Removal
Disconnect the ground cable from battery.
Remove the instrument panel lower cover.
Loosen the screw to remove steering column cover lower.
Scheme 1
Remove the screw to steering column cover upper.
Scheme 2
Disconnect the connector from combination switch.
Remove the screws which secure the switch, and then remove the switch.
Scheme 3
Installation
Install in the reverse order of removal.
Remove the driver's airbag module.
Remove the steering wheel.
Remove the steering column cover.
Remove the combination switch. and
Loosen the four screws and remove the roll connector.
Loosen the three screws.
Scheme 4
Disconnect the connector and remove the combination base switch assembly.
Install in the reverse order of removal.
Align the attaching direction of roll connector with the steering wheel, before installation of steering wheel.
Disconnect the ground cable from battery.
Remove the front bumper face.
Remove the four bolts and disengage the clips (1), and then detach the headlight assembly.
Scheme 5
Disconnect each harness connector.
Install in the reverse order of removal.
Install in the reverse order of removal.
| IMPORTANT | Attach the rubber cap with letters TOP on the top so the drain hole will be on the lower side. |
Install in the reverse order of removal.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Disengage the clip, and then turn over the lower mud guard.
Scheme 6
Disconnect the harness connector.
Remove the mounting bolts, and then remove the fog light assembly.
Scheme 7
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the clip, and then turn over the lower mud guard.
Scheme 8
Remove the harness connector.
Remove the back cover (A).
Scheme 9
Remove the spring retainer, and then detach the fog light bulb.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the clips, and then detach the rear combination light covers.
Scheme 10
Remove two bolts, and then remove the rear combination light by pulling it vehicle backward.
Scheme 11
Turn the sockets to remove each bulb.
Scheme 12
Install in the reverse order of removal.
Note. Install the rear combination light by aligning the clip with body side.
Scheme 13
Remove the rear combination light assembly.
Turn the socket and remove the bulb.
Scheme 14
Install in the reverse order of removal.
Remove the rear combination light assembly.
Turn the socket and remove the bulb.
Scheme 15
Install in the reverse order of removal.
Remove the rear combination light assembly.
Turn the socket and remove the bulb.
Scheme 16
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the license plate light installing screw.
Scheme 17
Remove the lens (A) and packing (B), and remove the bulb.
Scheme 18
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the roof spoiler.
Remove the two high-mounted stop light installing nuts.
Scheme 19
Take out the harness, and remove the high-mounted stop light.
Scheme 20
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the lens (A) and spot map light mounting screw (B).
Scheme 21
Scheme 22
Disconnect the harness connectors and remove the spot map light.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the lens (A) and room light mounting screws (B).
Scheme 23
Disconnect the harness connectors and remove the light.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the lens (A) and luggage room light mounting screws (B).
Scheme 24
Disconnect the harness connectors and remove the luggage room light.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the glove box.
Disconnect the harness connector.
Remove the glove box light.
Scheme 25
Install in the reverse order of removal.
