Bus and Diagnostics Communication: Wiring Saab 9-3 II

Body, Cab Control Systems 12 illustrations ~304 words

Crimp Connection J70, Instrument Harness

Location

LHD: Approx. 290 mm from branching point of light switch unit towards the column integration unit

RHD: Approx. 360 mm from grounding point G40 towards grounding point G41

Scheme 29

Scheme 29: Crimp Connection J70, Instrument Harness

Crimp Connection J72, Instrument Harness

Location

LHD: Approx. 210 mm from infotainment control panel

RHD: Approx. 90 mm from branching of SID control panel towards infotainment control panel

Scheme 30

Scheme 30: Crimp Connection J72, Instrument Harness

Crimp Connection J73, Instrument Harness

Location: Approx. 90 mm from infotainment control panel

Scheme 31

Scheme 31: Crimp Connection J73, Instrument Harness

Crimp Connection J74, Instrument Harness

Location: Approx. 90 mm from infotainment control panel

Scheme 32

Scheme 32: Crimp Connection J74, Instrument Harness

Crimp J80, Instrument Harness

Location

LHD: Approx. 80 mm from branching point grounding point G43 towards grounding point G41

RHD: Approx. 70 from branching point grounding point G43 towards SID

Scheme 33

Scheme 33: Crimp J80, Instrument Harness

Crimp Connection J100, Main Harness

Location

4D/5D: Approx. 10 mm from branching of seat-belt tensioner, left B-pillar towards the left A-pillar

CV: Approx. 40 mm from branching point to the side crash sensor by the LH B-pillar towards the LH window control module

Scheme 34

Scheme 34: Crimp Connection J100, Main Harness

Crimp Connection J105, Main Harness

Location

4D/5D: Approx. 290 mm from branching of grounding point G14 towards airbag control module

CV: Approx. 320 mm from branching to grounding point G14 towards the airbag control module

Scheme 35

Scheme 35: Crimp Connection J105, Main Harness

Crimp J233, Adapter Harness, Simtec

Location: Approx. 225 mm from branching of grounding point G7 towards the starter motor

Scheme 36

Scheme 36: Crimp J233, Adapter Harness, Simtec

Crimp J234, Adapter Harness, Simtec

Location: Approx. 175 mm from branching of grounding point G7 towards the starter motor

Scheme 37

Scheme 37: Crimp J234, Adapter Harness, Simtec

Crimp J276, Adapter Harness, EDC16

Location: Approx. 100 mm from branching point connector H11-1 towards the engine control module.

Scheme 38

Scheme 38: Crimp J276, Adapter Harness, EDC16

Crimp J277, Adapter Harness, EDC16

Location: Approx. 200 mm from branching of connector H11-1 toward engine control module

Scheme 39

Scheme 39: Crimp J277, Adapter Harness, EDC16

Checking the wiring harness

IMPORTANTMove the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
IMPORTANTMove the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
IMPORTANTMove the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
IMPORTANTMove the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
IMPORTANTMove the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
IMPORTANTMove the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.

Scheme 40

Scheme 40: Data Link Connector
