Fuses & Circuit Breakers: Other — Saab 9-3 II (2002-2008)

ENGINE COMPARTMENT

Underhood Fuse/Relay Box is located left side of engine compartment.

Scheme 1: ENGINE COMPARTMENT

Fuse/Relay No.	Amps	Fuse Function
Fuses
1
2	10A	Engine control module; automatic transmission control module
3	20A	Horn
4	10A	Engine control module; battery disconnect switch
5
6	10A	Selector lever, automatic transmission; clutch pedal switch
7
8	5A	Relay for vacuum pump (brake system)
9
10
11
12	10A	Washer fluid pump, rear window
13
14
15	30A	Washer fluid pump, headlights
16	30A	Front right parking light; front right turn signal; left and right side turn signal; right high beam; left low beam; front left fog light
17	30A	Windshield wiper motor, low speed
18	30A	Windshield wiper motor, high speed
19	20A	Parking heater; auxiliary heater
20	10A	Headlight levelling
21
22	30A	Washer fluid pump, windshield
23
24	20A	Flash-to-pass
25	20A	Amplifier, sound system II
26	30A	Front left turn signal; front left parking light; front right fog light; right low beam; left high beam
27-37	MAXI
Relays
R1		Washer fluid pump, windshield
R2
R3
R4
R5		Flash-to-pass
R6		Horn
R7
R8		Starter motor
R9		Windshield wipers ON/OFF
R10		Washer fluid pump, rear window
R11		Ignition +15
R12		Windshield wipers, high/low speed
R13
R14		Washer fluid pump, headlights
R15
R16

Underhood Fuse/Relay Box

Fuse/Relay No.	Amps	Fuse Function
Fuses
1		Air pump, secondary air
2	20A	Fuel pump; Preheated oxygen sensors (lambda probe)
3	10A	A/C compressor
4	30A	Main relay
Relays
1
2		A/C-compressor
3		Preheated oxygen sensors (lambda probe)
4		Main relay, Engine (ECM/EVAP/injectors)

Battery Fuse/Relay Box

Passenger compartment fuse box is located behind a hatch on the left-hand end of the dash.

Scheme 3: PASSENGER COMPARTMENT

Fuse No.	Amps	Fuse Function
1	15A	Steering wheel lock
2	5A	Steering column unit; ignition switch
3	10A	Hands-free; CD-player/CD-changer in cabin; SID
4	10A	Main instrument unit; manual climate control; automatic climate control (ACC)
5	7.5A	Control module in front doors; Park Brake Shift Lock (automatic transmission)
6	7.5A	Brake light switch
7	20A	Dash fuse panel; fuel filler door
8	30A	Control module in passenger front door
9	10A	Dash fuse panel
10	30A	Trailer socket; electrical socket in storage compartment between seats
11	10A	Data link connection (diagnostics)
12	15A	Interior lighting incl. glove box
13	10A	Accessories
14	20A	Radio, sound system I; control panel, Infotainment System
15	30A	Control module in driver's door
16	5A	Passenger Sensing System
17
18	7.5A	Manual climate control; fan
19
20	7.5A	Headlight levelling switch
21	7.5A	Hands-free; brake light switch; manual climate control; clutch pedal switch
22	30A	Cigarette lighter
23	40A	Cabin fan
24	7.5A	Airbag control module
25
26	5A	Yaw sensor (cars with ESP)
27

Passenger Compartment Fuse Box

Cargo area fuse box is located at left-hand side of the trunk.

Scheme 4: TRUNK/CARGO AREA

Fuse No.	Amps	Fuse Function
1-5	MAXI
6	30A	Control module in left rear door
7	30A	Control module in right rear door
8	20A	Trailer
9
10	30A	Left-hand brake light; rear right turn signal; right taillight; right reversing light; high-mounted brake light; trailer lights
11
12
13
14
15	15A	Seat heating, left seat
16	15A	Seat heating, right seat
17	7.5A	Auto-dimming rearview mirror; rain sensor
18	15A	Sunroof
19	7.5A	Telematics (OnStar)
20	7.5A	DVD player (navigation system)
21	7.5A	Saab Parking Assistance (SPA); control module in rear doors
22	30A	Amplifier, sound system III
23
24	10A	Movement sensor; CD changer in trunk
25	30A	Electrically adjustable driver's seat with memory
26	30A	Right-hand stop light; rear left turn signal; left taillight; rear fog light; left reversing light; license plate lighting; trunk lighting; trailer lights
27	10A	Convertible: Lumbar support, electrically adjustable front seat
28	15A	Telematics
29

Cargo Area Fuse Box
