Crimp J69, instrument harness
Location
LHD: Approx. 230 mm from branching point of light switch unit towards the column integration module
RHD: Approx. 200 mm from connector H33-1
Scheme 26
Crimp connection J70, instrument harness
Location
LHD: Approx. 290 mm from branching point of light switch unit towards the column integration unit
RHD: Approx. 360 mm from grounding point G40 towards grounding point G41
Scheme 27
Crimp J78, dashboard harness
Location
LHD: Approximately 130 mm from cigarette lighter branching point towards the airbag control module
RHD: Approximately 110 mm from grounding point G41 branching point towards connector H33-1
Scheme 28
Crimp J93, main harness
Location
Approx. 100 mm from branching point TCM control module (FA 57) towards the control module.
Scheme 29
Crimp J232, adapter harness, Simtec
Location: Approx. 60 mm from branching of reversing light switch towards the battery
Scheme 30
Crimp J275, adapter harness EDC16
Location: Approx. 50 mm from branching point H11-1 connector towards engine control module.
