Relays
Note. For additional relay information, see BUZZERS, RELAYS & TIMERS in ELECTRICAL COMPONENT LOCATOR article.
The electrical center can contain a greater number of relays than those listed below. In such cases, these are not connected to a wiring harness.
RELAYS ILLUSTRATION REFERENCE CHART Location No Description Illustration (1) Diagram (1) R1 432b Relay, washer fluid pump, windscreen R2 156 Relay, A/C compressor (Simtec and EDC16) Simtec EDC16 R3 - R4 641 Relay, diesel preheating R5 675 Relay, extra lights R6 68 Horn relay R7 229 Main relay, engine management system (Simtec and EDC16) R8 517 Relay, +50 B207 Z18XE B284 Z19 R9 83 Windscreen wiper relay R10 432c Relay, washer fluid pump, rear window R11 757F Relay, +15, UEC R12 709 Relay, windscreen wiper, full/half speed R13 - R14 667 Relay, washer fluid pump, high-pressure, headlamp R15 - R16 - (1) For relay identification, see BUZZERS, RELAYS & TIMERS in ELECTRICAL COMPONENT LOCATOR article. For wiring, see appropriate wiring diagram in SYSTEM WIRING DIAGRAMS
