Front Suspension: Overview Saab 9-3 II

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Remove the upper bumper shell attachments.
2. Hang two «83 95 212 STRAPS»(ref-275876-S25609733142007122900000) in place over the radiator member and the radiator unit so that they are accessible from below.
3. Raise the car.
4. Remove the front wheels.
5. Remove the lower front cover. CV: Remove «CHASSIS REINFORCEMENT, FRONT SUBFRAME, CV, PETROL»(ref-275876-S05650643942007122900000) .
6. Bind the radiator unit tightly with the straps.
7. Remove the radiator brackets from the subframe.
8. Remove «COMPLETE EXHAUST SYSTEM (2006)»(ref-275857-S38550756052007122900000) or «EXHAUST SYSTEM 4-CYLINDER-PETROL (2007)»(ref-275846) or «EXHAUST SYSTEM V6 (2007)»(ref-275857) . IMPORTANT: Take care so as not to crack the flex bellows.
9. Remove the engine torque rod from the subframe.
10. Remove the bolt and nut which attach the suspension arm to the steering swivel member on both sides. Left-hand suspension arm and cars with xenon lights: Remove the level sensor.
11. Remove the steering gear from the subframe. Mind the nuts and washers. Allow the steering gear to remain suspended.
12. Open the clips that secure the power steering pipe to the subframe.
13. Remove the front part of the wing liner and fold away slightly.
14. Position the «83 95 311 TROLLEY LIFT»(ref-275876-S15758916622007122900000) underneath with «83 94 801 PARENT FIXTURE»(ref-275876-S26333905402007122900000) and «83 96 137 REMOVAL/FITTING TOOL, SUBFRAME»(ref-275876-S05271366232007122900000) .
15. Remove the subframe bolts on both sides. Remove the stays from the body.
16. Lower the subframe slightly.
17. Pull out the suspension arms ball-and-socket joints from the steering swivel members.
18. Remove the anti-roll bar from the subframe.
19. Lower the subframe.
20. Subframe replacement: Remove the suspension arms and rear torque rod.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Place the frame on the «83 95 311 TROLLEY LIFT»(ref-275876-S15758916622007122900000) with «83 94 801 PARENT FIXTURE»(ref-275876-S26333905402007122900000) and «83 96 137 REMOVAL/FITTING TOOL, SUBFRAME»(ref-275876-S05271366232007122900000) .
2. Subframe replacement: Fit the rear torque rod and the suspension arms in the horizontal position. Rear torque rod 60 Nm (44 lbf ft) Rear bush to subframe 65 Nm +135° (48 lbf ft +135°) Front bush to subframe 65 Nm +135° (48 lbf ft +135°)
3. Lift the frame. Fit the ball joints for the suspension arms in the steering swivel member. Fit the anti-roll bar to the subframe. The opening of the rubber bushes should face forward (M05 only)
4. Lift the subframe into place and align «83 96 137 CENTERING TOOL, SUBFRAME - BODY»(ref-275876-S05271366232007122900000) with the locating holes in the body.
5. Attach the power steering pipe to the plastic clips on the subframe.
6. Lift the subframe so that the inner sections of the bushes are pressing against the body. Fit the front subframe bolts on both sides. Tightening torque 75 Nm +135° (55 lbf ft +135°) Fit the stays and the rear subframe bolts on both sides. Enter the rear stay bolts before tightening the subframe bolts. Tightening torque 75 Nm +135° (55 lbf ft +135°) Lower and pull away the trolley lift.
7. Tighten the rear stay bolts. Tightening torque 90 Nm +45° (66 lbf ft +45°)
8. Fit the steering gear with bolts, washers and nuts. Tightening torque 50 Nm +60° (37 lbf ft +60°)
9. Fit the engine torque rod to the subframe. Tightening torque, rear torque rod 80 Nm (59 lbf ft) Tightening torque, front torque rod 60 Nm +90° (44 lbf ft +90°) Set up «83 96 145 CENTERING TOOL, SUBFRAME - ENGINE»(ref-275876-S33252037272007122900000) and check that the engine is correctly positioned in relation to the subframe. Remove the centering tool.
10. Fit the suspension arms to the steering swivel members. WARNING: Press up the pin carefully. The groove in the pin must be visible in the screw hole in the spindle housing. If the rubber gaiter is pressed down, it will not seal properly to the swivel pin. Tightening torque 50 Nm (37 lbf ft) Left-hand suspension arm and cars with xenon lights: Fit the level sensor.
11. Fit the radiator brackets to the subframe. NOTE: Check that the upper radiator unit support is placed correctly.
12. Remove the straps.
13. Install «COMPLETE EXHAUST SYSTEM (2006)»(ref-275857-S38550756052007122900000) or «EXHAUST SYSTEM 4-CYLINDER-PETROL (2007)»(ref-275846) or «EXHAUST SYSTEM V6 (2007)»(ref-275857) . IMPORTANT: Take care so as not to crack the flex bellows.
14. Fit the front part of the wing liner on both sides of the car.
15. CV: Fit «CHASSIS REINFORCEMENT, FRONT SUBFRAME, CV, PETROL»(ref-275876-S05650643942007122900000) . Fit the lower front cover.
16. Fit the «WHEEL»(ref-275842-S20194743172007122900000) .
17. Lower the car to the floor.
18. Fit the upper bumper shell attachments.
19. Check the straight-ahead position of the steering wheel when driving on a level road. Adjust if necessary.
20. Replacement of subframe: Carry out «FOUR WHEEL ALIGNMENT»(ref-275876-S18379331632007122900000) .

