Charging System - Component Location, Removal & Installation: Overview Saab 9-3 I

Charging System 16 illustrations ~227 words

Identifying Battery 60 Ah. Scheme 7

Scheme 7: Identifying Battery 60 Ah
Scheme 7: Identifying Battery 60 Ah
Type designationVarta 56029
VoltageV12
CapacityAh60
GroundingNegative
Specific gravity of the electrolyte
When recharging is due1.21
When battery is fully charged1.28
Starting current
(European Norm)A580
SAEA600

BATTERY 60 AH DESCRIPTIONS

Identifying Battery 85 Ah. Scheme 8

Scheme 8: Identifying Battery 85 Ah
Scheme 8: Identifying Battery 85 Ah
Type designationBaren 60044S
VoltageV12
CapacityAh85
GroundingNegative
Specific gravity of the electrolyte
When recharging is due1.21
When battery is fully charged1.28
Starting current
EN (European Norm)A780
SAEA800

BATTERY 85 AH DESCRIPTIONS

Identifying Generator 90A. Scheme 9

Scheme 9: Identifying Generator 90A
Scheme 9: Identifying Generator 90A
Type designationBosch KC 14V 45-90A
Rated voltageV14
Stator connectionStar
Diameter of slip rings
NewMn15.4
MinMn14.4
Max. permissible radial runout
Belt pulleyMn0.2
Slip ringsMn0.02
RotorMn0.087
Min. Length of brushes, from lip of brush -holderMm7.5
Pulley ratio, engine/generator1:2.8

GENERATOR 90A DESCRIPTIONS

Test readings
Resistance, rotor winding (at 25°C)Ohm2.6
Resistance, stator between phases (at 25 °C)Ohm0.027
Generator speed/stated current at
1800 RPMA45
6000 RPMA90

TEST READINGS

Identifying Generator 120A. Scheme 10

Scheme 10: Identifying Generator 120A
Scheme 10: Identifying Generator 120A
Type designationBosch NC 14V 70 120A
Rated voltageV14
Stator connectionStar
Diameter of slip rings
NewMn15.4
MinMn14.4
Max. permissible radial runout
Belt pulleyMn0.2
Slip ringsMn0.02
RotorMn0.087
Min. length of brushes, from lip of brush -holderMm7.5
Pulley ratio, engine/generator1:2.9

GENERATOR 120A DESCRIPTIONS

Test readings
Resistance, rotor winding (at 25°C)Ohm2.6
Resistance, stator between phases (at 25 °C)Ohm0.051
Generator speed/stated current at
1800 RPMA70
6000 RPMA120

TEST READING

Identifying Generator 130A. Scheme 11

Scheme 11: Identifying Generator 130A
Scheme 11: Identifying Generator 130A
Type designationBosch NC 14V 65-130A
Rated voltageV14
Stator connectionDelta
Diameter of slip rings
NewMn15.4
MinMn14.4
Max. permissible radial runout
Belt pulleyMn0.2
Slip ringsMn0.02
RotorMn0.087
Min. length of brushes, from lip of brush -holderMm7.5
Pulley ratio, engine/generator1:2.8

GENERATOR 130A DESCRIPTIONS

Test readings
Resistance, rotor windingOhm2.6
Resistance, stator between phasesOhm0.038
Generator speed/stated current at
1800 RPMA65
6000 RPMA130

TEST READINGS

Identifying Tech 2. Scheme 12

Scheme 12: Identifying Tech 2
Scheme 12: Identifying Tech 2

See service manual 1:4 Tech2

Group: Test equipment

9000900 - M93900/9-39-59-3 (9440)
XXXXX

TOOLS DESCRIPTIONS

Identifying Hose Pinch-Off Pliers. Scheme 13

Scheme 13: Identifying Hose Pinch-Off Pliers
Scheme 13: Identifying Hose Pinch-Off Pliers

Prevents runoff from cooling system hoses

86 12 798 Toolboard T1 Service

Group: Engine

9000900 - M93900/9-39-59-3 (9440)
XXXXX

TOOLS DESCRIPTIONS

Identifying Wedge. Scheme 14

Scheme 14: Identifying Wedge
Scheme 14: Identifying Wedge

Group: Body, Engine

9000900 - M93900/9-39-59-3 (9440)
XXXXX

TOOLS DESCRIPTIONS

Qty: 5 pcs

Identifying Drawbar Handle. Scheme 15

Scheme 15: Identifying Drawbar Handle
Scheme 15: Identifying Drawbar Handle

For unloading the belt tensioner

86 12 798 Toolboard T1 Service

Group: Engine

9000900 - M93900/9-39-5
X

TOOLS DESCRIPTIONS

Identifying Battery Card. Scheme 16

Scheme 16: Identifying Battery Card
Scheme 16: Identifying Battery Card

Replacement card for battery maintenance program

Group: Test equipment

9000900 - M93l900/9-39-5
XXXX

TOOLS DESCRIPTIONS

Identifying Test Lamp, Red-Green. Scheme 17

Scheme 17: Identifying Test Lamp, Red-Green
Scheme 17: Identifying Test Lamp, Red-Green

Voltage range 8-16V

Group: Test equipment

9000900 - M93900/9-39-59-3 (9440)
XXXXX

TOOLS DESCRIPTIONS

Identifying Battery Tester. Scheme 18

Scheme 18: Identifying Battery Tester
Scheme 18: Identifying Battery Tester

Version 2, US

Group: Test equipment

9000900 - M93900/9-39-5
XXXX

TOOLS DESCRIPTIONS

Identifying Battery Tester (Version 2, EU). Scheme 19

Scheme 19: Identifying Battery Tester (Version 2, EU)
Scheme 19: Identifying Battery Tester (Version 2, EU)

Version 2, EU

Group: Test equipment

9000900 - M93900/9-39-5
XXXX

TOOLS DESCRIPTIONS

System Overview. Scheme 20

Scheme 20: System Overview
Scheme 20: System Overview
  1. Main instrument unit (540)
  2. Battery (1)
  3. Generator (2)

Identifying Main Components LHD. Scheme 21

Scheme 21: Identifying Main Components LHD
Scheme 21: Identifying Main Components LHD
  1. Main instrument unit (540)
  2. Battery (1)
  3. Generator (2)

Identifying Main Components RHD. Scheme 22

Scheme 22: Identifying Main Components RHD
Scheme 22: Identifying Main Components RHD
  1. Main instrument unit (540)
  2. Battery (1)
  3. Generator (2)
