Audio System (Electrical): Removal & Installation Saab 9-3 II

To Remove

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove the ACC/MCC unit with «82 93 474 REMOVAL TOOL»(ref-275865-S28612027982007122900000) . IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
2. Unplug the connector to the ACC/MCC unit.
3. Remove the EHU by pressing in the two catches. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Unplug the CD player.
5. Remove the CD player using «84 71 203 REMOVAL TOOL»(ref-275865-S12837119392007122900000) .

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Slide in the CD player until it locks in position. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
2. Plug in the CD player.
3. Fit the EHU. You should hear a click. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Plug in the connector to the ACC/MCC unit.
5. Fit the ACC/MCC unit.
6. Carry out «LUGGAGE COMPARTMENT TRIM, CV»(ref-275837-S20608773682007122900000) .
7. Check the function

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 28

Scheme 29

1. Remove «LUGGAGE COMPARTMENT TRIM, CV»(ref-275837-S20608773682007122900000) .
2. Remove the screws from the brackets. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
3. Unplug the connector.
4. Remove the two CD player/changer retaining screws.
5. Lift the CD player/changer out of the bracket.

Scheme 30

Scheme 31

1. Fit the CD player/changer into the bracket.
2. Fit the two CD player/changer retaining screws. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
3. Plug in the connector.
4. Fit the bracket with the CD player/changer.
5. Fit the bracket screws.
6. Carry out «PROCEDURE AFTER CHANGING THE CONTROL MODULE»(ref-275865-S17743978662007122900000) .
7. Check the function.
8. Fit «LUGGAGE COMPARTMENT TRIM, CV»(ref-275837-S20608773682007122900000) .

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 32

Scheme 33

1. Remove the ACC/MCC unit with «82 93 474 REMOVAL TOOL»(ref-275865-S28612027982007122900000) . IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
2. Unplug the connector to the ACC/MCC unit.
3. Remove the EHU by pressing in the 2 catches. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Unplug the CD player from the EHU.
5. Remove the CD player using «84 71 203 REMOVAL TOOL»(ref-275865-S12837119392007122900000) .

Scheme 34

1. Fit the CD player. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
2. Plug in the connectors to the CD player and the main entertainment unit.
3. Fit the EHU. You should hear a click. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Plug in the connector to the ACC/MCC unit.
5. Fit the ACC/MCC unit so that it locks into position.
6. Carry out «PROCEDURE AFTER CHANGING THE CONTROL MODULE»(ref-275865-S17743978662007122900000) .
7. Check the function.

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 35

Scheme 36

1. Remove «FRONT SEAT»(ref-275882-S09702464062007122900000) .
2. Remove the bolt.
3. Remove the amplifier. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Unplug the connector.

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 37

1. Remove the rear side trim on the left side. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
2. Unplug the connector.
3. Remove the bracket screws.
4. Remove the amplifier retaining screw.
5. Remove the amplifier from the bracket.

Scheme 38

1. Fit the amplifier into the bracket.
2. Fit the amplifier retaining screw.
3. Fit the assembled amplifier and bracket.
4. Fit the bracket screws. IMPORTANT: Take care when plugging in the connector so as not to damage or press out the pins/sleeves in the connector. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
5. Plug in the connector.
6. Carry out «PROCEDURE AFTER CHANGING THE CONTROL MODULE»(ref-275865-S17743978662007122900000) .
7. Check the function.
8. Fit «REAR SIDE TRIM, CV»(ref-275837-S38469841952007122900000) .

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 39

Scheme 40

1. Open the left-hand side hatch in the luggage compartment.
2. Remove the amplifier using «84 71 203 REMOVAL TOOL»(ref-275865-S12837119392007122900000) . IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
3. Unplug the connector.

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 41

Scheme 42

1. Remove «LUGGAGE COMPARTMENT TRIM, CV»(ref-275837-S20608773682007122900000) .
2. Remove the amplifier using «84 71 203 REMOVAL TOOL»(ref-275865-S12837119392007122900000) . IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
3. Unplug the connector.

Before removing the amplifier, carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 43

1. Remove «REAR SIDE TRIM, 5D»(ref-275837-S04125456152007122900000) on the right side.
2. Open the hatch in the luggage compartment.
3. Remove the amplifier. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Unplug the connector.

Carry out PROCEDURES BEFORE DISMANTLING THE CONTROL MODULE .

Scheme 44

Scheme 45

1. Remove the center air vent from the instrument panel by carefully bending the hooks that are accessible through the grille. NOTE: It is essential the correct hooks are bent as the hooks holding together the air vent are also visible through the grille.
2. Remove the ICM retaining screws.
3. Remove the ICM unit. IMPORTANT: Take care when releasing the locking mechanism on the connector so as not to damage the connector. Pull the halves straight apart to avoid bending the pins. For further information regarding connectors, refer to «CONNECTORS, HANDLING AND INSPECTION»(ref-275865-S20727114862007122900000) .
4. Unplug the connector.

1. Set the button in adjustment position.
2. Grip around the button and pull it straight back. NOTE: If the button is broken, remove any remains of the button.

Add/Remove

When you program a key / remote control, change a control module or fit an electrical accessory, you need to access a new menu called "Add / Remove". The menu option marries and separates components in relation to the car. During "divorcing", critical data can be copied from a control module which is later loaded into the new control module. Remember that any SPS programming should be done before an "Add" operation. You must also retrieve "Security Access" for control modules included in the car's immobilization function. This is retrieved via RS 232 from TIS 2000 when the diagnostic tool requests it. You can also retrieve security access in advance and then kept it for the entire time you are working on the car in question, even if you disconnect the diagnostic tool now and again. Key programming and some activations that concern the central locking system and electric window lifts, for example, are also protected and require security access.

When the Control Module Is To Be Replaced

1. Place the old control module in the return packaging without touching its pins.
2. Keep the new control module in its packaging as long as possible.

Before removing a control module, Tech 2 must be used to separate the control module from the car. From the "All" menu, select the control module under "And/Remove". Then select "Remove" and follow the instructions. The ignition key must be in the ON position. TIS 2000 may be required. Once the control module has been separated from the car, turned the ignition key to the OFF position. The control module can then be removed. Carry out the "Remove" action with Tech2 even if the control module cannot be contacted or is completely missing because data in other control modules must be changed.

When the Component Is To Be Replaced

1. Place the component in the return packaging without touching its pins.
2. Keep the new component in its packaging for as long as possible.
