Location
The driver airbag is located in the steering wheel and the passenger airbag is located in the dashboard above the glovebox. The side airbags are placed inside the backrest upholstery fabric on the outer edges of the front seats. The belt tensioners are located in the door sills by the B-pillars. The inflatable curtain is located between the A and C-pillar under the headlining on the LH and RH sides.
The driver airbag is located in the steering wheel and the passenger airbag is located in the dashboard above the glovebox. The side airbags are placed inside the backrest upholstery fabric on the outer edges of the front seats. The front belt pretensioners are placed in the sills by the B-pillars. The rear belt pretensioners are mounted in the torsion box behind the backrests of the outer rear seats. The roll bars are located behind the rear seat backrest.
The PPS system control module is located underneath the passenger seat. A mat containing the silicone filled seat mat and pressure sensor are located on the seat and the belt force sensor (643) on the belt mounting. The two ON/OFF indicator lamps are located in SID.
Belt contact, driver (70D)
Belt contact, passenger (70P)
Scheme 68
Belt tensioner, driver (236D)
Belt tensioner, passenger (236P)
Belt pretensioner, rear seat, driver's side (236RD) (CV).
Belt pretensioner, rear seat, passenger side (236RP) (CV).
CV
Scheme 69
4D, 5D
Scheme 70
Belt tensioner, driver (236D)
Belt tensioner, passenger (236P)
Impact sensor, side, driver's (328D)
Impact sensor, side, passenger, front (328P)
Impact sensor, side, rear, passenger side (328RD)
Impact sensor, side, rear, driver's side (328RP).
Scheme 71
Impact sensor, front, left (332FL)
Impact sensor, front right (332FR)
Airbag, driver (333D).
Airbag, passenger (333P).
Airbag, side, driver (333Db)
Airbag, side, passenger, front (333Pb)
4D
Scheme 72
CV
Scheme 73
Airbag control module (331).
Scheme 74
Control module, PPS (591)
Scheme 75
Pressure sensor, occupied seat cushion, front passenger (642).
Force sensor, front passenger seat belt (643)
Scheme 76
Position sensor, seat, driver's (669D)
Position sensor, seat, passenger's (669P)
Scheme 77
Driver inflatable curtain (732D)
Passenger inflatable curtain (732P)
4D
Scheme 78
5D
Scheme 79
in the floor console between the front seats
Scheme 80
The electrical center is located in the short left hand side of the dashboard.
in the driver seat-belt buckle
Scheme 81
in the passenger seat-belt buckle
Scheme 82
in the driver's side B-pillar
4D/5D
Scheme 83
CV
Scheme 84
in the passenger side B-pillar
4D/5D
Scheme 85
CV
Scheme 86
under the parcel shelf
Scheme 87
under the parcel shelf
Scheme 88
on the lower edge of the driver's side B-pillar
Scheme 89
on the lower edge of the passenger side B-pillar
Scheme 90
under the C-pillar near the lower edge of the rear seat
Scheme 91
under the C-pillar near the lower edge of the rear seat
Scheme 92
on the center tunnel behind the gear selector unit
K30
Scheme 93
K75
Scheme 94
on the bumper member under the LH horn
Scheme 95
on the bumper member under the RH horn
Scheme 96
in the steering wheel
Scheme 97
in the driver's seat
Scheme 98
in the dashboard
Scheme 99
in the passenger seat
Scheme 100
Integrated in the steering wheel assembly unit
Connection from steering column loom
Scheme 101
Connection from instrument loom
Scheme 102
The electrical center is located between the battery and the left front wing.
under the parcel shelf
Scheme 103
in front of rear left wheel housing
Scheme 104
in front edge of luggage compartment
Scheme 105
opposite the driver in the dashboard
Scheme 106
at the top of the instrument panel
Scheme 107
in the seat under the seat cushion
Scheme 108
in SID control panel
Scheme 109
in SID control panel
Scheme 110
in the passenger seat cushion
Scheme 111
in seat cushion
Scheme 112
in seat belt floor anchorage bracket
Scheme 113
in seat belt seat anchorage bracket
Scheme 114
in the seat
Scheme 115
in the seat
Scheme 116
battery positive terminal
Scheme 117
The electrical center is located in the luggage compartment on the left-hand wheel housing.
on the steering column below the steering wheel
K8
Scheme 118
K25
Scheme 119
in the dashboard electrical distribution unit
Scheme 120
in the roof above the driver's side window
Scheme 121
in the roof above the passenger side window
Scheme 122
in lower part of protective bow
Scheme 123
in lower part of protective bow
Scheme 124
On instrument panel next to main instrument unit
Scheme 125
black connector in front of the battery under the left-hand structural member
Scheme 126
black connector on the console to the left of the ignition switch
Scheme 127
under the left seat
Scheme 128
under the right seat
Scheme 129
Under the LH A-pillar
Scheme 130
LHD: Approximately 130 mm from cigarette lighter branching point towards the airbag control module
RHD: Approximately 110 mm from grounding point G41 branching point towards connector H33-1
Scheme 131
4D/5D: Approx. 160 mm from branching point to grounding point G33P/S towards LH rear door
CV: 170 mm from the branching point of grounding point G33P/S towards the left rear door
Scheme 132
4D/5D: Approx. 170 mm from branching point seat towards grounding point G33P/S
CV: 520 mm from the branching point of grounding point G33P/S towards the left rear door
Scheme 133
Approx. 330 mm from branching point connector H10-6 towards the luggage compartment electrical center
Scheme 134
Approx. 130 mm from branching point left-hand rear wing light cluster towards luggage compartment electrical center
Scheme 135
On the center tunnel
By seat member under left-hand seat
By the floor below the left A-pillar (black tape)
