# 2.0l turbo, automatic a/c circuit

# 2.0l turbo, automatic a/c circuit (1 of 2)

Air conditioning 2.0l turbo — 2.0l turbo, automatic a/c circuit — 2.0l turbo, automatic a/c circuit (1 of 2). Saab 9-2X I (2004-2006)

Components on the diagram

# 2.0l turbo, automatic a/c circuit (2 of 2)

Air conditioning 2.0l turbo — 2.0l turbo, automatic a/c circuit — 2.0l turbo, automatic a/c circuit (2 of 2). Saab 9-2X I (2004-2006)

Components on the diagram

Components on these wiring diagrams 33

Click a component to highlight it on every diagram it appears on.