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Remove the upper bumper shell attachments.
2. Remove the air filter cover. IMPORTANT: Be careful of the electrical connection to the brake vacuum valve.
3. Detach the hose between the air filter and mass air flow sensor. Remove the mass air flow sensor with hose.
4. Hang two «83 95 212 STRAPS»(ref-275876-S25609733142007122900000) in place over the radiator member and the radiator unit so that they are accessible from below.
5. Raise the car.
6. Remove the front wheels.
7. Remove the lower front cover. CV: Remove «CHASSIS REINFORCEMENT, FRONT SUBFRAME, CV, PETROL»(ref-275876-S05650643942007122900000) .
8. Bind the radiator unit tightly with the straps.
9. Remove the radiator brackets from the subframe.
10. Remove the front exhaust pipe section. IMPORTANT: Be careful with the flexible part. It must not be bent by more than 5°.
11. Remove the engine torque rod from the subframe.
12. Remove the bolt and nut which attach the suspension arm to the steering swivel member on both sides. Cars with xenon headlights: Remove the level sensor on the left-hand suspension arm.
13. Remove the steering gear from the subframe. Mind the nuts and washers. Allow the steering gear to remain suspended.
14. Open the clips that secure the power steering pipe to the subframe.
15. Position the «83 95 311 TROLLEY LIFT»(ref-275876-S15758916622007122900000) underneath with «83 94 801 PARENT FIXTURE»(ref-275876-S26333905402007122900000) and «83 96 137 REMOVAL/FITTING TOOL, SUBFRAME»(ref-275876-S05271366232007122900000) .
16. Remove the front part of the wing liner and fold away slightly.
17. Remove the subframe bolts on both sides. Remove the stays from the body.
18. Lower the subframe slightly.
19. Pull out the suspension arms ball-and-socket joints from the steering swivel members.
20. Remove the anti-roll bar from the subframe.
21. Lower the subframe.
22. Subframe replacement: Remove the suspension arms and rear torque rod.

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Place the frame on the «83 95 311 TROLLEY LIFT»(ref-275876-S15758916622007122900000) with «83 94 801 PARENT FIXTURE»(ref-275876-S26333905402007122900000) and «83 96 137 REMOVAL/FITTING TOOL, SUBFRAME»(ref-275876-S05271366232007122900000) . Subframe replacement: Fit the rear torque rod. Rear torque rod 60 Nm (44 lbf ft)
2. Replacement the subframe: Fit the suspension arms in a horizontal position. Rear bush to subframe 65 Nm +135° (48 lbf ft +135°) Front bush to subframe 65 Nm +135° (48 lbf ft +135°)
3. Lift the frame. Fit the ball joints for the suspension arms in the steering swivel member. Fit the anti-roll bar to the subframe.
4. Lift the subframe into place and align «83 96 137 CENTERING TOOL, SUBFRAME - BODY»(ref-275876-S05271366232007122900000) with the locating holes in the body.
5. Attach the power steering pipe to the plastic clips on the subframe.
6. Lift the subframe so that the inner sections of the bushes are pressing against the body. Fit the front subframe bolts on both sides. Tightening torque 75 Nm +135° (55 lbf ft +135°) Fit the stays and the rear subframe bolts on both sides. Enter the rear stay bolts before tightening the subframe bolts. Tightening torque 75 Nm +135° (55 lbf ft +135°) Lower and pull away the trolley lift.
7. Tighten the rear stay bolts. Tightening torque 90 Nm +45° (66 lbf ft +45°)
8. Fit the steering gear with bolts, washers and nuts. Tightening torque 50 Nm +60° (37 lbf ft +60°)
9. Fit the engine torque rod to the subframe. Tightening torque, rear torque rod 80 Nm (59 lbf ft) Tightening torque, front torque rod 60 Nm +90° (44 lbf ft +90°) Set up «83 96 145 CENTERING TOOL, SUBFRAME - ENGINE»(ref-275876-S33252037272007122900000) and check that the engine is correctly positioned in relation to the subframe. Remove the centering tool.
10. Fit the suspension arms to the steering swivel members. WARNING: Press up the pin carefully. The groove in the pin must be visible in the screw hole in the spindle housing. If the rubber gaiter is pressed down, it will not seal properly to the swivel pin. Tightening torque 50 Nm (37 lbf ft) Cars with xenon headlights: Fit the level sensor on the left-hand suspension arm.
11. Fit the radiator brackets to the subframe. Tightening torque 47 Nm (35 lbf ft) NOTE: Check that the upper radiator unit support is placed correctly.
12. Remove the straps.
13. Fit the front exhaust pipe section. Tightening torque 30 Nm (22 lbf ft) Clamp: Tightening torque 40 Nm (30 lbf ft) IMPORTANT: Be careful with the flexible part. It must not be bent by more than 5°.
14. Fit the front part of the wing liner on both sides of the car.
15. CV: Fit «CHASSIS REINFORCEMENT, FRONT SUBFRAME, CV, PETROL»(ref-275876-S05650643942007122900000) . Fit the lower front cover.
16. Fit the wheels.
17. Lower the car to the floor.
18. Fit the upper bumper shell attachments.
19. Attach the hose with mass air flow sensor to the turbocharger and attach the hose between the mass air flow sensor and the air filter.
20. Fit the air filter cover.
21. Check the straight-ahead position of the steering wheel when driving on a level road. Adjust if necessary.
22. Replacement of subframe: Carry out «FOUR WHEEL ALIGNMENT»(ref-275876-S18379331632007122900000) .

Description

Reinforcements bolted to the chassis compensate for the lack of a fixed roof. When the reinforcements are refitted after removal, you must tighten the retaining bolts to the stipulated tightening torques. Refer to TIGHTENING TORQUE , front or TIGHTENING TORQUE , rear.

Scheme 40

TIGHTENING TORQUES
