Fuses Saab 9-3 II

Wash/wipe Systems 8 illustrations ~173 words

The electrical center can contain a greater number of fuses than those listed below. In such cases, these are not connected to a wiring harness. For additional fuse information, see CIRCUIT PROTECTION DEVICES and POWER DISTRIBUTION articles.

No.	Amp	Type	Function
1
2
3
4	40	+30	Electrically adjustable seat without memory
5	40	+30	Electrically heated rear window (115) STC control module (CV) (565) Antenna amplifier (624)
6	30	+30	Control module, rear left door (702RL) Control module, rear left window lift (575RL)
7	30	+30	Control module, right rear door (702RR) Control module, rear right window lift (575RR)
8	20	+30	Connection, trailer (258)
9
10	30		High-level brake light Trailer lighting Luggage compartment illumination Left rear lighting brake lights Right rear lighting: Direction indicators taillights Reversing lights
11
12
13
14	15	+30	Rear window wiper motor (63R)
15	15	+30	Heating, left seat (64FL)
16	15	+30	Heating, right seat (64FR)
17	7.5	+15	Rain sensor (649) Sunroof (182) Interior rearview mirror (681) with: Remote control garage opening Compass ADM control module
18	15	+30	Sunroof (182)
19	7.5	+30	Positioning unit (468)
20	7.5	+30	DVD (729)
21	7.5	+30	Control module, rear doors (702R) Control module, rear window lifts (575R) Control module, SPA (630) Front lamp unit, interior lighting (185F) on CV
22	30	+30	Rear amplifier (354R)
23
24	10	+30	Siren, anti-theft alarm (275) Anti-theft alarm sensor (690) Rear CD changer (355R)
25	30	+30	Electrically adjustable driver's seat with memory control module (357Dk) Electrically adjustable seat without memory (CV)
26	30		Rear fog light Number plate lighting Luggage compartment illumination Trailer lighting Left rear lighting Direction indicators taillights Reversing lights Right rear lighting: brake lights
27	10		Electrically controlled lumbar support
28
29
(1) For additional fuse locations, see POWER DISTRIBUTION .

(1)	For additional fuse locations, see POWER DISTRIBUTION .

FUSES REFERENCE (1)

Scheme 167

Scheme 167: Relays

The electrical center can contain a greater number of relays than those listed below. In such cases, these are not connected to a wiring harness. For additional relay information, see BUZZERS, RELAYS & TIMERS .

RELAYS REFERENCE Location No Description Graphic Diagram R1 446 Electrically adjustable seat relay - R2 757R Relay, +15, REC - R3 - - - - R4 113 Electrically heated rear window relay HEATING, REAR WINDOW R5 83a Rear window wiper relay REAR WINDOW WIPER 5D R6 - - - - R7 710 Boot lid opening motor relay - R8 - - - - R9 - - - - R10 - - - - R11
