Convertible Top: Component Locations Saab 9-3 II

Sun Roof/t-Top/convertible Top 25 illustrations ~485 words

Location

POSITION SENSOR, FIRST BOW READY TO LOCK (561)

Scheme 199

Scheme 199: Location

POSITION SENSOR, FIRST BOW LOCKED (561C)

POSITION SENSOR, SOFT TOP COVER LOCKED, LH (562LH)

POSITION SENSOR, SOFT TOP COVER LOCKED, RH (562RH)

POSITION SENSOR, SOFT TOP LOWERED (562O)

Scheme 200

Scheme 200: Location

POSITION SENSOR, SOFT TOP BAG DOWN (564)

CONTROL MODULE, STC (565)

Scheme 201

Scheme 201: Main task

The driver request the opening or closing of the soft top with the switch on the SIDC or the remote control. The STC control module operates the soft top hydraulically using information from a number of position sensors integrated in the mechanism's cylinders.

POSITION SENSOR, SOFT TOP RAISED (577C)

POSITION SENSOR, SOFT TOP LOWERED (577O)

POSITION SENSOR, SIXTH BOW LOCKED, LH (578LH)

POSITION SENSOR, SIXTH BOW LOCKED, RH (578RH)

POSITION SENSOR, SIXTH BOW RAISED (578U)

MOTOR, HYDRAULIC PUMP, SOFT TOP (646)

Scheme 202

Scheme 202: Location

SOLENOID VALVE 1, SOFT TOP (647A)

SOLENOID VALVE 2, SOFT TOP (647B)

SOLENOID VALVE 3, SOFT TOP (647C)

Scheme 203

Scheme 203: Location

in the LH lock on the windscreen frame

Scheme 204

Scheme 204: Location

in the center of the first bow

Scheme 205

Scheme 205: Location

component: on the LH hinge of the soft top cover

connector: in front of the LH rear wheel housing

Scheme 206

Scheme 206: Location

component: on the RH hinge of the soft top cover

connector: gray connector in front of the RH rear wheel housing

Scheme 207

Scheme 207: Location

component: on the hydraulic cylinder of the soft top cover

connector: gray connector in front of the RH rear wheel housing

Scheme 208

Scheme 208: Location

component: on the soft top bag drive mechanism

connector: black connector by the soft top bag drive mechanism

Scheme 209

Scheme 209: Location

on the RH rear wheel housing

K27A

Scheme 210

Scheme 210: Location

K27B

Scheme 211

Scheme 211

component: on the RH hydraulic cylinder of the soft top cover

connector: black connector by the RH drive mechanism of the soft top bag

Scheme 212

Scheme 212: Location

component: on the RH hydraulic cylinder of the soft top cover

connector: black connector by the RH drive mechanism of the soft top bag

Scheme 213

Scheme 213: Location

on the LH side of the sixth bow

Scheme 214

Scheme 214: Location

on the RH side of the sixth bow

Scheme 215

Scheme 215: Location

component: on the hydraulic cylinder of the sixth bow

connector: grey connector by the soft top bag drive mechanism

Scheme 216

Scheme 216: Location

in the hydraulic unit by the RH rear wheel housing

Scheme 217

Scheme 217: Location

in the hydraulic unit by the RH rear wheel housing (green connector)

Scheme 218

Scheme 218: Location

in the hydraulic unit by the RH rear wheel housing (blue connector)

Scheme 219

Scheme 219: Location

in the hydraulic unit by the RH rear wheel housing (orange connector)

Scheme 220

Scheme 220: Location

The electrical center is located in the luggage compartment on the left-hand wheel housing.

Approx. 150 mm from solenoid valve 1

Scheme 221

Scheme 221: Location

Approx. 50 mm from branching point soft top storage position sensor towards the main cylinder

Scheme 222

Scheme 222: Location

Approx. 130 mm from branching point grounding point G48 towards connector H10-7

Scheme 223

Scheme 223: Location

by the STC control module
