped.
5	Roof Rail Courtesy and Reading Lamp Bulb
6	Roof Rail Courtesy and Reading Lamp Bezel NOTE: Remove any protective films from service part.

NOTE
Remove blocker, if equipped.

NOTE
Remove any protective films from service part.

Scheme 13

Scheme 13: Transmission Control Position Indicator Lamp Replacement

Callout	Component Name
Preliminary Procedures Remove the front floor console trim plate.
1	Transmission Control Position Indicator Lamp Bolts (Qty: 2) Refer to CAUTION: RETAINER
2	Transmission Control Position Indicator Lamp Procedure Disconnect the electrical connector.

Scheme 14

Scheme 14: Headlamp Replacement (T84 T85)

Callout	Component Name
Preliminary Procedures Remove the front bumper fascia assembly. Refer to FRONT BUMPER FASCIA REPLACEMENT .
1	Headlamp Bolt (Qty: 4) Refer to CAUTION: RETAINER Tighten 9 N m (80 lb in)
2	Headlamp Assembly Procedure Pull the headlamp assembly forward and disconnect the electrical harness connector. Aim the headlamps after the installation is complete. Refer to HEADLAMP AIMING .

Scheme 15

Scheme 15: Headlamp Replacement (TT6 HID)

Callout	Component Name
WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. WARNING: The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. Preliminary Procedures Remove the front bumper fascia assembly. Refer to FRONT BUMPER FASCIA REPLACEMENT .
1	Headlamp Bolt (Qty: 4) Refer to CAUTION: RETAINER Tighten 9 N m (80 lb in)
2	Headlamp Assembly Procedure 2 Lift slightly then pull the headlamp assembly forward and disconnect the electrical harness connector from the back side of the headlamp. Aim the headlamps after the installation is complete. Refer to HEADLAMP AIMING .

WARNING
The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly.

WARNING
The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system.

Scheme 16

Scheme 16: Headlamp Bulb Replacement - Left Side (T84 T85 High Beam)

Callout	Component Name
Refer to HALOGEN BULB WARNING . Preliminary Procedures Open and support the hood assembly. Remove the accessory bulb cover.
1	Headlamp Bulb (High Beam) Procedure Disconnect the electrical connector from the high beam bulb socket. Rotate the bulb counter-clockwise and remove.

Scheme 17

Scheme 17: Headlamp Bulb Replacement - Left Side (T84 T85 Low Beam)

Callout	Component Name
Refer to HALOGEN BULB WARNING . Preliminary Procedures Open and support the hood assembly. Remove the accessory bulb cover.
1	Headlamp Bulb Accessory Cover Procedure Rotate the accessory bulb cover counter-clockwise and remove from the headlamp housing.
2	Headlamp Bulb (Low Beam) Procedure Disconnect the electrical connector from the low beam bulb lamp socket. Rotate the bulb counter-clockwise and remove.

Scheme 18

Scheme 18: Headlamp Bulb Replacement - Right Side (High Beam T84 T85)

Callout	Component Name
Refer to HALOGEN BULB WARNING . Preliminary Procedures Open and support the hood assembly.
1	Headlamp Bulb Accessory Cover Procedure Rotate the headlamp bulb accessory cover counter-clockwise and remove.
2	Headlamp Bulb (High Beam) Procedure Disconnect the electrical connector from the high beam bulb socket. Rotate the bulb counter-clockwise and remove.

Scheme 19

Scheme 19: Headlamp Bulb Replacement - Right Side (Low Beam T84 T85)

Callout	Component Name
Refer to HALOGEN BULB WARNING . Preliminary Procedures Open and support the hood assembly.
1	Headlamp Bulb Accessory Cover Procedure Rotate the accessory cover counter-clockwise and remove.
2	Headlamp Bulb (Low Beam) Procedure Disconnect the electrical connector from the low beam bulb lamp socket. Rotate the bulb counter-clockwise and remove.

Scheme 20

Scheme 20: Headlamp Ballast Replacement

Callout	Component Name
WARNING: The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. Preliminary Procedures Remove the headlamp assembly. Refer to HEADLAMP REPLACEMENT (T84 T85) or HEADLAMP REPLACEMENT (TT6 HID) . Remove the headlamp accessory cover. Disconnect the electrical harness connector from the headlamp igniter.
1	Ballast Screw (Qty: 3) Refer to CAUTION: RETAINER
2	Headlamp Ballast Procedure Pull the ballast from the bottom side of the headlamp housing and disconnect the electrical connector.

WARNING
The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system.

WARNING
The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly.

Scheme 21

Scheme 21: Headlamp Ignitor Replacement (TT6 Left Hand)

Callout	Component Name
WARNING: The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. Preliminary Procedures Open and support the hood assembly.
1	Headlamp Bulb Accessory Cover Procedure Rotate the headlamp accessory bulb cover counter-clockwise and remove.
2	Headlamp Starter and Cable Procedure Disconnect the starter and cable assembly from the headlamp high intensity discharge bulb housing assembly.
3	High Intensity Discharge Bulb Squeeze the retainer clip at the top securing the high intensity discharge bulb to the headlamp housing. Remove the bulb from the headlamp assembly.

WARNING
The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system.

WARNING
The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly.

Scheme 22

Scheme 22: Headlamp Capsule Replacement

Callout	Component Name
WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. WARNING: The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. Preliminary Procedures Remove the front bumper fascia assembly. Refer to FRONT BUMPER FASCIA REPLACEMENT .
1	Headlamp Capsule Bolt (Qty: 4) Refer to CAUTION: RETAINER Tighten 9 N m (80 lb in)
2	Headlamp Capsule Procedure Lift slightly then pull the headlamp capsule forward and disconnect the electrical harness connector from the back side of the headlamp. Remove and transfer the accessory bulb covers. Remove and transfer the headlamp bulbs. Remove and transfer the headlamp ballast.

WARNING
The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly.

WARNING
The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system.
