Relay, +54 (21) Saab 9-3 II

Theft Protection (Electrical) 8 illustrations ~245 words

Relay, +54 (21)

Location: In main fuse box in instrument panel

Scheme 190

Scheme 190: Relay, +54 (21)

The electrical centre for most of the operations in the compartment and dashboard.

BCM control module 707 is located in the electrical centre

Electrical centre with relays, maxi and micro-fuses.

The 16 pin connector from the BCM 707 control module is connected directly to the electrical centre.

The electrical centre is fed with +30 voltage from the engine bay electrical centre 342 and is connected to the dashboard harness via a 42 pin connector.

Scheme 191

Scheme 191: Connect

The following current circuits are distributed by the electrical centre

  1. Power supply +30, dashboard's electrical centre
  2. Power supply +15, dashboard's electrical centre
  3. Power supply +54, dashboard electrical centre

Scheme 192

Scheme 192: Fuses

The electrical centre can contain a greater number of fuses than those listed below. In such cases, these are not connected to a wiring harness.

Note. Also see appropriate POWER DISTRIBUTION wiring diagram and . CIRCUIT PROTECTION DEVICES .

NoAmp.TypeFunction
115+30Steering column lock (708)
25+30Ignition Switch Module (20)
Column Integration Module (703a)
310+30CD player/changer, front (355F)
SID (541)
Connection, mobile phone (375)
410+30Main instrument display panel (540)
ACC (216)
MCC (504)
BCM (707)
57.5+30Control module, front doors (702D/P)
Gear Selector Module (726)
67.5+30Brake light switch signal (29)
720+30BCM (707)
Solenoid, fuel filler flap (434a)
830+30Control module, front passenger door (702P)
910+30BCM (707)
1030+5412 V socket, cabin, including lighting (480C/361)
12 V socket, luggage compartment (480R)
Connection, trailer (258)
1115+30Data link connector (445)
1215+30Interior lighting
Glove box lighting
1330Accessories
1420+30Main unit, audio (353)
Control panel, infotainment (736)
1530+30Control module, driver's door (702D)
167.5+15Control module, PPS (591)
177.5+15Connection, electronic road tolls (461)
187.5+54MCC (504)
19
207.5+15Switch, headlamp beam length adjustment (282)
217.5+15Switch, clutch, cruise control (133)
Switch, brake, cruise control (134)
Connection, mobile phone (375)
MCC (504)
2230+15Cigarette lighter (48)
2340 maxi+30Ventilation fan (36)
247.5+30Airbag control module (331)
25
265+15Yaw sensor (658)
27

FUSE FUNCTION CHART

Scheme 193

Scheme 193: Relays

For more information on relays, see BUZZERS, RELAYS & TIMERS .

The electrical centre can contain a greater number of relays than those listed below. In such cases, these are not connected to a wiring harness.

RELAYS DESCRIPTION CHART Location No Description Illustration R1 21 Relay, +54 R2 757C Relay, +15, IPEC R3 - R4 - R5 - R6 756 Relay, accessories R7 - Soldered circuit board 717 Interior lighting relay

Scheme 194

Scheme 194

Scheme 195

Scheme 195

Scheme 196

Scheme 196

Scheme 197

Scheme 197: Fuse 1, fuse box in the dashboard 22
