INSPECTION
CHECK COMBINATION METER.
Turn the ignition switch to ON (engine OFF).
Check other warning lights.
Does the warning lights go on?
YES
NO
Repair or replace the combination meter.
CHECK HARNESS CONNECTOR BETWEEN COMBINATION METER AND OIL PRESSURE SWITCH.
Turn the ignition switch to OFF.
Disconnect the connector from oil pressure switch.
Turn the ignition switch to ON.
Measure the voltage of harness between the oil pressure switch connector and chassis ground.
Connector & terminal
(E11) No. 1 (+) - Chassis ground (- )
Is the voltage more than 10 V?
YES
Replace the oil pressure switch.
NO
CHECK COMBINATION METER.
Turn the ignition switch to OFF.
Remove the combination meter.
Measure the resistance of combination meter.
Terminals
(i11) No. 7 - (i10) No. 2
Is the resistance less than 10 O?
YES
Replace the harness connector between combination meter and oil pressure switch.
NO
Repair or replace the combination meter.
Park the vehicle on a level surface.
Remove the oil level gauge and wipe it clean.
Reinsert the level gauge all the way. Be sure that the level gauge is correctly inserted and in the proper orientation.
Remove it again and note the reading. If the engine oil level is below the "L" line, add oil to bring the level up to "F" line.
After turning off the engine, wait a few minutes for the oil to drain back into the oil pan before checking the level.
Just after driving or while the engine is warm, engine oil level may show in the range between the "F" line and notch mark. This is caused by thermal expansion of the engine oil.
Note. To prevent overfilling the engine oil, do not add oil above the "F" line when the engine is cold.
Scheme 5
- Oil level gauge
- Engine oil filler cap
- Upper level
- Lower level
- Approx. 1.0 liters (1.1 US qt, 0.9 Imp qt)
